USER MANUAL CUT 800 AUDIOLINE

Exterior view of a modern office building (no signage)

Operating Instructions 24

Four identical cylindrical objects with varying shades of gray, arranged horizontally (no text or symbols)

12 Softkeytaste links

13 Menütaste "Info"

Basisstation

1 Mobilteil suchen (Paging)

1

Ladestation

^1 DECT: Digital Enhanced Cordless Telecommunication = Standard for cordless telephones.
cordless telephones.
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for
1 DECT: Digital Enhanced Cordless Telecommunication = Standard for

Putting the Telephone into Operation

2 Putting the Telephone into Operation

Safety information

Attention: It is essential to read the Safety Information in Chapter 1 before starting up.

Checking the contents of the package The package contains:

Content	CUT 80x-Model
	CUT 800	CUT 802^1	CUT 803^1	CUT 804^1
Base station with power adapter plug	1 1 1	1
Charging station with power adapter plug	- 1 2	3
Handset 1 2 3 4
Telephone connection cable 1 1 1 1
Rechargeable batteries 2 4 6 8
Operating manual 1 1 1 1

Connecting the base station

Attention: Position the base station at least 1 m away from other electronic devices, otherwise there is a risk of mutual disturbance.

Connect the base station as illustrated in the diagram. For reasons of safety, only use the power adapter plug (6V, 300mA) and telephone connection cable supplied.

Telephone connection
socket
Mains power
outlet

Connecting the charging station ^1

Connect the charging

station as illustrated

in the diagram. For

safety reasons, only

use the power

adapter plug (6V.

300mA) supplied.

Inserting the batteries

Insert the batteries in the open

battery compartment. Only

use batteries of the type AAA

Ni-MH 1.2 V. Pay attention to

correct polarity. Close the bat-

tery compartment.

^1 Visit www.audioline.de to find out whether this telephone set is

available.

Putting the Telephone into Operation

Charging the batteries

Before the handset is used for the first time, insert it in the base station/charging station for at least 16 hours. When the handset is inserted in the base station/charging station properly, you will hear a confirmation signal. The handset warns up during the charging process. This is normal and does not represent a risk. Do not charge the handset with charging units from other manufacturers. The current battery charge status is indicated in the display:

Four identical cylindrical objects with varying shades of gray and black, arranged horizontally (no text or symbols)

Full Half empty Weak Empty

Setting the language

The information on Page 35 explains how to set the display language when putting it into operation for the first time.

Setting the time and date on the handset

The time and date are set via the menu. Refer to Page 35 for the se-

Private branch exchanges

The information on Page 33 explains how to install your telephone in a print-vate branch exchange.

Operating Elements

3 Operating Elements

Handset

1 Scroll upwards / Call log

2 Softkey Right button

3 Phone book

4 R-button (Flash)

5 Scroll downwards

6 On-hook / Switch handset on/off

7 Hash button / Key lock

8 Switch ringing tone off /

Temporary tone dialling

9 Off-hook (Call) / Redialling

10 Handsfree mode

11 Move back / Muting function /

Delete digit

12 Softkey Left button

13 Menu button "Info"

Base station

1 Paging button (locate handset)

1

Charging station

The buttons in this operating manual are depicted with a uniform contour. Variations in the symbols on the telephone buttons compared to those depicted here are possible.

Introductory Information

4 Introductory Information Notation used in the operation instruction manual

Display Description
	The microphone is deactivated (muted) Page 32.
	The key lock function is activated Page 32.
and KeyGuard
	On: Battery charge capacity indicator. Run-through: The batteries are being charged Page 27.
CUT 800	Name of the telephone Page 39.
1 Internally assigned call number of the handset Page 39.
01.12 13:26	Display of date and time Page 35.
	New calls have been registered in the call log Pages 36.
and New Calls
	A new SMS ^1 message has been recorded Pages 34 and 38.
and New SMS
	Answering machine provided by the telephone network. VMWP - Optional service offered by the telephone net-work provider Page 33.

1 SMS: Short Message Service 2 VMWI: Visual Message Waiting Indication Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

On: The connection to the base station is good. Warning tone: The connection is being interrupted. Off: The connection has been interrupted. Move towards the base station.
Handsfree mode is activated Page 32.
On: A call is currently being made. Flashing: The telephone is ringing Page 31. The ringing tone has been switched off Page 32.

Display Description

Introductory Information

Navigation buttons

All descriptions in this operating manual assume that the handset is in Standby mode. The handset is in Standby mode after pressing the button.

The softkeys (1) and (8) are assigned different functions in the dif-

ferent menus. The function buttons are always referred to in this manual according to the texts directly above them in the display.

Int Menu 8 7 6 1 2 3 4 5

Button In Standby mode In Menu

1 - Open the main menu	- Opens the menu displayed
2 - Open the call log	- Scroll upwards- Change the settings
3 - Open the phone book - Scroll to the right
4	- Scroll downwards- Change the settings
5 - Switch handset on/off	- Cancel programming and saving processes
6 - Redialling
7	- Scroll to the left- Move one level back
8 - Internal call - Move one level back

Navigating in the menu

All the functions can be accessed via the various menus. Refer to the menu structure to find how to access the respective functions, Page 34 Menu Open the main menu or, or Move to and select the required submenu

Ok Open the submenu or ▲ Move to and select the required function Ok Open the function or ▲ Move to and select the required setting Enter digits or letters using the relevant digit keys

Ok or Store Confirm or store the entry C or << Move one level back Cancel programming and saving processes and return to Standby mode Every process is automatically cancelled if there is no input within 30 seconds.

Creating phone book entries - example

The way in which to navigate through the menus and enter data is explained by means of the example Creating phone book entries. Proceed as in this example for all the settings. ■■ Open the phone book Opt Open the Options menu ▲ or ▼ New Entry, Ok Select function and confirm Number: 🎨, Ok Enter the number (max. 24 digits) and confirm Name: 🎨, Store Enter the name (max. 15 characters) and store

Telephoning

5 Telephoning

Taking a call

((,, or □Take the call

Ending a call

or End the call

Making a call

Enter the phone number (max. 24

digits)

Delete the last digit if incorrect

Dial the phone number

It is also possible to press the Off-hook (Call) button for 2 seconds

Making internal calls

dialled immediately. It is not possible to correct wrong digits individually using this dialling procedure.

Redialling

The telephone stores the last 20 numbers dialled in a redialling list.

Open the redialling list

or ▲, Select an entry and dial the number

Calls log

The telephone stores the numbers of the last 30 calls received in a call

log.

?Open the calls log

▲ or ▼, ▶ Select an entry and dial the number

Dialling phone numbers from the phone book

Phone numbers must have been stored in the phone book for this function Pages 30 and 36.

Open the phone book

or, Select an entry and dial the number

e.g. Handset 2 , Ok

conversat

HS2: Take the internal call on the other

handset

HS1: Transfer the call

Dial the internal call number during the conversation with the external caller

If the handset called does not answer, take the external call back by pressing the ↗ button.

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

GB

Telephoning

Holding a call / brokering

While a call is in progress, it is possible to dial another handset in order to consult with someone. The external caller is put on hold while you converse with the second, internal person called. You can switch between the callers as often as necessary.

HS1: Int , ▲ or ▼ e.g. Handset 2 , Ok
HS1: Int , ▲ or ▼ e.g. Handset 2 , Ok

HS2: Take the internal call on the other handset

Change back and forth between the callers

HS1: Brok Conference calls

An external call can be transferred to another internal handset for a conference call. HS1: Int, or e.g. Handset 2, Ok Dial the internal call number during the conversation with the external caller HS2: Take the internal call on the other

handset HS1: Conf Start the conference At this point, you can switch between the two callers as necessary and then back to the conference. HS1/HS2: The conference is terminated by one of

Adjusting the receiver volume

Talk time display

The volume can be adjusted to one of 5 settings during a call. ▲ or ▼ Select the required volume
The duration of a received call is displayed in hours, minutes and seconds during the call.
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]

The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated underscores where none should exist based on the GT's visual context. Hence, the OCR result is inconsistent with the Ground Truth.

The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated underscores where none should exist based on the GT's visual context. Hence, the OCR result is inconsistent with the Ground Truth.

PABX/ Supplementary Services

6 PABX/ Supplementary Services

R button on private branch exchanges

If the telephone is connected to a private branch exchange, all the functions associated with the R-button, such as transferring calls and automatic call back, can be used. Please refer to the information in the operating manual enclosed with your private branch exchange with regard to the Flash time to set in order to use these functions. The dealer where you purchased the exchange can provide information as to whether the telephone will work properly with the exchange. Setting the Flash time, Page 35.

Number for an outside line

In the case of private branch exchanges, it is necessary to dial a specific number in order to obtain the dialling tone for an outside line. This number for an outside line can be stored. When the telephone detects this number preceding a phone number entered, a dialling pause is automatically inserted after the number. Setting the number for an outside line, Page 35.

Entering a dialling pause manually

It is possible to insert a dialling pause manually after the number for an outside line to be able to continue dialling directly without waiting for the dialling tone.

2 sec 0 Insert dialling pause

After dialling the number for the outside line, the telephone waits 3 seconds before dialling the actual phone number.

The pause can also be entered with the phone numbers in the phone book.

R-button and supplementary services

Your telephone supports the supplementary services offered by your telephone network provider, such as brokering, call waiting and conference facilities. These supplementary services can be used via the R-button. Please ask your telephone network provider which Flash time you need to set in order to use the supplementary services. Please contact the telephone network provider with regard to enabling the supplementary services. Setting the Flash time, Page 35.

^1 VMWI: Visual Message Waiting Indication ^2 CLIP: Calling Line Identification Presentation

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

GB

Menu Structure

7 Menu Structure

Main menu

You can access the main menu by pressing the Menu softkey. The way to navigate through the menus is described in chapter 4.

SMS ^1

Info Use the Info button to open this menu directly.

Incoming	Calls Log (-) (only displayed with new calls)
	SMS (-)		(only displayed with new SMS)
SMS	Page 34
Calls Log	Page 36
Info Service	Entry 1	Opt	Edit Entry	Number: Name:
	Entry...		Delete Entry	Delete ?

Display

Wallpaper Wallpaper 1 (Wallpaper in Standby mode)
	Wallpaper 2
	Wallpaper 3
	Wallpaper 4
	Wallpaper Off
Handset Name	Name:
Display Contrast	Level 1 - 8
Color Scheme	Blue / Pink / Green / Yellow /
Backlight On/Off	Off/On (for select version)

^1 Further information on SMS text messages, ☐ Page 38.

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

Menu Structure

	Dial Mode	Tone
		Pulse
	Exchange Code	Number:
	Change PIN2	Old PIN: New PIN: ➤
		►Repeat PIN:
	Default Reset Default Reset? Enter PIN: ➤
		►Please Wait
Date / Time Date: Time:
Flash Time Flash 80, 100,120, 180, 250, 300, 600, 800 ms
Register Handset Base A * 3 Enter PIN: Search Base!
	BaseB
	Base C
	Base D
Deregister HS	Enter PIN:	Handset 1	Delete HS?
		Handset ...

^1 This setting causes the volume to increase with each ring.

^2 The default PIN code is “0000”.

^3 There are 4 memory locations available for registration of base stations. Memory locations identified by a star (*) are already assigned. If a memory location is selected which is already assigned, the old registration in this memory location is overwritten.

Sound

Ringer Ring Volume Off
		Ring Volume1 - 5
		Ring Volume ▲1
	Ring Melody Ring Melody 1 - 15
Warning Tones Key tone Off/On
	Battery Low Off/On
	No Coverage Off/On

Settings

Setup Handset Direct Call Enter PIN: 2
	Baby Call On Number:
	Baby Call Off
	Base Selection Base A
		Base ...
	Auto Talk On/Off Off/On
	Emergency No. Emergency No. 1
		Number:
		Emergency No. ...
	Default Reset	Default Reset?
	Language	Deutsch
		English / Türkçe
Setup Base Ringer Ring Volume Off
		Ring Volume 1 -5
		Ring Melody	Ring Melody 1 - 5

GB

Menu Structure

Phone Book

Access the phone book by pressing

Phone Book

Entry 1	Opt	New Entry Number: Name:	1
Entry 2 Edit	Entry	Number: Name:
Entry ... Delete	Delete

Calls log

Press the ?# button to access the call log.

Calls Log ^2

Entry 1	Opt	Delete Entry Delete ?
Entry 2		Delete All List Delete ?
Entry ... Details
		Store in Phoneb. Name: 1

1 Letters are also imprinted on the digit keys. Letters, digits and special characters are entered by pressing the relevant key the respective number of times. Use the Star button to switch between entering upper and lower case and digits.
2 The (CLIP ^3 ) feature is necessary to display and save phone numbers in various call logs. The caller number display function is an optional service offered by telephone network providers. Contact your network provider for further information. Further information on the CLIP function Page 33.
^3 CLIP: Calling Line Identification Presentation

8

8 Special Functions

Auto talk function (taking calls directly)

If this function is activated, an incoming call is taken when the handset is removed from the base station. Setting the auto talk function, Page 35.

Dialling mode

The telephone can be operated in new, digital exchanges (TONE) as well as analogue exchanges (PULSE). Setting the dialling mode Page 35.

Temporary tone dialling

If you only operate the telephone using the PULSE dialling mode, you can still make use of the advantages of the TONE dialling mode (e.g.: remote access of the answering machine in the conventional telephone network). You can temporarily switch to Tone dialling when a connection has already been made.

2 sec ✱ Press the button when a connection

has been established

When the call is ended, the equipment automatically switches back to Pulse dialling.

Direct call (Babycall) function

This function enables you to store a number which is automatically dialled after any button is pressed (except the Opt softkey). Activating the direct call function Page 35.

Deactivate the direct call function

Emergency call numbers

Up to 4 emergency numbers can be stored in your handset. These numbers can be dialled even if the key lock function is activated. Storing emergency call numbers Page 35.

SMS

9 SMS

Conditions for using SMS

The CLIP ^1 feature must be available for your telephone connection. Contact your telephone network provider to ensure this feature is enabled on your telephone connection. To use the SMS ^2 service, your telephone network provider must enable it. •A text cannot be sent from every private branch exchange extension.

If you want to send SMS text messages from a private branch ex-

change extension, it is necessary to store the number for an outside line for your PBX in the handset preceding the Service Center number.

- Sending SMS messages is not available for Call-by-Call connections at present.

•Charges are made for sending SMS texts.

- If the recipient in the conventional telephone network does not use an SMS service or his telephone is not equipped to handle SMS

messages, the SMS is automatically converted to a voice message. •Costs are charged by your telephone network provider.

SMS Service Center

SMS messages are distributed via a Service Center. If you want to send SMS text messages, you must program a service center number in your handset ☐ Page 34. Please contact the provider of your choice for the necessary service center call numbers and the procedure for enabling the SMS service.

Your telephone has already been prepared to send SMS text

messages. Service Center numbers are already programmed in the handset. Activate the required Service Center in the SMS menu Page 34.

^1 CLIP: Calling Line Identification Presentation ^2 SMS: Short Message Service

Entering text

The digit keys are also labelled with letters for the entry of the respective letters. Letters, digits and special characters are entered by pressing the relevant key the respective number of times.

* Switch between entering upper and

lower case and digits

Delete the last character entered

Delete the entire text

SMS alert signal (alarm)

An acoustic signal is issued when a new SMS text message is received. You can activate or deactivate this signal. Activating/Deactivating the alarm signal, Page 34.

Service Center 1 Service Center 2
Deutsche Telekom: 0193 010 Anny	Way: 0900 3266900
Service Center 3 Service Center 4
Empty Empty

Expanding the Telephone System

10 Expanding the Telephone System

The international GAP ^1 standard regulates the comparability of handsets and base stations from different manufacturers. As a result, it is possible to integrate AUIDOLINE devices and devices from other manufacturers to eye there in one telephone system. It is possible, however, that certain functions are not available.

Multiple handsets

Up to 5 handsets can be registered on the base station. Registering handsets

Before starting with the registration process for a handset, switch the re-specific base station to Registration mode.

10 sec □(●)□, (●)□ Activate Registration mode

Complete the registration process for your handset, Page 35. The cur-ently void PIN code is used for registration purposes, Page 35. The handset is automatically assigned an internal call number following registration. The internal call number appears in the display.

To register handsets from other manufacturers, please refer to the operating manual supplied with them.

Derigstering handsets

Each handset can deregister itself and other handsets registered on the base station. The message "No Base found" appears in the display of the handset deregistered. Deregistering handsets Page 35.

1 GAP: Generic Access Profile = Standard for the interpretation of handsets and base stations from other manufacturers.

In the Case of Problems

11 In the Case of Problems

Service hotline

Should problems arise with the telephone, please refer to the following information first. In the case of technical problems, you can contact our hot-

line service, tel. [phone] (cost via Telekom at time of going to print: 14 ct/min). In the case of claims under the terms of guarantee, please contact your sales outlet. There is a 2 year period of guarantee.

Problems and solutions

Problems Solutions
No connection to base station possible	- Check that the handset has been registered on the base station with the correct PIN code. ☐ Page 35
No telephone calls possible	- The telephone is not connected properly or is defective. Only use the telephone connection cable supplied.- Test whether the telephone connection is in order by using another telephone.- The power adaptor plug is not plugged in or there is a complete power failure.- The rechargeable batteries are empty or defective.- The handset is too far from the base station.- Dialling mode is set incorrectly. ☐ Page 35
Connection is disturbed or cut off	- The handset is too far from the base station.- The base station is in an unsuitable location.
The system no longer responds	- Reset all the functions to their default settings. ☐ Page 41- Disconnect the power adapter plug briefly from the power socket.- Remove the batteries briefly from the handset.

Problems Solutions

The batteries are empty in a short time	- Batteries are empty or defective.- Place the handset in the base station properly. Clean the contact surfaces on the handset and base station with a soft, dry cloth.- Place the handset in the base station for 16 hours.
The CLIP ^1 function does not work	- The caller number display function is an optional service offered by telephone network providers. Contact your network provider for further information.- The caller has suppressed the transmission of their phone number.

^1 CLIP: Calling Line Identification Presentation

Technical Properties
12 Technical Properties Technical data

Feature Value			Empty
Standard DECT	1-GAP2		Number for outside line: Empty	Display contrast: 4
Power supply (base station) Input: 220/230 V, 50 HzOutput: 6 V, 300 mA			Key lock: Off Menu colour: Blue
Power supply (charging station) Input: 220/230 V, 50 HzOutput: 6 V, 300 mA			Battery warning signal: On Wallpaper: Sky
			Range warning signal: On
Range Outdoors: Approx. 300 m	Indoors: Approx. 50 m
Standby Up to 100 h			Base station (Restoring the default settings, Page 35)
Max. talk time Up to 10 h			Ringing melody: 1	Flash time: 100 ms
			Ringing tone volume: 3	Dialling mode: Tone dialling
Rechargeable batteries 2 x 1.2 V, size: AAA
Dialling mode Tone dialling mode	Pulse dialling mode		VIP phone book: 01805001388	PIN: 0000
Permissible ambient temperature 10 °C to 30 °C			Declaration of ConformityThis device fulfils the requirements stipulated in the EU direc-tive:1999/5/EU directive on radio equipment and telecommunica-tions terminal equipment and the mutual recognition of their conformity. Conformity with the above mentioned directive is confirmed by the CE symbol on the device.To view the complete Declaration of Conformity, please refer to the free download available on our web site www.audioline.de.
Permissible relative humidity 20 % to 75 %
Flash function 80 ms, 100 ms, 120 ms, 180 ms,250 ms, 300 ms, 600 ms, 800 ms
Language: German Emergency number 1: 112
Ringing melody: 2	Emergency number 2: 110
Ringing tone volume: 3	Emergency number 3: Empty
Receiver volume: 3	Emergency number 4: Empty
Handsfree mode volume: 3	Key tone: On
Phone book: Empty	HS name: CUT 800
Call log: Empty	SMS: Empty
Redialling list: Empty	SMS alarm signal: On

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)

GB

Maintenance / Guarantee

13 Maintenance / Guarantee

Maintenance

• Clean the housing surfaces with a soft, fluff-free cloth.

- Never use cleaning agents or solvents.

Guarantee

AUDIOLINE equipment is produced and tested according to the latest production methods. The implementation of carefully chosen materials and highly developed technologies ensure trouble-free functioning and a long service life. The terms of guarantee do not apply where the cause of equipment malfunction is the fault of the telephone network operator or any interposed private branch extension system. The terms of guarantee do not apply to the batteries or power packs used in the products. The period of guarantee is 24 months from the date of purchase.

All deficiencies resulting from material or production faults which occur during the period of guarantee will be eliminated free of charge. Rights to claims under the terms of guarantee are annulled following intervention by the purchaser or third parties. Damage caused as a result of improper handling or operation, incorrect positioning or storing, improper connection or installation, Acts of God or other external influence are not covered by the terms of guarantee. In the case of complaints, we reserve the right to repair or replace defect parts or provide a replacement device. Replacement parts or devices become our property. Rights to compensation in the case of damage are excluded where there is no evidence of intent or gross negligence by the manufacturer.

If your device shows signs of defect during the period of guarantee, please return it to the sales outlet in which you purchased the AUDIOLINE device together with the purchase receipt. All rights to claims under the terms of guarantee in accordance with this agreement must be asserted exclusively with regard to your sales outlet. Two years after the purchase and transfer of our products, claims under the terms of guarantee can no longer be asserted.

Index

14 Index
A	E	N	T
Answering machine in the telephone network, 33	Emergency call numbers, 37Ending a call, 31	Navigation buttons, 30Number for an outside line, 33	Taking a call, 31Talk time, 32
Auto talk function, 37	Entering a dialling pause manually, 33
Automatic dialling pause, 33	Entering text, 38	O	Technical data, 41
B	Expanding the telephone system, 39	Operating elements, 28	Telephoning, 31
Babycall, 37	Explanations, 29	Operating the telephone, 29	Temporary tone dialling, 37
Battery charge status, 27	F	P	Tone dialling (DTMF), 35
Brokering, 32	Flash time, 35	Package contents, 26	Transferring external calls internally, 31Troubleshooting, 40
C	G	Paging, 32	V
Call number display, 33	Guarantee, 42	Phone book, 36	VMWI, 33
Calls log, 31	H	Private branch exchanges, 33
Chain dialling, 31	Handsfree, 32	Problems and solutions, 40
Charging the batteries, 27	Holding a call, 32	Pulse dialling, 35
Conference calls, 32	I	Putting the telephone into operation, 26
Connecting the base station, 26	Icons and texts in the handset display, 29
Connecting the charging station, 26	In the case of problems, 40
Creating phone book entries, 30	Inserting batteries, 26
D	Internal calls, 31	R
Declaration of Conformity, 41	K	R button on private branch exchanges, 33
Default settings, 41	Key lock, 32	R-button and supplementary services, 33
Deregistering handsets, 39	L	Receiver volume, 32
Dialling mode, 35, 37	Language setting, 27	Redialling, 31
Dialling phone numbers from the phone book, 31	M	Registering handsets, 39
Direct call, 37	Main menu, 34	Ringing melody, 32
Direct call acceptance, 37	Maintenance, 42	S
Display, 29	Making a call, 31	Safety information, 25
	Making internal calls, 31	Searching for the handset, 32
	Menu structure, 34	Service hotline, 40
	Multiple base stations, 39	Setting the time and date on the handset, 27
	Multiple handsets , 39	SMS alarm, 38
	Muting the microphone, 32	SMS alert, 38
		SMS conditions, 38
		SMS Service Centre, 38
		Special functions, 37
		Supplementary services, 33
		Switching the handset on and off , 32

Service-Hotline Germany: Tel. [phone] (cost via Telekom at time of going to print: 14 ct/min)
