Product Type	Microwave Oven
Model	MM409
Brand	Manta
Capacity	20 liters
Dimensions (W x D x H)	440 x 360 x 260 mm
Weight	10.5 kg
Power Supply	230V~50Hz
Power Consumption	1050 W
Microwave Power Output	700 W
Functions	Defrost, Timer, Auto Cook Menus, Multi-stage Cooking
Display	Digital LED
Door Type	Drop-down
Turntable	Yes, 270 mm diameter
Interior Light	Yes
Safety Features	Child Lock, Overheat Protection
Cleaning Instructions	Wipe with damp cloth, avoid abrasive cleaners
Repair & Parts	Refer to authorized service, use genuine parts
Accessories Included	Glass turntable, rotating ring

Frequently Asked Questions - MM409 Manta

How do I set the cooking timer?

Turn the Timer knob clockwise to the desired time. The microwave will start automatically. You can also press the Time Cook button on some models.

How do I use the defrost function?

Press the Defrost button, enter the weight of the food, and the microwave will automatically set the time and power level. Turn or stir food halfway through for even thawing.

Why is my microwave not heating?

Possible causes: door not fully closed, power supply issue, or blown fuse. Ensure the door is latched properly. If the problem persists, contact a qualified technician.

How should I clean the interior?

Unplug the microwave and wipe with a damp cloth. For stubborn stains, use a mild detergent. Avoid abrasive cleaners or scouring pads. Do not let water seep into the vents.

Can I use metal containers or aluminum foil?

No, metal can cause sparks and damage the microwave. Only use microwave-safe glass, ceramic, or plastic containers. Small pieces of aluminum foil may be used to shield areas, but keep at least 1 inch from the walls.

What does the child lock do and how to activate it?

The child lock prevents accidental operation by disabling the control panel. To activate, press and hold the Stop/Clear button for 3 seconds until a beep sounds. Repeat to deactivate.

How do I cancel or stop a cooking program?

Press the Stop/Clear button once to pause, and twice to cancel. You can also open the door to pause; close it and press Start to resume if desired.

What is the maximum cooking time I can set?

The maximum cooking time is 99 minutes and 99 seconds (99:99). For longer cooking, you may need to restart after the timer ends.

Why does the turntable not rotate?

Check if the turntable glass and rotating ring are correctly seated. Also ensure the drive coupling (under the glass) is aligned. If it still doesn't rotate, the motor may be faulty.

How do I install the turntable correctly?

Place the rotating ring in the depression on the cavity floor. Then center the glass turntable on the rotating ring, ensuring it fits onto the drive coupling. The turntable should rotate freely when pushed.

USER MANUAL MM409 Manta

Exterior view of a MANTA microwave oven with digital display and control buttons (no visible text or symbols on main body)

MM409

MICROWAVE

Instrukcja obsługi

ŚRODKI OSTROŻNOŚCI, DLA UNIKNIĘCIA MOŻLI-WEGO NARAŻENIA SIĘ NA NADMIERNE DZIAŁANIE ENERGII MIKROFALOWEJ

Niebieski – NEUTRALNY

Brazowy – PRADOWY

Line drawing of a standard electrical outlet plug (no text or symbols)

MICROWAVE

• Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.
• Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
• Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the
• Door (bent),
  – Hinges and latches (broken or loosened),
  – Door seals and sealing surfaces.

The oven should not be adjusted or repaired by anyone except properly qualified service personnel.

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliance basic safety precautions should be followed, including the following:

WARNING:

To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy:

• Read all instructions before using the appliance.
• Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook or dry food. It is not designed for industrial or laboratory use.
• Do not operate the oven when empty.
• Do not operate this appliance if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard

WARNING:

Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

● To reduce the risk of fire in the oven cavity:
- When heating food in plastic or paper container, check the oven frequently to the possibility of ignition.

• Remove wire twist-ties from paper or plastic bags before placing bag in oven.
• If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
• Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or food in the cavity when not in use.

WARNING:

Liquid or other food must not be heated in sealed containers since they are liable to explode.

• Microwave heating of beverage can result in delayed eruptive boiling, therefore care has to be taken when handle the container.
• Do not fry food in the oven. Hot oil can damage oven parts and utensils and even result in skin burns.
• Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode even after microwave heating has ended.
• Pierce foods with heavy skins such as potatoes, whole squashes, apples and chestnuts before cooking.
  ● The contents of feeding bottles and baby jars should be stirred or shaken and the temperature should be checked before serving in order to avoid burns.
• Cooking utensils may become hot because of heat transferred from the heated food. Potholders may be needed to handle the utensil.
• Utensils should be checked to ensure that they are suitable for use in microwave oven.

WARNING:

It is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.

- This product is a Group 2 Class B ISM equipment. The definition of Group 2 which contains all ISM (Industrial, Scientific and Medical) equipment in which radio-frequency energy is intentionally generated and/or used in the form of electromagnetic radiation for the treatment of material, and spark erosion equipment. For Class B equipment is equipment suitable for use in domestic establishments and in establishments directly connected to a low voltage power supply network which supplies buildings used for domestic purpose.

MICROWAVE

INSTALLATION

● Make sure that all the packing materials are removed from the inside of the door.

WARNING:

Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surface, broken or loose door hinges and latches and dents inside the cavity or on the door. If there is any damage, do not operate the oven and contact qualified service personnel.

● This microwave oven must be placed on a flat, stable surface to hold its weight and the heaviest food likely to be cooked in the oven.
- Do not place the oven where heat, moisture, or high humidity are generated, or near combustible materials.
- For correct operation, the oven must have sufficient airflow. Allow 20cm of space above the oven, 10cm at back and 5cm at both sides. Do not cover or block any openings on the appliance. Do not remove feet.
- Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
● Make sure that the power supply cord is undamaged and does not run under the oven or over any hot or sharp surface.
● The socket must be readily accessible so that it can be easily unplugged in an emergency.
● Do not use the oven outdoors

RADIO INTERFERENCE

Operation of the microwave oven can cause interference to your radio, TV, or similar equipment.

When there is interference, it may be reduced or eliminated by taking the following measures:

● Clean door and sealing surface of the oven.
● Reorient the receiving antenna of radio or television.
- Relocate the microwave oven with respect to the receiver.
- Move the microwave oven away from the receiver.
- Plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch circuits.

GROUNDING INSTRUCTIONS

This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current. It is recommended that a separate circuit serving only the oven be provided. Using a high voltage is dangerous and may result in a fire or other accident causing oven damage.

WARNING Improper use of the grounding plug can result in a risk of electric shock.

Note:

• If you have any questions about the grounding or electrical instructions, consult a qualified electrician or service person.
  ● Neither the manufacturer nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures.

The wires in this cable main are colored in accordance with the following code:

Green and Yellow – EARTH

Blue – NEUTRAL

Brown – LIVE

MICROWAVE COOKING PRINCIPLES

• Arrange food carefully. Place thickest areas towards outside of dish.
  ● Watch cooking time. Cook for the shortest amount of time indicated and add more as needed. Food severely overcooked can smoke or ignite.
  ● Cover foods while cooking. Covers prevent spattering and help foods to cook evenly.
• Turn foods over once during microwaving to speed cooking of such foods as chicken and hamburgers. Large items like roasts must be turned over at least once.
• Rearrange foods such as meatballs halfway through cooking both from top to bottom and from the center of the dish to the outside.

BEFORE YOU CALL FOR SERVICE

If the oven fails to operate:

• Check to ensure that the oven is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds, and plug it in again securely.
• Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be operating properly, test the outlet with another appliance.

MICROWAVE

• Check to ensure that the control panel is programmed correctly and the timer is set.
• Check to ensure that the door is securely closed engaging the door safety lock system. Otherwise, the microwave energy will not flow into the oven.

IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT A QUALIFIED TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE OVEN YOURSELF.

UTENSILS GUIDE

● The ideal material for a microwave utensil is transparent to microwave, it allows energy to pass through the container and heat the food.
- Microwave can not penetrate metal, so metal utensils or dishes with metallic trim should not be used.
- Do not use recycled paper products when microwave cooking, as they may contain small metal fragments which may cause sparks and/or fires.
- Round /oval dishes rather than square/oblong ones are recommend, as food in corners tends to over-cook.
- Narrow strips of aluminium foil may be used to prevent overcooking of exposed areas. But be careful don't use too much and keep a distance of 1 inch (2.54cm) between foil and cavity.

The list below is a general guide to help you select the correct utensils.

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

A) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks.
B) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
C) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

ADDENDUM

If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation.

IMPORTANT SAFETY INSTRUCTIONS WARNING

To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:

1. Warning: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
2. Warning: It is hazardous for anyone other than a competent person to remove a cover which gives protection against exposure to microwave energy.

3. Warning: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understand the hazards of improper use.

4. Warning: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated. (only for grill series)

5. Only use utensils suitable for use in microwave ovens.

6. The oven should be cleaned regularly and any food deposits should be removed.

7. Read and follow the specific: "PRECAUTIONS TO VOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".

8. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.

9. If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.

10. Do not overcook food.

11. Do not use the oven cavity for storage purposes. Do not store items, such as bread, cookies, etc. inside the oven.

12. Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven.

13. Install or locate this oven only in accordance with the installation instructions provided.

MICROWAVE

1. Eggs in the shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
2. Use this appliance only for its intended uses as described in manual. Do not use corrosive chemicals or vapors in this appliance. This oven is especially designed to heat. It is not designed for industrial or laboratory use.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
4. Do not store or use this appliance outdoors.
5. Do not use this oven near water, in a wet basement or near a swimming pool.
6. The temperature of accessible surfaces may be high when the appliance is operating. Keep cord away from heated surface, and do not cover any events on the oven.
7. Do not let cord hang over edge of table or counter.
8. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
9. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.
10. Microwave heating of beverages can result in delayed eruptive boiling, therefore take care when handling the container.
11. The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
12. Children should be supervised to ensure that they do not play with the appliance.
13. The microwave oven shall not be placed in a cabinet.

To Reduce the Risk of Injury to Persons

Grounding Installation

DANGER

Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

CLEANING

Be sure to disconnect the oven from the power supply.

1. Clean the inside of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.

Two-round-pin plug

Line drawing of a plug with two leads (no text or symbols)

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.

This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:

● The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.

- The extension cord must be a groundingtype 3-wire cord.

- The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally.

MICROWAVE

UTENSILS

See the instructions on “Materials you can use in microwave oven or to be avoided in microwave oven.” There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below.

CAUTION

Personal Injury Hazard

It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

Utensil Test:

• Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
  ● Cook on maximum power for 1 minute.
• Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
• Do not exceed 1 minute cooking time.

Materials you can use in microwave oven

Utensils Remarks

Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls.

Browning dish Follow manufacturer's instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.

Dinnerware Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.

Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.

Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.

Oven cooking bags	Follow manufacturer's instructions. Do not close with metal tie. Make slits to allow steam to escape.
Paper plates and cupsi	Use for short-term cooking/warming only. Do not leave oven unattended while coo-king.
Paper towels	Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only.
Parchment paper	Use as a cover to prevent splattering or a wrap for steaming.
Plastic	Microwave-safe only. Follow the manufacturer's instructions. Should be la-beled “Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be slit, pierced or vented as directed by package.
Plastic wrap	Microwave-safe only. Use to cover food du-ring cooking to retain moisture. Do not al-low plastic wrap to touch food.
Thermometers	Microwave-safe only (meat and candy thermometers).
Wax paper	Use as a cover to prevent splattering and retain moisture.

Materials to be avoided in microwave oven

Utensils Remarks

Aluminum tray	May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle	May cause arcing. Transfer food into microwave-safe dish.
Metal or metaltrimmed utensils	Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties	May cause arcing and could cause a fire in the oven.
Paper bags	May cause a fire in the oven.
Plastic foam	Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood	Wood will dry out when used in the microwave oven and may split or crack.

MICROWAVE

SETTING UP YOUR OVEN

Names of Oven Parts and Accessories

Remove the oven and all materials from the carton and oven cavity.

Your oven comes with the following accessories:

Glass tray - 1

Turntable ring assembly - 1

Instruction Manual - 1

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system

A) Never place the glass tray upside down. The glass tray should never be restricted.
B) Both glass tray and turntable ring assembly must always be used during cooking.
C) All food and containers of food are always placed on the glass tray for cooking.
D) If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service center.

Countertop Installation

Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.

Cabinet: Remove any protective film found on the microwave oven cabinet surface.

Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.

Line drawing of a circular metal grate structure with four legs and supports (no text or symbols)

Grill Rack (Only for Grill series)

Shut off oven power if the door is opened during operation.

MICROWAVE

1) Select a level surface that provide enough open space for the intake and/or outlet vents. A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls. One side must be open.

• Leave a minimum clearance of 12 inches (30cm) above the oven.
  ● Do not remove the legs from the bottom of the oven.
• Blocking the intake and/or outlet openings can damage the oven.
• Place the oven as far away from radios and TV as possible. Operation of microwave oven may cause interference to your radio or TV reception.
• Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label.

WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged and the warranty would be void.

The accessible surface may be hot during operation.

Operation Instructions

1. Clock Setting

When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once.

1) Press „Clock/ Pre-Set“, the hour figures will flash, and the indicator for clock “☐” will light.

2) Turn “” to adjust the hour figures, the input time should be within 0--23.

3) Press "Clock/ Pre-Set", the minute figures will flash.

4) Turn “to adjust the minute figures, the input time should be within 0--59.

5) Press „Clock/ Pre-Set,, to finish clock setting. The indicator for clock “ 📁 ” will go out, “:” will flash, and the time will light.

2. Cooking food

Press „Micr./Grill/Combi.“ and turn ”, to select the function you want.

Press „Micr./Grill/Combi.“ and turn “ 📋, to select the cooking time.

Press „Start/Express Cook“ to start cooking. The maximum time is 95 minutes. Example: If you want to use 80% microwave to cook food for 20 minutes, you can operate the oven as the following steps.

1) Press „Micr./Grill/Combi.“, the screen display “P100”.

2) Turn ", to adjust the hour figures, the input time should be within 0--23.

3) Press „Micr./Grill/Combi.”, to confirm, the screen displays “P 80”.

4) Turn " , to adjust the cooking time until the oven displays "20:00".

5) Press „Start/Express Cook„ to start cooking or press „Stop/Clear„ to cancel the settings.

Note: the step quantities for the adjustment time of the coding switch are as follow:

"Micr./Grill/Combi." Pad instructions

Order	LED Display	Microwave Power	Grill Power
1		100%
2		80%
3		50%
4		30%
5		10%
6		0%	100%
7		55%	45%
8		36%	64%

3. Grill Cooking

1) Press the "Micr./Grill/Combi.".
2) Turn to select the grill function.

3) Press the "Micr./Grill/Combi." to confirm.
4) Turn to adjust the cooking time.
5) Press the „Start/Express Cook,, key to start cooking. The 📄 will flash, “:” will be lighted.

Note: If half the grill time passes, the oven pause and beep twice. This is normal. You can just press „Start/Express Cook“ to continue cooking. But in order to have a better effect of grilling food, you should turn the food over, close the door, and then press „Start/Express Cook“ to continue cooking. If no operation in one minute, it will continue running and sound once.

4. Combination Cooking

1) Press the „Micr./Grill/Combi.“.
2) Turn " 🔍" to select the combination 1 or combination2.

3) Press the " " to confirm.
4) Turn to adjust the cooking time.
5) Press the “key to start cooking. The and “will flash, “:” will be lighted.

5. Start/Quick Start

When the oven is in the waiting state, Press „Start/Express Cook“ to start cooking food with full microwave power for 1 minute. Each press will increase one minute. The maximum cooking time is 95 minutes.

6. Defrost By W.T.

1) Press „Defrost By W.T." button. LED will display "dEF1", "and" will light.

2) Turn “to select the weight of food, the weight should be 100-2000g.

3) Press "Start/Express Cook" to start defrosting food. "and" will flash.

7. Defrost By Time

1) Press „Defrost By Time” button. LED will display "dEF2", "and" will light.

2) Turn “” to select the cooking time. The maximum time is 95 minutes.

3) Press "Start/Express Cook", to start defrosting food. "and" "will flash.

8. Inquiring Function

1) In micro., grill or combi. cooking state, press "Micr./Grill/Combi", the current power will be displayed for 4 seconds. After 4 seconds, the oven will turn back to the former state;
2) In cooking state, press „Clock/ Pre-Set“ to inquire the time and the time will flash in the LED for 4 seconds.
3) In preset state, you can press „Clock/ Pre-Set“. to inquire the preset time.

MICROWAVE

9. Multi-section cooking

At most 3 sections can be input for cooking. In multi-section cooking, if one section is defrosting, then defrosting shall be placed in the first section.

Example: If you want to use "20 minutes of 100% microwave power + 5 minutes of 80% microwave power" to cook food.

1) Press „Micr./Grill/Combi." pad, the screen display "P100".

2) Press „Micr./Grill/Combi.“ to select 100% microwave power.

3) Turn “to select cooking time.

4) Press „Micr./Grill/Combi.“ pad, the screen display "P100".

5) Turn “to select 80% microwave power.

6) Press „Micr./Grill/Combi." pad, then turn " " to select cooking time of 80% microwave power.

7) Press „Start/Express Cook“ to start cooking or press „Stop/Clear“ to cancel the setting.

10. Program set in Advance

1) Set the clock first. (Consult the instruction of clock setting.)
2) Input the cooking program. Three stage power levels can be set at most. Defrost should always be set as

the first stage, if it is included in the multi-level program.

Example: If you want to use 20 minutes of 100% microwave power to cook.

a. Press „Micr./Grill/Combi.“ pad, the screen display "P100".
b. Press „Micr./Grill/Combi." to select 100% microwave power.
c. Turn " " to select cooking time.
d.Do not press „Start/Express Cook“ at the last step.
3) Press „Clock/ Pre-Set“, the hour figures will flash, and the indicator “.” will light.
4) Turn “to adjust the hour figures, the input time should be within 0--23.

5) Press „Clock/ Pre-Set“, the minute figures will flash.

6) Turn "to adjust the minute figures, the input time should be within 0--59.

7) Press „Start/Express Cook“ to finish setting. The indicator for clock will flash. If the door is closed, buzzer will ring twice when the time arrives, then cooking will start automatically and the indicator for clock will go out.

11. Lock-out Function for Children

Lock: In waiting state, press "Stop/Clear" for 3 seconds, there will be a long beep denoting entering the children-lock state and LED will display.

Lock quitting: In locked state, press „Stop/Clear“ for 3 seconds, there will be a long “beep” denoting that the lock is released.

12. Auto Menu

Example: If you want to use "Auto Menu" to cook fish of 250g.

1) Press "Auto Menu", "☐" and "☐ will light.

MICROWAVE

2) Turn “” to select the function you want.

3) Press „Auto Menu" button to confirm.

4) Turn "to select the weight of fish. "g" will light.

5) Press „Start/Express Cook“ to start. “g” will go out, „

and "will flash.

The automatic menu procedure:

Menu	Order	Weight	Display
A-1Auto Reheat	1	200 g	17.00
		400 g	17.00
		600 g	17.00
A-2Vegetable	2	200 g	17.00
		300 g	17.00
		400 g	17.00
A-3Fish	3	250 g	17.00
		350 g	17.00
		450 g	17.00
A-4Meat	4	250 g	17.00
		350 g	17.00
		450 g	17.00
A-5Pasta	5	50 g	17.00
		100 g	17.00
A-6Potato	6	200 g	17.00
		400 g	17.00
		600 g	17.00
A-7Pizza	7	200 g	17.00
		400 g	17.00
A-8Soup	8	200 ml	17.00
		400 ml	17.00

Trouble shooting

NORMAL

Microwave oven interfering TV reception	Radio and TV reception may be interfered when microwave oven operating. It is similar to the interference of small electrical appliances, like mixer, vacuum cleaner, and electric fan. It is normal.
Dim oven light	In low power microwave cooking, oven light may become dim. It is normal.
Steam accumulating on door, hot air out of vents	In cooking, steam may come out of food. Most will get out from vents. But some may accumulate on cool place like oven door. It is normal.
Oven started accidentally with no food in	It is forbidden to run the unit without any food inside. It is very dangerous.

Trouble Possible Cause Remedy
Oven can not be started.	Power cord not plugged in tightly.	Unplug. Then plug again after 10 sec.
	Fuse blowing or circuit breaker works.	Replace fuse or reset circuit breaker (repaired by professional personnel of our company).
	Trouble with outlet.	Test outlet with other electrical appliances
Oven does not heat. Door not closed well. Close door well.
Glass turntable makes noise when microwave oven operates	Dirty roller rest and oven bottom.	Dokładnie zamknij drzwiczki

Specification

Power Consumption: 1300W (Microwave), 1000W (Grill)

Rated Microwave Power Output: 800W

Operation Frequency: 2450MHz

Outside Dimensions:

287mm x 485mm x 410mm (H) x (W) x (D)

Oven Capacity: 21 litrów

Cooking Uniformity: 245mm

Power: 230V\~50Hz

Weight: 13,7kg

MICROWAVE

Line drawing of a standard electrical outlet plug (no text or symbols)

MICROWAVE
