My Dino KW-33 - Smartwatch Canyon - Free user manual and instructions

Product Type	Smartwatch
Brand	Canyon
Model	My Dino KW-33
Target User	Children of junior school age
Display	1.3-inch IPS touch screen, 240x240 resolution
Case Material	Plastic
Strap Material	Silicone
Dimensions	41.2 x 35.2 x 9.3 mm
Wristband Width	20 mm
Weight	45 g
Water Resistance	IP68 (submersible up to 1.5m for 30 min)
Battery Capacity	155 mAh
Standby Time	Up to 10 days
Active Use Time	Up to 4 days
Bluetooth	5.0
Compatible OS	iOS 8.0+ and Android 6.0+
Sensors	Heart rate monitor, accelerometer, pedometer
Key Features	Virtual friend Dino, educational games, notifications, music/camera control, sleep monitor, sedentary reminder, alarm clock, weather forecast, multisport tracking
App	Canyon Life App (for activity tracking and device management)
Maintenance	Clean with a soft, damp cloth. Avoid harsh chemicals.
Replacement Parts	Replacement wristbands available from manufacturer.
Safety Notes	Not suitable for children under 3 years due to small parts. Adult supervision recommended during charging.

Frequently Asked Questions - My Dino KW-33 Canyon

How do I charge the My Dino KW-33 smartwatch?

Use the included magnetic charging cable. Connect the puck to the watch's back and plug the USB end into a power adapter or computer. Charge fully before first use.

Is the watch waterproof?

Yes, it has an IP68 rating, meaning it can be submerged in up to 1.5 meters of water for 30 minutes. Not suitable for swimming or diving.

How do I pair the watch with my smartphone?

Download the Canyon Life app from the App Store or Google Play. Turn on Bluetooth on your phone, open the app, and follow the on-screen instructions to pair the watch.

How does the Dino virtual friend work?

Your child earns apples by being active (walking, running, exercising). These apples are used to feed the virtual dinosaur Dino inside the watch. It encourages regular physical activity.

Can I receive calls and messages on the watch?

Yes, the watch displays notifications for incoming calls, messages, and social media alerts. It vibrates to alert the user. You cannot answer calls directly on the watch.

What educational games are included?

The watch features two brain-training games: a puzzle game and a math game. These help develop cognitive skills in a fun way.

How long does the battery last?

Battery life is up to 10 days on standby and up to 4 days with active use (including workouts and notifications). Actual duration depends on usage.

How do I change the language on the watch?

Go to the settings menu on the watch, find the language option, and select your preferred language from the list. The watch supports multiple languages.

Does the watch have built-in GPS?

No, the My Dino KW-33 does not have built-in GPS. However, when connected to the Canyon Life app, your phone's GPS can be used to track outdoor routes.

How should I clean and maintain the watch?

Clean the watch and strap with a soft, damp cloth. Avoid using soap, alcohol, or abrasive cleaners. Dry thoroughly before charging. Store in a cool, dry place.

USER MANUAL My Dino KW-33 Canyon

SMARTWATCH My Dino KW-33

Modern smartwatch with camouflage pattern and a dinosaur graphic on screen (no readable text or symbols)

My Dino KW-33

My Dino Smartwatch

This smart and useful gadget is suitable for children of junior school age. The Interface of the watch is made by Canyon designers in a childish "hip-hop" style. Inside the watch, a cute dinosaur Dino lives. Let Dino be your kid's virtual friend in the world of health and sports. Your child can earn apples and feed them to Dino by doing workouts, walking or just not sitting still. Precise measurements of your child's activity will be provided by the watche's pedometer, heart rate monitor and other functions of a full-scale fitness gadget. The watch has two built in brain-training educational games - "puzzle" and "math". In addition, the watch can show notifications from social networks and messengers, vibrate on incoming calls, display the weather and allow your kid to switch music tracks and camera shutter on a smartphone.

Let your child take care of Dino by exercising and achieving great results in real life!

Move Collect apples Feed Dino Dino is happy

Two smartwatches, one green with camouflage and one blue with white and black designs, displayed against a yellow and black background (no text or symbols on the devices themselves)

CNE-KW33BB black camouflage EAN : 5291485007737

CNE-KW33GB green camouflage EAN : 5291485007744

CNE-KW33BL blue camouflage EAN : 5291485007751

Smartwatch with digital clock display showing 12:00 AM, 12:00 PM, and 10:00 PM (no readable text or symbols beyond clock face)

KEY FEATURES

Fits to children of junior school age
Full touchscreen
Light weight
iOS and Android application
Built-in virtual friend Dino
• Two brain-training games
Multisport

Heart rate monitor and pedometer
Sedentary reminder
Sleep monitor
Notifications and calls
Music and camera control
4-10 days of work

Alarm clock

Sleep monitoring

Sedentary reminder

Multilingual

Interactive interface, games

Water drinking reminder

Multisport Remote music and camera control

c and mera control

Activity statistics

Notifications on messages and calls

Weather forecast

Pedometer

Alarm clock

Sedentary reminder

Multilingual

Materials and dimensions

Materials: plastic case, silicone wristband

Dimensions: 41.2mm x 35.2mm x 9.3mm

Wristband width: 20mm

Screen size: 1.3"

Water resistance: IP68

Weight: 45 gr.

Technical specifications

IPS touch screen

Screen resolution: 240x240

Battery capacity: 155mAh

Chipset: PAR2860QN

32KB RAM 512KB ROM

Bluetooth: BT5.0

Standby time: up to 10 days

Active work: up to 4 days

Supports iOS 8.0+ Android 6.0+

Data transmission power <20mW

Sports

Sensors

Walking

Heart rate monitor

Jogging

Accelerometer

Hiking

Cycling

Two smartwatches with camouflage patterns and digital clock displays, one displaying a dinosaur and the other showing a red-and-white graphic (no readable text or symbols)

Advantages of Canyon Life App

Stable work with no lags Correct multilingual adaptations to

14 languages

Instant detection and connection to your watch

Compliance with the EU General Regulation of Data Protection, Storing and Processing (GDPR)

Messaging, calls and social notifications. Sports activity status.

Clearly understandable stats tracked per each workout and per day

All your watches and watches of your kids can be connected to one application

Track your route during sports activities and monitor your kids' location

*for watches with GPS function
