21300 - Toaster KORONA - Free user manual and instructions

Product Type	Toaster
Brand	Korona
Model	21300
Power Supply	220-240 V ~ 50 Hz
Rated Power	780-930 Watt
Number of Bread Slots	2
Browning Levels	7
Functions	Toasting, Reheating, Defrost
Self-Centering Function	Yes
Bun Rack	Removable
Crumb Tray	Removable
Indicator Lights	Power (red), Reheat (blue), Defrost (blue)
Stop Button	Yes
Cord Length	Approx. 1 m
Dimensions (approx.)	30 x 20 x 20 cm
Weight (approx.)	1.5 kg
Material	Plastic and stainless steel
Safety Features	Auto shut-off, overheat protection
Cleaning	Wipe with damp cloth, do not immerse
Guarantee	2 years
Protection Class	I
Country of Origin	Germany (company)
Color	White/Silver (typical)

Frequently Asked Questions - 21300 KORONA

How do I clean the toaster?

Always unplug and let it cool completely. Wipe the body with a damp cloth and remove the crumb tray for cleaning. Never immerse in water.

Can I toast frozen bread?

Yes, use the Defrost function by pressing the defrost button after selecting your browning level. The toaster will adjust the toasting time accordingly.

How do I use the bun rack?

Unfold the bun rack and place it on top of the toaster. Put buns or croissants on it, select browning level, and push down the toasting lever. For even heating, turn them over halfway.

What should I do if a slice of bread gets stuck?

Unplug the toaster immediately and let it cool completely. Then gently remove the bread. Do not use sharp metal objects.

Why does the toaster produce smoke or smell when first used?

This is normal due to manufacturing residues. Run the toaster empty on the highest setting for 3-4 minutes in a well-ventilated room. Let it cool and clean afterwards.

What is the self-centering function?

It automatically centers the bread slices for even browning on both sides.

How do I reheat toast?

Insert the bread, push down the lever, and press the Reheat button. The toaster will warm it for a few seconds without additional browning.

Can I use an extension cord with the toaster?

The manual advises against using an external timer or remote control, but for safety, plug directly into a wall socket. If necessary, use a heavy-duty cord rated for the power.

What is the power consumption?

The rated power is 780-930 Watt at 220-240 V.

Is the toaster safe for children?

No, the toaster is not a toy. Children should be supervised, and the appliance should be kept out of reach due to hot surfaces and risk of burns.

USER MANUAL 21300 KORONA

Three triangular warning symbols: warming, lightning bolt, and exclamation mark

1 Bread Slots
2 Toasting lever
3 Stop button
4 Reheat button
5 Defrost button
6 Browning control knob
7 Indicator light (red)
8 Reheat indicator light (blue)
9 Defrost indicator light (blue)
10 Crumb tray
11 Removable bun rack
12 Power Cord and plug

Intended Use

Before use, please read these instructions carefully and keep them in a safe place for future reference. When passing on the appliance to a third party, make sure to include these instructions for use.

This appliance is intended and suitable for toasting and reheating bread/toast or buns/croissants. All other use or modification of the appliance is not intended by the manufacturer and might entail a risk of damage or injury. This appliance is not intended for commercial use!

Safety

This symbol identifies hazards which may cause injuries!

This symbol warns of hot surfaces. Risk of burns!

This symbol identifies electric shock hazards!

General Safety Instructions

Manufacturer takes no responsibility for any damage caused by incorrect use. Incorrect or improper use can damage the appliance and cause injuries to the user. Before connecting this appliance to the mains, make sure your local voltage matches the technical data of the appliance. Otherwise the appliance may overheat and get damaged.

Caution! Danger of electric shock!

• Never put the appliance, cord or plug into water or any other liquid.
• Do not use the appliance near a sink or wash basin.
• Do not use the appliance with wet hands.
• Do not use the appliance outdoors.

An electric appliance is not a toy!

• Never leave the appliance unattended during use.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.
  • Always unplug your appliance when it is not in use, and before cleaning.
• Always pull the plug – not the cord.
• Keep the appliance and the cord well away from any hot surfaces to avoid any damage to the appliance.
• Make sure the cord may not inadvertently be pulled or cause anyone to trip when in use. Do not allow the cord to hang over sharp edges.
• Do not bend the cord or wind it round the appliance.

Do not use the appliance,

• if the cord is damaged.
• in case of malfunction.
• if the appliance was dropped or is damaged otherwise.

Have it checked and, if necessary, repaired by a qualified person/Customer Service. Never attempt to make any modifications to or repair the appliance yourself.

• Only use accessories evaluated for use with this appliance.
• Never attempt to drive any objects into the appliance.
• Never attempt to open the housing yourself!
• The appliance is not intended to be operated by means of an external timer or separate remote-control system.

Special Safety Instructions

Warning symbols including steam, lightning bolt, and exclamation mark inside a triangle

Warning! To avoid the possibility of injury/damage to the appliance, electric shock and risk of burns.

• Only use the appliance for its intended purpose and as described in this manual.
• Place the appliance on an even, non-slippery and heat resistant surface.
• When using your appliance for the first time, do not insert any bread into the bread slot. The appliance may produce some smoke or smell which is due to residues left over from the manufacturing process.

• Bread can burn! During use, temperature above the bread slot rises significantly. Therefore, do not operate the toaster underneath or near any inflammable material, such as curtains.

• Attention: The temperature of accessible surfaces may be high during operation. Therefore, do not touch the appliance during and/or immediately after operation. Danger of serious burns!

• Never cover the bread slots During operation.
• Never attempt to put your fingers and/or other objects (e.g. knives, forks) into the bread slot when using the appliance. This could lead to serious injuries and/or damage.
• Do not operate the appliance near a gas supply or any electric sources of heat.
• During use, make sure that neither the power cord nor any other objects lie across the bread slots.
• Always disconnect the appliance from the mains and let it cool down before cleaning.

Before First Use

• Remove all packaging material and check whether the appliance is complete.
• Place the appliance on an even, non-slippery and heat resistant surface.
• Fully unwind the power cord and connect the appliance to a properly installed wall socket.
• Set the browning control (6) to the maximum setting and slide down the toasting lever (2) until it clicks into place. Do not insert any slices of bread during this first use and let your toaster heat up for 3 - 4 minutes.
• After this preheating process, let the appliance completely cool down and clean it as described under Cleaning and Care.

Note: During this process, the appliance may briefly produce some smoke or smell which is due to residues on the heating elements left over from the manufacturing process. This is normal and not harmful. Make sure that the room is well ventilated.

Warning: Plastic bags are a danger to toddlers and babies, therefore keep them by to avoid suffocation.

Operation

The temperature of accessible surfaces may be high during operation. Therefore, do not touch the appliance during and/or immediately after operation.

⚠️ If your toaster should not switch off automatically, press the midcycle stop button or disconnect the appliance from the mains. The same applies in case of smoke coming out of the appliance.

Toasting

The toaster comes with a self-centering function which allows an even brown-ing process on both sides of the bread slices.

Place the appliance on an even, non-slippery and heat resistant surface and connect it to a properly installed wall socket.

1. Insert the bread into the bread slots (1).
2. Select your preferred browning degree (level 1 - 7) depending on the freshness and thickness of the bread by turning the browning control knob (6) into the resp. direction.
3. Push down the toasting lever (2) until it locks into place, the red indicator light (7) will illuminate.
4. The toaster will switch off automatically, once the set browning degree has been reached.
5. To interrupt the toasting cycle before automatic cut-off, press the Stop button (3). The bread slices will be ejected.

Attention: Toasted bread can be very hot. Let it cool down or use potholders to handle it.

If a slice of bread should get stuck during the toasting process, unplug the appliance and let it cool down completely, before trying to remove it. Do not use any sharp metal objects to do so.

During operation, bread crumbs are falling down onto the crump tray (10), make sure to clean it on a regular basis.

Use of the Bun Rack

Always use the bun rack (11) for toasting/reheating buns/croissants. Never put them directly into the bread slot.

1. Unfold the bun rack (11) and place it on top of the appliance.
2. Put one or two buns/croissants onto the bun rack (11).
3. Set the browning control (6) to the desired level.
4. Press down the toasting lever (2) until it locks in place. Once the required browning degree has been reached, the toaster switches off automatically. Toasted bread can be very hot. Let it cool or use potholders to handle it.
5. Carefully turn the buns/croissants over and switch the toaster on again.

Please note: The browning degree also depends on the size and freshness of the product.

Reheating Function

With this function, you can reheat bread which was toasted earlier, simply insert the bread into the bread slots (1), press down the toasting lever (2) and then press the reheat button (4). The red indicator light (7) as well as the blue reheat indicator light (8) light up. The reheating process starts. The toaster automatically stops after several seconds.

The pre-set browning level has no influence on the reheat cycle.

Defrost Function

With this function you can toast frozen bread. To activate the defrost function insert the bread into the bread slots (1), choose your desired browning level, press down the toasting lever (2) until it locks in place and then press the defrost button (5). The red indicator light (7) as well as the blue defrost indicator light (9) light up. The pre-set browning level determines the defrost/countdown time.

All functions can be interrupted by pressing the Cancel button (3).

Cleaning and Care

Before cleaning, always switch off the appliance and disconnect it from the mains. Let it completely cool down. Never immerse the appliance in water. Danger! Electric Shock!

Clean the body of the appliance with a moistened soft cloth. Do not use any aggressive cleaning agents and/or other hard objects to clean the appliance. Simply pull out the crump tray (10) and clean it on a regular basis.

Storage

Disconnect the appliance from the mains after each use and let it completely cool down.

Keep the appliance away from children and store it in a clean and dry place.

Disposal Instructions

Waste electrical devices marked with this sign must not be disposed of with your household waste, but – according to the EU directive on Waste Electric And Electronic Equipment of 24th March 2005 – are to be collected separately. Therefore, please return this device at the end of its life cycle to special collection points for disposal or your local dealer.

Your toaster 21300 is packed in a retail box. Such boxes are recyclable waste, i.e. they are reusable or recyclable.

Technical Data

Voltage: 220-240 V \~ 50 Hz

Rated Power: 780-930 Watt

Protection Class: I

Subject to change without notice.

Guarantee:

This product is guaranteed against defects in materials and workmanship for a period of 2 years.

This guarantee is not valid:

• if the appliance has not been used in accordance to the instructions
  • for damages due to wear and tear (batteries, etc.)
  • for damages known by customer at time of purchase
  • for damages caused by owner

This guarantee does not affect your statutory right, nor any legal right you may have as a costumer under applicable national legislation governing the purchase of goods.

In order to assert his/her right in a guarantee case during the guaranteed period, the customer must provide evidence of the date of purchase (receipt).

The guarantee is to be asserted against

KORONA electric GmbH, Sundern/Germany

Service Adress:

KORONA Service, Am Steinbach 9, 59872 Meschede, Germany

Telefon Hotline: Mail: web:

[phone] [e-mail] www.korona-electric.de

within 2 years after the date of purchase. In case of guarantee the customer is given the right to get the appliance repaired at our own or at an authorized shop. Further rights (due to guarantee case) are not given to the customer.
