USER MANUAL ZDQ-806 Yashe

Exterior view of a modern stainless steel steamer with eggs inside, no visible text or symbols on the main body.

Please read this manual carefully before use. Keep it properly.

CONTENTS

English......4\~7

Deutsch....8\~11

Français....12\~15

16\~19Italiano...

20\~23España....

WARNING: Follow basic safety precautions when using your egg cooker. Read all instructions.

Key Safety Points

Warning symbol with exclamation mark inside triangle (no text or numbers)

CAUTION

Hot surface.

Contact may cause burns.

Do not touch.

1. CAUTION: The product becomes very hot! Ensure that you do not touch the housing. Keep children away from the appliance. There is a risk of burns!
2. NEVER place the appliance on hot surfaces.
3. DO NOT immerse the appliance in water or other liquids.
4. DO NOT touch the appliance or the plug with wet hands.
5. ALWAYS place the appliance only on a level and dry surface.
6. DO NOT use the appliance near flam-mable or explosive materials and objects.

General Safety Points

1. Boil only eggs in the appliance.
2. Boil the eggs only if there is water in the bowl.

3. Make sure that the appliance has cooled down completely before using it.

4. The mains cable should not hang freely in the air or come into contact with hot surfaces/objects.

5. Do not allow the power cable to pro-trude over sharp corners, table edges or over hot surfaces.
6. Do not keep your hands, clothes or other objects over the opening in the lid while the appliance is working. And do not close the opening.
7. Disconnect the mains plug from the socket if the appliance is not being used.
8. Hot steam is generated when the appliance is working. Avoid contact with the steam when lifting the lid or when it escapes from the opening in the lid.
9. Make sure that the escaping steam or moisture does not accumulate on sensitive objects or surfaces.
10. Do not use any liquids to clean the outer surfaces of the appliance. Use a dry, soft cloth for this purpose.
11. This product is not intended to be used by individuals (including children) with reduced physical, sensory, or mental capabilities or lack of experience and/or knowledge unless they are supervised by a person responsible for their safety or have received instructions on how to use the product from any such authorised person.

Egg Cooker Diagram

Technical diagram of a kitchen appliance with labeled parts including a toaster, refrigerator, and cup

A. Egg Cooker
B. Egg Holder
C. Omelet Bowl

D. Transparent Lid

E. Measuring Cup with Egg Piercer

Specifications

Model No. ZDQ-806

Rated Power 500W

Rated Voltage 220-240V

Rated Frequency 50/60Hz

Capacity 1~8 eggs

Before First Use

1. Remove the egg cooker and the accessories from the packaging. CAUTION: The egg piercer is located at the bottom of the measuring cup. Therefore be careful when handling the measuring cup to avoid injuries. Now remove all the packaging material.

2. The egg cooker should be cleaned before using it for the first time to remove any production residues. When cleaning, please refer to the information provided under section [Cleaning] in this user manual.

3. Then place the egg boiler on a level, dry surface and connect the appliance to a properly installed and earthed 120V AC mains socket. Please refer to the following sections for details on the boiling procedure.

4. Before using the appliance for the first time, it is advisable to add 140 ml of cold water to the egg cooker and boil it. After boiling, you can discard the water. The egg cooker is now ready for use.

Boiling Eggs

The appliance allows you to adjust the degree of hardness of the eggs to be boiled. For this purpose, various options are provided on the On-Off switch [ "OFF", "soft" (○), "medium"(○) and "hard" (●)].

1. Fill the measuring cup with 140 ml of water.
2. Now carefully pour the water from the measuring cup into the stainless steel bowl at the top of the egg cooker and then insert the egg holder.
3. Using the egg piercer located at the bottom of the measuring cup, make a hole in the wider end of the egg and place the eggs into the egg holder with the hole facing upwards.
4. Close the egg cooker by placing the lid on it.
5. Connect the plug to a properly installed socket.
6. Using the selector switch on the front panel of the appliance, select the desired degree of hardness for your eggs. The indicator starts glowing.
7. An audible signal is heard as soon as the boiled eggs are ready.
8. Put the On-Off switch to the "OFF" position to switch off the egg cooker. Then open the lid.
9. Remove the egg holder along with the eggs and rinse the eggs under cold running water. This makes it easy to remove the eggshells.

NOTE: For best results, use M size eggs at room temperature.

Note: For poached eggs, add up to four eggs in the poaching bowl. Crack open an egg. Ensure that you do not damage the egg yolk. The hardness of poached eggs can be selected using the On-Off switch as in the normal boiling process.

Note: It is advisable to clean the appliance after each use and discard any excess water. When cleaning, please refer to the information provided under section [Cleaning] of this user manual.

Cleaning

Please follow these instructions when cleaning to avoid injuries and damage to the appliance:

1. Switch off the appliance before cleaning and allow it to cool down.
2. Ensure that the mains plug is disconnected from the socket.
3. Do not open the product.
4. Do not immerse the appliance in liquids
5. Do not use any cleaning agents or solvents

NOTE: The bowl and the mains cable can be cleaned using a slightly damp cloth. If there is any calcification, use a solution of water and a little vinegar. Then boil once using clean water only to remove the smell of vinegar.

1. Wipe the appliance dry after cleaning.

NOTE: The egg holder, lid and measuring cup can be cleaned using either detergent under running water or in the dishwasher.

Disposal Instructions

In line with the European WEEE directive, electrical and electronic appliances should not be disposed of along with domestic waste. Their components must be separately sent for recycling or disposal, as improper disposal of toxic and dangerous components may permanently damage the environment.

WEEE directive 2012/19/EU

Warning symbol with a triangle and smoke line inside, no text or numbers present

⚠ VORSICHT

Technical line drawing of a kitchen appliance with labeled parts including a toaster, refrigerator, and cup.

A. Eierkocher

B. Eierhalter

C. Omelettschüssel

D. Transparenter Deckel

Technical line drawing of a kitchen appliance with labeled parts including a toaster, refrigerator, and cup

A. Cuiseur à oeufs

B. Support à œufs

C. Bol à omelette

D. Couvercle transparent

Warning symbol with exclamation mark and smoke line inside triangle

ATTENZIONE

Technical line drawing of a kitchen appliance with labeled parts including a toaster, refrigerator, and cup

Warning symbol with a triangle and smoke line inside, enclosed in a square frame (no text)

PRECAUCIÓN

Technical line drawing of a kitchen appliance with labeled parts including a toaster, refrigerator, and cup
