T50RPmk3 - Headphones FOSTEX - Free user manual and instructions

Product Type	Semi-open RP Dynamic headphones
Brand	Fostex
Model	T50RPmk3
Driver Technology	RP Diaphragm (copper foil etched polyimide film)
Magnet Type	Neodymium
Frequency Response	15 Hz – 35 kHz
Impedance	50 Ω
Sensitivity	92 dB/mW
Maximum Input Power	3000 mW
Weight (without cable)	315 g
Cable Length	6.3 mm × 3 m, 3.5 mm × 1.2 m
Cord Type	Detachable, lockable plug (rotate 90° to lock)
Ear Pad Material	Low rebound high-grade
Enclosure Type	Semi-open
Intended Use	Studio, personal to professional workstations
Safety Warnings	Avoid extended high volume; do not use while driving or cycling
Maintenance	Wipe plug with dry cloth if noise occurs

Frequently Asked Questions - T50RPmk3 FOSTEX

Do Fostex headphones work well?

Despite the excellent build quality and high-grade materials, these are performance-oriented headphones, not luxury goods. They are built to last and popular among professionals.

Does Fostex still operate?

Yes, Fostex primarily operates as a recording company and offers a variety of products including mixers, recorders, cables, and patch bays.

Are these headphones comfortable?

Yes, the headphones feature low rebound high-grade ear pads for increased comfort during extended use.

Are these headphones suitable for video calling?

Yes, they are suitable for video calling and can be used for Zoom calls and meetings.

How do dome type drivers work?

Dome structures directly emit sound with excellent directionality. They are frequently used for mid- and high-frequency reproduction.

Which bass driver is the best?

Dynamic drivers (voice coil, diaphragm, magnet) are common and produce quality audio, especially bass. The T50RPmk3 uses a RP diaphragm for high power handling.

Does a larger driver imply improved bass?

Generally, larger drivers produce better bass, but driver design and tuning also matter. The T50RPmk3 has a 50mm driver.

Do 50mm drivers work well?

The ideal driver size depends on design. 50mm is on the larger side for headphones, allowing louder sound waves, especially in bass and sub-bass.

Does a larger driver imply better audio?

Greater driver diameter typically improves sound quality. The T50RPmk3's 50mm driver contributes to its high-quality audio.

What is the maximum input power?

The T50RPmk3 can handle up to 3000 mW input power, thanks to its RP diaphragm technology.

USER MANUAL T50RPmk3 FOSTEX

Black T50RP headphones with red cable, no visible text or symbols on the device body

Wstep

• TYP: Półotwarta gra RPG Dynamiczna
- ODPOWIEDŹ CZĘSTOTLIWOŚCI: 15 Hz \~ 35 kHz
• IMPEDANCJA: 50 Ω
• CZUŁOŚĆ: 92 dB/mW
- MAKSYMALNA MOC WEJŚCIOWA: 3000 mW
• WAGA: 315 g (bez sznurka)
• DŁUGOŚĆ PRZEWODU: Φ6,3×3 m, Φ3,5×1,2 m

Mechanical diagram showing a mechanical assembly with a rotating component and directional arrow (no text or symbols)

Schemat połączeń

• Do Fostex headphones work well?

Despite the expensive price, these are not to be regarded as luxury goods despite the excellent build quality. The materials utilised are of a high caliber since the construction quality is performance oriented. Fostex wants you to own these headphones for a very long time, especially given how well-liked they are among professionals.

- Does Fostex still operate?

Despite being primarily a recording firm, Fostex has persevered through the years by offering a wide variety of related goods to its distributors and clients, including analogue and digital mixers, analogue and digital effects, CD-R/RW recorders, cables, and patch bays.

• Are these headphones comfortable?

Yes, these are very comfortable.

- Are these headphones suitable for video calling?

YES

• Can you use these headphones for Zoom calls?

Yes, these can easily be used for the zoom calls and meetings.

• How do dome type drivers work?

Dome structures directly emit sound. This sort of driver has the benefit of having excellent directionality. It is frequently used for replication of mid- and high-frequency sounds.

• Which bass driver is the best?

These are respectable driver units that are conveniently accessible and generate quality audio, particularly bass. They are fairly widespread, and the majority of headphones include them. A voice coil, a diaphragm, and a magnet are the three primary parts of a dynamic driver.

- Does a larger driver imply improved bass?

Size of Driver Effect on Audio Quality Simply said, better bass is produced with bigger drivers.

• Do 50mm drivers work well?

The design of the specific headphones will determine the ideal driver size. Headphone drivers normally range in diameter from 20mm to 50mm, whilst earphone drivers are typically 8mm to 15mm. Although a bigger driver creates louder sound waves (especially in the bass and sub-bass), this does not always imply that they sound better.

- Does a larger driver imply better audio?

Driver Diameter – The size of the diaphragm of a headphone greatly affects the sound quality; the greater the driver diameter, the better the sound quality typically is. The majority of earbud

drivers have a diameter of 13.5–15.4 mm, whereas canal phone drivers have a diameter of 8.8–12.5 mm.

• Better speaker drivers are they bigger?

Large speakers provide less strained audio. Large speakers actually offer complete sound, whilst small speakers only give the impression of it. The audio has a rich, organic, and genuine sound. Hearing music with loud speakers also improves the sound quality.

T20RPmk3 / T40RPmk3 / T50RPmk3 Owner's Manual

POSTEX RP TECHNOLOGY

Thank you for purchasing the Fostax product. We hope you will read through this manual so that you can correctly use it.

Outstanding features:

1. The T-RP series headphones feature a "RP Diaphragm" employing copper foil etched polyimide film to provide resistance to high level input peaks of up to 3000mW and a neodymium magnet for excellent transient characteristics.
2. The T-RP series are designed for studio applications. It can be widely used from a personal studio to professional work shops.
3. A detachable type headphone cord is connected to the left side housing making it difficult to tangle and easy to use and replace.
4. Low rebound high-grade ear pads are used for increased comfort during extended use.
5. As you wish to choose depending on the intended use, we offer 3 models with different shielding properties, i.e. open type (T20RPmk3), closed type (T40RPmk3) and semi-open type (T50RPmk3).

Method of installing the head- phone cord Insert the plug point into the headphone jack as shown in the figure. Then, rotate the plug by 90 degrees in direction of arrow to lock it finally.

Simple line drawing of a mechanical device with a curved arrow indicating rotation (no text or symbols)

Connecting diagram

Specifications

Model No.	T20RPmk3	T40RPmk3	TS0RPmk3
Type	Open RP Dynamic	Close RP Dynamic	Bemi-open RP Dynamic
Freq. response	15 Hz ~ 35 kHz	20 Hz ~ 35 kHz	15 Hz ~ 35 kHz
Impedance	50 Ω	50 Ω	50 Ω
Sensitivity	92 dB/mW	91 dB/mW	92 dB/mW
Maximum input	3,000 mW	3,000 mW	3,000 mW
Weight	316 g (Excl. Cord)	315 g (Excl. Cord)	315 g (Excl. Cord)
Cord length	6.3x3 m 3.5x1.2 m	6.3x3 m 3.5x1.2 m	6.3x3 m 3.5x1.2 m

* Design and specifications are subject to change without notice.
* Avoid an extended use at high volume levels as your hearing may be permanently impaired. You are advised never to use headphones in such situations as driving vehicle and cycling as your ability to react to emergencies will be considerably reduced.
* On rare occasions, noise may occur when the headphone plug is connected and turned 90 degrees to lock it. Unless noise is heard with the plug in the locked position, it is not a problem. However, if noise or uneven reproduction volume occurs, there is a possibility that the headphone plug has become dirty. In such a case, wipe the plug with a dry cloth.

Fostex

POSTEX COMPANY

1-1-102, Tautsugapoka, Akshima City, Tokyo, 196-8550, Japan

PRINTED IN CHINA JUL 2018 812549 (5555146100)
