Quicklux-3F - Switch Vemer - Free user manual and instructions
Find the device manual for free Quicklux-3F Vemer in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Interruptor (Switch) |
| Brand | Vemer |
| Model | Quicklux-3F |
| Dimensions | 86 x 86 mm (standard) |
| Weight | Approx. 50 g |
| Rated Voltage | 230 V AC |
| Rated Current | 10 A |
| Frequency | 50/60 Hz |
| Operating Temperature | -10°C to 40°C |
| Number of Poles | 1-way (SPST) |
| Material | Thermoplastic, self-extinguishing |
| Mounting Type | Flush mounting (UK/European box) |
| Terminal Capacity | Up to 2.5 mm² wires |
| Protection Class | IP20 (indoor use) |
| Color | White (standard) |
| Main Functions | On/Off switching of lighting and appliances |
| Cleaning & Maintenance | Wipe with a soft dry cloth; do not use solvents |
| Safety Features | Self-extinguishing, high flame resistance |
| Spare Parts & Repairability | No user-serviceable parts; replace if faulty |
| General Information | Vemer Quicklux series, easy snap-fit installation |
Frequently Asked Questions - Quicklux-3F Vemer
How do I install the Quicklux-3F switch?
Ensure power is off. Connect the live wire to the common (L) terminal and the load wire to the L1 terminal. Secure the switch into a standard flush mounting box.
Is the Quicklux-3F compatible with LED bulbs?
Yes, it is compatible with most LED, CFL, and incandescent bulbs, as long as the total load does not exceed 10 A at 230 V AC.
Can I use this switch for a dimmer function?
No, the Quicklux-3F is a standard on/off switch. It does not have dimming capabilities.
Does it have a backlit or indicator light?
No, this model does not include any indicator or backlight. It is a plain toggle/rocker switch.
What is the maximum power rating?
The maximum load is 10 A, equivalent to 2300 W at 230 V AC for resistive loads.
Is the Quicklux-3F suitable for outdoor use?
No, it has an IP20 rating, meaning it is only suitable for indoor, dry locations.
What wire gauge can be connected?
The terminals accept solid or stranded wires up to 2.5 mm² (14 AWG). Strip 10-12 mm of insulation.
How do I clean the switch?
Wipe gently with a soft, dry cloth. Do not use water, cleaning agents, or abrasive materials.
Can I replace a broken switch myself?
If you are confident in electrical work, yes. Always turn off the circuit breaker. Replacement is straightforward with the same model.
Does it comply with safety standards?
Yes, the Quicklux-3F meets European safety standards (CE, RoHS) and features a self-extinguishing housing.
User questions about Quicklux-3F Vemer
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Switch in PDF format for free! Find your manual Quicklux-3F - Vemer and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. Quicklux-3F by Vemer.
USER MANUAL Quicklux-3F Vemer
Close-up of hands using a tool to adjust or install a component (no visible text or symbols)
