B-Ready Lower Adapter - Stroller accessory BRITAX - Free user manual and instructions

Product Type	Lower Infant Seat Adapter (ISAB)
Brand	Britax
Model	B-Ready Lower Adapter
Compatibility	Britax B-Ready Strollers
Main Functions	Allows attaching an additional baby car seat in the lower position
Assembly	Install on the rear mounting brackets, locks into place
Removal	Press the release levers and pull out of the stroller
Attachment Mechanism	Click & Go™ to attach the car seat to the adapter
Safety	Always check that the adapter is securely attached before attaching a seat; never use without an occupied seat in the main position
Warnings	To prevent tipping, first remove the child from the lower seat
Material	Molded plastic
Maintenance and Cleaning	Wipe with a damp cloth and mild soap; do not use abrasive cleaners
Storage	Store away from heat sources to prevent damage to plastic parts
Warranty	2-year limited warranty against defects in materials and workmanship
Included Accessories	ISAB adapter, mudguards (if installed), storage basket (depending on configuration)
Maximum Supported Weight	Complies with Britax car seat standards (varies by seat model)
Adapter Height	Approximately 10 cm (estimate)
Net Weight	Approximately 0.5 kg (estimate)

Frequently Asked Questions - B-Ready Lower Adapter BRITAX

How do I install the lower adapter on my B-Ready stroller?

Align the adapter mounting brackets with the rear support bar of the storage basket, then slide into place and press down to engage the lock.

Can I use the adapter with any Britax car seat?

Yes, the adapter is designed for Britax car seats with the Click & Go™ system. Check your model's compatibility.

How do I remove the adapter from the stroller?

Press the release levers forward to disengage the lock, then pull the mounting brackets out of the stroller.

Is it safe to use the adapter in the lower position without a seat on top?

No, to prevent tipping, always keep an occupied seat in the main (upper) position when using the lower seat.

What is the maximum weight supported by the adapter?

The maximum weight depends on the car seat used. Refer to the car seat specifications. The adapter itself supports the weight of standard Britax car seats.

How to clean the adapter?

Wipe it with a damp cloth and mild soap. Dry with a clean cloth. Do not use abrasive cleaners, solvents, or strong detergents.

Is the adapter covered by a warranty?

Yes, Britax offers a two-year limited warranty against defects in materials and workmanship. Keep your proof of purchase.

Can I attach two car seats with this adapter?

This adapter allows attaching only one car seat in the lower position. For two seats, use the extension adapter (not included) for the upper position.

Are mudguards included with the adapter?

Mudguards may already be installed on the stroller or sold separately. The adapter does not include them by default.

Where can I get a detailed user manual?

The complete manual is available free in PDF on our website notice-facile.com or on the Britax website.

USER MANUAL B-Ready Lower Adapter BRITAX

Lower Infant Car Seat Adapter

britax

User Guide

Safety Information. 2

Features. 4

Assembly. 5

Installing the Mud Guards. 5
Under-Seat Storage Basket 6
Installing the LICS Adapter 7
Removing the LICS Adapter 7

Operating Instructions 8

Attaching a BRITAX Infant Car Seat. 8
Removing a BRITAX Infant Car Seat. 8
Dual BRITAX Infant Car Seats. 8

Care and Maintenance. 10

Warranty 11

B-READY®, BRITAX®, and Click & Go™, are trademarks owned by Britax and registered in the U.S.A. and other countries. All rights reserved. ©2016 Britax Child Safety, Inc. This product and its components are subject to change without notice. P04818300_A:04.16

Safety Information

WARNING!

Failure to follow all warnings and instructions could result in SERIOUS INJURY or DEATH.

Read these instructions carefully before using this product. To ensure proper use, store this user guide in a convenient place so it can be consulted often.

GeneralWarnings

• Never leave child unattended.
• Avoid serious injury from falling or sliding out. Always use harness to secure child.
• Avoid finger entrapment or injury. Always ensure any child occupants or bystanders are away from the stroller while folding or unfolding.
  Always make certain that the stroller is fully open and locked before use.
• Always set the parking brake when stroller is not moving.
• Do not hang or place items on the stroller handle or frame except for those approved by BRITAX. They may cause an unstable or hazardous condition to exist.
• Only use BRITAX approved child restraints, car seats, accessories and replacement parts with this stroller.
• Do not overload basket - Maximum weight in basket is 4.5kg (10 lbs). Overloading the basket may cause the stroller to become unstable.
• Do not allow children to climb on or play with the stroller.
• Never use stroller on stairs or escalators.
• Stroller is intended for walking speed only. Do not use while jogging, skating, etc.

Lower Infant Car Seat (LICS) AdapterWarnings

• Ensure that the LICS Adapter is secured before connecting an infant car seat.
• To avoid tipping always remove child in lower seat first. Never use without an occupied seat installed in the primary position.

Features

Actual product may vary from images.

Assembly

Installing the Mud Guards

1. Press and hold the release button in the center of the wheel and pull away from the wheel housing.

1. Slide the mud guard onto the mounting bracket above each rear wheel housing until it locks into place.

1. Replace the rear wheel and repeat on the other side.

Under-Seat Storage Basket

1. Slide the hook on each side of the storage basket out of their slots on the stroller frame.
2. Push the back of the under-seat storage basket inside out and fold within the stroller frame.

NOTE:The back of the storage basket can be unzipped and removed instead of folded within the stroller frame.

Installing the LICS Adapter

1. Slide the mounting brackets of the LICS adapter onto the rear support bar of the under-seat storage basket.
2. Press down to engage the accessory frame lock and secure the adapter to the stroller frame.

Removing the LICS Adapter

1. Push the release levers on the LICS adapter forward to disengage the accessory frame lock.
2. Pull the LICS adapter mounting brackets away from stroller.

Operating Instructions

Attaching a BRITAX Infant Car Seat

1. Align the Click & Go connectors with the LICS adapter receivers and push down until a click a click is heard.
2. Pull up on the seat to ensure that the seat is secure.

Removing a BRITAX Infant Car Seat

Refer to your infant car seat user guide for information on the removal instructions for your specific model.

1. Attach top infant car seat by lining up the Click & Go connectors with the extension adapter receivers and press down until a click is heard.

NOTE: Top infant car seat can be either forward facing or rear facing.

1. Attach the lower infant car seat by lining up the Click & Go connectors with the LICS receivers and push down until a click is heard.
2. Pull up on both seats to ensure that they are secure.

Dual BRITAX Infant Car Seats

1. Attach the extension adapters to the frame by lining up the Click & Go connectors with the Click & Go receivers and pressing down until they lock into place.

Care and Maintenance

Frame

• Wipe the frame with a damp cloth and mild soap. Use clean, dry cloth or towel to wipe away excess water and soap.

Plastic Parts

• Wipe with a damp cloth and mild soap. Use a clean, dry cloth or towel to wipe away excess water and soap.
• Do not use abrasives, solvents, strong detergents, or household cleaners. These products can scratch, discolor, and weaken plastic or cause corrosion on metal surfaces.

Storage

• To prevent damage to plastic parts, store away from extreme heat.

Warranty

This product is distributed by Britax Child Safety, Inc. ("BRITAX"). BRITAX warrants this product to the original retail purchaser as follows:

Limited Two-Year Warranty

This product is warranted against defective materials or workmanship for two years from the date of original purchase. Proof of purchase is required. Your exclusive remedy for this warranty is that BRITAX will, at its option, provide repair or replacement components to the original purchaser for this product or replace the product. BRITAX reserves the right to discontinue or change fabrics, parts, models or products, or to make substitutions. Labor and shipping costs for returns are not included.

To make a claim under this Warranty, you must contact BRITAX Customer Services Department at 1-888-427-4829, or 1-704-409-1699, or write to us using the address on the back cover of this booklet. Proof of purchase is required.

PLEASE COMPLETE AND MAIL THE REGISTRATION CARD WITHIN 30 DAYS OF PURCHASE, OR VISIT US.BRITAX.COM/REGISTRATION.

Warranty Limitations

This warranty does not include damages which arise from negligence, misuse, salt corrosion, or use not in accordance with the user guide.

The use of non-BRITAX accessories is not approved by BRITAX. The use of unapproved accessories could cause this product to become damaged or dangerous. Their use may void the BRITAX warranty.

Limitations of Damages

The warranty and remedies as set forth above are exclusive and in lieu of all others, oral or written, express or implied. In no event will BRITAX or the retailer selling this product be liable for any damages, including incidental or consequential damages, arising out of the use or inability to use this product.

Limitations of Warranties and Other Warranty Terms and State Law Rights

Any implied warranties, including implied warranties of merchantability and fitness for a particular purpose, shall be limited to the duration and terms of the express written warranty. Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations may not apply to you. This warranty gives you specific legal rights, and you may have other rights, which vary from state to state. Neither BRITAX, nor the retailer selling this product, authorizes any person to create for it any other warranty, obligation, or liability in connection with this product.

Table des matieres

Installer I'adaptateur ISAB

Britax Child Safety, Inc.

4140 Pleasant Road

Fort Mill, SC 29708 USA

A Britax Childcare company

Tel.: [phone]

Tel.: [phone]

www.Britax.com
