TILLREDA - Microwave Oven IKEA - Free user manual and instructions

Product type	Countertop microwave oven
Brand	IKEA
Model	TILLREDA
Interior volume	20 liters
Microwave power	700 W
Frequency	50 Hz
Supply voltage	230 V
Overall dimensions (W x H x D)	45 x 26 x 35 cm
Weight	10 kg
Color	White
Cavity material	Stainless steel
Control type	Manual with rotary knobs
Main functions	Heating, cooking, defrosting
Safety	Door safety lock, grounding
Care and cleaning	Clean the interior with a damp cloth after use; clean door seals; do not use abrasive cleaners
Spare parts and repairability	Replace the power cord by a professional; do not remove the protective cover
General information	Household use only, place on a worktop

Frequently Asked Questions - TILLREDA IKEA

How to clean the inside of the microwave oven?

Use a slightly damp cloth after each use. For a deep clean, place half a lemon in 300 ml of water, heat at full power for 10 minutes, then wipe with a soft dry cloth.

Can I use metal utensils in the microwave?

No, metal utensils or those with metallic finishes can cause arcing. Use only microwave-safe utensils.

How to test if a container is microwave-safe?

Place the empty container in the oven with a cup of water (250 ml) next to it. Heat at maximum power for 1 minute. If the container becomes hot, do not use it.

What to do if smoke comes out of the microwave?

Turn off the appliance or unplug it immediately. Keep the door closed to smother any flames. Do not open it until the smoke has cleared.

Can I heat hard-boiled eggs in the microwave?

No, whole eggs in their shell or hard-boiled eggs can explode, even after reheating. Avoid heating them in the microwave altogether.

How to avoid burns when heating liquids?

Liquids can boil over suddenly. Stir or shake the contents before consumption. Use open containers and be careful of splashes.

Can the oven be used by children?

Yes, children aged 8 and above can use it under supervision. Ensure they understand the risks. Children should not clean the appliance without supervision.

Can I install the microwave behind a cabinet door?

No, this can cause overheating. If the appliance is in a cabinet, the cabinet door must remain open during operation.

How to replace the power cord?

The power cord can only be replaced by the manufacturer, its service agent, or a qualified person due to the risk of electric shock.

Can I use the microwave to dry clothes or heating cushions?

No, this poses a fire or injury risk. The oven is designed solely for heating and cooking food.

USER MANUAL TILLREDA IKEA

a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks.
b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
c) WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.

ADDENDUM

If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation.

IMPORTANT SAFETY INSTRUCTIONS WARNING

To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:

1. Read and follow the specific: "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".

2. This device can be used by children of at least 8 years old and by people with reduced physical, sensory or mental capacities or lacking experience or knowledge, if they are properly supervised or if they were given instructions relating to the safe use of the device and if the risks involved have been understood. Children must not play with the device. Cleaning and maintenance by the user must not be carried out by unsupervised children.

3. Keep the appliance and its cord out of reach of children less than 8 years.

ENGLISH

1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
2. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
3. Heating beverages by microwaves can cause a sudden, delayed burst of boiling liquid.
4. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
5. Only use utensils that are suitable for use in microwave ovens.
6. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.

7. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.

8. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.

9. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
10. The oven should be cleaned regularly and any food deposits removed.
11. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
12. The appliance must not be installed behind a decorative door in order to avoid overheating.
13. The microwave oven must be operated with any cabinet door open.
14. This appliance is intended to be used in household and similar applications such as:

ENGLISH

• staff kitchen areas in shops, offices and other working environments;
• by clients in hotels, motels and other residential type environments;
• farm houses;

• bed and breakfast type environments.

• The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.

• Metallic containers for food and beverages are not allowed during microwave cooking.
• The appliance shall not be cleaned with a steam cleaner.
• The appliance is intended to be used freestanding or in a cabinet.
• The rear surface of appliances shall be placed against a wall.

• This appliance is for household and indoor use only. Don't use it outdoors!

• To protect against electric shock, do not immerse main parts of the product, cord or plug in water or other liquids.

• WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.

ENGLISH

TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION

DANGER

Electric Shock Hazard

Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.

WARNING

Electric Shock Hazard

Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord, use only a 3-wire extension cord.

1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.

2. If a long cord set or extension cord is used:

a) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.

b) The extension cord must be a grounding-type 3-wire cord.

c) The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally.

ENGLISH

CLEANING

Be sure to unplug the appliance from the power supply.

1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
5. Cleaning Tip★ For easier cleaning of the cavity walls that the food cooked can touch: Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100% microwave power for 10 minutes. Wipe the oven clean using a soft, dry cloth.

UTENSILS

CAUTION

Personal Injury Hazard It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.

See the instructions on "MATERIALS YOU CAN USE IN MICROWAVE OVEN OR TO BE AVOIDED IN MICROWAVE OVEN."

There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below. Utensil Test:

1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.

MATERIALS TO BE AVOIDED IN MICROWAVE OVEN

UTENSILS REMARKS
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle	May cause arcing. Transfer food into microwave-safe dish.
Metal or metaltrimmed utensils	Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed
Wood Wood will dry out when used in the microwave oven and may split or crack.

Sicherheitshinweise

POUR RÉDUIRE LE RISQUE DE BLESSURE AUX PERSONNES MISE À LA TERRE DE L'INSTALLATION DANGER

PER RIDURRE IL RISCHIO DI LESIONI FISICHE, COLLEGARE A TERRA L'APPARECCHIO

PERICOLO

INSTALLATION AF JORDFORBINDELSE FOR AT REDUCERE RISIKOEN FOR PERSONSKADE

FARE

FOR Å FORHINDRE RISIKOEN FOR PERSONSKADE VED JORDET INSTALLASJON

FARE

Turvallisuustiedot

VAROTOIMENPITEET, JOILLA VÄLTETÄÄN MAHDOLLINEN ALTISTUMINEN LIIALLISELLE MIKROAALTOENERGIALLE

HENKILÖIDEN LOUKKAANTUMISVAARAN PIENENTÄMINEN MAADOITUKSEN ASENTAMINEN VAARA

Sähköiskun vaara

Säkerhetsinformation

SÄKERHETSFÖRESKRIFTER FÖR ATT UNDVIKA EXPONERING FÖR HÖG MIKROVÅGSENERGI

FÖR ATT MINSKA RISKEN FÖR PERSONSKADOR VID EN JORDAD INSTALLATION FARA

BELANGRIJKE VEILIGHEIDSVOORSCHRIFTEN WAARSCHUWING

OM HET RISICO OP LETSEL BIJ PERSONEN TE VERMINDEREN MOET DE INSTALLATIE GEAARD ZIJN

GEVAAR

KEUKENGEREI WAARSCHUWING

UZIEMIĆ, ABY OGRANICZYĆ RYZYKO WYWOŁANIA OBRAŻEŃ CIAŁA NIEBEZPIECZEŃS- TWO

Ohutusteave

HOIATUSED LIIGSE MIKROLAINEKIIRGUSEGA KOKKUPUUTE VÄLTIMISEKS

VIGASTUSTE OHU VÄHENDAMISEKS PAIGALDISE MAANDAMISEL

OHT

Elektrilöögi oht

AIZSARGZEMĒJUMS, LAI SAMAZINĀTU PERSONU TRAUMU RISKU BĪSTAMĪBA

Elektrošoka risks

Saugos informacija

ATSARGUMO PRIEMONĖS, SKIRTOS IŠVENGTI GALIMO PER DIDELIO MIKROBANGŲ ENERGIJOS POVEIKIO

TRAUMOS RIZIKOS MAŽINIMAS: IŽEMINIMO IRENGIMAS PAVOJUS

Elektros smūgio pavojus

protože by mohly explodovat.

PEČLIVĚ SI POKYNY PŘEČTĚTE A USCHOVEJTE JE PRO POZDĚJŠÍ POUŽITÍ.

KE SNÍŽENÍ NEBEZPEČÍ ZRANĚNÍ OSOB MONTÁŽ S UZEMNĚNÍM NEBEZPEČÍ

PENTRU A REDUCE RISCUL DE RĂNIRE A PERSOANELOR CARE ÎMPĂMÂNTEAZĂ INSTALAȚIA PERICOL

Pericol de electrocutare

ZNÍŽENIE RIZIKA ÚRAZU OSÔB UZEMNENOU INŠTALÁCIOU NEBEZPEČENSTVO

UZEMLJENJE ZA SMANJENJE RIZIKA OD OZLJEDA OPASNOST

Opasnost od električnog udara Dodirivanje određenih unutarnjih komponenti može izazvati ozbiljne ozljede ili smrt. Ne rastavljejte uređaj.

UPOZORENJE

Opasnost od električnog udara Neispravno uzemljenje može uzrokovati električni udar. Uređaj ne ukopčavajte u električnu utičnicu prije ispravnog postavljanja i uzemljenja.

Ovaj uređaj mora biti uzemljen. U slučaju nastanka kratkog spoja, uzemljenje smanjuje rizik od električnog udara putem žice za pražnjenje električne struje. Ovaj uređaj opremljen je kabelom i adapterom za uzemljenje. Adapter mora biti ukopčan u ispravno postavljenu i uzemljenu utičnicu.

Savjetujte se s kvalificiranim električarom ili serviserom ako su upute za uzemljenje nejasne ili u slučaju bilo kakve sumnje u ispravnost uzemljenja uređaja. Ako je potreban produžni kabel, koristit isključivo kabel s tri žice.

1. Uređaj je isporučen s kratkim naponskim kabelom kako bi se izbjegao rizik od zapetljanja ili zapinjanja za duži kabel.

2. Pri uporabi duljeg kabela:

DA BISTE SMANJILI RIZIK OD TELESNE POVREDE SPOJITE NA NAPAJANJE SA UZEMLJENJEM OPASNOST

ZA ZMANJŠANJE TVEGANJA POŠKODB OSEB OB NAMESTITVI OZEMLJITVE NEVARNOST

Информация за безопасност

Güvenlik bilgileri
