RAZE 3 Radion - Loudspeaker Niceboy - Free user manual and instructions

Product Type	Portable Bluetooth Speaker
Brand	Niceboy
Model	RAZE 3 Radion
Power Output	24 W
Battery Capacity	Li-Ion 5000 mAh
Battery Life	Up to 24 hours (at 50% volume)
Charging Time	Approximately 5 hours
Charging Port	Micro USB (5V, 1A)
Bluetooth Version	5.0
Wireless Range	10 meters
Waterproof Rating	IP67
FM Tuner	Yes (87.5 - 108 MHz)
Supported Audio Formats	MP3, WMA, WAV
Card Slot	Micro SD (max 32 GB)
USB Port	Yes (for charging devices and USB flash drive)
TWS Function	Yes (pair two speakers)
Speakerphone	Yes (hands-free calling)
Audio Input	3.5 mm AUX
Frequency Response	65 Hz - 20 kHz
Impedance	8 Ω
Sensitivity	>75 dB

Frequently Asked Questions - RAZE 3 Radion Niceboy

How to charge the RAZE 3 Radion speaker?

Use the supplied micro USB cable to connect the speaker's charging port to a USB power adapter (5V, 1A minimum) or a computer USB port. Full charge takes about 5 hours. The two LED indicators show charging progress; they turn off when fully charged.

How do I pair the speaker with my phone via Bluetooth?

Power on the speaker (press and hold the power button for 3 seconds). The speaker automatically enters pairing mode (LED flashes blue). On your phone, enable Bluetooth and select "Niceboy RAZE 3 radion" from the available devices. Successful pairing is confirmed by an audio signal and the LED flashing every 5 seconds.

Can I use the FM radio on this speaker?

Yes. First, connect the micro USB cable (acts as an antenna) to the charging port. Press the Mode button to switch to FM mode. Press and hold the Play/Pause button to auto-scan and save stations. Use volume up/down buttons to switch between saved stations.

How to connect two RAZE 3 Radion speakers via TWS?

Power on both speakers and ensure they are not connected to any device. Long press the Mode button on one speaker; you'll hear an audio signal when they pair. Then, on your source device, connect to Bluetooth as usual – both speakers will play simultaneously.

Can I play music from a micro SD card or USB flash drive?

Yes. Insert a micro SD card (max 32 GB) or a USB flash drive (max 32 GB) into the appropriate slot. The speaker automatically switches to that mode. Supported audio formats are MP3, WMA, and WAV. Use the controls to play, pause, and skip tracks.

Is the speaker waterproof?

Yes, the RAZE 3 Radion has an IP67 waterproof rating, meaning it is dust-tight and can be submerged in up to 1 meter of water for 30 minutes. However, avoid saltwater and sand.

What is the battery life of the speaker?

The built-in Li-Ion 5000 mAh battery provides up to 24 hours of playback at 50% volume. Lower volumes may extend battery life; higher volumes will reduce it.

How to use the speaker for phone calls?

When connected via Bluetooth, press the Play/Pause button to answer an incoming call. Press again to end the call. To call the last dialed number, press the button twice quickly. The speaker has a built-in microphone for hands-free calling.

What devices are compatible with the RAZE 3 Radion?

Any device that supports Bluetooth 5.0 or earlier (smartphones, tablets, laptops) can connect. It also works with non-Bluetooth devices via the 3.5 mm AUX input or by playing files from a USB drive or micro SD card.

How to reset or troubleshoot if the speaker is not responding?

If the speaker freezes or won't connect, try turning it off and on again by pressing and holding the power button for 3 seconds. For persistent issues, charge the speaker fully. If problems continue, consult the full manual or contact Niceboy support.

USER MANUAL RAZE 3 Radion Niceboy

NABÍJENÍ

https://niceboy.eu/cs/declaration/raze-3-radion

INFORMACE PRO UŽIVATELE K LIKVIDACI ELEKTRICKÝCH A ELEKTRONICKÝCH ZAŘÍZENÍ (DOMÁCNOSTI)

NABÍJANIE

Micro USB charging cable

Audio cable

Instructions for Use

PRODUCT DESCRIPTION

1. Turn down volume / Previously played track
2. Turn up volume / Next track
3. LED indicator
4. Power on/off
5. Change modes
6. Playback / Pause / Call accept / call decline / hang up / last called number
7. AUX port 3.5 mm jack
8. USB charging - output, input for USB flash disk
9. SD card slot
10. Micro USB charging port

CHARGING

We recommend fully charging the speaker before its first use to maximize the battery's lifespan. The speaker takes approximately 5 hours to fully charge. Low battery is announced by an audible signal. To charge the speaker's battery connect the enclosed micro USB cable to the charging port (10) and connect to any charging adapter (voltage 5V and output current minimum of 1A) or to a USB port on your PC. You can follow the charging progress thanks to the 2 charging LED diodes (3), after a full charge is complete both diodes will go out.

POWERING ON/OFF

Press and hold button (4) for 3 seconds to power on/off the speaker. Powering on and off is announced via an audio signal.

CONNECTING TO BT

1. The speaker is ready for Bluetooth connection from the moment it is powered on. Pairing mode is signalled by the LED diodes (3) flashing blue.
2. Activate Bluetooth on your own device. Select "Niceboy RAZE 3 radion" from the list of available devices.
3. Your device will connect to the speaker. Successful pairing is announced by an audio signal and flashing of the LED diodes (3) at five second intervals.

*Once powered on again, the speaker will automatically connect to the device with which it was last paired.

PLAYBACK

Play or pause tracks by pressing button (6). Press and hold the volume controls, located on buttons (1) and (2) to change volume. Press the volume up button to jump to the next track and the volume down button to jump to the previously played track.

AUX MODE

1. Insert the enclosed 3.5 mm jack cable into the audio port (7) and the speaker will automatically switch to the relevant mode.
2. Use the device with which you are connected to the speaker to control music playback.

Press and hold the volume controls, located on buttons (1) and (2) to change volume. Play or pause tracks by pressing button (6).

FM MODE

Connect the enclosed micro USB cable to the charging port (10) and it will act as an antenna. Press button (5) and FM mode will be announced with an audio signal; press and hold button (6) to automatically search and save radio stations. You can stop the automatic search function by pressing and holding the same button (6). While out of the search function you can switch between radio stations by pressing buttons (1) and (2). Play or pause playback by pressing button (6).

MICRO SD CARD, USB FLASH DISK

The speaker will automatically switch over to the relevant mode once an SD card or USB disk has been inserted. Play or pause playback by pressing button (6).

Press and hold the volume controls, located on buttons (1) and (2) to change volume. Press the volume up button to jump to the next track and the volume down button to jump to the previously played track.

TELEPHONE CALLS

Press button (6) to accept and then end telephone calls. Incoming calls may be declined on your device. Press button (6) twice to call the last number in your call list.

TRUE WIRELESS (TWS) CONNECTION

With the help of True Wireless (TWS) you can connection two Niceboy RAZE 3 radion speakers to one device and simultaneously play music through both.

1. Power on both Niceboy RAZE 3 radion speakers and ensure they are not connected to any other Bluetooth device (mobile, laptop, etc.)
2. Long press button (5) on one of the speakers. An audio signal will announce the successful connection of both speakers and both speakers.
3. Now you may open the Bluetooth settings on your own device. Select "Niceboy RAZE 3 radion" from the list of available devices. Successful pairing is announced by an audio signal.

PARAMETERS

BT version: 5.0

Frequency band: 2.4GHz

Radio frequency power: ≤ 2,5mW

Supported codecs: SBC, A2DP, AVRCP, HFP

Power: 24W

Electrical impedance: 8Ω

Sensitivity: >75dB

Frequency range: 65 Hz – 20 kHz

BT transmission distance: 10 meters

FM frequency: 87.5MHz \~ 108MHz

Supported data carrier: micro SD card, USB flash disk, max. 32GB

Supported audio formats: MP3, WMA, WAV

Battery: Li-Ion 5000 mAh

Battery life: 24 hours (at 50% volume)

Watertightness: IP67

SAFETY INFORMATION

Listening to music at excessive volume can damage your hearing. Do not subject the equipment to fluids and moisture. Do not expose the device to excessively high/low temperatures, and do not attempt to disassemble it. Protect the device from sharp objects and falls from height. Batteries - Improper handling (prolonged charging, short circuit, breakage by other objects, etc.) may result in fire, overheating or battery leakage.

The battery or accumulator that may be included with the product has a life of six months because it is a consumable item.

Information on all frequency bands in which the radio equipment operates and intentionally transmits radio waves as well as the maximum radio frequency power transmitted in the frequency band in which the radio equipment is operated is included in the instructions and safety information.

NICEBOY s.r.o. hereby declares that the type of radio equipment NICEBOY RAZE 3 RADION complies with Directives 2014/53 / EU, 2014/30 / EU, 2014/35 / EU, and 2011/65 / EU. The full content of EU Declaration of Conformity is available on the following websites: https://niceboy.eu/en/declaration/raze-3-radion

USER INFORMATION FOR DISPOSING ELECTRICAL AND ELECTRONIC DEVICES (HOME USE)

This symbol located on a product or in the product's original documentation means that the used electrical or electronic products may not be disposed together with the communal waste. In order to dispose of these products correctly, take them to a designated collection site, where they will be accepted for free. By disposing of a product in this way, you are helping to protect precious natural resources and helping to prevent any potential negative impacts on the environment and human health, which could be the result of incorrect waste disposal. You may receive more detailed information from your local authority or nearest collection site. According to national regulations, fines may also be given out to anyone who disposes of this type of waste incorrectly. User information for disposing electrical and electronic devices.

(Business and corporate use)

In order to correctly dispose of electrical and electronic devices for business and corporate use, refer to the product's manufacturer or importer. They will provide you with information regarding all disposal methods and, according to the date stated on the electrical or electronic device on the market, they will tell you who is responsible for financing the disposal of this electrical or electronic device. Information regarding disposal processes in other countries outside the EU. The symbol displayed above is only valid for countries within the European Union. For the correct disposal of electrical and electronic devices, request the relevant information from your local authorities or the device seller.
