HM730D - Hand blender Clas Ohlson - Free user manual and instructions

Product Type	Electric Hand Mixer
Brand	Clas Ohlson
Model	HM730D
Color	Black
Voltage	220–240 V AC, 50 Hz
Power	150 W
Speed Settings	Variable with speed selector
Turbo Function	Yes, momentary boost
Accessories Included	2 Whisks, 2 Dough Hooks
Release Button	Yes, for easy accessory removal
Housing Material	Plastic (estimated)
Whisk Material	Stainless steel (estimated)
Dishwasher Safe	Whisks and dough hooks only
Motor Unit Cleaning	Wipe with damp cloth, do not immerse
Maximum Continuous Operation	3 minutes, then cool down for 1 minute
Turbo Maximum Duration	1 minute at a time
Child Safety	For ages 8+ with supervision
Power Cord Length	Approx. 1 m (estimated)
Weight	Approx. 0.8 kg (estimated)

Frequently Asked Questions - HM730D Clas Ohlson

Can I use the hand mixer to blend hot liquids?

It is not recommended to blend hot liquids directly in a pot as the heat may damage the motor unit. Allow liquids to cool to room temperature before mixing.

How do I use the turbo function?

The turbo button provides a temporary speed boost. Press it at any speed setting. Do not use for longer than 1 minute at a time.

Are the whisks and dough hooks dishwasher safe?

Yes, both the whisks and dough hooks are dishwasher safe. However, the motor unit must never be immersed in water; clean it with a damp cloth.

Why does my hand mixer stop during use?

The mixer is designed to stop automatically if used for longer than 3 minutes continuously to prevent overheating. Allow the motor to cool for at least 1 minute before resuming.

Can I use the mixer to knead heavy dough?

Yes, the included dough hooks are designed for kneading. However, avoid overloading the mixer; if it struggles, reduce the amount of dough or use a lower speed.

How do I attach the whisks?

Ensure the mixer is unplugged and set to 0. Insert the whisks into the holes on the bottom until you hear a click. To remove, press the release button.

What should I do if the power cord is damaged?

If the power cord is damaged, it must be replaced by the manufacturer, a qualified service facility, or a qualified technician to avoid hazard. Do not use the product.

Is the hand mixer suitable for use by children?

Children aged 8 years and above can use the mixer if supervised and instructed properly. Children under 8 must be kept away from the product and cord.

Can I beat egg whites with this mixer?

Yes, use the whisks at a medium to high speed. Ensure the bowl and whisks are clean and free from grease for best results.

How do I store the hand mixer?

Store the mixer and accessories in a dry place indoors. Avoid laying the cord over sharp edges or hot surfaces. Keep out of reach of children under 8.

USER MANUAL HM730D Clas Ohlson

Black electric mixer with a stand and whisk, no visible text or symbols

Electric Hand Mixer

Art.no 44-2010-1, -2, -3 Model HM730D

Please read the entire instruction manual before using the product and then save it for future reference. We reserve the right for any errors in text or images and any necessary changes made to technical data. In the event of technical problems or other queries, please contact our Customer Services (see address details on the back).

Safety

• Incorrect handling of this product could result in personal injury.
• The product should always be disconnected from the mains when it is not in use, when it is to be assembled/disassembled and when it is to be cleaned.
• The product may be used by children of 8 years and above and by persons with reduced physical, sensory or mental capability or lack of experience and knowledge provided they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved.
• Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
• Keep the product and its mains lead out of reach of children under the age of 8.
• Switch the product off and disconnect it from the mains before changing any accessories or handling any of the moving parts.
• Never let children play with the product.
• Ensure that the product is used with the correct voltage. Refer to the rating plate on the product.
• Never use the product for anything other than its intended use.
• Only use the provided accessories.
• The product should only be used and stored indoors.
• Never use the product close to heat sources.
• Always disconnect the product from the power supply by holding and pulling the plug. Do not pull the mains lead.

• Never lay the mains lead over hot surfaces, sharp edges or corners.

• To prevent electric shocks, the product and its mains lead should be kept dry.

• Make sure that all parts are correctly assembled and that the product is switched off before it is connected to the power supply.
• The mains lead should be checked regularly. Never use the product if the mains lead or plug is damaged. The mains lead must be changed if damaged. This is to prevent the risk of electric shock or fire and should only be carried out by the manufacturer, qualified service facility or qualified technician.

Product description

Line drawing of a portable water heater with handle and spout (no text or symbols)

1. Release button for whisks
2. Turbo button
3. Speed selector
4. Mains lead
5. Holes
6. Housing
7. Whisks

Operating instructions

Note: Wash the whisks before using them for the first time.

They are dishwasher safe.

• Make sure that the product is unplugged from the wall socket and that the speed selector is on 0.
• Insert the whisks into the holes on the bottom of the motor unit. A click sound will be heard when they are properly inserted.
• Plug the mains lead into a wall socket.
• Lower the whisks into the food which is to be whisked/mixed before switching the hand mixer on.
• Choose an appropriate speed using the speed selector.
• The turbo button can be pushed at any speed setting for a temporary boost in speed.
  Note: Never use the turbo mode for longer than 1 minute at a time.

Removing the whisks

1. Wait until the rotating parts have come to a complete standstill.
2. Unplug the mains lead from the wall socket.
3. Press the release button.

Note: Never use the product for longer than 3 minutes at a time. Switch the product off and let the motor cool down for a minute before using it again.

Care and maintenance

• Always unplug the product from the wall socket before cleaning.
- Wash the whisks and dough hooks thoroughly after use. They are dishwasher safe.
- The motor unit must not be immersed in water – clean it by wiping with a damp cloth.

Responsible disposal

This symbol indicates that this product should not be disposed of with general household waste. This applies throughout the entire EU. In order to prevent any harm to the environment or health hazards caused by incorrect waste disposal, the product must be handed in for recycling so that the material can be disposed of in a responsible manner. When recycling your product, take it to your local collection facility or contact the place of purchase. They will ensure that the product is disposed of in an environmentally sound manner.

Symbol of a trash bin with no text or labels, crossed by two diagonal lines and a solid rectangle below (no text or symbols present)

Specifications

Voltage 220–240 V AC, 50 Hz

Power 150 W

Elvisp

Art.nr 18-4711-1, -2, -3 Modell HM730D

44-2010-1, -2, -3 HM730D

Line drawing of a portable radio receiver with a handle and antenna (no text or symbols)

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Specifikationer

Line drawing of a portable radio with a handle and antenna (no text or symbols)

Symbol of a trash bin crossed out by two crossed lines, with no text or labels present.

Spesifikasjoner

Strømforsyning 220–240 V AC, 50 Hz

Effekt 150 W

Sähkövatkain

Tuotenro 18-4711-1, -2, -3 Malli HM730D

44-2010-1, -2, -3 HM730D

Line drawing of a mechanical device with handle and spool (no text or symbols)

Symbol of a trash bin crossed out by two crossed lines, with a solid black rectangle below (no text or labels)

Tekniset tiedot

Line drawing of a mechanical device with handle and spout (no text or symbols)

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Technische Daten
