USER MANUAL Perfect Smoothie LQ-600.007A Haeger

Exterior view of a modern HAE GERTBC blender with clear glass and handle (no text or symbols on the device itself)

CE RoHS

Thank you for having chosen a HÆGERTEC product.

The HÄEGERTEC products have been produced to think about the welfare of the consumer privileging the most raised standards of quality, functionality and assign. We are sure you will be happy with this appliance.

We assume that the user is familiar with the common procedures of handling household appliances.

Before using the appliance for the first time please read carefully and thoroughly through these operating instructions and the safety advice, completely familiarising yourself with the appliance. Retain these instructions for future reference and pass them on to whoever might acquire the appliance at a future date.

Intended use

This appliance has been designed to blend liquids such as dairy products, sauces, fruit juices, soups; to mix drinks, shakes, etc. It can be used to mix soft foods or to make purées with cooked ingredients, such as carrots or baby food ingredients. You can also use the blender to make cocktails with crushed ice.

This appliance is for household use only, not for industrial use. Any use other than what is indicated could be dangerous.

General Safety Instructions

When using electrical appliances, basic safety precautions should always be followed, including the following:

• Read these instructions completely before using the appliance.
• Remove all elements from the inside or outside of the appliance used for protection during transport or for sales promotions, such as paper or plastic bags, plastic sheets, cardboard and stickers.
• Do not modify or repair the appliance. In the event of any anomaly in the cord or any other part of the appliance, do not use it and take it to an authorised assistance service.
• Before plugging the appliance into the mains, check that the indicated voltage matches that of your home.
• Always unplug the appliance after use and before removing or installing parts and before doing any maintenance or cleaning. Also unplug it in the event of a power outage.

English

• Never pull on the cord or use it to hang up the appliance. Always unplug the appliance by pulling on the plug, never the cord.
• Prevent the power cord from coming into contact with sharp edges or hot surfaces.
• If the power cord is damaged, it should be replaced by the manufacturer or by your after-sales service shop or similar qualified personnel to prevent possible hazards.
• Do not leave the blender in operation unattended.
• Never submerge the main body of the appliance in water or any other liquid or put it in the dishwasher.
• The blades are very sharp. Be very careful when handling them. Do not handle them when the appliance is plugged in. While it is operating, keep hands, hair, clothes and any utensil away from the moving blades.
• Only use the blender with the lid fitted on the jar. Never use the blender when it is empty.
  • The jar is not suitable for use in microwave ovens.

Children and Frail Individuals

• To ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.
• Do not allow small children to play with the foil as there is a danger of suffocation!
• The appliance may be used by children 8 years or older and by persons with reduced physical or mental capabilities, if they are under supervision or if they have been instructed in the use of the appliance in a safe manner and understand the potential risks. Children must not carry out cleaning and maintenance of the appliance, unless they are 8 years or older and under supervision. Children younger than 8 years must be kept away from the appliance and its power supply.
• Children should be supervised to ensure that they do not play with the appliance.

Description

1. Cap
2. Lid
3. Glass Jar

4. Sealing ring

5. Cutting Blade

6. Cup base
7. Motor Housing (Base unit)
8. Speed Selector

2 Instructions for use

Assembly instructions

1. Put the rubber sealing ring (4) on the inner edge of the blade unit (5).
2. Put the blade unit with sealing ring into the cup base (6).
3. Mount the glass cup (3) onto the cup base unit and tune the cup base unit, in clockwise direction until it is fixed.
4. Mount the glass jar with cup base on the base unit.
5. After putting the ingredients in the jug, fix the lid (2) on the jug by pressing down.
6. Insert the inner cover (1) into the opening of the lid and tune it in anticlockwise direction until it is locked.

Putting into Service

Electrical Connection

1. Connect the device to a duly installed 220-240V\~ 50Hz with protective contact socket.
2. Before inserting the plug into the socket. Make sure that the mains voltage to be used matches that of the device. You can find this information on the nameplate.

Operation

• This appliance has been designed to blend liquids such as dairy products, sauces, fruit juices, soups; to mix drinks, shakes, etc. It can be used to mix soft foods or to make purées with cooked ingredients, such as carrots or baby food ingredients. You can also use the blender to make cocktails with crushed ice. Never put in more than 10 ice cubes at a time.
• Under no circumstance should the appliance be operated for more time than what is necessary. After using the appliance continuously for one minute, allow it to cool to room temperature to prevent it from overheating. You can use it again after 10 minutes.

- Do not put any wooden, plastic, glass, metal or similar objects in the jar.

1. Assemble the blender as explained in section "Assembly Instructions". Be sure that it is assembled correctly.
2. Put food into the jar without exceeding 2/3 of the maximum capacity (upper edge).
3. Put on the lid and press and the cap. Be sure that they are on correctly.

4. Plug in the power cord.

5. Put the speed selector between position 1 (low speed) and 2 (maximum speed) or P quick pulse at high speed. Leave it in this position while operating the appliance (maximum of 1 minute of continuous operation).

During operation hold the lid on firmly using both hands. NEVER remove the lid while the appliance is operating.

1. If you want to add any ingredient during the blending process, remove the dispenser cap and add ingredients through the hole in the lid.

2. When you obtain the desired result, place the speed selector in the off position.

3. Unplug the cable from the mains and wait until the blade has stopped turning.

4. Remove the jar from the main body and empty it.

Useful Tips

• Do not use this jar to store food or other objects.
• It is not advisable to pour very hot food in the jar to avoid the danger of burning yourself.
  • We recommend adding the ingredients little by little instead of all at once.
• First blend the harder ingredients and then add the softer ones. This makes it easier to obtain an even mix.
• The slower speed is more suitable for beating or mixing foods with a liquid consistency. The faster speed is recommended for mincing or mixing more solid or thicker foods.
  • Coarse and fibrous foods must be cut into 2 or 3 cm cubes at most.
• To make cocktails with crushed ice, first put in the ingredients then the ice, and lastly the liquid needed or a little water. Do not forget to add the liquid otherwise the ice will not be crushed correctly.
• When crushing ice, use the high speed for a few seconds to crush it completely. The ice cubes will be propelled upwards, so they will not get stuck in the bottom.
• If the foods stick to the walls of the jar during blending or remain out of the range of the blades, switch off the appliance, remove the jar from the base and take off the lid. Remove the lid and carefully push the food towards the blades with a spatula. Put the lid on the jar, place it on the main body and carry on blending the ingredients.
• Do not exceed the maximum level indicated on the blender jar.

4 Instructions for use

Cleaning

The blades are very sharp. Avoid touching the blades with your hands while cleaning and drying the inside of the jug.

Never submerse the main body in water or wash it in the dishwasher.

1. Clean the appliance before using it for the first time, immediately after use and after not being used for a long period of time.

2. Clean the jar and other plastic pieces immediately, given that some foods (such as carrots) are very difficult to clean once they are dry.

Quick cleaning

1. With the blender assembled, open the lid and pour in some warm water with a drop of liquid detergent.

2. Close the lid. Be sure that it is closed firmly.

3. Put the speed selector in the P position for a few seconds.

4. Put the speed selector in position 0 and unplug the appliance.

5. Remove the jar and rinse with warm water.

Thorough cleaning

1. Empty the jar and dismantle the blender.

2. Clean the main body and the mains cable with a damp cloth.

3. Clean the other parts with soapy water and rinse thoroughly under the tap. Never wash in the dishwasher. Turn the jug upside down to dry.

4. Assemble the blender as explained in paragraph "Assembly Instructions".

Technical Data

Model: LQ-600.007A

Power supply: 220-240V\~ 50/60 Hz

Power consumption: 600W

Jug capacity: 1.5 Litres

Conformity CE

This product has been tested and produced according to all relevant current CE guidelines, such as:

- electromagnetic compatibility Directive 2014/30/EU,

- Low voltage Directive (LVD) Directive 2014/35/EU,

- RoHS Directives 2011/65/EU and (EU)2015/863,

and has been constructed in accordance with the latest safety regulations.

The CE mark attests this product with all relevant directives.

Disposal – Environment policy

This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE).

By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

This symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.

Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information about treatment, recovery and recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

Guarantee

This unit is covered by a 24 months (*) warranty, from the purchase date, and covers the repair free of charges of the damaged due to the manufacturer fault or defected components. The distributor reserves the right to change the unit for an equivalent model.

The warranty does not cover any damaged caused by incorrect use, lightning, incorrect installation, external factors or any intentional damaged. The warranty does not cover damage thus attributable to falls, blows, spill, exposure to extreme environmental conditions or deterioration caused by normal use of plastic parts or keyboards, as well as using batteries other than those specified in this manual.

For the repairing, during the warranty period, the unit shall be sent to the distributor or reseller, or to the address indicated by them, and must be jointed the warranty certificated and the respective original invoice or selling ticket, where the buying date is expressed indicated.

The consumer is protected by the guarantee provided by Directive 1999/44/CE of European Parliament and Council of 25 May.

(*) Only for European Union countries
