DO905WK - Wine cellar DOMO - Free user manual and instructions

Product type	Wine cellar
Brand	Domo
Model	DO905WK
Number of temperature zones	2 (upper and lower compartments)
Temperature range - upper compartment	5 °C to 12 °C
Temperature range - lower compartment	12 °C to 18 °C
Display	Digital
Interior lighting	Yes, with automatic shut-off after 10 minutes
Lock	Yes, with key
Reversible door	Yes (customer service intervention required)
Installation type	Freestanding or built-in
Adjustable feet	Yes
Power supply	220-240 V ~ 50 Hz (estimated)
Climate class	Ambient temperature 0 °C to 35 °C
Warranty	2 years
Interior cleaning	Hot water and soda
Exterior cleaning	Damp cloth and mild detergent
Recycling	Do not dispose of with household waste

Frequently Asked Questions - DO905WK DOMO

How to adjust the temperature of the Domo DO905WK wine cellar?

Use the Set Upper and Set Lower buttons to set the temperature of the upper (5-12 °C) and lower (12-18 °C) compartments respectively. Each press changes the temperature by 1 °C. The set temperature flashes, then the actual temperature reappears.

How to change the display from Celsius to Fahrenheit?

Press and hold the Set Upper and Set Lower buttons simultaneously until you hear a beep. The display toggles between °C and °F.

What to do in case of a power failure?

Do not open the door too often. Most power failures are brief and do not affect the interior temperature. If the power failure is prolonged (more than a few hours), protect the contents as needed. After a power failure or unplugging, wait 3 to 5 minutes before restarting the appliance.

How to clean the wine cellar?

Unplug the appliance and empty it. Clean the interior with a solution of hot water and soda. Clean the shelves with a mild detergent. Clean the control panel only with a damp cloth. Clean the exterior with a damp cloth and a little mild detergent, then dry.

How to use the cellar lock?

The key is in the instruction manual bag. Insert it into the lock and turn counterclockwise to open, and clockwise to close. Remove and store the key in a safe place after use.

Does the interior light turn off automatically?

Yes, the light turns off automatically after 10 minutes of use. You can also turn it on or off manually by pressing the lamp symbol.

How to reverse the door opening direction?

The door can be mounted to open on the left or right, but the operation requires intervention by customer service. Contact customer service for instructions.

Where to place the wine cellar for optimal operation?

Place it away from direct sunlight and heat sources. The ambient temperature should be between 0 °C and 35 °C. Avoid humid environments and ensure the plug remains accessible.

What to do if the displayed temperature differs from the set temperature?

After a long period of inactivity or a restart, there may be a temporary discrepancy. Let the cellar run for a few hours: the temperature will stabilize on its own.

How to replace the interior bulb?

First, unplug the appliance. Use a replacement bulb of the same wattage as the original. Follow the instructions in the manual or contact customer service if necessary.

USER MANUAL DO905WK DOMO

Front view of a double-bowel refrigerator with multiple wine rings (no visible text or labels)

GARANTIEVOORWAARDEN

CONDITIONS DE GARANTIE

This appliance has a two year warranty period. During this period the manufacturer is responsible for any failures which are the direct result of construction failure. When these failures occur the appliance will be repaired or replaced if necessary. The warranty will not be valid when the damage to the appliance is caused by wrong use, not following the instructions or repairs executed by a third party. The warranty will only be valid if the warranty application has been completed by the dealer at the time of purchase. All parts, which are subject to wear, are excluded from the warranty.

Type nr. Apparaa

RECYCLING INFORMATIONEN

RECYCLING INFORMATION

The symbol 📄 on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be brought to the applicable collection point for recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service of the shop where you purchased the product.

ONDERDELEN

Diagram of a server rack with numbered components for identification

WAARSCHUWING

Diagram of a server rack with numbered components for identification

AVERTISSEMENT

Diagram of a server rack with numbered components for identification

ACHTUNG

1. Digital control panel
2. Recessed handle
3. Large shelves
4. Leveling legs
5. Security lock
6. Bottom grille

Diagram of a server rack with numbered components for identification

WARNING

To prevent damaging the door gasket, make sure to have the door all the way opened when pulling shelves out of the rail compartment.

The appliance must be positioned so taht the plug is accessible. Release the electric cord. Do not move your cabinet while loaded with wine. You might distort the body. The wine cooler should be installed in a suitable place in order to avoid touching the compressor with the hand.

If the supply cord is damaged, it must be replaced by manufacturer of its service agent or a similarly qualified person in order to avoid a hazard

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of ofi re, electrical shock or injury when using your appliance follow these basic precautions :

Read all instructions before using the wine cooler.

Risk of child entrapment. Child entrapment and suffcation are not problems of the past. Junked or abandoned appliances are still dangerous ... even if hey will “just sit in the garage a few days”.

Before you throw away your old wine cooler : take off the door. Leave the shelves in place so that chilcrren may not easily climb inside.

Never allow children to operate, play with, or crawl inside the appliance.

Never clean appliance parts with fl ammable fluids. The fumes can crate a fire hazard or explosion.

Do not store or use galsoline or any other fl ammable vapors and liquids in the vicinity of this or any other appliance. The fumes can create a fi re hazard or explosion

SAVE THESE INSTRUCTIONS

BEFORE USING YOUR WINE COOLER

• Remove the exterior and interior packing.
• Before connecting the Wine Cooler to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.
• Clean the interior surface with lukewarm water using a soft cloth.
• Install the handle on the left side of the door.

- When replace the illuminating lamp, please select the lamp which comply with the rated power input of lamp according to the rating label. Shut off the power supply before replacing the lamp.

- When disposing your appliance, please choose an authorized disposal site.

INSTALLATION OF YOUR WINE COOLER

- This appliance is designed to be for free standing installation or built-in (fully recessed).

- Place your Wine Cooler on a floor that is strong enough to support it when it is fully loaded. To level your Wine Cooler, adjust the front leveling leg at the bottom of the Wine Cooler.

- Locate the Wine Cooler away from direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform properly.

- Avoid locating the unit in moist areas.

- Plug the Wine Cooler into an exclusive, properly installed-grounded wall outlet. Do not under any circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning power and/or grounding should be directed toward a certifi ed electrician or an authorized Products service center

REVERSING THE DOOR SWING OF YOUR APPLIANCE

This appliance has the capability of the door opening from either the left or right side. The unit is delivered to you with the door opening from the left side. Should you desire to reverse the opening direction, please call service for reversal instructions.

HOW TO REMOVE THE SHELF

First pull the shelf outward to the end, then lift the edge of the shelf upward and pull the shelf out of the cabinet. Operate reversed when you need to install the shelf. (Note: you should first insert the right side of the shelf into the rail compartment.) as follow

The Wine Cooler should be placed in where the ambient temperature is between 0-35°C. If the ambient temperature is above or below this range, the performance of the unit may be affected. For example, placing your unit in extreme cold or hot conditions may cause interior temperatures to fluctuate. The range of 5-18°C may not be reached.

The above temperatures may fluctuate depending on whether or not the interior bulb is ON or OFF or whether the bottles are located on the upper/middle or lower section.

Setting the Temperature Contro

– Each cooling compartment of the wine cooler (upper & lower) is independently controlled. To set the temperature

Connect the power cord to a properly grounded outlet. In the event of a power interruption, all previous temperature settings are automatically erased and each compartment will default to a preset temperature setting of: 6^ C ( 43^ F) for upper compartment and 12^ C ( 54^ F) for lower compartment.

Set the desired cooling temperature by pressing the buttons adjacent to the “set upper/set lower” program. Each depression of the buttons will scroll through the available temperature settings (for each compartment) in increments of 1 degree. The temperature selected will flash in the LED display for approximately 5 seconds, then revert back to display the temperature of the internal cabinet

Upper compartment: The temperature setting can be adjusted from 5^ C to 12^ C Lower compartment: The temperature setting can be adjusted from 12^ C to 18^ C o view the “set” temperature. (anytime) press and hold the corresponding button for approximately 5 seconds, the “set” temperature will temporarily “fl ash” in the LEI display for 5 seconds

- This unit has the option to display temperatures in either Celsius or Fahrenheit. To change the setting, press and hold both buttons (Set Upper/Set Lower) simultaneously for approximately 5 seconds, a prompt (beep) will sound and the blue pilot light adjacent to the C or F mode illuminates. (Due to different market, some units can only display Fahrenheit or Celsius)

NOTE:

- If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes before restarting the unit. If you attempt to restart before this time delay, the Wine Cooler will not start.

- When you use the Wine Cooler for the first time or restart the Wine Cooler after having been shut off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the LED readout. This is normal and it is due to the length of the activation time. Once the Wine Cooler is running for a few hours everything will be back to normal

Interior Light

You can turn the interior light ON or OFF by pushing the button marked with the “bulb” symbol.

The light will be turned off automatically if it remains ON for 10 minutes. You have to push the button marked with the “bulb” symbol again and the light will turn back on.

DOOR LOCK

Your unit is provided with a lock and key combination.

The keys are located inside the plastic bag that contains the User's Guide. Insert the key into the lock and turn it counterclockwise to unlock the door. To lock the door do the reverse operation making sure metal pin is engaged completely. Remove the key and place it in a secure place for safekeeping.

CARE AND MAINTENANCE

• Turn off the power, unplug the appliance, and remove all items including shelves and rack.
• Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a quart of water.
• Wash the shelves with a mild detergent solution.
• Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts.
• Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a clean soft cloth.

POWER FAILURE

Most power failures are corrected within a few hours and should not affect the temperature of your appliance if you minimize the number of times the door is opened. If the power is going to be off for a longer period of time, you need to take the proper steps to protect your contents.

VACATION TIME

Short vacations: Leave the Wine Cooler operating during vacations of less than three weeks.

Long vacations: If the appliance will not be used for several months, remove all items and turn off the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door open slightly: blocking it open if necessary.

MOVING YOUR WINE COOLER

• Remove all items.
• Securely tape down all loose items (shelves) inside your appliance.
• Turn the adjustable leg up to the base to avoid damage.
• Tape the door shut.
• Be sure the appliance stays secure in the upright position during transportation. Also protect outside of appliance with a blanket, or similar item.

ENERGY SAVING TIPS

The Wine Cooler should be located in the coolest area of the room, away from heat producing appliances, and out of the direct sunlight.
