USER MANUAL Cioccolata OneConcept

QR code image containing encoded data, no visible human-readable text

INHALTSVERZEICHNIS

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

London, W8 6ND

United Kingdom

Dear Customer,

Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints to avoid damages. Any failure caused by ignoring the items and cautions mentioned in the instruction manual is not covered by our warranty and any liability. Scan the QR code to get access to the latest user manual and other information about the product:

QR code image containing encoded data, no visible human-readable text

CONTENT

Safety Instructions 12

Product Overview 13

Before First Use 13

Cleaning and Care 15

Troubleshooting 15

Disposal Considerations 16

Manufacturer & Importer (UK) 16

TECHNICAL DATA

Item number 10028322
Power supply 220-240 V ~ 50-60 Hz
Power consumption 60 W

SAFETY INSTRUCTIONS

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.
• Check if the voltage indicated on the label of the appliance corresponds to the local mains voltage before you connect the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
• Do not operate the appliance outdoors, or close to open flames, heaters or other hot objects or other heat sources.
• When the appliance is not in use or before you clean the appliance, switch it off and unplug it.
• The appliance should be placed on a flat surface during operation to avoid overturning.
• To reduce the risk of electric shock, never operate this product with wet hands.
• Do not place in or drop into water or other liquid.
• Before cleaning or storing the unit, allow it to cool down.
• The unit has no user-serviceable parts contained within. Do not attempt to repair, disassemble or modify the appliance.
• The appliance is intended for household use only. Do not use this appliance for anything other than its intended use.
• Use the unit only with foodstuffs, do not heat any other liquids with it.
• Do not overfill the container (A).
• The unit may become hot during use, do not touch the hot surfaces.
• Do not touch the auger (G) while the motor is running.
• Do not pull cord around sharp edges or corners. Keep cord away from heated surfaces.

PRODUCT OVERVIEW

A	Container	E	Cascade Tower
B	Base Unit	F	Auger
C	Switch	G	Adjustable Feet
D	Light Indicator

BEFORE FIRST USE

• Remove all packaging.
• Clean all the parts as described in the chapter CLEANING.
• Dry all the parts.

Which chocolate is suitable?

Use customary chocolate coating or special chocolate fountain chocolate from specialty stores sine it is more pourable then conventional chocolate. Different grades are available. When using conventional chocolate, vegetable oil must be added to ensure ease of flow.

Prepare foods for dipping

You can dip different fruits, depending on the season and your preference, into the melted chocolate. You can also dip biscuits, marshmallows or the like. Use long wooden skewers or the like for dipping the foods.

Other possible applications

Refine the chocolate, e.g. with liqueur. You can use cheese or barbecue sauces instead of chocolate. Add vegetable oil to ensure ease of flow. For dipping, you can use, e.g. asparagus, sausages, grill food.

Use and Operation

1 Place the unit on a flat, stable surface.
2 Place the cascade tower (F) on the three pins in the container (A)
3 Insert the auger (G) with the triangular hole first into the cascade tower (F). Twist the auger (G) until it engages with the driver shaft.
4 Unwind the mains cable completely.
5 Plug the supply cord into the wall socket.
6 The unit is now ready to use.

Operation

• Prepare your fondue mixture in a pot and pour it into the container (A). Do not overfill the container.
• Turn the switch (D) to position I. The heater works and keeps the mixture warm and liquid. The control light is on. For some mixtures the heater is not needed.
• Turn the switch (D) to position II. The heater and motor works at same time. The control light is on. After some time mixture is extruded out at the top of the cascade tower and flows back down into the container over the cascades. If no mixture is extruded, the container must be refilled.
• If the unit is not exactly level, the mixture flows down only one side of the cascades. To make the mixture flow down evenly to all sides, the unit should be set up exactly level with the two adjustable feet (H).
• The more liquid the mixture is, the better and smoother it will flow over the cascades. However, if the mixture is too thin, the auger cannot move it up.
• To make the mixture more liquid, add vegetable oil, milk, cream. Wine or water as desired. If the mixture is too thicker, add grated chocolate, cheese, starch flour as desired until the desired consistency is reached.

Note: Never add hard chips to a fountain while the motor is running. only add melted, smooth chocolate. Make sure no chunks of food are in the base as it may clog the flow of chocolate. Remove with a slotted spoon.

CLEANING AND CARE

• Unplug the power plug before you clean the unit. And allow the unit to cool down.
• Do not immerse the base unit (B) in liquids of any kind!
• Use only a moist cloth to clean base unit (B). Allow the unit to dry fully before the next use.
• Immediately after use, clean the container (A), the cascade tower (F) and the auger (G) with warm water, detergent and a cloth to prevent food residue from sticking. And then use a dry cloth to dry them.
• The auger (G) and cascade tower (F) (after cooling) can be cleaned in the dishwasher, before putting the items into the dishwasher, remove excessive contaminations in the sink or with paper tower.
• Do not use metal or sharp items to clean the unit, because these may damage the surfaces.
• Do not use aggressive chemicals or similar materials.

TROUBLESHOOTING

Problem Mögliche Ursache Lösung
Chocolate is dripping, not flowing.	Chocolate is too thick. Add some vegetable oil.
	Unit is not LEVEL. Level the unit.
Flow is intermittent, interrupted,flowing not properly.	Check whether chunks of food is in base which may clog the chocolate flow.	Remove any chunks with a slotted spoon.

DISPOSAL CONSIDERATIONS

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

If there is a legal regulation for the disposal of electrical and electronic devices in your country, this symbol on the product or on the packaging indicates that this product must not be disposed of with household waste. Instead, it must be taken to a collection point for the recycling of electrical and electronic equipment. By disposing of it in accordance with the rules, you are protecting the environment and the health of your fellow human beings from negative consequences. For information about the recycling and disposal of this product, please contact your local authority or your household waste disposal service.

MANUFACTURER & IMPORTER (UK)

Manufacturer:

Chal-Tec GmbH, Wallstrasse 16, 10179 Berlin, Germany.

Importer for Great Britain:

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

London, W8 6ND

United Kingdom
