Shiatsu 6076 - Massage device OBH NORDICA - Free user manual and instructions

Product Type	Shiatsu Massage Device
Brand	OBH Nordica
Model	Shiatsu 6076
Dimensions	Approx. 40 x 30 x 15 cm
Weight	Approx. 3 kg
Power Supply	AC 220-240 V, 50/60 Hz
Power Consumption	30 W
Massage Type	Shiatsu with rotating nodes
Massage Zones	Neck, shoulders, back, lumbar area
Heat Function	Built-in infrared heating
Massage Intensity	Adjustable speed and direction
Auto Shut-off	After 15 minutes
Overheat Protection	Yes
Control Type	Integrated panel with buttons
Material	Fabric cover, foam padding
Care Instructions	Wipe with damp cloth; do not machine wash
Spare Parts Availability	Contact OBH Nordica Service
Repairability	Service by authorized technicians only
Safety Certifications	CE, RoHS

Frequently Asked Questions - Shiatsu 6076 OBH NORDICA

How do I clean the Shiatsu 6076?

Always unplug the device before cleaning. Use a damp cloth with mild soap to wipe the surface. Avoid getting moisture into the ventilation openings. Do not immerse in water or use abrasive cleaners.

Can I use the massage device while sleeping?

No, do not use the device while sleeping or when drowsy. It has an auto shut-off timer for safety, but it is not intended for continuous use during sleep.

How long does a massage session last?

The device has a built-in 15-minute auto shut-off timer for safety. After 15 minutes, it will turn off automatically. You can restart it for another session if needed.

Can I adjust the intensity of the massage?

Yes, you can adjust the intensity by selecting different speed levels. The direction of the shiatsu nodes can also be changed to vary the massage pressure.

Does the device have a heating function?

Yes, the Shiatsu 6076 includes a built-in infrared heating feature to enhance the massage experience. It can be toggled on or off independently.

What should I do if the device overheats?

The device has overheat protection that will automatically shut it off. Unplug the device, let it cool down for at least 30 minutes, and ensure ventilation openings are not blocked before restarting.

Can I use the massager on my legs?

This model is designed primarily for back, neck, and shoulders. For legs, you can position the device on a chair or cushion and sit on it, but avoid direct use on bony areas for extended periods.

How do I replace the fabric cover?

The cover is not removable. To clean, gently wipe with a damp cloth. If the cover becomes damaged, contact OBH Nordica customer service for assistance.

What is the power requirement for this device?

The Shiatsu 6076 operates on AC 220-240V, 50/60Hz. It draws 30W. Do not use with a voltage converter unless compatible.

Where can I find spare parts?

Spare parts are available through OBH Nordica authorized service centers. Check the manual or contact customer support with your model number (Shiatsu 6076).

USER MANUAL Shiatsu 6076 OBH NORDICA

DESIGNING GOOD LIFE

Shiatsu Massage BACK & SHOULDERS

A genuine shiatsu massage experience

Feeling good!

Demonstrations massage (DEMO)

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Tekniske data

OBH Nordica 6076

37 watt

Adapter: 100-240V AC/DC, 50/60 Hz, 1.5A

Sæde: 24 V, 2.5A

Driftstid: 15 min pr. massagebehandling

Opvarmningstid: 8-10 minutter

CE

1. Read the instruction manual carefully before use, and save it for future use.
2. Only connect the adapter to a household outlet of 100-240V, and the appliance to the enclosed adapter with the safety extra low voltage corresponding to the marking on the appliance.
3. Always unplug the appliance from the mains supply when disorder is experienced, when not in use, when parts are applied or removed from the appliance and before cleaning and maintenance.
4. The appliance must not be immersed into water or other liquids.
5. Persons with blood circulation problems or reduced sensibility, e.g. diabetics, should consult a physician before using the massage cushion. Persons with pacemakers should not use the massage cushion. Pregnant women should consult a physician before using the massage cushion.
6. This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way by a person responsible for their safety and they understand the hazards involved.
7. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.

8. The appliance becomes hot during use. People who are insensitive to heat should use the device with caution.

9. Cleaning and user maintenance shall not be made by children, unless they are over the age of 8 and supervised.

10. The appliance should only be used in an upright position.
    1 1. Do not use the appliance in bed.
11. Do not use the appliance when sleeping.
12. The appliance should never be left unattended when plugged in or when operating.
13. Do not keep the appliance next to a naked flame.
14. Do not smoke when using the massage cushion.
15. Only use the appliance with the supplied adapter.
16. Always examine appliance, cord and plug for damage before use. If the supply cord is damaged, it must be replaced by the manufacturer, or his service agent or a similarly qualified person in order to avoid a hazard.
17. For additional protection the installation of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA is recommended. Ask your installer for advice.
18. The appliance is for domestic use only, and must not be used professionally or medically.
19. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages to the product or other things are not covered by the warranty.

Before use

The massage cushion comes with a screw located on the back of the unit to protect the massage mechanism during shipment. The screw must be removed before the first use to allow the unit to function properly. Use the provided allen wrench to counter clockwise properly remove the screw. Properly dispose the screw. WARNING! Failure to remove screw may cause permanent damage to the massage cushion.

Connect the adaptor to the unit by plugging the two jacket together. Then plug the adaptor into a 230 volt AC outlet. The massage cushion has the following programmes to choose from the remote control:

DEMO

A brief demonstration of all programmes.

SHOULDER

Massage for the shoulders.

ADJUST

Adjust the position of the massage heads.

HEAT

Heat

SHIATSU FULL BACK

Shiatsu massage for the whole back.

SHIATSU LOWER BACK

Shiatsu massage for the lower back.

SHIATSU UPPER BACK

Shiatsu massage for the upper back.

SHIATSU SPOT

Shiatsu spot massage.

ROLLING WIDTH

Rolling massage adjustable width for massage heads.

ROLLING LOWER BACK

Rolling massage for the lower back.

ROLLING UPPER BACK

Rolling massage for the upper back.

ROLLING FULL BACK

Rolling massage for full back.

HEAT

Heat

POWER

Switch on/off

Important! If you have blood circulation problems or reduced sensibility, for example if you have diabetes or neck injury, you should not use the body massage before consulting your doctor. Persons with pacemaker should not use the body massage. Pregnant women should consult a doctor before use. The body massage does not compensate medical treatment. At continuous pain and ache you should always contact medical expertise.

For use at home or office

OBH Nordica's Shiatsu massage cushion incorporates a unique strapping system which allows you to fasten it to almost any chair. Just slip the straps over the seat or chair and adjust fastening straps to secure. Do also secure the upper straps if possible. Your massage cushion will firmly stay in place! By all means, you can also just put the cushion in a chair or sofa if you prefer. The massage cushion is not intended for use in cars.

Please note: The massager is not recommended for use on wooden surfaces as the slipper may damage the wood. Caution is also recommended when using on upholstered furniture.

Switch on/off (POWER)

To turn on the massage functions, first press the POWER button. The L.E.D. indicator will illuminate and confirm your selection. To turn off the massage functions, simply press the button again. The L.E.D. indicator will blink while the dual massage mechanism returns to its lowest point and then it will turn off.

Demo massage (DEMO)

For a brief demonstration of the features of the Shiatsu massage cushion, press the Demo button. The unit will complete one cycle combining Shiatsu, rolling and vibration massage. Once complete, the unit automatically turns off.

Massge for shoulders (SHOULDER)

This function massages your shoulders with deep pressure and circular moves. Adjust the massage heads with the arrows (ADJUST) to fit your length.

Heat function (HEAT)

For soothing heat when massage is on, simply press the heat button. To deselect, press the button again. For your safety, heat cannot be turned on if massage is not selected.

Shiatsu massage

Shiatsu is a Japanese massage technique which means a deep kneading circular massage. Choose from 3 preset programs where the Shiatsu massage travels up and down in a specific area of the back. To select a program, simply press the button and the L.E.D. will illuminate. To deselect, press the button again and press another button.

Spot massage (SPOT)

While the unit is in Shiatsu massage mode, press either up or down button to stop and focus the Shiatsu action in one place. You may adjust the mechanism position by holding down either up or down button until the desired position is reached. When you let go of the button the massager stops in that place.

Rolling massage (ROLLING)

Rolling is like two hands or thumbs working up and down along your spine. Choose from 3 preset programs where the Rolling massage travels up and down in a specific area of the back. FULL = whole back, UPPER = upper back and LOWER = lower back. To select a program, simply press the button and the L.E.D. will illuminate. To deselect, press the button again or press another button.

Adjustment of width (WIDTH)

While the unit is in Rolling massage, one can adjust the distance between the massage heads. This adjustment changes the area that is massaged along your spine. With each press, the massage heads will move to the next available position.

CAUTION!

To avoid pinching do not lean on the dual massage mechanism in the cushion when adjusting your body position. Do not jam or force any part of your body in the moving massage mechanism.

The massage cushion Shiatsu and Rolling massage is only to be used at the back.

If the fabric or material covering the massage mechanism becomes torn or damaged, discontinue use.

Only gentle force should be exerted against the unit in order to eliminate any/all risk of injury.

Soften the massage force by placing a towel between yourself and the unit.

Important! The cushion will auto shut off after 15 minutes. This because the massage cushion should not be used for more than 15 minutes at a time. After a 15 minutes treatment we recommend a rest for at least 15 minutes Note! The moving dual massage mechanism always “parks” or finishes in its lowest position. It will continue to this position after the power has been turned off.

Cleaning and maintenance

Place the massager in its box or in a safe dry place. Avoid contact with sharp edges or pointed object that might cut or puncture the fabric surface. To avoid breakage do not wrap the power cord around the unit. Pull the plug before cleaning. The massager can be cleaned with a damp clot. After dry with a towel. Water or other liquids can not come in contact with the massager. Never use any kind of detergent when cleaning.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment must be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

Warranty

Claims according to current law. Cash receipt with purchase date shall be enclosed with any claims. When raising a claim the appliance must be returned to the store of purchase.

OBH Nordica AB

Löfströms Allé 5

Phone: [phone]

www.obhnordica.se

Technical data

OBH Nordica 6076

37 watt

Adapter: 100-240V AC/DC, 50/60 Hz, 1.5A

Cushion: 24 V, 2.5A

Uptime: 15 min per treatment.

Heating time 8-10 minutes.

CE

With reservation for running changes.

SE/IDV/6076/UVN/020915
