| Product Type | Microwave Oven |
| Brand | MPM |
| Model | 20-KMG-03 |
| Capacity | 20 liters (estimated) |
| Power Output | 700 W (estimated) |
| Power Supply | 230 V ~ 50 Hz |
| Power Cord Length | 0.88 m |
| Control Type | Knob and button |
| Display | LED digital display |
| Turntable | Glass turntable, motorized |
| Number of Power Levels | 5 (20%, 40%, 60%, 80%, 100%) |
| Maximum Cooking Time | 60 minutes |
| Defrost Function | By weight (0.1 - 2.0 kg) |
| Auto Cooking Menus | 8 (Popcorn, Potato, Vegetable, Meat, Fish, Reheat, Beverage, Rice) |
| Cavity Material | Stainless steel (estimated) |
| Door Type | Drop-down with viewing window |
| Safety Features | Door interlock, overheat protection |
| Cleaning Method | Wipe with damp cloth; mild soap for turntable and ring |
| Installation Clearances | Back: 10 cm, Sides: 5 cm, Top: 20 cm, Above ground: 85 cm |
| Dimensions (W x D x H) | Approx. 45 x 35 x 25 cm (estimated) |
| Weight | Approx. 10 kg (estimated) |
Frequently Asked Questions - 20-KMG-03 MPM
User questions about 20-KMG-03 MPM
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Microwave in PDF format for free! Find your manual 20-KMG-03 - MPM and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. 20-KMG-03 by MPM.
USER MANUAL 20-KMG-03 MPM
Pokrywa
magnetronu
(UWAGA! Nie wolno
zdejmować pokry-
wy magnetronu!)
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
The following basic precautions should always be followed when using electrical appliance:
Make sure the voltage in your living area corresponding to the one shown on the rating label of the appliance. And the wall socket is properly grounded.
To reduce the risk of fire in the oven cavity:
a. Do not overcook the food.
b. Remove wire twist -ties from paper or plastic bags before placing bags in the oven.
c. Do not heat oil or fat for deep drying as the temperature of oil cannot be controlled.
d. After use wipe the waveguide cover with a damp cloth, followed by dry cloth to remove any food splashes and grease. Built-up grease may overheat and begin to cause smoke or catch fire.
e. If materials inside the oven should smoke or ignite, keep oven door closed, turn oven off and disconnect the power supply.
f. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition
To reduce the risk of explosion and sudden boiling:
a. WARNING: Liquids and other foods must not be heated in sealed container since they are liable to explode; Baby bottles fitted with a screw cap or teat are considered to be sealed containers.
b. Use the wide -mouthed container to cook liquid, and the cooked liquid should not be removed out immediately. Several moments should be waited before removing. In order to avoid possible hazards caused by delayed eruptive boiling of liquids.
c. Potatoes, sausage and chestnut should be peeled or pierced before cooking. Eggs in their shell, whole hard -boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
d. The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to be checked before consumption, in order to avoid burns.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a qualified technician in order to avoid a shock hazard.
After cooking, the container is very hot. Using gloves to take out the food and avoid steam burns by directing steam away from the face and hands.
- Slowly lift the furthest edge of dishes cover and microwave plastic wrap and carefully open popcorn and oven cooking bags away from the face.
To prevent the turntable from breaking:
a. Let the turntable cool down before cleaning.
b. Do not place hot foods or utensils on the cold turntable.
c. Do not place frozen foods or utensils on the hot turntable.
Make sure the utensils do not touch the interior walls during cooking.
Only use utensils that are suitable for use in microwave ovens.
Do not store food or any other things inside the oven.
Do not operate the oven without any liquid or food inside the oven. This would do damage the oven.
WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated.
- Any accessories not recommended by the manufacturer may cause injuries to persons.
Do not use outdoors.
Save these instructions. The microwave oven must not be placed in a cabinet.
WARNING: If the door or door seals are damaged or the oven is malfunctioned, the oven must not be operated until it has been repaired by a competent person;
WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames;
Microwave heating of beverages can result in delayed eruptive boiling; therefore care must be taken when handling the container;
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
The lamp of microwave oven is not intended for other purposes.
The appliances are not intended to be operated by means of an external timer or separate remote -control system.
This appliance is intended to be used in household and similar applications, such as:
- Staff kitchen areas in shops, offices and other working environments;
- Farm houses;
- By clients in hotels, motels and other residential environments;
- Bed and breakfast type environments.
The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire. It is not intended for industrial use of laboratory.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised. Keep the appliance and its cord out of reach of children less than 8 years.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
A steam cleaner is not to be used.
The door or the outer surface may get hot when the appliance is operating.
WARNING: Accessible parts may become hot during use. Young children should be kept away.
WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.
During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven.
The surfaces are liable to get hot during use.
Do not block the ventilation openings on the microwave oven.
The minimum height of free space necessary above the top surface of the oven.
CAUTION: HOT SURFACE
Household use only
- Never place the appliance near other electrical appliances, burners, cookers, ovens, etc.
Always make sure that all parts of the appliance have been properly attached before turning on the power.
Do not operate the oven with the door open
The oven should be cleaned regularly and any food deposits removed.
Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
Do not plug the power cord with wet hands. - Do not hang the cord on any sharp edges and prevent any contact with hot surfaces.
Do not remove the plug from the mains by pulling by the cord.
In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.
WARNING! Do not allow small children to play with the foil as there is a danger of suffocation!
INSTALLATION
- Take out all the packing. If there is a safe film over the oven, tear it off before Use. Check carefully for damage. If any, immediately notify dealer or send to the manufacturer's service center.
- Microwave ovens must be placed under dry and non-corrosiveness environments, kept away from heat and humidity, such as gas burner or water tank. Place the appliance on a flat, stable and level surface. Place the oven on a flat, dry, stable and heat-resistant surface.
- To ensure sufficient ventilation, the distance of the back of microwave to the wall should be at least 10 cm, the side to the wall should be at least 5 cm, the free distance above the top surface at least 20 cm. the distance of the microwave to the ground should be at least 85 cm.
- The position of the oven shall be such that it is far from the TV, Radio or antenna as picture disturbance. The distance should be more than 5m.
- The appliance must be positioned so that the plug is accessible, and must ensure a good grounding in case leakage, ground loop can be formed to avoid electric shock.
- The microwave oven must be operated with the door closed.
- The microwave oven must not be placed in a cabinet. The microwave oven is intended to be used freestanding.
- As there is manufacturing residue or oil remained on the oven cavity or heat element, it usually would smell the odor, even a slight smoke, It is normal case and would not occur after several times use, keep the door or window open to ensure good ventilation. So it is strongly recommended to place a cup of water in the turntable, setting at high power and operate for several times.
CLEANING
MICROWAVE OVEN CARE
CAUTION
The oven should be cleaned regularly and any food deposits removed.
WARNING
- Remove the power cord from the wall outlet before cleaning. Don't immerse the appliance in water or other fluids when cleaning.
- Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
- Never use hard detergent, gasoline, abrasive powder or metal brush to clean any part of the appliance.
- Do not remove the waveguide cover.
- When the microwave oven has been used for a long time, there may be some strange odors exist in oven, Following 3 methods can get rid of them:
a. Place several lemon slices in a cup, then heat with high Micro Power for 2-3 min.
b. Place a cup of red tea in oven, then heat with high micro power.
c. Put some orange peel into oven, and then heat them with high Micro Power for 1 minute.
TIPS FOR CLEANING
Details for cleaning door seals, cavity and adjacent parts:
Exterior:
Wipe the enclosure with a dampened soft cloth
Door:
Using a dampened soft cloth, wipe clean the door and window
Wipe the door seals and adjacent parts to remove any spill or spatter
Wipe the control panel with a slightly dampened soft cloth
Interior walls:
Wipe clean the cavity with a dampened soft cloth
Wipe clean the waveguide cover to remove any food splashed
Turntable/ Rotation ring/ Rotation axis:
Wash with mild soap water
Rinse with clean water and allow drying thoroughly
PRODUCT INSTRUCTION
Waveguide Cover (WARNING! Never remove the waveguide cover)
1. Door lock
Microwave oven door must be properly closed in order for it to operate
2. Viewing window
Allow user to see the cooking status
3. Rotating axis
The glass turntable sits on the axis; the motor underneath it drives the turntable to rotate
4. Rotating ring
The glass turntable sits on its wheels; it supports the turntable and helps it to balance when rotating
5. Turntable
The food sits on the turntable, its rotation during operation helps to cook food evenly
CAUTION
- Place the rotating ring first
- Fit the turntable onto the rotating axis and make sure that it is geared in properly
6. Control panel
See below in details (the control panel is subject to change without prior notice)
7. Waveguide cover
It is inside the microwave oven, next to the wall of control panel.
WARNING
Never remove the waveguide cover
- Menu selector – To select the desired cooking menu
- Turn the knob to set cooking time or weight
- After setting menu and time, press it to start. During cooking, press it to stop cooking, press twice to start again
- LED display - displays the time programmed / declared / remaining to the end of the process, the declared weight of products and selected cooking menu
Switching the Menu Selector knob (1) to Defrost facilitates the input of a defrosted product weight instead of the time (2).
BEFORE COOKING
The LED flashes 3 times when plugged in power supply. Then it shows "0:00", prompting you to input cooking menu and time. During setting the cooking process, it will return to standby state or clock state automatically if it is suspended and not entered cooking menu in 2 minutes.
SYGNAŁ PRZYPOMNIENIA
When your preset cooking procedure have finished, the LED Display will show End and three beeps sound will be heard to prompt you to take out food. If you do not turn Menu Selector or not open the door, the beep will be sounded at an interval of 3 minutes.
MICROWAVE COOKING
This function is used for cooking and heating food. There are five selections for microwave cooking by turning the Menu Selector.
| High power (100P) 100% microwave power. Applicable for quick and thorough cooking | |
| MediumHigh power (80P) | 80% microwave power. Applicable for medium express cooking |
| Medium power (60P) 60% microwave power. Applicable for steaming food | |
| MediumLow power (40P) | 40% microwave power. Applicable for defrosting food |
| Low power (20P) 20% microwave power. Applicable for keeping warm | |
CAUTION
a. The max time which can be set is 60 minutes.
b. Never operate the oven empty.
c. At the maximum microwave power, the oven will automatically lower the power after a certain time of cooking to lengthen the service life.
| Example: To cook at Medium Power for 10 minutes. | ||
| Steps Display | ||
| 1Power-up the oven 0:00 | ||
| 2 | Select the desired microwave power by turning Menu Selector to Med | 60P |
| 3 | Set cooking time by turning Time. Weight knob | 10:00 |
| 4 | Press Start button and LED will count down to show running time. | |
DEFROST
This function is used for defrosting food, turning the Menu Selector to Defrost is available to carry out this function. The weight range to defrost is 0.1 kg\~2.0 kg. Each declared weight of products corresponds to the factory programmed time.
| Example: To defrost 0.4kg poultry | ||
| Steps Display | ||
| 1Power-up the oven 0:00 | ||
| 2 | Turn Menu Selector to Defrost | dEF |
| 3 | Turn Time. Weight knob to set the defrost weight | 0.4 |
| 4 | UStart cooking by pressing Start button | 5:16 |
| 5 | In half way during defrosting beep sounds will be heard to prompt you turn over the food. Open the door and turn over the food. Then close the door. Press Start button again to continue defrosting. | |
CAUTION
a. It is necessary to turn over the food during operation to obtain uniform effect.
b. Usually defrosting will need longer time than that of cooking the food.
c. If the food can be cut by knife, the defrosting process can be considered completed.
d. Microwave penetrates around 4cm into most food
e. Defrosted food should be consumed as soon as possible, it is not advised to put back to fridge and freeze again.
AUTO COOKING
The oven has default cooking menu for simple operation. When the oven is in standby state, turn the Menu Selector to Auto cooking, and then turn Time.Weight knob can select auto cooking menu.
Choose the appropriate menu according to the food type and weight and strictly observe the directions in below table, otherwise the cooking effect will be largely influenced. Each item on the menu corresponds to the pre-programmed time.
| Display Kind Method | ||
| A.1 | Popcorn | Suitable for popping a bag of corn, which is available in the market, weighted 3.50z. |
| A.2 | Potato | Cooking the potato strips, cut into 5mm width and height, length. Total weight is about 0.45kg. Place the strips on a large dish and cover the dish with a thin film to prevent water loss |
| A.3 | Vegetable | Place 0.3kg vegetable in a microwave-safe bowl. Add water. Cover with wrap, After cooking, stir and allow standing. Add water amount according to the vegetable quantity. |
| A.4 | Meat | Cut the meat (0.3kg) into small pieces, then place on a dish, add desired flavoring and stir it |
| A.5Fish | Suitable for steaming a fish of 0.5kg. After the fish washed and scales removed, make a slits on the skin of fish .Put the fish on a shallow dish of 22-27cm diameter sprinkle lightly with some ingredient and cover the dish with a thin film to prevent water loss. After cooking, stand for 2 minutes. | |
| A.6 | Reheat | Let you reheat a dinner plate of chilled leftovers about 0.5kg with good results |
| A.7Beverage | Heating a cup of 250 ml liquid. The liquid temperature is about 5–10°C. Use a big mouth cup and do not seali. | |
| A.8Rice | Wash rice (0.3kg) and soak for 30 minutes Place rice in a deep and large bowl. After cooking, stand cover for 5 minutes or until water is absorbed. | |
CAUTION
a. The temperature of food before cooking would be 20–25°C. Higher or lower temperature of the food before cooking would require increase or decrease of cooking time.
b. The temperature, weight and shape of food will largely influence the cooking effect. If any deviation has been found to the factor noted on above menu, you can adjust the cooking time for best result.
| Example: Steam 0.5kg fish | ||
| Steps Display | ||
| 1 Power up the oven 0:00 | ||
| 2 | Turn Menu Selector to Auto cooking | A.1 |
| 3 | Turn Time. Weight to select auto cooking menu | A.5 |
| 4 | Start cooking by pressing Start button | 11:00 |
UTENSILS GUIDELINE
It is strongly recommended to use the containers which are suitable and safe for microwave cooking. Generally speaking, the containers which are made of heat-resistant ceramic, glass or plastic are suitable for microwave cooking. Never use the metal containers for microwave cooking and combination cooking as spark is likely to occur. You can take the reference of below table.
| Material of container | Microwave Notes | |
| Heat-resistant ceramic | Yes | Never use the ceramics which are decorated with metal rim or glazed |
| Heat-resistant plastic | Yes | Can not be used for long time microwave cooking |
| Heat-resistant glass | Yes | |
| Plastic film | Yes | It should not be used when cooking meat or chops as the over-temperature may do damage to the film |
| Grill rack No | ||
| Metal container No | It should not be used in microwave oven. Microwave can not penetrate through metal | |
| lacquer No Poor heat-resistant. Can not be used for high-temperature cooking | ||
| Bamboo wood and paper | No Poor heat-resistant. Can not be used for high-temperature cooking | |
COOKING TIPS
The following factors may affect the cooking result:
Food arrangement
Place thicker areas towards outside of dish, the thinner part towards the centre and spread it evenly. Do not overlap if possible.
Cooking time length
Start cooking with a short time setting, evaluate it after it times out and extend it according to the actual need. Over cooking may result in smoke and burns.
Cooking food evenly
Food such as chicken, hamburger or steak should be turned once during cooking.
Depending on the type of food, if applicable, stir it from outside to centre of dish once or twice during cooking.
Allow standing time
After cooking times out, leave the food in the oven for an adequate length of time, this allows it to complete its cooking cycle and cooling it down in a gradual manner.
Whether the food is done
Color and hardness of food help to determine if it is done, these include:
- Steam coming out from all parts of food, not just the edge
– Joints of poultry can be moved easily
– Pork or poultry shows no signs of blood
– Fish is opaque and can be sliced easily with a fork
Browning dish
When using a browning dish or self-heating container, always place a heat-resistant insulator such as a porcelain plate under it to prevent damage to the turntable and rotating ring.
Microwave safe plastic wrap
When cooking food with high fat content, do not allow the plastic wrap come into contact with food as it may melt
Microwave safe plastic cookware
Some microwave safe plastic cookware might not be suitable for cooking foods with high fat and sugar content. Also, the preheating time specified in the dish instruction manual must not be exceeded.
MAINTENANCE
SERVICING
Please check the following before calling for services.
- Place one cup of water (approx. 150ml) in a glass measure in the oven and close the door securely. Oven lamp should go off if the door is closed properly. Let the oven work for 1 min.
-
Does the oven lamp light?
-
Does the cooling fan work?
(Put your hand over the rear ventilation openings.)
- Does the turntable rotate?
(The turntable can rotate clockwise or counter clockwise. This is quite normal.)
- Is the water inside the oven hot?
If "NO" is the answer to any of the above questions, please check your wall socket and the fuse in your meter box.
If both the wall socket and the fuse are functioning properly, CONTACT YOUR NEAREST SERVICE CENTER APPROVED.
SERVICING SAFEGUARDS
Caution: MICROWAVE RADIATION
- The high voltage capacitor remains charge after disconnection; short the negative terminal of H. V capacitor to the oven chassis (use a screwdriver) to discharge before touching.
- During servicing below listed parts are liable to be removed and give access to potentials above 250V to earth.
- Magnetron
– High voltage transformer
– High voltage capacitor
– High voltage diode
– High voltage fuse
-
The following conditions may cause undue microwave exposure during servicing
-
Improper fitting of magnetron;
- Improper matching of door interlock, door hinge and door;
– Improper fitting of switch support; - Door, door seal or enclosure has been damaged.
The technical parameters are given on the data plate of the product.
Power cord lenght: 0,88 m
NOTE! MPM agd S.A. reserves its right to modify the technical data.
PROPER DISPOSAL OF THE PRODUCT (waste electrical and electronic equipment)
This symbol on the product indicates that the product, after its lifetime, should not be disposed with other household wastes. To avoid harmful influence on the environment and human health due to uncontrolled waste disposal, dispose the waste device to the service point of waste household appliances or report collecting it from home. In order to obtain detailed information about the location and how to dispose the waste electrical and electronic equipment in a safe way, contact your retailer or local Department of
Environmental Protection. Do not dispose the device with other municipal waste.
МЕРЫ БЕЗОПАСНОСТИ
We wish you satisfaction from using the product and invite you to check a wide range of other MPM appliances
- KUCHENKA MIKROFALOWA MPM-20-KMG-03
- READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
- WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated.
- WARNING: If the door or door seals are damaged or the oven is malfunctioned, the oven must not be operated until it has been repaired by a competent person;
- WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
- WARNING: Accessible parts may become hot during use. Young children should be kept away.
- WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.
- CAUTION: HOT SURFACE
- Household use only
- INSTALLATION
- CLEANING
- MICROWAVE OVEN CARE
- CAUTION
- WARNING
- TIPS FOR CLEANING
- Exterior:
- Door:
- Interior walls:
- Turntable/ Rotation ring/ Rotation axis:
- PRODUCT INSTRUCTION
- Door lock
- Viewing window
- Rotating axis
- Rotating ring
- Turntable
- Control panel
- Waveguide cover
- BEFORE COOKING
- SYGNAŁ PRZYPOMNIENIA
- MICROWAVE COOKING
- DEFROST
- AUTO COOKING
- UTENSILS GUIDELINE
- COOKING TIPS
- Food arrangement
- Cooking time length
- Cooking food evenly
- Allow standing time
- Whether the food is done
- Browning dish
- Microwave safe plastic wrap
- Microwave safe plastic cookware
- MAINTENANCE
- SERVICING
- SERVICING SAFEGUARDS
- Caution: MICROWAVE RADIATION
- PROPER DISPOSAL OF THE PRODUCT (waste electrical and electronic equipment)
- МЕРЫ БЕЗОПАСНОСТИ
Brand : MPM
Model : 20-KMG-03
Category : Microwave
