Product Type	Wireless surveillance camera
Brand	TP-Link
Model	Tapo C402
Category	Outdoor surveillance camera (with spotlight)
Weight (with spotlight)	680 g
Operating temperature	-20 °C to 45 °C
Power supply	Built-in rechargeable battery, compatible with solar panel (optional)
Battery charging	Via power adapter (PS2/LPS) or solar panel, charging temperature 0 °C to 45 °C
Main functions	Motion detection, night vision, two-way audio, push notifications
Connectivity	Wi-Fi 2.4 GHz
Mobile app	Tapo (available on App Store and Google Play)
Installation	Wall mounting, maximum mounting height 2 m
Safety	Do not disassemble, repair or modify; use only recommended adapter; do not immerse in water
Maintenance and cleaning	Clean with a soft dry cloth; avoid corrosive products; do not expose to fire
Spare parts and repairability	No user-replaceable parts; contact after-sales service for any repairs
Light source (spotlight)	LED energy class E, not replaceable
Included accessories	Camera with spotlight, USB cable, power adapter, mounting kit
Warranty	See the manual for conditions

Frequently Asked Questions - Tapo C402 TP-LINK

How to install the Tapo C402 camera?

Download the Tapo app from the App Store or Google Play. Turn on the camera by holding the power button for 3 seconds. Add the camera via the app by pressing the ⊕ button and follow the instructions.

How to recharge the camera battery?

Use the included power adapter (PS2/LPS) or a compatible TP-Link solar panel. The charging temperature must be between 0 °C and 45 °C. Do not use a damaged charger.

Is the Tapo C402 camera waterproof?

The manual states do not immerse the device in water or any other liquid. However, it is designed for outdoor use with an unspecified protection rating. Protect it from heavy rain.

What is the Wi-Fi range?

Range depends on the environment. The camera operates on Wi-Fi 2.4 GHz. For a stable connection, place the router within 30 meters without major obstacles.

How to reset the camera?

Hold the power button for about 10 seconds until the light flashes. You can also use the Tapo app in the device settings.

Can I use the camera without a solar panel?

Yes, the camera runs on rechargeable battery. You can recharge it via the power adapter. The solar panel is an option for extended battery life.

How to view images remotely?

Open the Tapo app on your smartphone, log in to your account and select the camera. You can view live feed, enable night mode and receive alerts.

Does the camera emit an audio signal?

The camera has a built-in microphone and speaker for two-way audio. You can speak through the app and hear what's happening.

How to clean the Tapo C402 camera?

Use a soft dry cloth to wipe the surface. Avoid chemical or abrasive products. Do not spray liquid directly onto the device.

What is the battery life?

Battery life depends on usage (motion detection, recordings). Under normal use, it can last several months. The solar panel can extend it indefinitely.

USER MANUAL Tapo C402 TP-LINK

Visit www.tapo.com/support

for technical support, user guides, warranty, and more information

© 2025 TP-Link

Quick Start Guide

Solar-Powered Security Camera

7100001757 REV1.1.0

CONTENTS

1 / English

Get the Tapo app from the App Store or Google Play, and log in.

2 SET UP CAMERA

Press and hold the power button on your camera for about 3 seconds to turn it on.

Tap the⊕ button in the app and select your camera model. Follow app instructions to complete setup.

Português Brasil

1 BAIXAR APLICATIVO

Baixe o aplicativo Tapo na App Store ou no Google Play, e faça login.

2 CONFIGURAÇÃO

2 POSTAVITI

Pritisnite i držite tipku za napajanje na kameri oko 3 sekunde da biste je uključili.

Dodirnite gumb ⭕ u aplikaciji i odaberite model kamere. Pratite upute aplikacije da biste dovršili postavljanje.

Български

1 ИЗТЕГЛЕТЕ ПРИЛОЖЕНИЕто

2 CONFIGURER LA CAMÉRA

2 NASTAVENÍ

2 PENGATURAN

2 БАПТАУ

2 カメラの設定

2 카메라 설정

2 IESTATIT KAMERU

2 CONFIGUREAZĂ CAMERA

2 KONFIGURACJA KAMERY

2 НАСТРОЙТЕ КАМЕРУ

2 NASTAVITEV KAMERE

Za vklop kamere pritisnite in držite gumb za vklop približno 3 sekunde.

Pritisnite ⊕ tipko v aplikaciji in izberite model svoje kamere. Sledite navodilom aplikacije in zaključite nastavitve.

Slovenčina

1 STIAHNITE SI APLIKÁCIU

2 NASTAVTE KAMERU

2 KAMERA KURULUMU

2 設定攝影機

2 ติดตั้งกล้อง

2 НАЛАШТУЙТЕ КАМЕРУ

2 CÀI ĐẶT CAMERA

TP-Link hereby declares that the battery camera is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.

The original EU Declaration of Conformity may be found at https://www.tapo.com/support/ce/.

TP-Link hereby declares that the battery camera is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017.

The original UK Declaration of Conformity may be found at https://www.tapo.com/support/ukca/.

For Solar Panel:

TP-Link hereby declares that the solar panel is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863.

The original EU declaration of conformity may be found at https://www.tapo.com/support/ce/.

TP-Link hereby declares that the solar panel is in compliance with the essential requirements and other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.

The original UK declaration of conformity may be found at https://www.tapo.com/support/ukca/.

Български:

За камера:

English: Safety Information

For Camera:

- Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.

- Do not use damaged charger or USB cable to charge the device.

- Do not use any other chargers than those recommended.

- Do not use the device where wireless devices are not allowed.

- Keep the device away from fire or hot environments. DO NOT immerse in water or any other liquid.

- Adapter shall be easily accessible.

- This equipment can be powered only by equipment that complies with Power Source Class 2 (PS2) or Limited Power Source(LPS) defined in the standard of IEC 62368-1.

- Operating Temperature: -20 °C \~ 45 °C

- The light source of this luminaire is not replaceable; when the light source reaches its end of life, the whole luminaire shall be replaced. (Only for floodlight cameras)

• Weight of the floodlight camera (solar panel excluded): 680 g (23.99 oz). (Only for floodlight cameras)

• Maximum projected area of the floodlight: 14739.6 mm² (22.85 sq in). (Only for floodlight cameras)

• This product contains a light source of energy efficiency class E. (Only for floodlight cameras)

Non-replaceable light source

Non-replaceable control gear

CAUTION!

Avoid replacement of a battery with an incorrect type that can defeat a safeguard. Avoid disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion. Do not leave a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; Do not leave a battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas.

For Solar Panel

• Keep the device away from fire or hot environments. DO NOT immerse in water or any other liquid.
• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
• Avoid scratching and hitting the surface of the solar panel during use.
• Avoid contact with highly corrosive substances during use.
• The suitable temperature for Tapo Solar Panel and accessories is -20^ 45^ . The working temperature range for battery charging should be maintained at 0^ 45^ .
• Make sure the USB connector is fully plugged into your Tapo device.
• Make sure you follow the user manual to install the solar panel correctly.
  • Make sure the waterproof gasket and other accessories can protect the connectors on your Tapo device.
  The mounting height should not be higher than 2 meters.
  Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk.
