Infra - Massage device OBH NORDICA - Free user manual and instructions

Product Type	Massage device
Brand	OBH Nordica
Model	Infra (6035)
Voltage	230 V ~
Infrared Lights	9
Settings	Massage (M), Infrared heat (V), Combined (VM)
Maximum Usage Time	20 minutes (then 20-minute break required)
Heating Time	8–10 minutes
Handle Adjustment	4 angles (press button in center of handle to adjust)
Attachments Included	Scalp massager, Two-point massager, Zone massager, Joint massager
Attachment Attachment Method	Push on and pull off
Cleaning Method	Wipe with damp cloth; attachments can be cleaned with water and detergent (do not immerse appliance)
Safety Features	Do not use in bath/shower; caution for persons with reduced sensitivity; automatic break after 20 min
Warranty	Valid according to current law with purchase receipt
Disposal	Must be collected separately for recycling (WEEE)
Intended Use	Domestic only (not professional or medical)
Country of Origin	Denmark (OBH Nordica Denmark A/S)

Frequently Asked Questions - Infra OBH NORDICA

What are the different settings on the OBH Nordica Infra massage device?

The device has three settings: M (massage only), V (infrared heat only), and VM (combined massage and infrared heat).

How long does it take for the infrared heat to warm up?

When the switch is in position V or VM, the appliance needs 8–10 minutes to reach the desired temperature.

Can I use the massager in the bath or shower?

No, never use the massage apparatus in the bathtub, in the shower, or over a sink containing water. It is not waterproof.

How do I clean the massager and attachments?

Wipe the massager with a damp cloth. The attachments can be cleaned in water with some detergent. Never submerge the massager in water or any other liquid.

What are the four attachments and what are they used for?

The attachments are: Scalp massager (for scalp and neck), Two-point massager (deep massage for small areas like hands and feet), Zone massager (gentle vibrating waves for legs, hip, back), and Joint massager (for all over body).

How do I adjust the handle angle?

Press the circular button in the middle of the handle, hold it while adjusting the angle, then release the button to lock the desired position.

How long can I use the massager continuously?

The massager should only be used for 20 minutes at a time, followed by a 20-minute break.

Is it safe for people with diabetes or circulation problems?

Persons with circulation problems or reduced perception of touch (e.g., diabetics) should consult a physician before use.

Can I use the massager on clothes?

For optimal effect, use the combined heat and massage setting (VM) directly on the skin without clothes.

What should I do if the power cord is damaged?

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly qualified person to avoid hazard. Do not use the appliance.

USER MANUAL Infra OBH NORDICA

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Tekniske data

OBH Nordica 6035

OBH Nordica Sweden AB

Box 58

163 91 Spånga

Tel: [phone]

www.obhnordica.se

Tekniska data

OBH Nordica 6035

230 volt växelström

Korttidsdrift max 20 minuter

OBH Nordica Norway AS

Postboks 5334 Majorstuen

0304 Oslo

Tlf.: 22 96 39 30

www.obhnordica.no

Tekniske data

OBH Nordica 6035

230V vekselstrøm

Please read the instruction manual carefully before use and save it for later reference.

Massage has a relaxing effect on the body. It also can work as a preventive measure and is used in coordination with beauty care.

Use

Plug in the cord. Make sure that the switch is in off position. Start the appliance by sliding the switch to the desired position.

0 The appliance is turned off

M Massage

V Infrared light

VM Combined infrared light and massage

If the switch is in position "V" or "VM", the appliance needs 8-10 minutes to get warm.

Test the temperature of the massager with the palm of your hand to make sure that the desired temperature is reached. If the appliance has been on for more than 10 minutes in position “V” or “VM”, make sure that the massager is not to warm. The temperature can be adjusted by switching off the heat for shorter periods of time.

The handle of the massager can be adjusted for best massaging position. Simply press the circular button in the middle of the handle, hold it while you are adjusting the angle of the handle. Release the button upon reaching the desirable angle.

When the massager is used with a combination of heat and massage (“VM”) directly on the skin without clothes, the optimal effect is reached.

Important!

Persons with circulation problems or reduced perception of touch (for ex. Diabetics) should not use the appliance without first consulting a physician.

The massager comes with 4 attachments that can be used for different areas. The attachments can be pressed on and easily taken off by pulling upwards.

• Scalp massager, used to massage the scalp. Can also be used on the neck.
• Two point massager, concentrated deep penetrating massage for smaller areas like hands and feet.
• Zone massage, provides gentle vibrating waves for wider body area such as legs, hip and back.
  • Joint massager, used all over body.

Scalp massager Two point- Zone-massage Joint-massager massager

Hold with an easy grip and move massager in circular motion over the area. Do not press too hard.

The massager should only be used for 20 minutes at a time. After 20 minutes a 20-minute break should be taken.

Cleaning

The massager should be wiped off with a damp cloth. The attachments can be cleaned in some water with detergent. Never submerge the massager in water or any other liquid.

Safety instructions

1. Read the instruction manual carefully before use, and save it for future use.
2. Plug the appliance to a household outlet of 230V only, and use the appliance only for the intended use.
3. Always unplug the appliance from the mains supply when disorder is experienced, when not in use, when parts are applied or removed from the appliance and before cleaning and maintenance.
4. The appliance must not be immersed into water or other liquids.
5. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
6. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
7. Check that the cord is not hanging over the edge of the table.
8. The appliance must not be covered when in use, and should only be used under supervision.
9. Never use the massage apparatus in the bathtub, in the shower, or over a sink containing water.

10. When in use the surface of the appliance will become warm. Persons insensitive to heat should be careful when using the appliance.

11. Always examine appliance, cord and plug for damage before use. If the supply cord is damaged, it must be replaced by the manufacturer, or his service agent or a similarly qualified person in order to avoid a hazard.

12. The electrical installation must comply with the present legislation concerning additional protection in the form of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA). Check with your installer.
13. The appliance is for domestic use only, and must not be used professionally or medically, since the appliance is not included in the CE directive concerning electro-medical appliances.
14. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages to the product or other things are not covered by the warranty.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment must be collected for reuse and re cycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

Warranty

Claims according to current law. Cash receipt with purchase date shall be enclosed with any claims. When raising a claim the appliance must be returned to the store of purchase.

OBH Nordica Sweden AB

Box 58

163 91 Spånga

Tel: [phone]

Technical data

OBH Nordica 6035

230 V

Max using time 20 min

Heating time 8-10 min

9 infrared lights

3 settings:

- massage

- infrared heat

- combined heat and massage

Adjustable handle - 4 angles

4 detachable attachments
