USER MANUAL Easy 41PB Plus ARDES

3. Safety screw of the fan

5. Lock ring of the back grille

16. Screw and washer

A-B. Locking pin for the rear grille DO NOT expose yourself for a long period to the air ow generated by the device because it can cause damage to the health. If the fan must be stored for a long period and is not used regularly, place the fan in its original packaging in a dry place. When you use it for the rst time after a long period of inactivity, make sure the fan is clean and the motor blades turn feely (with the device not powered) without any restraint.13 Place the fan on a at, dry and stable surface, and insert the plug of the fan in a socket. Select the desired speed by rotating the knob on the control panel (10): 0 = o󰀨 1 = minimum speed 2 = medium speed 3 = maximum speed OSCILLATION: For the automatic oscillation from right to left press the knob (8) placed on top of the motor. To disable it, pull up the knob. VERTICAL SLOPE: You can vertically point the front of the fan choosing the desired angle. It is su󰀩cient to move the front of the fan up or down according to the desired slope. ADJUSTMENT HEIGHT Loosen the height adjustment knob (13), then set the desired height for the fan. Tighten rmly the knob after adjusting the rod. N.B: this operation must always be carried out while the fan is turned o󰀨.
