Product Type	Back Protector
Brand	Crivit
Model	SP-412-2
Protection Level	Level 1 (EN 1621-2:2014)
Standard Compliance	European Standard 1621-2:2014, CE certified (EU Directive 89/686/EEC)
Size Options	XS/S, M, L/XL
Body Height Range (XS/S)	141–157 cm
Body Height Range (M)	157–173 cm
Body Height Range (L/XL)	173–191 cm
Hip-Shoulder Distance (XS/S)	40–44 cm
Hip-Shoulder Distance (M)	45–49 cm
Hip-Shoulder Distance (L/XL)	50–54 cm
Designated Use	Motorcycle riding, cycling, winter sports
Material	Conventional impact-absorbing foam
Fastening	Waist strap with hook-and-loop closure
Care Instructions	Wipe with dry cloth; store in dry, ventilated place away from direct sunlight and heat
Service Life	Up to 5 years (depending on use and care)
Warranty	3 years
Disposal	Via authorized waste disposal facility
Notified Body	TÜV Rheinland LGA Products GmbH (0197)

Frequently Asked Questions - SP-412-2 CRIVIT

What protection level does the Crivit SP-412-2 back protector offer?

The back protector complies with Level 1 of European Standard EN 1621-2:2014, meaning it limits transmitted residual force to less than 18 kN under an impact energy of 50 J.

What sizes are available for the SP-412-2?

The protector comes in three sizes: XS/S (body height 141–157 cm), M (157–173 cm), and L/XL (173–191 cm). Exact fit depends on hip-shoulder distance.

How do I determine the correct size of the back protector?

Measure the user's body height and hip-to-shoulder distance. Refer to the size table in the manual (e.g., XS/S: 40–44 cm hip-shoulder). Ensure the protector sits along the spine without gap.

Can the back protector be used for sports other than motorcycling?

Yes, it is designed for motorcycle riders, cyclists, and winter sports such as skiing or snowboarding. It should be worn under appropriate outer clothing.

How should I clean and maintain the back protector?

Clean the outer side with a dry cloth. Do not use chemicals. Store in a dry, ventilated area away from heat sources and direct sunlight, and avoid temperatures below 5°C or above 70°C.

What is the service life of the SP-412-2?

The protector should be replaced after 5 years or immediately after any significant impact or visible damage. Regular checks are recommended.

Does the back protector come with a warranty?

Yes, the product includes a 3-year warranty from the date of purchase. Retain proof of purchase for claims.

What should I do if the back protector is damaged?

If you notice any tears, cracks, or deformation, stop using it immediately and contact the manufacturer. Do not attempt repairs yourself as they may compromise protection.

Is it safe to wear the back protector outside clothing?

No, the protector must be worn under clothing. It is not designed for external use and will not provide proper protection if exposed directly.

What are the environmental conditions for optimal performance?

The protector is tested at 15–22°C and 60–70% relative humidity. Extreme temperatures or humidity may alter its impact absorption capacity.

USER MANUAL SP-412-2 CRIVIT

Line drawing of a sleeveless dress with symmetrical side panels and front trim (no text or symbols)

MODEL SP-412-2

GB IE

BACK PROTECTOR

SP-412-2

Kezelési utmutató

SI

ŠČITNIK ZA HRBET

SP-412-2

Navodila za uporabo

CZ

CHRÁNIČ PÁTEŘE

SP-412-2

Navod k použiti

IAN 101554

GB IE

BACK PROTECTOR SP-412-2 03

1. Level of protection 04
2. Designated use 04
3. Tips for use 04
4. Correct size 04
5. Limitations of use 05
6. Protection zone 05
7. Storage, care, cleaning	05
8. Service life	06
9. Advice for disposal	06

INFORMATION SHEET FOR BACK PROTECTORS WHICH ARE USED WITH MOTORBIKE, BICYCLE OR WINTER SPORTS CLOTHING OR OTHER PROTECTIVE CLOTHING.

This back protector was designed, manufactured and tested according to EUROPEAN STANDARD 1621-2:2014 LEVEL 1 for devices which protect against mechanical impact.

CAUTION:

Provided that it is correctly used and worn, this protector can minimise the consequences associated with mechanical impact in the areas protected by it.

However, it cannot guarantee complete protection. Spinal injuries or fractures cannot be prevented.

MEANING OF THE 'CE' MARK

The CE mark of conformity on the protective device documents the conformity of the product with the corresponding standard and directive of the European Community which demands the affixing of this mark and certifies that the protective device has been subjected to an EC prototype test. The conformity with the requirements of the European Directive 89/686/EEC for personal protective equipment (and subsequent modifications) as well as with the those of the harmonising technical standard 1621-2:2014 was certified by the testing institute TÜV Rheinland LGA Products GmbH, Tillystr. 2, D-90431 Nürnberg, Germany, notified body 0197.

GB / IE Owner's Manual 03 - 06

SI Navodila za uporabo 07 - 10

CZ Navod k použiti 11 - 12

GB IE

GB IE

1. LEVEL OF PROTECTION

Degree of protection '1', 'kerbstone test': impact energy 50J, transmitted residual force less than 18 kN

Degree of protection '2', 'kerbstone test': impact energy 50J, transmitted residual force less than 9 kN

The degree of protection given is printed on the webbing sewn in to the interior of the protector (or simply on its exterior).

This protector complies with Class 1.

The protector offers limited protection (in so far as it is correctly used and worn) against the consequences of a strong mechanical force, such as would occur with a fall or an impact. also, in the case of a fall on a motorbike or cycle, or during winter sports, for example, it can lessen the severity of cuts and bruises in the region protected by the device. however, it does not provide a guarantee that no physical injury will be sustained! it is therefore recommended that motorcycle riders, sports cyclists and those practising winter sports use the back protector. However, this should not be interpreted as encouragement to be careless or to drive recklessly while using it. The degree of protection given by the back protector remains undiminished only as long as its original characteristics remain unaltered. For this reason modifications and/or repairs must not be undertaken without the approval of the manufacturer.

The cushioning in the neck and rump areas do not comply with the 1621-2:2014 and do not provide sufficient protection.

The manufacturers cannot accept liability for any consequences whatsoever which are attributable to unauthorised alterations or repairs.

2. DESIGNATED USE

This back protector has been designed for use by motorbike riders, sport cyclists and those practising winter sports. It may be used on its own, with other suitable protective equipment or combined with clothing.

3. TIPS FOR USE

It is important to wear the back protector along the spinal area of the back (with the soft padding against your back) to ensure that maximum effect is achieved. Make sure that the writing is readable and not upside down.

4. CORRECT SIZE

The back protector is available in three sizes. Please use the back protector according to the body size and the hip - shoulder distance of the wearer. No single variable can be suitable for all body dimensions.

Size Body height	Hip-Shoulder Distance
XS/$ approx. 141-157 cm 40-44 cm
M approx. 157-173 cm 45-49 cm
L/XL approx. 173-191 cm 50-54 cm

! FURTHER TIPS:

Once the protector is positioned as per instructions, check its fit by putting the appropriate jacket on over it and carrying out all the physical actions you will later go through when performing the particular activity for which its use is designed (i.e. cycling, motorcycling, winter sports). Secure the back protector using the waist strap (which has hook-and-loop fastening).

CAUTION:

It is important to carry out a basic check on the protector before use in case there is any damage, such as fractures or tears. Even only minor ones may impair its function. In case of damage, or if the protector has been subjected to a significant impact, the protector must be replaced.

The back protector will only fulfil its protective function if it is correctly fitted and secured and is in an undamaged state. The manufacturers cannot accept liability for any damage and any consequences whatsoever which may arise from improper use, or from wearing clothing that is partially or wholly unsuitable for the back protector to be positioned correctly.

5. LIMITATIONS OF USE

The tests to ascertain the back protector's impact absorption capacity were carried out according to the regulations, at a temperature of between 15 °C and 22 °C and with a relative humidity of between 60% and 70%. With values beyond these ranges the impact absorption capacity of the back protector may change.

It is absolutely necessary to wear appropriate clothing over the back protector.

Under no circumstances must it be worn outside (or without) clothing.

6. PROTECTION ZONE

The back protector gives protection within the protection zone, as shown in the illustration (1). if the back protector is no longer in the condition it was as supplied to the customer, or if a damaged back protector is used adequate protection is no longer afforded.

7. STORAGE, CARE, CLEANING

To keep the protector in good condition we recommend that you store it in a dry, well-ventilated environment, away from heat sources, windows, doors or glass panels, and that you avoid leaving it in direct sunlight. The ambient temperature must thereby never fall below 5 °C or above 70°C (which temperature can be exceeded in the car in summer weather, for example). avoid both extreme cold and heat.

You should also make sure that the back protector is stored with its inside uppermost to ensure that no weight will come to rest on it, as this can cause deformation or damage.

We strongly advise that you check the fastener systems of the protector after each use for possible breaches or other defects. should any tears or damaged areas, even of a minor nature, be discovered, please correspond with the manufacturer to arrange a further assessment.

GB IE

SI

Should the damage be significant, the protective device must be replaced immediately.

The manufacturers cannot accept liability for any consequences whatsoever which arise from repairs or modifications to the back protector which have not been carried out by the manufacturers themselves.

CAUTION:

Contact with aggressive chemical substances (acids, oils, solvents, etc.) may compromise the integrity of the back protector.

Cleaning: first remove the back protector from clothing, then simply wipe the outward facing side with a dry cloth to remove dust and small spots of dirt.

washable vest.

Conventional materials have been used in manufacturing the back protector. These materials are not known to be hazardous to health.

8. SERVICE LIFE

Provided that the back protector is stored with care as recommended above and has not been exposed to any mechanical impact it can retain its protective function for a long period of time. The duration of its service life depends in particular on how it is used/worn, the resulting wear and tear of its constituent materials and climatic conditions and other environmental factors.

Subject to the stresses it is put under, it is advisable to check its condition regularly and, when necessary, to replace it.

The back protector should ultimately be replaced after a period of 5 years.

9. ADVICE FOR DISPOSAL

Dispose of the back protector via an authorised waste disposal company or your local authority disposal facility. Be careful to comply with all regulations which apply. In case of doubt, enquire at your local disposal facility about disposing of the item in an environmentally friendly manner.
