USER MANUAL Protein Shaker 307930 Arendo

QR code image containing encoded data, no visible human-readable text

ENG: Current drivers, user manuals and other relevant documents for this product can be found on our homepage.

Warning symbol with exclamation mark inside triangle

Warning sign depicting a lightning bolt symbol in a triangular hazard triangle

Labeled diagram of a blender with six numbered parts showing internal components and functions.

IMPORTANT SAFETY INSTRUCTIONS FOR THIS DEVICE!

• Never immerse the motor unit in water.
• Do not use the container to store carbonated contents. This can cause the lid to pop open and the contents to leak out.

- Only carry or transport the product in an upright position.

- Do not leave the contents in the container for longer than 24 hours.

- This product is not suitable for microwave ovens or similar.

- Never put your fingers or other objects (hair, clothing, cooking utensils, knives, screwdrivers, etc.) near the axis when the appliance is in use.

- Do not use this appliance with wet hands.

- Children should be supervised to ensure that they do not play with the appliance.

- This appliance is not intended for use, cleaning or maintenance by persons (including children up to the age of 8) with reduced physical, sensory or mental capabilities, or lack of experience and/or knowledge. Unless they are supervised by a person responsible for their safety or have received instructions from this person on how to use the appliance and have understood the resulting dangers.

• For safety reasons, please do not leave any packaging parts (plastic bags, cardboard, polystyrene, etc.) within reach of children.
• Children may only use or clean the appliance under supervision or instruction.
• Cleaning and maintenance by the user must not be carried out by children unless they are 8 years or older and are supervised. The appliance and its connecting cable must be kept away from children under the age of 8.
• Never stop the blender by hand.

Thank you for purchasing a product from Arendo. Please read the following quick guide carefully so that you can enjoy your purchased appliance for a long time.

1. Scope of delivery

• Mixing container
• Quick guide

2. Technical data

Input 5V - 1A - 5W via Type-C
Nominal output 7,4W
Filling quantity 700ml jar (600ml scale)
Battery 3.7V, 750mAh; Lithium Ion

3. Produkt-Details

Diagram of a blender with numbered parts for identification

12 English

1 Lid opening
2 Lid opening
3 Container
4 Mixing unit
5 Mixing button +	status LED
6 Battery + motor	unit (base)

4. Important safety regulations for rechargeable batteries

Attention!

• Always keep rechargeable batteries and the device out of the reach of children. Rechargeable batteries contain chemical substances and can be harmful to health if handled incorrectly.
• Never use damaged, deformed, leaking or overheated batteries. There is a risk of explosion and fire.
• Batteries must not be opened, short-circuited, thrown into a fire or dismantled.
• Batteries with a significantly reduced operating time must not be reused - risk of overheating or explosion.

Loading instructions

• Only charge batteries under regular supervision.
• Avoid unsupervised charging, especially overnight or in the vicinity of flammable materials.
• Only use approved chargers that are suitable for the respective battery type (e.g. Li-Ion 18650, NiMH AA).
• Only use the mains adapter supplied or a mains adapter with identical output voltage, polarity and current.
• Other power supply units can lead to overcharging, overheating, damage to the device or fire.
• Only charge on a non-flammable, stable and heat-resistant surface in a well-ventilated area.
• Monitor the charging process. Stop charging immediately if the battery becomes hot or if smoke, odours or unusual noises occur.
• Batteries must not be charged or stored in direct sunlight, on radiators or in vehicles at high temperatures.
• Ideal ambient temperature: 10^ - 30^ .

Notes on battery types

• Li-ion cells (e.g. 18650) must not be deep discharged (< 2.5 V).
• NiMH cells are considered to be deeply discharged at voltages < 0.8V .
• Deep-discharged batteries may only be charged using suitable chargers with reactivation mode.

Disclaimer

The manufacturer accepts no liability for damage caused by the use of unsuitable, damaged or modified batteries, chargers or power supply units.

Additional note for permanently installed battery:

- For devices with an integrated battery, this may only be replaced or opened by qualified specialists. Unauthorised tampering may result in injury, damage to the device or loss of warranty.

5. Start-up

Remove the device from the packaging and remove all packaging material. Fully charge the device before using it for the first time. To do this, connect a USB Type-C cable to the battery unit (base) and to a corresponding 5V / 1A power supply. The status LED on the mixing button flashes during the charging process. As soon as the device is fully charged, it lights up permanently.

5.1 Utilisation

Pour the desired ingredients into the cup. Press the mix button to mix the contents. The appliance stops automatically after one minute.

6. Cleaning and care

To make cleaning easier, disassemble the components (2 + 3 + 4) and remove the battery unit (base)

Caution! Do not immerse the battery unit in water!

- Wash all parts with warm soapy water before first use and as soon as possible after each use. Rinse all parts thoroughly and allow them to dry. The contents should not remain in the container for more than 24 hours. Wash the cup as soon as possible after each use.

• Do not use abrasive cleaners or scrubbing brushes as these can damage the paintwork.
• Do not use bleach or cleaners containing chlorine.
• Liquid residues, food or other contents can collect between the product components, e.g. the lid parts, container parts and seals.

7. Safety instructions and disclaimer

Never attempt to open the appliance to carry out repairs or modifications. Avoid contact with the mains voltage. Do not short-circuit the product. The device is not approved for outdoor use; only use it in dry conditions. Protect it from high humidity, water and snow. Keep the device away from high temperatures. Do not expose the device to sudden temperature changes or strong vibrations, as this could damage the electronic components. Check the device for damage before use. The appliance should not be used if it has been knocked or damaged in any other way. Please observe the national regulations and restrictions. Do not use the device for purposes other than those described in the instructions. This product is not a toy. Keep it out of the reach of children or mentally impaired persons. Any repair or modification to the appliance that is not carried out by the original supplier will invalidate the warranty or guarantee. The appliance may only be used by persons who have read and understood these instructions. The device specifications may change without prior notice.

8. Disposal instructions

According to the European WEEE Directive, electrical and electronic devices may not be disposed of with household waste. Their components must be recycled or disposed of separately, as toxic and hazardous components can cause lasting damage to the environment if disposed of incorrectly.

As a consumer, you are obliged under the Electrical and Electronic Equipment Act (ElektroG) to return electrical and electronic equipment free of charge at the end of its life to the manufacturer, the point of sale or to public collection centres set up for this purpose. Details are regulated by the respective state law. The symbol on the product, the operating instructions and/or the packaging refers to these regulations. By separating, recycling and disposing of old appliances in this way, you are making an important contribution to protecting our environment. For information on authorised collection points in your area, please contact your local city or municipal administration.

9. Notes on battery disposal

In connection with the sale of batteries or the delivery of devices containing batteries, the supplier is obliged to inform the customer of the following: The customer is legally obliged to return used batteries as the end user. The customer can return used batteries that the supplier carries or has carried as new batteries free of charge to the supplier's dispatch warehouse (dispatch address). The symbols shown on the batteries have the following meaning: Pb = battery contains more than 0.004 per cent lead by mass, Cd = battery contains more than 0.002 per cent cadmium by mass, Hg = battery contains more than 0.0005 per cent mercury by mass.

The crossed-out dustbin symbol means that the battery must not be disposed of with household waste.

WEEE Directive 2012/19/EU

WEEE Register No.: DE 67896761

Hereby, the company WD Plus GmbH declares that the device 307201/307929/30730 is in compliance with the essential requirements and other relevant provisions. You can obtain a complete declaration of conformity from WD Plus GmbH, Wohlenbergstraße 16, 30179 Hanover, Germany

Warning symbol with exclamation mark inside triangle

Warning sign depicting a lightning bolt symbol in a triangular hazard triangle

CONSIGNES DE SÉCURITÉ IMPORTANTES POUR CET APPAREIL !

Diagram of a blender with numbered parts for identification

Warning symbol with exclamation mark inside triangle

Warning sign depicting a lightning bolt symbol inside a triangle

IMPORTANTI ISTRUZIONI DI SICUREZZA PER QUESTO DISPOSITIVO!

Labeled diagram of a blender with six numbered parts showing internal components and functions.

Diagram of a blender with numbered parts for identification
