Candy UPCR-780A-P07 - Sports Watch ADIDAS - Free user manual and instructions

Product Type	Sports Watch
Brand	Adidas
Model	Candy UPCR-780A-P07
Display Type	Digital
Water Resistance	5 ATM (50 meters)
Functions	Time/Calendar, Dual Time (T1/T2), Chronograph (Lap/Split), Countdown Timer, 4 Alarms, EL Backlight, Chime
Power Source	Battery (not user-replaceable)
Battery Life	Approximately 2 years
Case Material	Resin
Strap Material	Resin (estimated)
Backlight	EL (Electroluminescent) with push button
Chronograph Capacity	10 laps
Timer Range	Countdown up to 99:59:59 (estimated)
Alarm Type	4 independent alarms with chime
Operating Modes	Time, Chronograph, Timer, Alarm
Accuracy	Quartz (±20 seconds per month)
Maintenance	Keep crown pushed in; avoid water contact beyond specified depth; clean with soft dry cloth

Frequently Asked Questions - Candy UPCR-780A-P07 ADIDAS

How do I set the time on my Adidas Candy UPCR-780A-P07 watch?

In normal time display, press and hold A to enter setting mode. The chime will flash. Press C to increase and D to decrease the flashing value. Press B to advance to the next value. The setting sequence is: chime, 12/24-hour format, hour, minute, second, year, month, date, and Auto EL. Press A to save and exit.

How do I switch between Time 1 and Time 2?

Press C to toggle between Time 1 (T1) and Time 2 (T2) in normal time display. To set Time 2, press and hold C for 2 seconds to enter Time 2 mode, then press and hold B to adjust the time difference.

How do I use the chronograph?

Press B to enter Chronograph mode. Press C to start. While running, press D to record a lap. Press C to stop. Press D to reset when stopped. You can recall laps by pressing A or B depending on the model variant.

How do I set the timer?

Press B to enter Timer mode. Press and hold A to enter timer setting. Use C and D to select timer type (count down stop, repeat, or count up). Press B to advance to hour, minute, second fields. Adjust with C/D. Press A to save and exit.

How do I set an alarm?

Press B to enter Alarm mode. Press C to select alarm 1-4. Press and hold A to enter alarm setting. Press C/D to adjust hour and minute. Press B to advance. Press A to exit. The alarm automatically turns on when exiting setting mode.

What is the water resistance of this watch?

The Adidas Candy UPCR-780A-P07 is water resistant to 5 ATM (50 meters). It can withstand splashes, rain, and swimming but not scuba diving. Ensure the crown is always pushed in.

How do I activate the backlight?

Press A (or B on some models) to activate the EL backlight. In the setting menu, you can enable Auto EL, which will light up the display with any button press.

How many laps can the chronograph record?

The chronograph can record up to 10 laps. After 10 laps, the last lap will be overwritten each time a new lap is recorded.

How do I enable or disable the chime?

In normal time display, press D to toggle the chime on or off. An indicator (e.g., 'CHM' or a bell icon) shows when chime is active.

What should I do if my watch stops working?

First, check if the battery needs replacement. If the watch has been exposed to water beyond its rating, dry it thoroughly. If issues persist, consult the manual or contact Adidas customer service. Avoid opening the watch yourself.

USER MANUAL Candy UPCR-780A-P07 ADIDAS

NOTE: If you do not find your watch movement here, please go to www.adidas.com/watches

PEACHTREE FL145GB

REAL TIME DISPLAY MODE

1. Press A for EL in any mode.
2. Press C to toggle between Time 1 and Time 2.
3. Press and hold C to set Time 1 or Time 2 as the default timer.
4. Press D to toggle chime on/off.

TIME/CALENDAR SETTING

1. In normal time display, press and hold A to enter setting mode; chime will begin flashing.
2. Press C to increase setting value. Press D to decrease setting value.
3. Press B to set and advance to next setting value.
4. Setting sequence is chime, 12/24-hour time, hour, minute, second, year, month, date, Auto EL.
5. Press A to save data and exit setting mode.

CHRONOGRAPH MODE

1. Press B to change to chronograph mode.
2. Press C to start chronograph; press D for lap when the chronograph is running.
3. Press D to change views while chronograph is running.
4. Press C to stop chronograph.

NOTE: When running, there is a maximum of 10 laps, afterward last lap will be overwritten each time additional lap is recorded.

RECALL MODE

1. Press A to recall the memory when the chronograph is stopped.
2. Press A to view the next lap.
3. Press C or D to exit Recall Mode and go back to chronograph mode.

TIMER MODE

1. Press B to change to timer mode.
2. Press C to start timer.
3. Press C to stop timer. Press D to reset the timer when it is stopped.

TIMER SETTING

1. In timer mode, press and hold A to enter setting mode; timer type will begin flashing.
2. Press C and D to select count down stop, count down repeat, or count up timer.
3. Press B to advance to next setting field.

4. Press C to decrease and D to increase.

5. Press B to set and advance to next setting value.

6. Setting sequence is timer type, hour, minute, second.
7. Press A to save data and exit setting mode.

NOTE: Alarm will sound at 2 beeps per second, and will beep for 30 seconds after timer reaches zero.

ALARM MODE

1. Press B to change to alarm mode.
2. Press C to toggle between alarms 1, 2, 3, 4.
3. Press D to enable the alarm; press D again to disable the alarm.
4. Press B to exit alarm mode.

ALARM SETTING

1. In alarm mode, press and hold A to enter setting mode, hour will begin flashing.
2. Press C to increase; press D to decrease.
3. Press B to set and advance to next setting value.
4. Setting sequence is hour, minute.
5. Press A to exit setting mode.

CANDY / SYDNEY UPCR-780A-P07 / QUPCR-823A-P03 /

QUPCR-780A-3-P16

NORMAL TIME DISPLAY

1. Press A for EL.
2. Press C to select T1 or T2 format.

TIME SETTING

1. In time mode, press and hold D for 2 seconds to enter time setting; hour will begin flashing.
2. Press C to increase setting value.
3. Press B to enter next setting field.
4. Setting sequence is hour, minute, day, year, month, date.
5. Press D to exit setting mode.

ALARM MODE

1. Press B to enter alarm mode.
2. Press C to toggle alarm/chime on/off.
3. Press D to select Home Alarm or T2 Alarm.

ALARM SETTING

1. Press and hold D for 2 seconds to enter alarm setting; hour will begin flashing.
2. Press C to increase setting value.
3. Press B to set minutes.

1. Press D to exit setting mode.

NOTE: Alarm turns on automatically when exiting setting mode.

CHRONO MODE

1. Press B to enter chrono mode.
2. Press D to select split or lap mode. Split mode will display the full time of all records after each split. Lap mode will display only the new lap time after each record has been recorded.
3. Press C to start chrono.
4. Press C again to split time.
5. Repeat step 4 until desired number of laps have been reached (maximum 10).
6. Press D to stop chrono.
7. To review, press B to enter recall mode before resetting.
8. Press D again to reset chrono.

RECALL MODE

1. Press C to recall each lap (10 maximum).
2. Press D to return to chrono.

TIMER MODE

1. Press C to start countdown timer.
2. Press D to stop countdown timer. Press D again to reset timer.

TIMER SETTING

1. Press B to enter timer mode.
2. Press and hold D to enter setting mode; hour will begin flashing.
3. Press C to increase setting value.
4. Press B to enter next setting field.
5. Setting sequence is hour, minute, second.
6. Press D to exit setting mode.

SEOUL / CURITIBA QFL657

NORMAL TIME DISPLAY

1. Press A to change mode. Mode sequence is normal time, chronograph, timer, alarm.
2. Press B for EL.
3. Press C to flash time zone 2. Press and hold C 2 seconds to toggle normal time display/time zone 2.
4. Press D to toggle key tone on/off. NOTE: At any point in any setting mode, press B to exit setting mode. NOTE: In any setting mode, if no pusher is operated for 30 seconds, all changes will be saved and the setting will automatically return to normal time display.

TIME AND CALENDAR SETTING

1. In normal time display, press and hold B 2 seconds; auto EL on/off will begin flashing.
2. Press C toggle auto EL on/off.
3. Press A to set and advance to next setting value.
4. Press C to increase digit; press D to decrease digit. Press and hold C or D for fast increment/decrement.
5. Repeat steps 3 and 4 through setting sequence. Setting sequence is: auto EL, chime on/off, 12/24-hour format, hour, minute, second, year, month/date or date/month format, month and date.
6. Press B to exit setting mode.

NOTE: Weekday is automatically updated upon exiting setting mode.

TIME ZONE 2 SETTING

1. To set Time Zone 2, press and hold C 2 seconds to change to Time Zone 2.
2. Press and hold B 2 seconds; time difference between time zone 1 and time zone 2 will begin flashing.
3. Press C to increase value; press D to decrease value. Press and hold C or D for fast increment/decrement.
4. Press B to exit setting mode.

CHRONOGRAPH MODE

1. Press A to change to chronograph mode.
2. Press B to recall lap data. Press B to scroll through laps.
3. Press C to start/stop the chronograph.
4. Press and hold D 2 seconds to reset to zero.

NOTE: Insert chronograph indicator here will flash in all modes if the chronograph is running.

LAP COUNTING

1. Press D while the chronograph is running for lap counting (up to 10 laps).

NOTE: After 8 seconds, display will show total chronograph time in the lower portion of the display; next lap running time will show in upper portion of the display.

1. Press C to stop chronograph.
2. Press B when the chronograph is stopped to recall chronograph lap data.
3. Press C or D to exit recall mode and return to chronograph.

TIMER MODE

1. Press A to change to timer mode.
2. Press C to start/stop timer.
3. Press D to reset the timer.

NOTE: Alarm will sound for 30 seconds when countdown reaches zero. Press any pusher to silence alarm.

TIMER SETTING

1. In timer mode, press and hold B 2 seconds to enter setting mode; timer type will begin flashing.
2. Press C to select countdown-stop ("CD-STP"), countdown-repeat ("CD-REP"), or countdown-then up timer ("CD-UP").
3. Press A to set and advance to next setting value.
4. Press C to increase digit; press D to decrease digit. Press and hold C or D for fast increment/decrement.
5. Repeat steps 3 and 4 through setting sequence. Setting sequence is: timer type, hour, minute, seconds.
6. Press B to exit setting mode.

ALARM MODE

1. Press A to change to alarm mode.
2. Press C to select alarm 1-4.
3. Press D to toggle alarm on/off.

ALARM SETTING

1. In alarm mode, press and hold B 2 seconds; hour will begin flashing.
2. Press C to increase digit; press D to decrease digit. Press and hold C or D for fast increment/decrement.
3. Press A to set and advance minute.
4. Repeat step 2.
5. Press B to exit setting mode.

NOTE: Alarm will sound for 30 seconds. Press any pusher to silence alarm.

USE PRECAUTIONS - RESISTANCE TO WATER

All adidas timepieces are designed to withstand use as indicated on the following chart.

INDICATION WATER-RELATED USE
Level of resistance	Caseback marking		Light spray perspiration, light rain, etc.	Bathing, etc.	Swimming, etc.	Skin diving, (without oxygen cylinder)	Scuba diving, (with air cylinder)
3 ATM 30	METERS 3 ATM		OK NO NO	NO NO
5 ATM 50	METERS 5 ATM		OK NO NO	NO NO
10 ATM 100	METERS 10 ATM		OK OK OK	NO NO
20 ATM 200	METERS 20 ATM		OK OK OK	OK NO
30 ATM 300	METERS 30 ATM		OK OK OK	OK OK
Always set the crown in position 1 (the normal position). Tighten screw-down crown completely, if applicable.
