Shiatsu + Air 4.0 FMS-347HJ - Massage device HOMEDICS - Free user manual and instructions

Product Type	Shiatsu + Air Foot Massager
Brand	Homedics
Model	FMS-347HJ
Power Supply	120 V~, 60 Hz (polarized plug)
Power Consumption	Not specified (estimated 30-60 W)
Auto Shut-off	15 minutes
Massage Functions	Kneading (shiatsu) and air compression
Air Compression Levels	3 intensities: low, medium, high
Massage Programs	3 preset programs combining kneading and air
Heating	Yes, soothing heat (activated with massage)
Control Panel	Power, Mode, Heat, Intensity buttons
Covering	Fabric with removable washable liners
Liner Maintenance	Unzip, hand wash in cold water, lay flat to dry
Cleaning the Unit	Soft slightly damp cloth, do not immerse
Safety	Polarized plug, auto shut-off 15 min, do not cover
Warranty	1 year limited (parts and labor)
Approximate Dimensions	Approximately 40 x 30 x 20 cm (estimate)
Weight	Approximately 3 kg (estimate)
Usage	Household use only, in seated position
Included Accessories	Washable liners
Certifications	FCC Part 15 Class B, ICES-003
Repairability	No user-serviceable parts
Country of Origin	Not specified

Frequently Asked Questions - Shiatsu + Air 4.0 FMS-347HJ HOMEDICS

How to plug in the foot massager?

Insert the power cord into a 120-volt AC outlet. The plug is polarized (one blade wider); do not modify it.

Can I use the massager without socks?

It is highly recommended to wear socks during use. Do not use the unit with shoes.

How to activate the heat?

Press the heat button. The indicator light turns red. Heat can only be used with massage functions.

What to do if the unit does not turn on?

Check that the plug is properly inserted and the outlet is working. If the problem persists, contact Homedics customer service.

How long can I use the device continuously?

The unit has an auto shut-off after 15 minutes of continuous use to prevent overheating.

How to clean the washable liners?

Unzip and remove the liners. Hand wash only in cold water with a mild detergent. Lay flat to dry. Do not use bleach, do not iron, do not dry clean.

Can I use the device if I am pregnant?

Consult your doctor before using this product if you are pregnant. It is not recommended for diabetic individuals.

How to change the air compression intensity?

Press the intensity button to switch between low, medium, and high intensity.

What to do in case of overheating?

Stop all use and let the unit cool down before reusing. Never cover the unit while operating.

Where to find the serial number?

The serial number is usually on the label under the unit or in the box. Keep it for warranty service.

USER MANUAL Shiatsu + Air 4.0 FMS-347HJ HOMEDICS

activate your warranty and meet your product

Scan the QR code within 7 days of receiving your product to activate your warranty and experience all your product's benefits!

QR code image containing encoded data, no visible human-readable text

shiatsu + air 4.0 foot massager INSTRUCTION MANUAL AND WARRANTY INFORMATION

FMS-347HJ | L-04856 Rev. 1

IMPORTANT SAFEGUARDS

WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:

READ ALL INSTRUCTIONS BEFORE USING.

DANGER – TO REDUCE THE RISK OF ELECTRIC SHOCK:

• Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
• DO NOT reach for an appliance that has fallen into water. Unplug it immediately.
• NEVER use pins or other metallic fasteners with this appliance.

WARNING – TO REDUCE THE RISK OF BURNS, ELECTRIC SHOCK, FIRE, OR INJURY TO PERSONS:

• An appliance should NEVER be left unattended when plugged in. Unplug from outlet when not in use, and before putting on or taking off parts or attachments.
• Not for use by children.
• Close supervision is necessary when this unit is used by, on, or near children, invalids, or disabled persons.
  • DO NOT use outdoors.
• Use this appliance only for its intended use as described in this manual. DO NOT use attachments not recommended by Homedics; specifically, any attachments not provided with the unit.
• DO NOT carry this appliance by the supply cord or use cord as a handle.
• NEVER operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return it to a Homedics Service Center for examination and repair.
• Keep the cord away from heated surfaces.
• NEVER operate the appliance with the air openings blocked. Keep the air openings free of lint, hair, and the like.
• NEVER drop or insert any object into any opening.
• DO NOT operate where aerosol (spray) products are being used or where oxygen is being administered.
• DO NOT stand on or in appliance. Use only while seated.

• DO NOT operate under a blanket or pillow. Excessive heating can occur and cause fire, electric shock, or injury to persons.

• To disconnect, turn all controls to the off position, then remove plug from outlet.

• Use heated surfaces carefully. May cause serious burns. DO NOT use over insensitive skin areas or in the presence of poor circulation. The unattended use of heat by children or incapacitated persons may be dangerous.
• DO NOT use massager in close proximity to loose clothing or jewelry.
• Keep long hair away from massager while in use.

SAVE THESE INSTRUCTIONS

CAUTION – PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE OPERATING.

- Consult your doctor prior to using this product, if:

• You are pregnant
• You have a pacemaker

• You have any concerns regarding your health

• Not recommended for use by diabetics.

• NEVER leave the unit unattended, especially if children are present.
• NEVER cover the unit when it is in operation.
• If at any time, soreness, rash, or pain occurs, discontinue use and consult your physician.
• DO NOT use this product for more than 15 minutes at a time.
• Extensive use could lead to the product's excessive heating and shorter life. Should this occur, discontinue use and allow the unit to cool before operating.
• NEVER use this product directly on swollen or inflamed areas or skin eruptions.
• DO NOT use this product as a substitute for medical attention.
• NEVER use this product while in bed.
• This product should NEVER be used by any individual suffering from any physical ailment that would limit the user's capacity to operate the controls or who has sensory deficiencies.
• This product should not be used by children or invalids without adult supervision.
• This product is intended for household use only.
• This product is not intended for use in automobiles.

To avoid injury and irreparable damage, always remain seated when using massager. NEVER stand on the unit.

INSTRUCTIONS FOR USE

To reduce the risk of electric shock, this appliance is equipped with a polarized plug (one blade wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

Close-up of a person's leg and foot resting on a small white object, possibly a device or device component (no visible text or symbols)

Homedics M B

Fig. 1 Fig. 2

1. Insert the power cord into a 120-volt AC outlet.
2. It is highly recommended that you wear socks while using this foot massager. Do not use the unit with shoes.
3. Place massager on the floor in front of your chair or seat and place feet in massager (Fig. 1).
4. To activate massage, press the POWER button once (Fig. 2). The massage will begin in the default settings.

AIR COMPRESSON INTENSITY

Press the intensity button to toggle between low, medium, and high intensity air compression.

MODE BUTTON

Press the mode button button to toggle between three preset massage programs. Each program combines the massage functions in unique patterns to provide a relaxing and therapeutic massage. When the unit is powered on the massage will begin in program 1.

HEAT BUTTON

To activate soothing heat, press the heat button. The indicator will illuminate red to confirm your selection. To turn heat off, press the button again and the red light will turn off.

When finished, turn the unit "OFF" by pressing the POWER BUTTON and unplug.

NOTE: For your safety, heat can only be used with the massage function.

MAINTENANCE

TO STORE

Place massager in its box or in a cool, dry place. Avoid contact with sharp edges or pointed objects. To avoid breakage, DO NOT wrap the power cord around the unit. DO NOT hang the unit by the cord.

TO CLEAN THE MASSAGER

Unplug the unit and allow it to cool before cleaning. Clean only with a soft, slightly damp cloth. NEVER allow water or any other liquids to come into contact with the unit.

- DO NOT immerse in any liquid to clean.

- NEVER use abrasive cleaners, brushes, or strong chemicals that may or may not be flammable and/or damaging to the product to clean.

- DO NOT attempt to repair the massager. There are no user-serviceable parts. For service, contact Consumer Relations at the number listed in the Warranty section.

TO CLEAN THE WASHABLE LINERS

Unzip and remove the washable liners. Hand wash only with cold water and a mild detergent. Lay flat to dry.

• DO NOT bleach.

- DO NOT iron.

• DO NOT dry clean.

LOCATION OF PARTS AND CONTROLS

RHYTHMIC AIR MASSAGE

Rhythmic air massages by squeezing feet in a rhythmic wavelike motion.

KNEADING MASSAGE

Kneading massage simulates 2 hands pressing firmly and slowly, traveling back and forth on the soles of your feet.

REMOVABLE, WASHABLE INSERTS

Unzip the fabric to clean. See care instructions on page 5.

CONTROL PANEL

Homedics

NOTE: For your safety, there is a 15-minute auto shutoff on the unit.

SUPPLIER'S DECLARATION OF CONFORMITY

Product Description: SHIATSU + AIR 4.0 FOOT MASSAGER

Model Number: FMS-347HJ

Trade Name: Homedics

FCC Compliance Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

U.S. Contact Information

Company: Homedics, LLC.

Address: 3000 N Pontiac Trail, Commerce Township, MI 48390

8:30am-7:00pm EST Monday-Friday 1-800-466-3342

Homedics is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

CAN ICES-003(B)/NMB-003(B)

Homedics

1 YEAR LIMITED WARRANTY

Homedics sells its products with the intent that they are free of defects in manufacture and workmanship for a period of 1 year from the date of original purchase, except as noted below. Homedics warrants that its products will be free of defects in material and workmanship under normal use and service. This warranty extends only to consumers and does not extend to Retailers.

To obtain warranty service on your Homedics product, contact a Consumer Relations representative for assistance. Please make sure to have the model number of the product available.

Homedics does not authorize anyone, including, but not limited to, Retailers, the subsequent consumer purchaser of the product from a Retailer or remote purchasers, to obligate Homedics in any way beyond the terms set forth herein. This warranty does not cover damage caused by misuse or abuse; accident; the attachment of any unauthorized accessory; alteration to the product; improper installation; unauthorized repairs or modifications; improper use of electrical/power supply; loss of power; dropped product; malfunction or damage of an operating part from failure to provide manufacturer's recommended maintenance; transportation damage; theft; neglect; vandalism; or environmental conditions; loss of use during the period the product is at a repair facility or otherwise awaiting parts or repair; or any other conditions whatsoever that are beyond the control of Homedics.

This warranty is effective only if the product is purchased and operated in the country in which the product is purchased. A product that requires modifications or adoption to enable it to operate in any other country than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifications is not covered under this warranty.

THE WARRANTY PROVIDED HEREIN SHALL BE THE SOLE AND EXCLUSIVE WARRANTY. THERE SHALL BE NO OTHER WARRANTIES EXPRESS OR IMPLIED INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS OR ANY OTHER OBLIGATION ON THE PART OF THE COMPANY WITH RESPECT TO PRODUCTS COVERED BY THIS WARRANTY. HOMEDICS SHALL HAVE NO LIABILITY FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES. IN NO EVENT SHALL THIS WARRANTY REQUIRE MORE THAN THE REPAIR OR REPLACEMENT OF ANY PART OR PARTS WHICH ARE FOUND TO BE DEFECTIVE WITHIN THE EFFECTIVE PERIOD OF THE WARRANTY. NO REFUNDS WILL BE GIVEN. IF REPLACEMENT PARTS FOR DEFECTIVE MATERIALS ARE NOT AVAILABLE, HOMEDICS RESERVES THE RIGHT TO MAKE PRODUCT SUBSTITUTIONS IN LIEU OF REPAIR OR REPLACEMENT.

This warranty does not extend to the purchase of opened, used, repaired, repackaged and/or resealed products, including but not limited to sale of such products on internet auction sites and/or sales of such products by surplus or bulk resellers. Any and all warranties or guarantees shall immediately cease and terminate as to any products or parts thereof which are repaired, replaced, altered, or modified, without the prior express and written consent of Homedics.

This warranty provides you with specific legal rights. You may have additional rights which may vary from state to state and country to country. Because of individual state and country regulations, some of the above limitations and exclusions may not apply to you.

For more information regarding our product line in the USA, please visit www.Homedics.com. For Canada, please visit www.Homedics.ca.

FOR SERVICE IN THE USA

[e-mail]

8:30AM-7:00PM EST MONDAY-FRIDAY

1-800-466-3342

FOR SERVICE IN CANADA

[e-mail]

8:30AM-5:00PM EST MONDAY-FRIDAY

1-888-225-7378

©2024 Homedics, LLC. All rights reserved.

Homedics is a registered trademark of Homedics, LLC.

Distributed by Homedics, LLC, 3000 N Pontiac Trail, Commerce Township, MI 48390

IB-FMS347HJ

Homedics ^ND

QR code image containing encoded data, no visible human-readable text

FMS-347HJ | L-04856 Rev. 1

CONSIGNES DE SÉCURITÉ IMPORTANTES

L'UTILISATION D'APPAREILS ÉLECTRIQUES, EN PARTICULIER EN PRÉSENCE D'ENFANTS, DOIT FAIRE L'OBJET DE MESURES DE SÉCURITÉ ÉLÉMENTAIRES, NOTAMMENT LES SUIVANTES : LIRE TOUTES LES INSTRUCTIONS AVANT D'UTILISER L'APPAREIL.

DANGER – POUR RÉDUIRE LE RISQUE DE DÉCHARGE ÉLECTRIQUE :

Close-up of a person's leg and foot resting on a small, curved object (no text or symbols visible)

Fig. 1

Homedics ↑

Fig. 2

Adresse: 3000 N Pontiac Trail, Commerce Township, MI 48390

QR code image containing encoded data, no visible human-readable text

FMS-347HJ | L-04856 Rev. 1

PRECAUCIONES IMPORTANTES DE SEGUIRIDAD

Close-up of a person's leg and foot resting on a small white foam roller (no text or symbols visible)

Fig. 1

Homedics M M B

Fig. 2

[e-mail]

8:30 A. M. A 7:00 P. M. EST

DE LUNES A VIERNES

1-800-466-3342

PARA SERVICIO EN CANADÁ

[e-mail]

8:30 A. M. A 5:00 P. M. EST

DE LUNES A VIERNES

1-888-225-7378
