USER MANUAL Rock'nToast Classic + CECOTEC

Sandwichera/Sandwich maker

3D rendering of a black plastic grater with open lid and internal compartments (no text or symbols visible)

Safety instructions 7

1. Parts and components 32

2. Before use 32

3. Operation 32

4. Cleaning and maintenance 33

5. Troubleshooting 34

6. Technical specifications 34

7. Disposal of old electrical and electronic appliances 35

8. Technical support and warranty 35

9. Copyright 35

SOMMAIRE

Read these instructions thoroughly before using the device. Keep this instruction manual for future reference or new users.

- This symbol means "caution, hot surface". The

accessible surfaces of the appliance may reach high temperatures during operation. Be careful not to burn yourself.

- The appliance is not intended to be operated by means of an external timer or separate remote-control system.

- Check the power cable regularly for visible damage. If the cable is damaged, it must be repaired by the official Cecotec Technical Support Service to avoid any type of danger.

- This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children must not play with the device. Cleaning and user maintenance should not be carried out by children unless they are over 8 years old and are under supervision.

- Keep this appliance and its power cable out of reach of children under the age of 8.

- Supervise children to prevent them from playing with the appliance. Close supervision is necessary if the appliance is used by or near children.

- This device is designed for domestic use only and is not intended for bars, restaurants, farmhouses, hotels, motels, and offices.

- Place the appliance on a dry, stable, heat-resistant surface.

Position the appliance in such a way to avoid spillage of hot liquids. Be especially careful with the handle.

• Do not immerse the cable, plug, or any other non-removable part of the device in water or any other liquid or expose electrical connections to water. Make sure your hands are dry before handling the plug or switching on the device.
• Make sure that the mains voltage matches the voltage stated on the appliance marking and that the wall outlet is earthed.
• The appliance will be very hot during and immediately after operation. Use gloves or other convenient protective equipment to avoid burns and injuries.
• Use a heat-resistant base when using the appliance on surfaces sensitive to high temperatures.
• Do not twist, bend, pull, or damage the power cable. Protect it from sharp edges and heat sources. Do not allow the cable to touch hot surfaces. Do not let the cable hang over the edge of the working surface or worktop.
• Do not use the appliance outdoors, near a gas or electric hob, in heated ovens, or near open flames.
• Do not operate the appliance after it has been dropped or if it malfunctions.
• Extreme caution must be taken when moving the appliance.
• Always turn off and disconnect the appliance from the power supply when not in use or if it is not going to be used for a long period of time and before cleaning it. Pull from the plug, not the cable, to disconnect it from the outlet.

INSTRUCTIONS DE SÉCURITÉ

1. Hinged handle
2. Bottom plate
3. Top plate
4. Overheating indicator
5. High temperature indicator

NOTE:

the graphics in this manual are schematic representations and may not exactly match the device.

2. BEFORE USE

• This device is packaged in a way as to protect it during transport. Take the device out of its box and remove all packaging materials. You can keep the original box and other packaging elements in a safe place. This will help you prevent damage to the device when transporting it in the future. In case the original packaging is disposed of, make sure all packaging materials are recycled accordingly.
• Make sure all parts and components are included and in good conditions. If there is any piece missing or in bad conditions, contact the official Cecotec Technical Support Service immediately.
• Before the first use, wipe the plates with a damp cloth, a dry cloth with paper, then brush the plates with a little butter, margarine or cooking fat.

Box content

• Rock'nToast Grill + Sandwich Maker
• Instruction manual

3. OPERATION

• Plug the device to a power supply.
• Close the sandwich maker and, while it is preheating, prepare the food you wish to cook.
• Wait 3 minutes: the temperature indicator light will illuminate green, indicating the end of preheating.
• Open the sandwich maker and put a slice of bread in the bottom plate.
• Add the filling and top with another slice of bread. Close the sandwich maker loosely. Steam will escape through the opening between the plates during cooking. Keep hands away from hot surfaces and steam.

- If desired, lock the sandwich maker with the folding handle locking system by pressing it down when closing the appliance.

NOTE: during toasting, the thermostat indicator light will turn on and off, indicating that the appliance is being maintained at a suitable toasting temperature. Only cook with the sandwich maker closed, and never touch the hot areas of the appliance while the high temperature indicator is on.

• The sandwich will take 2 to 3 minutes to toast, as desired. Open the sandwich maker and remove the sandwich with the help of a plastic or wooden spatula. Never use metal utensils that could damage the non-stick coating of the plate.
• Close the sandwich maker to keep it warm while you prepare the next food you wish to toast.
• Please note that when the hot plates are hot, the heating indicator will light up to warn you and prevent burns.
• When you have finished using the sandwich maker, unplug it.

Recommendations for better roasting results

• Always preheat the appliance before use. Plug in the appliance and prepare the sandwich fillings.
• It is also possible to spread the bread with a little butter to give it more flavour and a crispier end result.

4. CLEANING AND MAINTENANCE

• Unplug the device and allow it to cool down before cleaning it.
• Wipe the inside and edges of the plate with kitchen paper or a soft cloth. If it is difficult to remove food residues stuck to the plate, pour a little cooking oil on the food residues to soften them and wipe the plate after 5 minutes.
• Clean the outside of the appliance only with a slightly damp cloth to prevent moisture, oil or grease from entering the ventilation slot.
• Do not clean the interior and exterior surface with abrasive pads or steel wool to avoid damaging the finish.
• Only use water to clean the appliance. Do not use any other chemical solution for cleaning.
• Do not immerse the appliance in water or other liquids.

5. TROUBLESHOOTING

Problem Possible cause Possible solution
The appliance does not work The product is not plugged in. Plug the appliance in.
The sandwich maker gives off a certain smell of smoke	There is too much food that has not been removed during previous cooking and is burning.	Wipe the surface with a damp cloth and remove food residues.
	You are preparing greasy ingredients.	When greasy food is cooked, a large amount of oil will leak into the container. Cooking oil causes white smoke to come out of the device and it gets hotter than normal. This does not affect the device or the result.
The ingredients are cooked unevenly in the air fryer	The preparation time is not enough.	Leave the sandwich in the sandwich maker for a longer period of time.
Fried food is not crispy when they come out the device	The bread you are using is excessively moist.	Try using a slightly drier bread and add, if you consider it necessary, a pinch of sugar or butter.
The bread does not adapt well to the shape of the plates	The slice of bread it too big. Try	trimming the slice a little if it does not fit the standard size.

6. TECHNICAL SPECIFICATIONS

Product: Rock nToast Classic +

Product reference: 02963

Power: 700 - 800 W

Voltage and frequency: 220-240 V \~, 50/60 Hz

Technical specifications may change without prior notification to improve product quality.

Made in China | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC APPLIANCES

This symbol indicates that, according to the applicable regulations, the product and/or batteries must be disposed of separately from household waste. When this product reaches the end of its shelf life, you should dispose of the cells/batteries/accumulators and take them to a collection point designated by the local authorities.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

Compliance with the above guidelines will help protecting the environment.

8. TECHNICAL SUPPORT AND WARRANTY

Cecotec shall be liable to the end user or consumer for any lack of conformity that exists at the time of delivery of the product under the terms, conditions, and deadlines established by the applicable regulations.

It is recommended that repairs be carried out by qualified personnel.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact the official Cecotec Technical Support Service at [phone].

9. COPYRIGHT

The intellectual property rights over the texts in this manual belong to CECOTEC

INNOVACIONES, S.L. All rights reserved. The contents of this publication may not, in whole or in part, be reproduced, stored in a retrieval system, transmitted, or distributed by any means (electronic, mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC INNOVACIONES, S.L.
