Product Type	Two-stage snow blower
Engine Displacement	113 cc
Clearing Width	24 inches (61 cm)
Intake Height	20 inches (51 cm)
Weight	Approx. 145 lbs (66 kg)
Fuel Type	Unleaded gasoline
Starting System	Electric start with recoil backup
Drive System	Belt-driven auger and impeller; wheel drive with differential lock
Chute Control	Remote chute rotation and deflector adjustment
Lights	Integrated LED headlight
Heated Handles	No
Wheel Type	Pneumatic tires with tread
Safety Key	Yes, for ignition
Maintenance Interval	Check belt tension and shear pins; change oil annually
Warranty	2-year limited warranty

Frequently Asked Questions - 1132 STIGA

What type of fuel should I use for the Stiga 1132 snow blower?

Use clean, unleaded gasoline with an octane rating of 87 or higher. Do not use ethanol blends above 10% (E10).

How do I start the engine?

Ensure the safety key is inserted. Set the choke to 'full' for a cold start, then press the primer bulb 3 times. Turn the ignition key to start (electric) or pull the recoil starter rope firmly. After starting, gradually move the choke to 'run'.

The auger does not turn. What should I check?

First, check the shear pins on the auger. If they are broken, replace them. Also inspect the drive belt tension; if loose, adjust the tension roller as described in the manual (3-4 mm clearance).

How do I adjust the chute direction?

Rotate the chute control lever (usually located on the handlebar) to change the chute direction left or right. For up/down deflection, adjust the deflector manually using the wing nut.

What is the differential lock for?

The differential lock improves traction in deep snow or slippery conditions by locking both wheels together. Engage it only when needed, as it reduces steering ability.

How do I maintain the drive belt?

Inspect the belt periodically for wear. Adjust the tension roller to maintain 3-4 mm clearance between the belt and the tension roller. Replace the belt if it shows signs of cracking or glazing.

Can I use the snow blower on gravel surfaces?

Yes, but adjust the skid shoes to raise the scraper blade slightly to avoid picking up gravel. The default setting is for paved surfaces.

Why does the engine stall when clearing heavy snow?

If the engine stalls, reduce the forward speed or take smaller cuts. Also ensure the shear pins are intact; if broken, the auger won't spin and the engine may stall. Check the fuel valve and choke settings.

How do I change the oil?

Run the engine to warm the oil, then turn it off and disconnect the spark plug. Drain the old oil through the dipstick tube or drain plug. Refill with the recommended SAE 5W-30 oil to the correct level. Check the manual for capacity (likely 0.4-0.5 liters).

Where can I find replacement parts?

Replacement parts such as shear pins, belts, and spark plugs are available at authorized Stiga dealers or online. Use only genuine Stiga parts for safety and performance.

USER MANUAL 1132 STIGA

Black-and-white photo of a person in a wheelchair with a bicycle, no visible text or symbols

Black-and-white photo of a vintage-style off-road vehicle with wheels and a small boat, no visible text or symbols.

Modell 1132

Black-and-white photo of a person operating a snowman in a snowy landscape (no visible text or symbols)

Close-up of a dark, textured object with no visible text or symbols

Modell 825T

Black-and-white photo of a mechanical assembly or robotic arm (no visible text or symbols)

Diagram showing a person operating a vehicle with directional arrows indicating movement (no text or symbols present)

Modell 828,1132

STALL IN SNOUTKASTET

DIFFERENTIALSPÄRR (modell 521, 825, 828,

Microscopic view of a biological cell with visible nucleus and cytoplasm (no text or labels)

Microscopic view of a circular biological structure with chains and granular texture (no visible text or symbols)

Black-and-white photo of a person in motion with abstract patterns and no visible text or symbols

1. Justera in spännrullen 3--4 mm mot remmen.
2. Drag åt spännrullen.
3. Skruva fast remskyddet.

8

Black-and-white photo of a vehicle with visible suspension and tracks, no text or symbols present

Modell 521,825,825T

Black-and-white architectural sketch of a building interior with stairs and structural elements (no visible text or symbols)

Modell 828,1132
