Moto G55 5G - Smartphone MOTOROLA - Free user manual and instructions

USER MANUAL Moto G55 5G MOTOROLA

QR code image with a central logo, likely linking to a digital resource or website.

moto g55 5G

English 3

Deutsch....7

Français....11

Español....15

Português....19

Italiano 23

Nederlands 27

suomi....31

Polski 35

Scan with your Camera app for how-to videos.

QR code with a central circular logo containing a play button symbol

Let's get started

Before using your phone, please read the legal, safety and regulatory information provided with your product.

Main camera Ultra-wide/ Macro camera Speaker Front camera SIM and microSD card tray Headset jack Microphone Microphone Flash NFC touchpoint Proximity sensor Volume buttons Power button/ fingerprint sensor USB-C®/charging port Speaker

Put in the card(s) and power on

1 Insert the SIM tool into the hole next to the SIM and microSD card tray to pop out the tray.

Make sure that you use the correct size of SIM card and don't cut the SIM card.

2 Insert the SIM card with the gold contacts down, then gently push the tray into the slot.

Add a microSD card micro (optional, sold separately) for additional storage.

eSIM option: your phone may support an eSIM (embedded SIM card) in addition to the physical SIM card. Contact your service provider for details if you want to activate and use it.

Connect with 5G: 5G service plan and 5G network coverage required; available only in selected areas; device not compatible with all 5G networks. Contact your service provider for details.

3 Press and hold the power button ⏻ to turn on your phone, then follow the prompts to get started.

To turn off your phone, press the power and volume up buttons 🔊+ at the same time.

Note: your phone is not waterproof. For more about your phone's water-repellent design and care, swipe up and tap Settings > Help.

Help and more

Get answers, updates and info:

• Help is here: from the Home screen, swipe up and tap Settings > Help to learn how to use your phone and get support.
  • Getmore: get software, user guides and more at www.motorola.com/mymotog.
  • Get apps: tap Play Store to browse and download apps.

Legal information. This guide provides important legal, safety and regulatory information that you should read before using your product. For the complete legal information, from the Home screen swipe up and tap Settings >Q, then type Legal information or visit www.motorola.com/device-legal.

Charging and battery safety. To prevent possible burning and injury, the battery in your phone should only be removed by a Motorola-approved service centre or similar skilled personnel. If your phone becomes unresponsive, press and hold the power button until the screen goes dark and your phone restarts.

The phone is PD (Power Delivery) and QC (Quick Charge) capable. For the fastest charging speeds, choose a Motorola 33W or higher USB-A, QC charger (may be sold separately) with the included QC cable, or a Motorola 30W or higher USB-C PD charger and compatible PD cable (both sold separately). Use of other chargers is not recommended and may impair the charging performance. The power delivered by the charger must be between the min 5 Watts required by the radio equipment and the max 30 Watts to achieve the fastest charging speed.

Chargers that do not comply with applicable national standards may be unsafe, with risk of death or injury, and may cause slow charging or product damage. Don't charge your phone in temperatures below -20°C or above 45°C. To view applicable standards and to learn more, see the "Legal information" section of this guide or visit www.motorola.com/device-legal.

Warning about high volume usage. To prevent possible hearing damage, do not listen at high volume levels for long periods. When your headset volume reaches the high volume threshold, a warning will be shown. Tap OK to dismiss it, or with to five seconds, then press the volume up button to dismiss it and enable the volume to continue to be adjusted.

Disposal and recycling. For help recycling products and packaging responsibly, visit www.motorola.com/recycling.

Extreme heat or cold. Don't use your phone in temperatures below -20°C or above 45°C. Don't store/transport your phone in temperatures below -20°C or above 60°C.

Legal disclaimers. Features, services and applications are network dependent and may not be available in all areas; additional terms/charges may apply. Product specifications and other information contained in this guide are believed to be accurate at the time of printing or release. Motorola reserves the right to correct or change

any information without notice.

Arbitration. Your purchase is governed by a binding arbitration clause. For more information and how to opt out, see the legal guide that came with your phone.

SAR information (on e-label). To view specific absorption rate (SAR) values for this phone, from the Home screen swipe up and tap Settings > 🔒, then type Regulatory labels, from your phone's dial pad, type *#07# or visit www.motorola.com/sar.

Supported frequencies and power (Model XT2435-2). This phone is capable of operation on the following frequencies, subject to location and network availability.

Operating mode	Frequency range MHz/band	Maximum nominal transmit power dBm
Bluetooth	2400 - 2483.5	20 dBm EIRP
Wi-Fi	2400 - 2483.5	20 dBm EIRP
Wi-Fi	5150 - 5250	23 dBm EIRP
Wi-Fi	5250 - 5350	20 dBm EIRP
Wi-Fi	5470 - 5725	20 dBm EIRP
Wi-Fi	5725 - 5850	14 dBm EIRP
NFC	13.56	-21.09 dBuA/m@10 m
GNSS	1559 - 1610/1164 - 1300	N/A
FM receive	87.5 - 108	N/A
GSM	2*/3*/5/8	33/30*
UMTS	1/2/5/8	24
LTE	1/2/3/5/7/8/20/26/28/32/38/40/41*/42/66	23/26*
SG	N1/3/5/7/8/20/26/28/38/40/41/77*/78*	23/26*

Copyright and trademarks. MOTOROLA, the stylised M logo, MOTO and the MOTO family of marks are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. Google, Android, Google Play, and other related marks and logos are trademarks of Google LLC. microSD Logo is a trademark of SD-3C, LLC. USB Type-C® and USB-C® are registered trademarks of USB implementers Forum. All other product or service names are the property of their respective owners.

© 2024 Motorola Mobility LLC. All rights reserved.

Product ID: moto g55 5G (Model XT2435-2)

Manual Number: 711608084361-A

Erste Schritte

Protect your phone with

moto care. Visit:

motorola.com/motocare.

QR code image containing encoded data, no visible human-readable text

With moto care, extend your warranty coverage up to three years, and take advantage of features like accidental damage protection.
