| Product Type | 4-Channel Car Amplifier |
| Number of Channels | 4 |
| Power Output RMS @ 4 ohms | 4 x 110W |
| Power Output RMS @ 2 ohms | 4 x 200W |
| Power Output Bridged (Mono) | 2 x 400W RMS @ 4 ohms |
| Frequency Response | 20Hz - 20kHz |
| Signal-to-Noise Ratio | >95 dB |
| Total Harmonic Distortion | <0.05% |
| Channel Separation | >60 dB |
| Damping Factor | >150 |
| Input Sensitivity | 0.2 - 4V |
| Input Impedance | >20 kOhm |
| Crossover Type | Variable High-Pass / Low-Pass / Bandpass |
| High-Pass Crossover Range | 15Hz - 1kHz |
| Low-Pass Crossover Range | 50Hz - 500Hz |
| Bass Boost | 0dB to +18dB at 45Hz |
| Remote Bass Control | Yes (optional) |
| Fuse Rating | 4 x 20A |
| Dimensions (W x H x D) | 268 x 63 x 435 mm |
| Weight | Approximately 3.0 kg |
| Power Supply | 12V DC (negative ground) |
| Speaker Impedance | 2-4 ohms per channel, 4 ohms bridged |
| Installation Location | Trunk or under seat |
| Protection Features | Short circuit, overload, thermal |
Frequently Asked Questions - RX 8407 Hifonics
User questions about RX 8407 Hifonics
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Car radio in PDF format for free! Find your manual RX 8407 - Hifonics and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. RX 8407 by Hifonics.
USER MANUAL RX 8407 Hifonics
Owner's Manual in English Page 9
INSTALLATION & STROMANSCHLUSS
Installationshinweise
Top-down line drawing of a car interior with four seats and four windows (no text or symbols)Kabelanschlüsse
Installation of the Amplifier, Electrical Connection 10
4-CHANNEL AMPLIFIER RX 8407
Functions & Controls 11
4-Channel-Mode: 2 Frontspeakers / Stereo & 2 Rearspeakers / Stereo 12
3-Channel-Mode: 2 Speakers / Stereo with 1 Subwoofer / Mono Bridged 13
2-Channel-Mode: 2 Subwoofer / Mono bridged 14
TROUBLE SHOOTING 15
Specification
| RX 8407 | |
| Channels | 4 |
| Watts RMS/MAX. @ 4 Ohms | 4 x 110/220 |
| Watts RMS/MAX. @ 2 Ohms | 4 x 200/400 |
| Watts @ 4 Ohms mono bridgedRMS/MAX. | 2 x 400/800 |
| Damping Factor | >150 |
| S/N Ratio | >95 dB |
| Channel Separation | >60 dB |
| THD&N | <0,05 % |
| Input Gain | 0.2 - 4 Volt |
| Input Impedance | >20 kOhm |
| X-Over CH1 & CH2 | |
| Filter Switch | HP/OFF/LP(BP) |
| Low Pass Adjust LP | 50Hz - 500Hz |
| High Pass Adjust HP | 15Hz - 1KHz |
| X-Over CH3 & CH4 | |
| Filter Switch | HP/OFF/LP(BP) |
| Low Pass Adjust LP | 50Hz - 500Hz |
| High Pass Adjust HP | 15Hz - 1KHz |
| Bass-Boost @ 45Hz | 0dB - +18dB |
| Bass Remote Switch | ON/OFF |
| Twin Sub Switch | ON/OFF |
| Line Input Switch | 4CH/2CH |
| Fuses | 4 x 20 Ampere |
| Dimensions in mm | |
| Width x Height x Length Heatsink | 268 x 63 x 435 |
All specifications are object to change!
INSTALLATION & ELECTRICAL CONNECTION
General Installation Notes
The amplifier is generally mounted in the rear trunk area but can be mounted in any convenient area such as beneath a seat. Please be sure to locate this unit where you have reasonable air circulation and protection from moisture. When considering the mounting location you should minimize the length of the power and speaker leads. Minimizing both leads will yield a more reliable installation. It is also important to ensure that the heat sink fins are not against a panel or a surface, preventing air circulation. Do not install the amplifier on a subwoofer box or on vibrating parts of the vehicle, since the vibrations can cause damage to the amplifier's electrical components.
Installation of the amplifier
At first you have to pull out the screws of the cover of the amplifier. Then you are abel to remove the cover and now you can mark the location for the mounting screw holes by using the amplifier as a template. Drill holes at the marked locations and firmly fasten the amplifier in place with the mounting screws supplied in the accessory kit. Before drilling or cutting any holes, investigate the layout of your automobile thoroughly:
Take care when working near the gas lines or hydraulic lines and electrical wiring of your car.
Electrical Connection
Ground (GND)
This wire is the electrical ground and must be fastened securely to the vehicle's chassis. The best method is to use a threading sheet metal screw since the threads cut into bare metal. Ensure that all paint or other insulation is removed from around the hole area, and using self tapping screw, securely affix the bare wire ends to the vehicle chassis. Use as short a piece of cable as possible - use the same gauge that is used for the +12V cable. Make sure that the connection is safe, a loose connection may result in amplifier noise and fault condition.
Many music sources have an output terminal for connection of the remote turn-on of the power amplifier. If a radio doesn't have a remote turn-on feature, then you can use the antenna relay wire, which activates the antenna motor. Please note, if the power antenna retracts when the radio is operating, then you cannot use the antenna relay wire to operate the remote turn-on.
Battery Connection (+12V)
This wire is usually connected directly to the positive battery terminal. Ensure that the + power supply wire is fused via an assigned fuse in line with the + power supply wire. Please use a sufficient gauge for the installed amplifiers (16 - 25 mm²). This connection must be completed using spade lug with insulating sleeve.
Fuses
The integrated amplifier fuses protect the units from short circuit and overload. The fuse rating is for 4 Ohm loads (impedance) of the speakers, for 2 Ohm loads the fuses may have to get increased in case of higher power consumption.
Power / Ground / Remote Connection
![CH1 CH2 CH3 CH4 CH3/4[2CH MODEL] CH1/2 REMOTE CONTROL MOS THRS 20K FETER FIRE + CH1 + CH2 + CH3 + CH4 BRIDGED BRIDGED FUSE -12V REM GND POWER INPUT Fuse FUSE Battery Remote Ground Ground](/content/2026/05/766794/images/5ddc37fef61be4053a9e4d1b4a6f1cf35292e171d08a7b730761d623635b768d.jpg)
4-CHANNEL AMPLIFIER - FUNCTIONS & CONTROLS


4-CHANNEL AMPLIFIER - SPEAKER & RCA-CONNECTION
4-Channel-Mode: 2 Frontspeakers / Stereo & 2 Rearspeakers / Stereo
- Connect the head unit line outputs with good quality RCA to RCA cables with the LINE INPUT SECTION for CH1/2 & CH3/4 of the amplifier.
- Connect the speakers with the terminal blocks (SPEAKER OUTPUT + CH1 -, + CH2 -, + CH3 - and + CH4 -) of the amplifier.
- The minimum final speaker impedance must not be below 2 Ohms per channel. Too low speaker loads results in too high heat dissipation and may cause the amplifier runs into protection-mode.
- Please observe speaker channel and polarity as printed by the speaker terminal block. Incorrect phasing of the speakers results in total loss of bass response.
Caution Please avoid to connect speaker (-) to the ground or vehicle chassis.
FILTER - Switches & Controls Channel 1/2 & Channel 3/4
- If larger than 20 cm speakers are used, the FILTER selector should be set on "OFF" (Full-range).
- For all smaller speakers ( 8.7cm - 16cm) the FILTER selector should be set on "HP", which eliminates the lowest frequencies and protects the speakers from damages. Set the crossover-frequency between 60Hz - 150Hz, depending on the size of the installed speakers. The Highpass adjustment can be done with the HP control. The crossover-frequency is continuously variable from 15Hz - 1KHz.
TWIN SUB - Switch
- This switch should be set on "OFF" - position.
BASS REMOTE - Switch
- This switch should be set on "OFF" - position.
INPUT MODE - Switch
- This switch should be set on "4CH" - position, when you use two RCA to RCA cables. This switch should be set on "2CH" - position, when you use one RCA to RCA cable. Use the inputs CH3 & CH4 when you only use one RCA to RCA cable for connection with the head unit.
INPUT GAIN - Control Channel 1/2 & Channel 3/4
- Turn the INPUT GAIN - controls on the amplifier to "MIN." - position.
- Turn the head unit volume control to about 80-90% of its full setting.
- Turn the INPUT GAIN - controls clockwise until you hear some distortion.
- Then turn back the INPUT GAIN - controls slightly until you can hear clean sound.
BASS BOOST - Control Channel 3/4
- Turn the BASS BOOST control into "0dB" - position.
REMOTE CONTROL - Channel 3/4

4-CHANNEL AMPLIFIER - SPEAKER & RCA-CONNECTION
3-Channel-Mode: 2 Speakers / Stereo & 1 Subwoofer / Mono bridged
- Connect the head unit line outputs with good quality RCA to RCA cables to the LINE INPUT SECTION CH1/2 & CH3/4 of the amplifier.
- Connect the speakers with the terminal block (SPEAKER OUTPUT + CH1 - and + CH2 -) of the amplifier.
- Connect the subwoofer with the terminal block (SPEAKER OUTPUT + MONO BRIDGED - from CH3/4) of the amplifier.
- The minimum final speaker / subwoofer impedance must not be below 2 Ohms / 4 Ohms mono. Too low speaker loads results in too high heat dissipation and may cause the amplifier runs into protection-mode.
- Please observe speaker channel and polarity as printed by the speaker terminal block. Incorrect phasing of the speakers results in total loss of bass response.
Caution Please avoid to connect speaker (-) to the ground or vehicle chassis.
FILTER - Switches & Control Channel 1/2
- If larger than 20 cm speakers are used, the FILTER selector should be set on "OFF" (Full-range).
- For all smaller speakers ( 8.7cm - 16cm) the FILTER selector should be set on "HP", which eliminates the lowest frequencies and protects the speakers from damages. Set the crossover-frequency between 60Hz - 150Hz, depending on the size of the installed speakers. The Highpass adjustment can be done with the HP control. The crossover-frequency is continuously variable from 15Hz - 1KHz.
FILTER - Switches & Control Channel 3/4
- In 1-Channel-Mode in Mono the FILTER selector should be set on "LP", which eliminates the higher frequencies. The recommended crossover-frequency should be between 60Hz - 150Hz , depending on the size and response of the subwoofer. The lowpass adjustment can be done with the LP control. The crossover-frequency is continuously variable from 50Hz - 500Hz . When you use this setting the HP control is activated as a subsonic-filter. This filter eliminates too low frequencies. The threshold is continuously variable from 15Hz up to 1KHz and should be between 15Hz and 50Hz .
TWIN SUB - Switch
- This switch should be set on "OFF" - position.
BASS REMOTE - Switch
- This switch should be set on "ON" - position, if you want to use remote control. When this switch is set on "ON" - position BASS BOOST - Control of the amplifier is out of function.
INPUT MODE - Switch
- This switch should be set on "4CH" - position, when you use two RCA to RCA cables. This switch should be set on "2CH" - position, when you use one RCA to RCA cable. Use the inputs CH3 & CH4 when you only use one RCA to RCA cable for connection with the head unit.
INPUT GAIN - Control Channel 1/2 & Channel 3/4
- Turn the INPUT GAIN - controls on the amplifier to "MIN." - position.
- Turn the head unit volume control to about 80-90% of its full setting.
- Turn the INPUT GAIN - controls clockwise until you hear some distortion.
- Then turn back the INPUT GAIN - controls slightly until you can hear clean sound.
BASS BOOST - Control Channel 3/4
- The BASS BOOST controls the bass level (only CH3/4) from "0dB - +18dB" at 45Hz.
REMOTE CONTROL - Channel 3/4
- Allows to control Bass Boost via remote control from any location, e.g. from driver's seat.

4-CHANNEL AMPLIFIER - SPEAKER & RCA-CONNECTION
2-Channel-Mode: 2 Subwoofer / Mono bridged
- Connect the head unit's subwoofer line output with a good quality RCA to RCA cable to the LINE INPUT SECTION CH3/4 of the amplifier.
- Connect the subwoofers with the terminal blocks (SPEAKER OUTPUT + MONO BRIDGED - from CH1/2 and + MONO BRIDGED - from CH3/4) of the amplifier.
- The minimum final speaker impedance must not be below 4 Ohms per channel pair. Too low speaker loads results in too high heat dissipation and may cause the amplifier runs into protection.
- Please observe speaker channel and polarity as printed by the speaker terminal block. Incorrect phasing of the speakers results in total loss of bass response.
Caution Please avoid to connect speaker (-) to the ground or vehicle chassis.
FILTER - Switch & Control Channel 1/2 & Channel 3/4
- In 2-Channel-Mode with 2 subwoofers mono bridged set the FILTER selector to "LP"- position, which eliminates the higher frequencies. The recommended crossover-frequency is between 60Hz - 150Hz , depending on the size and response of the subwoofer. The lowpass adjustment can be done with the LP control. The crossover-frequency is continuously variable from 50Hz - 500Hz . When you use this setting the HP control is activated as a subsonic-filter. This filter eliminates too low frequencies. The threshold is continuously variable from 15Hz up to 1KHz and should be between 15Hz and 50Hz .
TWIN SUB - Switch
- When this switch is set on "ON" - position the same parameters of CH 3 & 4 for GAIN, HIGH PASS, LOW PASS and BASS BOOST are also used for CH 1 & 2. When you use this setting the controls of channel-pair CH1/2 are out of function.
BASS REMOTE - Switch
- This switch should be set on "ON" - position, if you want to use remote control. When this switch is set on "ON" - position BASS BOOST - Control of the amplifier is out of function.
INPUT MODE - Switch
- This switch should be set on "4CH" - position. Use the Inputs CH3 & CH4 for connection with the head unit.
INPUT GAIN - Control Channel 3/4
- Turn the INPUT GAIN - controls on the amplifier to "MIN." - position.
- Turn the head unit volume control to about 80-90% of its full setting.
- Turn the INPUT GAIN - controls clockwise until you hear some distortion.
- Then turn back the INPUT GAIN - controls slightly until you can hear clean sound.
BASS BOOST - Control Channel 3/4
- The BASS BOOST controls the bass level from "0dB - +18dB" at 45Hz.
REMOTE CONTROL - Channel 3/4
- Allows to control Bass Boost via remote control from any location, e.g. from driver's seat.
Caution! Please use the Bass Boost carefully. The additional boost may result in clipping or overload.

©
