Product Type	Cordless DECT telephone with answering machine
Model Variants	CUT 880 (1 handset), CUT 882 (2 handsets), CUT 883 (3 handsets), CUT 884 (4 handsets)
Standard	DECT / GAP
Range (outdoor)	Approx. 300 m
Range (indoor)	Approx. 50 m
Battery Type (per handset)	2 x AAA NiMH 1.2 V
Talk Time	Up to 10 hours
Standby Time	Up to 100 hours
Charging Time (first use)	At least 16 hours
Answering Machine Recording Time	Up to 15 minutes / 99 messages
Phonebook Capacity	Multiple entries (max. 24 digits, 15 characters per entry)
Call Log	Last 30 calls
Redial List	Last 20 numbers
Functions	Handsfree, key lock, baby call, emergency numbers, SMS, call screening, remote access
Display	LCD with icons and text
Base Station Power Supply	Input: 220-230 V AC, 50 Hz; Output: 6 V DC, 600 mA
Charging Station Power Supply	Input: 220-230 V AC, 50 Hz; Output: 6 V DC, 300 mA
Number of Handsets Supported	Up to 5
Ringer Volume Levels	5
Ringer Melodies	5
Flash Time Settings	80, 100, 120, 180, 250, 300, 600, 800 ms
Color	Silver/Black (typical)
Maintenance	Clean with soft, lint-free cloth; do not use cleaning agents

Frequently Asked Questions - CUT 88x AUDIOLINE

How do I register a new handset to the base station?

Press and hold the paging button on the base station for 10 seconds to activate registration mode. On the handset, go to Menu > Settings > Register Handset, enter the base PIN (default 0000), and select the base. The handset will be assigned an internal number.

What should I do if the handset shows 'No Base found'?

Ensure the handset is registered to the base. If not, re-register it. Also check that the base station is powered on and within range. If the problem persists, reset the handset and base by removing power and batteries for a few seconds.

How can I change the outgoing message on the answering machine?

From the handset menu, go to Answer Machine > Answer Settings > Outgoing Message > Record OGM. Choose between 'Answer & Record' or 'Answer Only', then speak your message (max 2 minutes) and press Save.

How do I set the date and time manually?

Press Menu, select Settings > Date/Time. Use the navigation keys to adjust the date and time, then confirm with Ok. The answering machine time is set automatically via the handset.

Can I use this phone during a power failure?

No, the phone requires mains power for the base station. Keep a corded phone that does not need external power for emergencies.

How do I activate the handsfree function during a call?

Press the handsfree button (icon with speaker) on the handset during a call. The microphone and speaker are activated. Press again to return to handset mode.

What is the maximum number of handsets that can be registered?

You can register up to 5 handsets to a single base station. Each handset must be registered separately following the registration procedure.

How do I delete all messages on the answering machine?

On the base station, press and hold the Delete button for 2 seconds, then press Delete again to confirm. On the handset, go to Answer Machine > Delete All Mess, select Yes to confirm.

Why do calls break up or lose connection?

The handset may be out of range (beyond 50m indoors or 300m outdoors). Move closer to the base station. Other electronic devices nearby can cause interference; keep the base away from them. Check that batteries are adequately charged.

How do I set the phone to pulse dialing?

Go to Menu > Settings > Dial Mode, select 'Pulse', then confirm. This is needed for older analog exchanges. You can temporarily switch to tone dialing during a call by pressing the star button for 2 seconds.

USER MANUAL CUT 88x AUDIOLINE

Exterior view of a silver audio recording device with a digital display and control panel (no visible text or symbols on the device body)

Operating Instructions 31

Four identical cylindrical objects with varying shades of gray, arranged horizontally (no text or symbols)

12 Softkeytaste links

13 Menütaste "Info"

Service-Center 1 Service-Center 2

1 Safety Information 32.
2 Putting the Telephone into Operation 33.
3 Operating Elements 35.
4 Introductory Information 36.
5 Telephoning 38.
6 Answering Machine 40.
7 PABX/ Supplementary Services 44
8 Menu Structure	45
9 Special Functions	48.
10 SMS	49
11 Expanding the Telephone System	50
12 In the Case of Problems	51
13 Technical Properties	52
14 Maintenance / Guarantee	53
15 Index	54

Safety Information

1 Safety Information

Please read this operating instruction manual thoroughly.

Intended use

The telephone is suitable for telephoning within a public telephone net-

work system. Any other use is considered unintended use. Unauthorised

modification or reconstruction is not permitted. Under no circumstances open the device or complete any repair work yourself.

Installation location

Prevent excessive exposure to smoke, dust, vibration, chemicals, moisture, heat and direct sunlight.

Do not use the handset in potentially explosive areas.

Power adapter plug

Attention: Only use the power adapter plug supplied because other power supplies could damage the telephone. Ensure ac-

cess to the power adapter plug is not obstructed by furniture or such.

Rechargeable batteries

Attention: Never throw batteries into a fire. Only use batteries of

the same type! Pay attention to correct polarity. Incorrect polarity of the batteries represents a risk of explosion during charging.

Power failure

The telephone cannot be used to make calls in the event of a power fail-

ure. Always keep a cord connected telephone which operates without an external power supply available in case of emergency situations.

Medical equipment

Attention: Never use the telephone in the vicinity of medical

equipment. Effects on such equipment cannot be fully ruled out.

^1 DECT: Digital Enhanced Cordless Telecommunication = Standard for cordless telephones.

Putting the Telephone into Operation

2 Putting the Telephone into Operation

Safety information

Attention: It is essential to read the Safety Information in Chapter 1 before starting up.

Checking the contents of the package The package contains:

Content	CUT 88x-Model
	CUT 880	CUT 882^1	CUT 883^1	CUT 884^1
Base station with power adapter plug	1 1 1	1
Charging station with power adapter plug	- 1 2	3
Handset 1 2 3 4
Telephone connection cable 1 1 1 1
Rechargeable batteries 2 4 6 8
Operating manual 1 1 1 1

Connecting the base station

Attention: Position the base station at least 1 m away from other electronic devices, otherwise there is a risk of mutual disturbance.

Connect the base station as illustrated in the diagram. For reasons of safety, only use the power adapter plug (6V, 600mA) and telephone connection cable supplied.

Diagram showing connections between a device with labeled ports and indicators, including battery, switch, and power supply.

Telephone connection
socket
Mains power
outlet

Connecting the charging station ^1

Connect the charging station as illustrated in the diagram. For safety reasons, only

use the power adapter plug (6V, 300mA) supplied.

Inserting the batteries

Insert the batteries in the open
battery compartment. Only
use batteries of the type AAA
Ni MH 1.2 V. Pay attention to
N-MSF 1.2 v.1 ay attention to
correct polarity. Cl tery compartment.

- AAA + + AAA -

Only applies to telephone sets with at least two handsets; "Checking the contents of the package" on Page 33.

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

GB

Adapter plug (61, 600mA) and telephone contact on tion¹ Mains power outlet

1 Visit www.audioline.de to find out whether this telephone set is
available.

Putting the Telephone into Operation

Charging the batteries

Before the handset is used for the first time, insert it in the base station/charging station for at least 16 hours. When the handset is inserted in the base station/charging station properly, you will hear a confirmation signal. The handset warms up during the charging process. This is normal and does not represent a risk. Do not charge the handset with charging units from other manufacturers.

The current battery charge status is indicated in the display:

Four black cylindrical objects of varying sizes arranged horizontally (no text or symbols)

Full Half empty Weak Empty

Setting the language

The information on Page 46 explains how to set the display language when putting it into operation for the first time.

Setting the time and date on the handset

The time and date are set via the menu. Refer to Page 46 for the sequence of option selections.

Private branch exchanges

The information on Page 44 explains how to install your telephone in a private branch exchange.

Setting the weekday and time on the answering machine

The weekday and time are set automatically on the answering machine via the handset.

The buttons in this operating manual are depicted with a uniform contour. Variations in the symbols on the telephone buttons compared to those depicted here are possible.

3 Operating Elements Handset

1 Scroll upwards / Call log
2 Softkey Right button
3 Phone book
4 R-button (Flash)
5 Scroll downwards

6 On-hook / Switch handset on/off 7 Hash button / Key lock

8 Switch ringing tone off /

Temporary tone dialling

9 Off-hook (Call) / Redialling

10 Handsfree mode

11 Move back / Muting function / Delete digit

12 Softkey Left button

13 Menu button "Info"

Base station (answering machine)

1 Paging button

(locate handset)

2 LED Call indicator

3 LED SMS

4 Play

5 Stop

6 Answering machine on/off

7 Skip back

8 2-digit Display

9 Skip forward

10 Volume +

11 Delete

12 Volume -

Introductory Information

4 Introductory Information

Notation used in the operation instruction manual

Enter digits or letters

* Press the button depicted briefly

2 sec ✱ Press the button depicted for 2

seconds

((Handset rings

(( ) Base station rings

Remove the handset from the base

station

Place the handset in the base station

English or Text or icon in the display

Press the softkey 📋 Page 37.

Icons and texts in the handset display

Display Description

On: The connection to the base station is good. Warning tone: The connection is being interrupted.

Off: The connection has been interrupted. Move towards the base station.

Handsfree mode is activated Page 39.

On: A call is currently being made.

Flashing: The telephone is ringing Page 38.

The ringing tone has been switched off Page 39.

1 SMS: Short Message Service

^2 VMWI: Visual Message Waiting Indication

Display Description

The microphone is deactivated (muted) Page 39.

The key lock function is activated ☐ Page 39.

and

KeyGuard

1 Internally assigned call number of the handset

Page 50.

01.12 13:26 Display of date and time Page 46.

and
New Calls
and
New SMS
New calls have been registered in the call log
Pages 47.
[Non-Text]
A new SMS ^1 message has been recorded 📋 Pages 45 and 49.
[Non-Text]
Answering machine provided by the telephone network. VMWI ^2 - Optional service offered by the telephone net-
work provider 📄 Page 44.
The answering machine is activated ☐ Pages 47.
A new message has been recorded (TAM) 📄 Pages 47.
Answering machine provided by the telephone network. VMWI ^2 - Optional service offered by the telephone net-
work provider 📋 Page 44.
The answering machine is activated 📄 Pages 47.
A new message has been recorded (TAM) ➕ Pages 47.

1 SMS: Short Message Service

^2 VMWI: Visual Message Waiting Indication

Introductory Information
Navigating in the menu

All the functions can be accessed via the various menus. Refer to the menu structure to find how to access the respective functions, Page 45
Menu	Open the main menu
or, or	Move to and select the required submnu
Ok	Open the submnu
or Move to and select the required function
Ok	Open the function
or Move to and select the required setting
Enter digits or letters using the relevant digit keys
Ok or Store	Confirm or store the entry
or <<	Move one level back
Cancel programming and saving processes and return to Standby mode
Every process is automatically cancelled if there is no input within 30 seconds.
g phone book entries - exampleThe way in which to navigate through the menus and enter data is explained by means of the example Creating phone book entries. Proceed as in this example for all the settings.
Open the phone book
Opt	Open the Options menu
or
New Entry, Ok	Select function and confirm
Number: Ok	Enter the number (max. 24 digits) and confirm
Name: Store	Enter the name (max. 15 characters) and store

Navigation buttons

Button In Standby mode In Menu
1 - Open the main menu	- Opens the menu dis-played
2 - Open the call log	- Scroll upwards- Change the settings
3 - Open the phone book - Scroll to the right
4	- Scroll downwards- Change the settings
5 - Switch handset on/off	- Cancel programming and saving processes
6 - Redialling
7	- Scroll to the left- Move one level back
8 - Internal call - Move one level back

Telephoning

5 Telephoning

Taking a call

((", or △) Take the call

Ending a call

or End the call

Making a call

Enter the phone number (max. 24

digits)

Delete the last digit if incorrect

Dial the phone number

It is also possible to press the Off-hook (Call) button for 2 seconds to obtain the dialling tone. The phone number then entered is dialled immediately. It is not possible to correct wrong digits individually using this dialling procedure.

Redialling

The telephone stores the last 20 numbers dialled in a redialling list.

Open the redialling list

or ▲, Select an entry and dial the number

Calls log

The telephone stores the numbers of the last 30 calls received in a call log.

?Open the calls log

▲ or ▼, ▶ Select an entry and dial the number

Dialling phone numbers from the phone book

Phone numbers must have been stored in the phone book for this function Pages 37 and 47.

Open the phone book

Select an entry and dial the number

Transferring external calls internally

HS1: Int , ▲ or ▼ e.g. Handset 2 , Ok

Dial the internal call number during the conversation with the external caller

HS2: Take the internal call on the other handset

HS1: Transfer the call

If the handset called does not answer, take the external call back by pressing the ↗ button.

GB

Telephoning

Handsfree

While a call is in progress, it is possible to dial another handset in order to consult with someone. The external caller is put on hold while you converse with the second, internal person called. You can switch between the callers as often as necessary.
HS1: Int , ▲ or ▼e.g. Handset 2 , Ok	Dial the internal call number during the conversation with the external caller
HS2: Take the internal call on the other handset
HS1: Brok	Change back and forth between the callers
Conference callsAn external call can be transferred to another internal handset for a conference call.
HS1: Int , ▲ or ▼e.g. Handset 2 , Ok	Dial the internal call number during the conversation with the external caller
HS2: Take the internal call on the other handset
HS1: Conf	Start the conference
At this point, you can switch between the two callers as necessary and then back to the conference.
HS1/HS2: The conference is terminated by one of the internal handset users ending the call
Adjusting the receiver volumeThe volume can be adjusted to one of 5 settings during a call.▲ or ▼Select the required volume
Talk time displayThe duration of a received call is displayed in hours, minutes and seconds during the call.

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

GB

Answering Machine

6 Answering Machine

All the functions provided on the answering machine (TAM) can be operated via the handset. Some functions can also be controlled directly on the base station.

Your answering machine is equipped with a vocal operator guidance. Observe the instructions and information provided.

Proceed as follows to open the answering machine's Answer Settings menu:

Menu		Open the main menu
◀ or ▶
Answer Machine	, Ok	Open the Answer Machine menu
▲ or ▼
Answer Settings	, Ok	Open the Answer Settings menu

Setting the weekday and time

The weekday and time of receipt is announced when each message is played back. The weekday and time are set automatically on the answering machine via the handset. Page 46.

Switching the answering machine on/off

Via the base station:

Switch the answering machine on/off

Via the handset using the Answer Machine menu:

or

Answer On/Off, Ok

or Off

On , Ok

Maximum recording time

The answering machine can store up to 99 messages. The maximum total recording time is 15 minutes. When there is no memory capacity available to record new messages, no further messages are recorded.

Setting the volume

The volume of the operator guidance can be set to one of 5 levels. Via the base station:

▲ or ▼ Set the volume Via the handset:

or Set the volume

Setting the number of rings (delay)

You can select from 2 to 8 ringing tones or the Time Saver setting for pre-remote access free of charge.

The free pre-remote access function enables you to determine whether new messages have been left on your answering machine. • If new message have been recorded on your answering machine, your call is taken after 2 rings.

- If no messages have been recorded, the call is taken after 6 rings. Replace the receiver before the 6th ring. No charges are accrued. Via the Answer Settings menu:

or

Answer Delay , Ok Select the function and confirm

or

e.g.: Time Saver, Ok Select the setting and confirm

Further information on remote access is provided on Page 43

Call screening

You can listen-in to the caller without actually taking the call.

Scr Activate the call screening function

End Deactivate the call screening function

Taking a call being recorded

It is possible to take a call even if the answering machine has already begun to take it. Recording of the message is stopped in this case. Take the call

Answering Machine
Checking the current outgoing message

Via the Outgoing Message menu:
or▼
Play OGM, Ok	Select the function and confirm
or▼Answer & Record
orAnswer Only, Ok	Select the outgoing message and confirm
Deleting outgoing messages and returning to pre-recorded messagesAfter deleting your own outgoing message, the pre-recorded message is automatically reactivated.
Via the Outgoing Message menu:
or▼
Play OGM, Ok	Select the function and confirm
Del	Delete the message during playback
Recording a memoA memo is a message left for other machine users and can be played in the same way as an incoming message.
Recording the memoVia the Answer Machine menu:
or▼
Record Memo, Ok	Select the function and confirm
Store	Speak your memo and store it

Selecting the answering mode

The answering machine is provided with two, pre-recorded outgoing messages, OGM 1 and OGM 2. After the “Answer & Record” OGM has been played, the caller can leave a message. The Answer Only OGM is purely an announcement after which no message can be left. The pre-recorded outgoing messages can be replaced by ones of your own. When the answering machine’s memory is full, the Answer Only message is automatically played.
Via the Answer Settings menu:
▲ or ▼
Answer Mode , Ok	Select the function and confirm
▲ or ▼ Answer & Record
or Answer Only , Ok	Select the setting and confirm
Recording/Controlling/Deleting outgoing messages
Recording outgoing messages
An outgoing message may be up to 2 minutes long.
Via the Answer Settings menu:
▲ or ▼
Outgoing Message , Ok	Open the Outgoing Message menu
▲ or ▼
Record OGM , Ok	Select the function and confirm
▲ or ▼ Answer & Record
or Answer Only , Ok	Select the outgoing message and confirm
Save	Speak your message and store it

Answering Machine

Playing or deleting recorded messages/memos

Play the messages

Key function assignment in the Play Messages menu

Button Functions
2 Play/Stop
4, |<	Play the previous message
5 Delete the current message
6, >|	Play the next message
Deleting all messages/memos
All the old messages/memos are deleted. However, new messages/memos not yet played are retained. Via the base station:
2 sec ☒ Initiate the deleting process
☒ Confirm the deleting process
Via the handset using the Answer Machine menu:
▲ or ▼
Delete All Mess, Ok	Select the function and confirm
Delete ? Yes	Confirm the deleting process or
Delete ? No	Cancel the deleting process

The recorded messages/memos are played back in the sequence they were received. The weekday and time of recording are announced before the respective message or memo is played back.Via the base station:

▶ Play

■ Stop playback

◀◀ Repeat playback of message

2 x ◀◀ Play the previous message

▶▶ Play the next message

Via the handset using the Answer Machine menu:

▲ or ▼

Play Messages , Ok Open the Play Messages menu

Further operations, ☑ Key function assignment in the Play Messages menu

Deleting a message

Via the base station:

▶ Play the message to be deleted

⊗ Delete the message

Via the handset using the Answer Machine menu:

▲ or ▼

Play Messages , Ok Open the Play Messages menu

5 Delete the current message

Further operations, ☑ Assignment of functions to keys in the Play Messa-ges menu

Answering Machine
Remote activation of the answering machine

Dial your own phone numberIf you forgot to activate your answering machine, you call is taken after the 10th ring.# ,Press the button while the OGM is playing and enter the PIN

Switch the answering machine on/offYou can now execute other functions. Key function assignment for remote access.

Key function assignment for remote accessRemote access is automatically cancelled if there is no input within 8 seconds.The following table provides an overview of the respective functions assigned to the individual buttons.

Button Functions

1 Play Options menu

2 Start playback of all messages

3 Start playback of new messages

4 Repeat playback of current message

2 x 4 Play previous message

5 Delete current message

6 Play next message

7 Select the answering mode: “Answer & Record” or “Answer Only”

8 Play currently set outgoing message

9 Record new outgoing message

0 Switch answering machine on/off

# End recording of the outgoing messagePlace the telephone on-hook to end remote access

Remote access

You can call your answering machine from another telephone to play any new messages or execute other functions. A condition for this is the use of a telephone which implements tone dialling.
PIN code for remote accessThe default setting of the security PIN code is "0000". In order to use the remote access function, the default PIN code "0000" must be changed.Remote access is only possible when the PIN code is not set to "0000".
Changing the PIN codeVia the Answer Settings menu:
	or
	Change RemotePIN, Ok	Select the function and confirm
	Old PIN: , Ok	Enter the old PIN
	New PIN: , Ok	Enter the new PIN
	Repeat PIN: , Ok	Re-enter the new PIN
Starting remote access
	Dial your own phone number
	*,Press the button while the OGM is playing and enter the PIN
	If the PIN code entry is incorrect, the OGM is repeated. If the PIN is entered incorrectly three times, the line is automatically disconnected.
	You can now execute other functions. Key function assignment for remote access

PABX/ Supplementary Services

7 PABX/ Supplementary Services

R button on private branch exchanges

If the telephone is connected to a private branch exchange, all the functions associated with the R-button, such as transferring calls and automatic call back, can be used. Please refer to the information in the operating manual enclosed with your private branch exchange with regard to the Flash time to set in order to use these functions. The dealer where you purchased the exchange can provide information as to whether the telephone will work properly with the exchange. Setting the Flash time, Page 46.

Number for an outside line

In the case of private branch exchanges, it is necessary to dial a specific number in order to obtain the dialling tone for an outside line. This number for an outside line can be stored. When the telephone detects this number preceding a phone number entered, a dialling pause is automatically inserted after the number. Setting the number for an outside line, Page 46.

Entering a dialling pause manually

It is possible to insert a dialling pause manually after the number for an outside line to be able to continue dialling directly without waiting for the dialling tone.

2 sec 0 Insert dialling pause

After dialling the number for the outside line, the telephone waits 3 seconds before dialling the actual phone number.

The pause can also be entered with the phone numbers in the

phone book.

R-button and supplementary services

Your telephone supports the supplementary services offered by your telephone network provider, such as brokering, call waiting and conference facilities. These supplementary services can be used via the R-button. Please ask your telephone network provider which Flash time you need to set in order to use the supplementary services. Please contact the telephone network provider with regard to enabling the supplementary services. Setting the Flash time, Page 46.

^1 VMWI: Visual Message Waiting Indication ^2 CLIP: Calling Line Identification Presentation

The caller number display function is an optional service offered by telephone network providers. Contact your network provider for further information. If this function is available, the number of the caller appears in the display when the phone rings. If callers suppress transmission of their phone numbers, the numbers do not appear in the display and are not stored in the call log. A corresponding message indicating this appears in the display.

Answering machine in the telephone network

If your telephone network provider has an answering machine available for you in the telephone network, the (VMWI ^1 ) indicates a new message has been recorded for you. The provision of an external answering machine and indication of new messages via an mailbox icon are optional services from the telephone network provider. These functions can only be used when your telephone network provider actually offers the service. Contact your network provider for further information. number display (CLIP ^2 )

Caller number display (CLIP ^2 )

The caller number display function is an optional service offered

by telephone network providers. Contact your network provider for further information.

If this function is available, the number of the caller appears in the display when the phone rings. If callers suppress transmission of their phone numbers, the numbers do not appear in the display and are not stored in the call log. A corresponding message indicating this appears in the display.

^1 VMWI: Visual Message Waiting Indication ^2 CLIP: Calling Line Identification Presentation

Menu Structure

SMS1
Write New SMS Text: Number: Send SMS
		Store SMS
		Delete SMS
Incoming Entry 1	Opt	Answer SMS Use Text?
	Entry 2 Delete SMS
	Entry ... Call Number
Outgoing Entry 1	Opt	Send SMS Number:
	Entry 2 Edit SMS
	Entry ... Delete SMS
SMS Settings SMS-Center SMS-Cen-ter 1 - 4		Number:
	Select Send SMSC SMS Send1 - 4
	SMS Alert Off/On

8 Menu Structure

Main menu

Info Use the Info button to open this menu directly.

Incoming TAM (-) (only displayed with new messages)
	Calls Log (-) (only displayed with new calls)
	SMS (-) (only displayed with new SMS)
SMS Page 45
Calls Log Page 47
Info Service Entry 1 Opt Edit Entry Number: Name:
	Entry ...		Delete Entry Delete ?

^1 Further information on SMS text messages, Page 49.

Menu Structure

	Dial Mode	Tone
		Pulse
	Exchange Code	Number:
	Change PIN2	Old PIN: New PIN: ➤
		➤ Repeat PIN:
	Default Reset Default Reset? Enter PIN: ➤
		➤ Please Wait
Date / Time Date: Time:
Flash Time	Flash 80, 100,120, 180, 250, 300, 600, 800 ms
Register Handset Base A*3		Enter PIN: Search Base!
	BaseB
	Base C
	Base D
Deregister HS	Enter PIN:	Handset 1	Delete HS?
		Handset ...

^1 This setting causes the volume to increase with each ring. ^2 The default PIN code is “0000”. ^3 There are 4 memory locations available for registration of base stations. Memory locations identified by a star (*) are already assigned. If a memory location is selected which is already assigned, the old registration in this memory location is overwritten.

Sound
	Ringer Ring Volume Off
		Ring Volume1 - 5
		Ring Volume ▲1
	Warning Tones Key tone Off/On
		Battery Low Off/On
		No Coverage Off/On
Settings
	Setup Handset Direct Call Enter PIN: 2
		Baby Call On Number:
		Baby Call Off
		Base Selection Base A
			Base ...
		Auto Talk On/Off Off/On
		Emergency No. Emergency No. 1
			Number:
			Emergency No. ...
		Default Reset	Default Reset?
		Language	Deutsch
			English / Türkçe
	Setup Base Ringer Ring Volume Off
			Ring Volume 1 -5
		Ring Melody	Ring Melody 1 - 5

Menu Structure

Phone Book

Access the phone book by pressing

Phone Book

Calls log

Press the ?# button to access the call log.

Calls Log ^3

^1 Further information on the answering machine, ☐ Page 40. ^2 Letters are also imprinted on the digit keys. Letters, digits and special characters are entered by pressing the relevant key the respective number of times. Use the Star button to switch between entering upper and lower case and digits. ^3 The (CLIP ^3 ) feature is necessary to display and save phone numbers in various call logs. The caller number display function is an optional service offered by telephone network providers. Contact your network provider for further information. Further information on the CLIP function, ☐ Page 44.

^4 CLIP: Calling Line Identification Presentation

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

Answer Machine ^1

Play Messages

Delete All Mess Delete ?

Answer On/Off Off/On

Answer Settings Answer Mode Answer & Record

Answer Or

Outgoing Message Record

OGM

The image contains no text.

| |

Play OG

The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), if the GT contains lines used for stylistic emphasis or as background elements (like ruled paper), the OCR result must ignore them. The provided OCR content is "____", which consists of four underscores. This is incorrect because underscores are not equivalent to a solid line and are not permitted under the “Stylistic/Background Lines (Ignore)” rule. Outputting underscores for a stylistic line violates the rule and constitutes an error. Therefore, the OCR result is inconsistent with the Ground Truth.

|

(No text)

Recording Time 30 / 60 / 120 :

Unlimit

Answer Delay Time Saver

2 Ringe

6 Ringe

Change RemotePIN Old PIN:

New

▶Repe:

Record Memo

(No text)

[Non-Text]

[Non-Text]

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

Special Functions

9 Special Functions

Auto talk function (taking calls directly)

If this function is activated, an incoming call is taken when the handset is removed from the base station. Setting the auto talk function, Page 46.

Dialling mode

The telephone can be operated in new, digital exchanges (TONE) as well as analogue exchanges (PULSE). Setting the dialling mode ☐ Page 46.

Temporary tone dialling

If you only operate the telephone using the PULSE dialling mode, you can still make use of the advantages of the TONE dialling mode (e.g.: remote access of the answering machine in the conventional telephone network). You can temporarily switch to Tone dialling when a connection has already been made.

2 sec | ✱ Press the button when a connection

has been established

When the call is ended, the equipment automatically switches back to Pulse dialling.

Direct call (Babycall) function

This function enables you to store a number which is automatically dialled after any button is pressed (except the Opt softkey). Activating the direct call function Page 46.

Opt , ▲ or ▼

Deactivate the direct call function

Baby Call Off, Ok

Emergency call numbers

Up to 4 emergency numbers can be stored in your handset. These numbers can be dialled even if the key lock function is activated. Storing emergency call numbers Page 46.

SWS

Service Center 1 Service Center 2

Deutsche Telekom: 0193 010 Anny | Way: 0900 3266900

Service Center 3 Service Center 4

Empty Empty

The digit keys are also labeled with letters for the entry of the respective letters. Letters, digits and special characters are entered by pressing the relevant key the respective number of times.

0, 1 or # Enter special character

Switch between entering upper and lower case and digits

Del Delete the last character entered

2 sec Del Delete the entire text

10 SMS

Conditions for using SMS

• A text cannot be sent from every private branch exchange extension. • Work provider must enable it. • Your telephone connection. To use the SMS service, your telephone net- • that your telephone network provider to ensure this feature is enabled on • Your telephone connection. To use the SMS service, your telephone net-

If you want to send SMS text messages from a private branch ex- change extension, it is necessary to store the number for an out- side line for your PBX in the handset preceding the Service Cen- ter number.

• Sending SMS messages is not available for Call-by-Call connections at present.

• Charges are made for sending SMS texts. • If the recipient in the conventional telephone network does not use an

• Costs are charged by your telephone network provider. • SMS service or his telephone is not equipped to handle SMS messages, the SMS is automatically convered to a voice message.

SMS Service Center

SMS service. SMS messages are distributed via a Service Center. If you want to send handset Page 45. Please contact the provider of your choice for the new cessary service center call numbers and the procedure for enabling the SMS service.

Your telephone has already been prepared to send SMS text messages. Service Center numbers are already programmed in the handset. Activate the required Service Center in the SMS menu Page 45.

1 CLIP: Calling Line Identification Presentation 2 SMS: Short Message Service

Expanding the Telephone System

11 Expanding the Telephone System

The international GAP ^1 standard regulates the compatibility of handsets and base stations from different manufacturers. As a result, it is possible to integrate AUDIOLINE devices and devices from other manufacturers together in one telephone system. It is possible, however, that certain functions are not available.

Multiple handsets

Up to 5 handsets can be registered on the base station. Registering handsets

Before starting with the registration process for a handset, switch the respective base station to Registration mode.

10 sec [●]), («€») Activate Registration mode

Complete the registration process for your handset, Page 46. The currently valid PIN code is used for registration purposes, Page 46. The handset is automatically assigned an internal call number following registration. The internal call number appears in the display.

To register handsets from other manufacturers, please refer to the operating manual supplied with them.

Deregistering handsets

Each handset can deregister itself and other handsets registered on the base station. The message "No Base found!" appears in the display of the handset deregistered.

1 GAP: Generic Access Profile = Standard for the interoperation of handsets and base stations from other manufacturers.

Multiple base stations

Your handsets can be simultaneously registered on up to 4 different base stations. Each base station requires its own telephone cable socket. Connections can be used with the same call number or with different ones. Switch the respective base stations to Registration mode. Register the handset Page 46. Select the base station you wish to use for telephoning using the "Base Selection" menu, Page 46.

In the Case of Problems

12 In the Case of ProblemsService hotlineShould problems arise with the telephone, please refer to the following information first. In the case of technical problems, you can contact our hotline service, tel. [phone] (cost via Telekom at time of going to print: 14 ct/min). In the case of claims under the terms of guarantee, please contact your sales outlet. There is a 2 year period of guarantee.Problems and solutions
Problems Solutions
No connection to base station possible	- Check that the handset has been registered on the base station with the correct PIN code. ☐ Page 46
No telephone calls possible	- The telephone is not connected properly or is defective. Only use the telephone connection cable supplied.- Test whether the telephone connection is in order by using another telephone.- The power adaptor plug is not plugged in or there is a complete power failure.- The rechargeable batteries are empty or defective.- The handset is too far from the base station.- Dialling mode is set incorrectly. ☐ Page 46
Connection is disturbed or cut off	- The handset is too far from the base station.- The base station is in an unsuitable location.
The system no longer responds	- Reset all the functions to their default settings. ☐ Page 52- Disconnect the power adapter plug briefly from the power socket.- Remove the batteries briefly from the handset.

^1 CLIP: Calling Line Identification Presentation
Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

12 In the Case of Problems Service hotline

Technical Properties
13 Technical Properties
Technical data

Baby call:	Off/ Empty	Auto talk:	On
Number for outside line:	Empty	Display contrast:	4
Key lock:	Off Menu colour:	Blue
Battery warning signal:	On Wallpaper:	Sky
Range warning signal:	On
Base station (Restoring the default settings, Page 46)
Ringing melody:	1	Flash time:	100 ms
Ringing tone volume:	3	Dialling mode:	Tone dialling
VIP phone book:	01805001388	PIN:	0000
Answering machine
Ring delay:	Time Saver	Answering mode	With recording
Answering machine:	On	Volume:	3
Declaration of ConformityThis device fulfils the requirements stipulated in the EU direc-tive:1999/5/EU directive on radio equipment and telecommunica-tions terminal equipment and the mutual recognition of their conformity. Conformity with the above mentioned directive is confirmed by the CE symbol on the device.To view the complete Declaration of Conformity, please refer to the free download available on our web site www.audioline.de.
1 DECT: Digitally Enhanced Cordless Telecommunication = Standard for cordless telephones.2 GAP: Generic Access Profile = Standard for the interoperation of handsets and base stations from other manufacturers.

Feature Value
Standard DECT	^1-GAP^2
Power supply (base station) Input: 220/230 V, 50 HzOutput: 6 V, 600 mA
Power supply (charging station) Input: 220/230 V, 50 HzOutput: 6 V, 300 mA
Range Outdoors: Approx. 300 m	Indoors: Approx. 50 m
Standby Up to 100 h
Max. talk time Up to 10 h
Rechargeable batteries 2 x 1.2 V, size: AAA
Dialling mode Tone dialling mode	Pulse dialling mode
Permissible ambient temperature 10 °C to 30 °C
Permissible relative humidity 20 % to 75 %
Flash function 80 ms, 100 ms, 120 ms, 180 ms,250 ms, 300 ms, 600 ms, 800 ms
Settings
et (Restoring the default settings, Page 46)Language: German Emergency number 1: 112
Ringing melody: 2 Emergency number 2: 110
Ringing tone volume: 3	Emergency number 3: Empty
Receiver volume: 3	Emergency number 4: Empty
Handsfree mode volume: 3	Key tone: On
Phone book: Empty	HS name: CUT 880
Call log: Empty	SMS: Empty
Redialling list: Empty	SMS alarm signal: On

Default settings
Handset (Restoring the default settings, Page 46)
To view the complete Declaration of Conformity, please refer to the free download available on our web site www.audioline.de.
^1 DECT: Digitally Enhanced Cordless Telecommunication = Standard for cordless telephones. ^2 GAP: Generic Access Profile = Standard for the interoperation of handsets and base stations from other manufacturers.

14 Maintenance / Guarantee

Maintenance

- Clean the housing surfaces with a soft, fluff-free cloth.

- Never use cleaning agents or solvents.

Guarantee

AUDIOLINE equipment is produced and tested according to the latest production methods. The implementation of carefully chosen materials and highly developed technologies ensure trouble-free functioning and a long service life. The terms of guarantee do not apply where the cause of equipment malfunction is the fault of the telephone network operator or any interposed private branch extension system. The terms of guarantee do not apply to the batteries or power packs used in the products. The period of guarantee is 24 months from the date of purchase.

All deficiencies resulting from material or production faults which occur during the period of guarantee will be eliminated free of charge. Rights to claims under the terms of guarantee are annulled following intervention by the purchaser or third parties. Damage caused as a result of improper handling or operation, incorrect positioning or storing, improper connection or installation, Acts of God or other external influence are not covered by the terms of guarantee. In the case of complaints, we reserve the right to repair or replace defect parts or provide a replacement device. Replacement parts or devices become our property. Rights to compensation in the case of damage are excluded where there is no evidence of intent or gross negligence by the manufacturer.

If your device shows signs of defect during the period of guarantee, please return it to the sales outlet in which you purchased the AUDIOLINE device together with the purchase receipt. All rights to claims under the terms of guarantee in accordance with this agreement must be asserted exclusively with regard to your sales outlet. Two years after the purchase and transfer of our products, claims under the terms of guarantee can no longer be asserted.

Index

15 Index

Display, 36

E

|

K

L

M

0

P

R

v

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

15 Index
A	Display, 36	Multiple base stations, 50	S
Answer only, 41	E	Multiple handsets, 50	Safety information, 32
Answering machine, 40	Emergency call numbers, 48	Muting the microphone, 39	Searching for the handset, 39
Answering machine in the telephone network, 44	Ending a call, 38	N	Selecting the answering mode, 41
Auto talk function, 48	Entering a dialling pause manually, 44	Navigation buttons, 37	Service hotline, 51
Automatic dialling pause, 44	Entering text, 49	Number for an outside line, 44	Setting the answering machine volume, 40
B	Expanding the telephone system, 50	O	Setting the answering machine weekday and time, 40
Babycall, 48	Explanations, 36	Operating elements, 35	Setting the number of rings, 40
Battery charge status, 34	Flash time, 46	Operating the telephone, 36	Setting the time and date on the handset, 34
Brokering, 39	G	P	Setting the weekday and time on the answering machine, 34
C	Guarantee, 53	Package contents, 33	SMS alarm, 49
Call number display, 44	H	Paging, 39	SMS alert, 49
Call screening, 40	Handsfree, 39	Phone book, 47	SMS conditions, 49
Calls log, 38	Holding a call, 39	PIN code for remote access, 43	SMS Service Centre, 49
Chain dialling, 38	I	Playing memos, 42	Special functions, 48
Charging the batteries, 34	Icons and texts in the handset display, 36	Playing messages, 42	Supplementary services, 44
Conference calls, 39		Private branch exchanges, 44	Switching the answering machine on/off, 40
Connecting the base station, 33	In the case of problems, 51	Problems and solutions, 51	Switching the handset on and off, 39
Connecting the charging station, 33	Inserting batteries, 33	Pulse dialling, 46
Creating phone book entries, 37	Internal calls, 38	Putting the telephone into operation, 33
D	K	R	T
Declaration of Conformity, 52	Key function assignment for remote access, 43	R button on private branch exchanges, 44	Taking a call, 38
Default settings, 52		R-button and supplementary services, 44	Taking a call being recorded, 40
Delay, 40	Key lock, 39	Receiver volume, 39	Talk time, 39
Delete all messages/memos, 42	L	Recording a memo, 41	Technical data, 52
Deleting memos, 42	Language setting, 34	Recording outgoing messages, 41	Telephoning, 38
Deleting messages, 42		Redialling, 38	Temporary tone dialling, 48
Deleting outgoing messages, 41	M	Registering handsets, 50	Time saver, 40
Deregistering handsets, 50	Main menu, 45	Remote access, 43	Tone dialling (DTMF), 46
Dialling mode, 46, 48	Maintenance, 53	Remote control of the answering machine, 43	Transferring external calls internally, 38
Dialling phone numbers from the phone book, 38	Making a call, 38	Ringing melody, 39	Troubleshooting, 51
Direct call, 48	Maximum recording time, 40		V
Direct call acceptance, 48	Menu structure, 45		VMWI, 44

Notes
