USER MANUAL RR25A5410S9 SAMSUNG

Refrigerator User manual Free Standing Appliance Untitled-6 1 2022-11-01 3:56:51English2 Contents Contents Safety information 3 What you need to know about the safety instructions 3 Important safety symbols and precautions: 5 Important safety precautions 6 Severe warning signs for transportation and site 9 Critical installation warnings 10 Installation cautions 14 Critical usage warnings 14 Usage cautions 19 Cleaning cautions 22 Critical disposal warnings 24 Additional tips for proper usage 25 Instructions about the WEEE 26 Installation 27 Refrigerator at a glance 27 Step-by-step installation 28 Operations 34 Control panel 34 Maintenance 35 Door reversal 35 Handle and care 44 Cleaning 45 Replacement 45 Pair installation 46 Troubleshooting 53 General 53 Do you hear abnormal sounds from the refrigerator? 55

Safety Instruction 57 Install Instruction 57 Temperature Instruction 58 Information for model and ordering spare parts 61 Untitled-6 2 2022-11-01 3:56:51English 3 Safety information Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efciently. What you need to know about the safety instructions

• Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your appliance.

• Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact your nearest service center or nd help and information online at www.samsung.com.

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your appliance. When this product contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used. Safety information Untitled-6 3 2022-11-01 3:56:51Safety information English4 Safety information

• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room must be 1 m

in size for every 8 g of R-600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identication plate inside the appliance.

• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When refrigerant leaks from the pipe, avoid any naked ames and move anything ammable away from the product and ventilate the room immediately. - Failing to do so may result in re or explosion.

• To avoid contamination of food, please respect the following instructions: - Opening the door for long periods can cause a signicant increase of the temperature in the compartments of the appliance. - Clean regularly surfaces that can come in contact with food and accessible drainage systems. - Clean water tanks if they have not been used for 48 h; ush the water system connected to a water supply if water has not been drawn for 5 days - Store raw meat and sh in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food. - Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making icecream and making ice cubes. Untitled-6 4 2022-11-01 3:56:51English 5 Safety information - One-, two- and three-star compartments are not suitable for the freezing of fresh food.- If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance. Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. NOTE Useful information that helps users understand or benet from the refrigerator. These warning signs are here to prevent injury to you and others. Please follow them carefully. After reading this section, keep it in a safe place for future reference. Untitled-6 5 2022-11-01 3:56:52Safety information English6 Safety information Important safety precautions Warning; Risk of re / ammable materials WARNING

• When positioning the appliance, ensure the supply cord is not trapped or damaged.

• Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.

• Fill with potable water only.

• Connect to potable water supply only.

• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

• Do not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or those who lack experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. Untitled-6 6 2022-11-01 3:56:52English 7 Safety information

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.

• The socket must be easily accessible so that the appliance can be quickly disconnected from the supply in an emergency. - It must be outside the area of the rear of the appliance.

• Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.

• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center. - Use only the LED Lamps provided by the manufacturer or its service agents.

• New hose-sets supplied with the appliance are to be used and old hose-sets should not be reused.

• Have the refrigerator’s water supply connected only to a potable water supply. To operate the ice maker properly, water pressure of 206-861 kPa (30-125 psi) is required. Untitled-6 7 2022-11-01 3:56:52Safety information English8 Safety information

• For the most efcient use of energy, please keep the all inner ttings such as baskets, drawers, shelves on the position supplied by manufacturer.

• To get the best energy efciency of this product, please leave all shelves, drawers and baskets on their original position. How to minimize the energy consumption

• Install the appliance in a cool, dry room with adequate ventilation.

• Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (radiator, for example). - Not to block any vents or grilles is recommended for energy efciency. - Allow warm food to cool down before placing it in the appliance. - Put frozen food in the refrigerator to thaw. You can then use the low temperatures of the frozen products to cool food in the refrigerator. - Do not keep the door of the appliance open for too long when putting food in or taking food out. - The shorter time for which the door is open, the less ice will form in the refrigerator. - Clean the rear of the refrigerator regularly. Dust increases energy consumption. - Do not set temperature colder than necessary. - Ensure sufcient air exhaust at the refrigerator base and at the back wall of the refrigerator. Do not cover air vent openings. Untitled-6 8 2022-11-01 3:56:52English 9 Safety information - Allow clearance to the right, left, back and top when installing. This will help reduce power consumption and keep your energy bills lower. This appliance is intended to be used in household and similar applications such as - staff kitchen areas in shops, ofces and other working environments; - farm houses and by clients in hotels, motels and other residential type environments; - bed and breakfast type environments; - catering and similar non-retail applications. Severe warning signs for transportation and site WARNING

• When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak is detected, avoid any naked ames or potential sources of ignition and air the room in which the appliance is standing for several minutes. Untitled-6 9 2022-11-01 3:56:52Safety information English10 Safety information - This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

• When transporting and installing the refrigerator, do not touch the water hose on the back side of the refrigerator. - This may damage the refrigerator and as a result the water dispenser can not be used. Critical installation warnings WARNING

• Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or re.

• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.

• Do not plug several appliances into the same multiple power strip. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate. - This provides the best performance and also prevents overloading of house wiring circuits, which could cause a re hazard from overheated wires. Untitled-6 10 2022-11-01 3:56:52English 11 Safety information

• If the wall socket is loose, do not insert the power plug. - There is a risk of electric shock of re.

• Do not use a power cord that has cracks or abrasion damage along its length or at either end.

• Do not bend the power cord excessively or place heavy objects on it.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.

• When moving the refrigerator, be careful not to roll over or damage the power cord. - This may result in an electric shock or re.

• Never unplug your refrigerator by pulling on the power cord. Always grip the plug rmly and pull straight out from the outlet. - Damage to the cord may cause a short-circuit, re, and/ or electric shock.

• Do not use aerosols near the refrigerator. - Using aerosols near the refrigerator may cause an explosion or re.

• Do not install this appliance near a heater or inammable material.

• Do not install this appliance in a location where gas may leak. - This may result in an electric shock or re. Untitled-6 11 2022-11-01 3:56:52Safety information English12 Safety information

• This refrigerator must be properly located and installed in accordance with the instructions in this manual before you use it.

• Connect the power plug in the proper position with the cord hanging down. - If you connect the power plug upside down, the wire can get cut off and cause a re or electric shock.

• Make sure that the power plug is not crushed or damaged by the back of the refrigerator.

• Keep the packing materials out of reach of children. - There is a risk of death from suffocation if a child puts the packing materials on his or her head.

• Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). - Deteriorated insulation of electrical parts may cause an electric shock or re.

• If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in an electric shock, re, problems with the product, or injury.

• You need to remove all the protective plastic lm before you initially plug the product in. Untitled-6 12 2022-11-01 3:56:52English 13 Safety information

• Children should be supervised to ensure that they do not play with the snap rings used for door adjustment or the water tube clips. - There is risk of death by suffocation if a child swallows a snap ring or water tube clip. Keep the snap rings and water tube clips out of children’s reach.

• The refrigerator must be safely grounded. - Always make sure that you have grounded the refrigerator before attempting to investigate or repair any part of the appliance. Power leakages can cause severe electric shock.

• Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground. - You must ground the refrigerator to prevent any power leakages or electric shocks caused by current leakage from the refrigerator. - This may result in an electric shock, re, explosion, or problems with the product.

• Plug the power plug into the wall socket rmly. Do not use a damaged power plug, damaged power cord, or loose wall socket. - This may result in an electric shock or re.

• The fuse on the refrigerator must be changed by a qualied technician or service company. - Failing to do so may result in an electric shock or personal injury. Untitled-6 13 2022-11-01 3:56:52Safety information English14 Safety information Installation cautions CAUTION

• Allow sufcient space around the refrigerator and install it on a at surface. - If your refrigerator is not level, cooling efciency and durability can be declined.

• Allow the appliance to stand for 2-3 hours before loading foods after installation and turning on.

• We strongly recommend you have a qualied technician or service company install the refrigerator. - Failing to do so may result in an electric shock, re, explosion, problems with the product, or injury. Critical usage warnings WARNING

• Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock.

• Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage.

• Do not insert hands, feet or metal objects (such as chopsticks, etc.) into the bottom or the back of the refrigerator. - This may result in an electric shock or injury. - Any sharp edges may cause a personal injury. Untitled-6 14 2022-11-01 3:56:52English 15 Safety information

• Do not touch the inside walls of the refrigerator or products stored in the refrigerator with wet hands. - This may cause frostbite.

• Do not put a container lled with water on the refrigerator. - If spilled, there is a risk of re or electric shock.

• Do not keep volatile or ammable objects or substances (benzene, thinner, propane gas, alcohol, ether, LP gas, and other such products) in the refrigerator. - This refrigerator is for storing food only. - This may result in re or explosion.

• Children should be supervised to ensure that they do not play with the appliance. - Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.

• Do not put your ngers or children's ngers between the doors. - Keep ngers out of the left and right door gaps. Be careful when you open the doors if your ngers are in between the doors.

• Do not let children hang on the door or door bins. A serious injury may occur.

• Do not let children go inside the refrigerator. They could become trapped.

• Do not insert your hands into the bottom area under the appliance. - Any sharp edges may cause personal injury. Untitled-6 15 2022-11-01 3:56:52Safety information English16 Safety information

• Do not store pharmaceutical products, scientic materials, or temperature sensitive products in the refrigerator. - Products that require strict temperature controls must not be stored in the refrigerator.

• If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center.

• If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re.

• Do not let children step on a drawer. - The drawer may break and cause them to slip.

• Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter inside the refrigerator.

• Do not allow babies or children go inside the drawer. - It can cause death from suffocation by entrapment or personal injury.

• Do not overll the refrigerator with food. - When you open the door, an item may fall out and cause personal injury or material damage.

• Do not spray volatile material such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in an electric shock, re, or problems with the product.

• Never put ngers or other objects into the water dispenser hole, ice chute and ice maker bucket. - It may cause a personal injury or material damage. Untitled-6 16 2022-11-01 3:56:52English 17 Safety information

• Do not use or place any substances sensitive to temperature such as ammable sprays, ammable objects, dry ice, medicine, or chemicals near or inside of the refrigerator.

• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator for removing bad odours. - This may result in an electric shock or re.

• Fill the water tank, ice tray and water cubes only with potable water (mineral water or puried water). - Do not ll the tank with tea, juice or sports drink, this may damage the refrigerator.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in an electric shock, re, problems with the product, or injury. Do not put a container lled with water on the appliance. - If spilled, there is a risk of re or electric shock.

• Never stare directly at the UV LED lamp for long periods of time. - This may result in eye strain due to the ultraviolet rays.

• Do not put shelf in upside down. Shelf stopper could not work. - It may cause a personal injury because of glass shelf drop.

• Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area. Untitled-6 17 2022-11-01 3:56:52Safety information English18 Safety information

• If a gas leak is detected, avoid any naked ames or potential sources of ignition, and air the room in which the appliance is standing for several minutes. - Do not touch the appliance or power cord. - Do not use a ventilating fan. - A spark may result in explosion or re.

• Bottles should be stored tightly together so that they do not fall out.

• This product is intended only for the storage of food in a domestic environment.

• Never put ngers or other objects into the water dispenser hole, ice chute and ice maker bucket. - It may cause a personal injury or material damage.

• Do not attempt to repair, disassemble, or modify the refrigerator yourself.

• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse.

• If your refrigerator needs to be repaired or reinstalled, contact your nearest service center. - Failing to do so may result in an electric shock, re, problems with the product, or injury.

• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or re hazards.

• Pull the power plug out of the socket before changing the interior lamps of the refrigerator. - Otherwise, there is a risk of electric shock.

• If you experience difculty changing a non-LED light, contact a Samsung service center. Untitled-6 18 2022-11-01 3:56:52English 19 Safety information

• Plug the power plug into the wall socket rmly.

• Do not use a damaged power plug, damaged power cord or loose wall socket. - This may result in an electric shock or re. Usage cautions CAUTION

• Do not refreeze thawed food. - Frozen and thawed food will develop harmful bacteria faster than fresh. - The second thaw will break down even more cells, leaching out moisture and changing the integrity of the product.

• Do not thaw meat at room temperature. - Safety will depend on whether the raw product was handled properly.

• Do not place glass bottles or carbonated beverages into the refrigerator. - The container may freeze and break, and this may result in injury.

• Use only the ice maker provided with the refrigerator.

• If you will be away from home for a long period of time (on vacation, for example) and won’t be using the water or ice dispensers, close the water valve. - Otherwise, water leakage may occur. Untitled-6 19 2022-11-01 3:56:52Safety information English20 Safety information

• If you won’t be using the refrigerator for a very long period of time, (3 weeks or more) empty the refrigerator including the ice bucket, unplug it, close the water valve, wipe excess moisture from the inside walls, and leave the doors open to prevent odors and mold.

• To get the best performance from the product: - Do not place food too close to the vents at the rear of the refrigerator as this can obstruct free air circulation in the refrigerator compartment. - Wrap food up properly or place it in airtight containers before putting it into the refrigerator. - Please observe maximum storage times and expiration dates of frozen goods. - There is no need to disconnect the refrigerator from the power supply if you will be away for less than three weeks. However, if you will be away for more than three weeks, remove all the food and ice in the ice bucket, unplug the refrigerator, close the water valve, wipe excess moisture from the inside walls, and leave the doors open to prevent odors and mold.

• Service Warranty and Modication. - Any changes or modications performed by a 3rd party on this nished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modications. Untitled-6 20 2022-11-01 3:56:52English 21 Safety information

• Do not block the air vents inside the refrigerator. - If the air vents are blocked, especially with a plastic bag, the refrigerator can be over cooled. If a cooling period lasts too long, the water lter may break and cause water leakage.

• Use only the ice-maker provided with the refrigerator.

• Wipe excess moisture from the inside and leave the doors open. - Otherwise, odor and mold may develop.

• If the refrigerator is disconnected from the power supply, you should wait for at least ve minutes before plugging it back in.

• When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center.

• Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage.

• Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or puried water). - Do not ll the tank with tea or a sports drink. This may damage the refrigerator.

• Be careful that your ngers are not caught in.

• If the refrigerator is ooded, make sure to contact your nearest service center. - There is a risk of electric shock or re. Untitled-6 21 2022-11-01 3:56:52Safety information English22 Safety information

• Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difcult to use. In addition, the open container can leak and the leaked oil can cause the door bin to crack. After opening an oil container, it is best to keep the container in a cool and shaded place such as a cupboard or pantry. - Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc. Cleaning cautions CAUTION

• Do not spray water directly on the inside or outside the refrigerator. - There is a risk of re or electric shock.

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not place a lighted candle in the refrigerator to remove bad odors. - This may result in an electric shock or re.

• Do not spray cleaning products directly on the display. - Printed letters on the display may come off.

• If any foreign substance such as water has entered the appliance, unplug the power plug and contact your nearest service center. - Failing to do so may result in an electric shock or re. Untitled-6 22 2022-11-01 3:56:52English 23 Safety information

• Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug. - Otherwise, there is a risk of re or electric shock.

• Do not clean the appliance by spraying water directly onto it.

• Do not use benzene, thinner, or Clorox, Chloride for cleaning. - They may damage the surface of the appliance and may cause a re.

• Never put ngers or other objects into the dispenser hole. - It may cause a personal injury or material damage.

• Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Failing to do so may result in an electric shock or re.

• Use a clean sponge or soft cloth and a mild detergent in warm water to clean the refrigerator.

• Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, ammable uids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.

• Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impacts such as bumping or dropping. Untitled-6 23 2022-11-01 3:56:53Safety information English24 Safety information Critical disposal warnings WARNING

• Please dispose of the packaging material from this product in an environmentally friendly manner.

• Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal.

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. If this refrigerator contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• When disposing of this refrigerator, remove the door/ door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance. If trapped inside, a child may get hurt or suffocate to death. - If trapped inside, the child may become injury and suffocate to death.

• Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product.

• Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. - If a child places a bag over his or her head, the child could suffocate. Untitled-6 24 2022-11-01 3:56:53English 25 Safety information Additional tips for proper usage

• In the event of a power failure, call the local ofce of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off. - Should the power failure last more than 24 hours, remove and discard all frozen food.

• The refrigerator might not operate consistently (frozen contents can thaw or temperatures can become too warm in the frozen food compartment) if sited for an extended period of time in a location where ambient air temperatures are constantly below the temperatures for which the appliance is designed.

• In case of particular foods, keeping it under refrigeration can have a bad effect on preservation due to its properties.

• Your appliance is frost free, which means there is no need to manually defrost your appliance. This will be carried out automatically.

• Temperature rise during defrosting complies with ISO requirements. If you want to prevent an undue rise in the temperature of frozen food while the appliance defrosts, wrap the frozen food in several layers of newspaper.

• Do not re-freeze frozen foods that have thawed completely. Untitled-6 25 2022-11-01 3:56:53Safety information English26 Safety information Instructions about the WEEE Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government ofce, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, WEEE or Batteries, visit our sustainability page available via www. samsung.com (For products sold in European countries and in the UK only) Untitled-6 26 2022-11-01 3:56:53English 27 Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING

• Use the refrigerator only for its intended purpose as described in this manual.

• Any servicing must be performed by a qualied technician.

• Dispose of the product packaging material in compliance with the local regulations.

• To prevent electric shock, unplug the power cord before servicing or replacements. Refrigerator at a glance The actual image and provided parts of the refrigerator may differ, depending on the model and the country.

• For best energy efciency, make sure all of shelves, drawers, and baskets are placed in their original position. Installation Untitled-6 27 2022-11-01 3:56:53Installation English28 Installation Step-by-step installation STEP 1 Select a site Site requirements:

• Solid, level surface without carpeting or ooring that may obstruct ventilation

• Away from direct sunlight

• Adequate room for opening and closing the door

• Away from a heat source

• Room for maintenance and servicing

• Temperature range: between 10 °C and 43 °C Clearance See the following gures and tables for space requirements for installation.

Depth “A” 685Width “B” 455Overall Height “C” 1853 (unit : mm) Untitled-6 28 2022-11-01 3:56:53English 29 Installation

01 more than 50 mm recommended 02 more than 12 mm recommended 03 105°

(unit : mm) NOTE The measurements in the table may differ, depending on the measuring method. Untitled-6 29 2022-11-01 3:56:53Installation English30 Installation STEP 2 Flooring

• The surface to install the refrigerator must support a fully loaded refrigerator.

• To protect the oor, put a large piece of cardboard on each foot of the refrigerator.

• Once the refrigerator is in its nal position, do not move it unless necessary to protect the oor. If you have to, use a thick paper or cloth such as old carpet along the movement path. STEP 3 Installing as a standalone product CAUTION When installing as a standalone product, make sure to install brackets or supports to prevent the product from tipping over. Important

• If using the product, which is narrow, as a standalone unit, you must install the included brackets or supports and thereby prevent the product from shaking and tilting. If you use the product without installing the brackets or supports on the product’s rear, the weight of the refrigerator’s door and the food stored inside the refrigerator can cause the product to tilt and fall over (on to the door side).

• If installing as a standalone unit, you may need to set the product next to a cabinet or install brackets or supports. Please consult your installation technician on the installation spot and method. - If installing supports, you need minimum 10 cm of clearance on left and right sides of the product. CAUTION

• If brackets or supports are not installed, the product could topple over and cause a serious injury.

• Use of brackets or supports is strongly recommended if installing the product as a standalone unit.

• Make sure to install the brackets or supports whenever you relocate the product (such as after moving to a new home).

• Do not hang on the refrigerator’s door while it’s open.

• Check the refrigerator’s level after installing.

• When installing the supports, carefully lay the refrigerator down on the oor while being mindful not to damage the oor.

• When pushing the product in, make sure the power cord does not get stuck between the brackets. Untitled-6 30 2022-11-01 3:56:53English 31 Installation STEP 4 Bracket Installation

1. Position the bracket so that the part

with the holes is up against the wall at the same level as the height of the product and secure the bracket in place using two screws. - If the wall is a concrete wall, use a concrete drill.

2. Push the product in and securely

position it under the left and right brackets. - Make sure the bracket is covering at least 10 cm from the back of the product. CAUTION When pushing the product in, make sure the power cord does not get stuck between the brackets. STEP 5 Support Installation

1. Lay the product down on the oor on

its rear. Undo the single screw next to the left and right wheels on the rear side of the product. Untitled-6 31 2022-11-01 3:56:54Installation English32 Installation

2. Install the supports using two screws

3. Stand the product up, rotate the dials

of the supports so that the dials touch the oor, install the support covers, and screw the covers in place. Untitled-6 32 2022-11-01 3:56:54English 33 Installation STEP 6 Initial settings By completing the following steps, the refrigerator should be fully functioning.

1. Remove the PE foam sheet on each shelf corner, which is attached to protect the

refrigerator during transportation.

2. Plug the power cord into the wall socket to turn the refrigerator on.

3. Open the door, and check if the interior light lights up.

4. Set the temperature to the lowest, and wait until the refrigerator reaches the set

temperature. Now the refrigerator is ready for use. NOTE When the refrigerator powers on, the alarm will sound. To turn off the alarm, press Temp.. STEP 7 Final check When installation is complete, conrm that:

• The refrigerator is plugged into an electrical outlet and grounded properly.

• The refrigerator is installed on a at, level surface with a reasonable clearance from the wall or the cabinet.

• The refrigerator is level and is sitting rmly on the oor.

• The door opens and closes freely, and the interior light turns on automatically when you open the door. Untitled-6 33 2022-11-01 3:56:54English34 Operations Control panel

• Press the Temp. to change the temperature setting. - Fridge mode: You can change the temperature between 1 °C and 7 °C. - Soft Freeze mode: You can change the temperature between -5 °C and -1 °C.

• Press and hold Temp. for 3 seconds to change the refrigerator mode. 02 Door Alarm You can set the alarm for reminder. If the door is left open for more than 2 minutes, the alarm will sound with the Alarm indicator blinking. You can toggle to enable and disable the alarm by pressing Door Alarm. 03 Lock (3 sec) To prevent accidental manipulation, press and hold Lock for 3 seconds to activate the Lock. All controls will be disabled with the LED indicator on the left side of the button on. To deactivate, press and hold again for 3 seconds. The controls will be enabled as normal. Operations Untitled-6 34 2022-11-01 3:56:54English 35 Maintenance Door reversal WARNING

• The warranty does not cover reversal failure or property damage occurring due to unapproved agencies.

• Make sure that the refrigerator is disconnected from the power source before reversing the door.

• You must wait for at least an hour after door reversal is complete. This is to prevent any electric shock that could occur.

• Reversing the door must be performed by Samsung-approved servicing personnel at your own expense because this kind of servicing is not covered by the Warranty. CAUTION The door is heavy. Have at least two people work on the door reversal. Otherwise, it may cause a personal injury. Tools required (not provided) Phillips screwdriver Flat-head screwdriver Adjustable wrench 8 mm socket wrench (for bolts) Accessories The accessories below may differ in appearance depending on the model. Top-right door hinge Top-left door cover Top-right door hinge cover CAUTION Throughout the entire reversal procedure, keep all the small parts (screws, caps, etc.) of the refrigerator away from children or infants for safety reasons. Maintenance Untitled-6 35 2022-11-01 3:56:55Maintenance English36 Maintenance Step-by-step instructions

1. Use a at-head screwdriver to remove

the top-left door hinge cover (A). NOTE Keep the removed part in a safe place for later use.

the screws fastening the top-left door hinge (B).

3. Lift the top-left door hinge (B) to

remove it. NOTE Keep the removed part in a safe place for later use. Untitled-6 36 2022-11-01 3:56:55English 37 Maintenance

4. Lift the door to remove it from the

bottom hinge. CAUTION The door is heavy. To prevent damage or injury, use caution while removing the door.

5. Remove the top-right door cover (C)

from the door. NOTE Keep the removed part in a safe place for later use.

6. Attach the provided top-left door cover

(R) to the door. Untitled-6 37 2022-11-01 3:56:56Maintenance English38 Maintenance

door cam riser (E) and the door stopper (F) in that order. - Use a Phillips screwdriver to remove the screw fastening each part.

8. Fasten the door stopper (F) and the

door cam riser (E), in that order, to the opposite side of the door. - Use a Phillips screwdriver to fasten each part with the screw.

9. Carefully lay the refrigerator down.

counterclockwise to remove it.

opposite side of the bottom hinge.

17. Use a Phillips screwdriver to fasten the

18. Use an adjustable wrench to fasten the

the screw (J). Untitled-6 38 2022-11-01 3:56:56English 39 Maintenance

opposite side. - Use a socket wrench (8 mm) to fasten the bottom hinge (G) with the screws.

22. Carefully stand the refrigerator back up.

the screw cover (N).

25. Use a Phillips screwdriver to fasten the

screw into the hole on the opposite side. Untitled-6 39 2022-11-01 3:56:56Maintenance English40 Maintenance

26. Attach the screw cover (N) to the

the top-right door hinge (P) with the screws. Untitled-6 40 2022-11-01 3:56:57English 41 Maintenance

reattach it to the door. Untitled-6 41 2022-11-01 3:56:57Maintenance English42 Maintenance Reversing the door handle position

1. Remove the handle covers.

2. Use a Phillips screwdriver to remove the

screws and detach the handle.

3. Use a at-head screwdriver to remove

the hole caps from the opposite side of the door.

4. Insert the hole caps into the holes from

which you detached the handle. Untitled-6 42 2022-11-01 3:56:58English 43 Maintenance

5. Place the handle on the opposite side

of the door, aligning the holes on the handle and the door.

6. Use a Phillips screwdriver to attach the

handle with the screws.

7. Attach the handle covers.

Untitled-6 43 2022-11-01 3:56:58Maintenance English44 Maintenance Handle and care Shelves Slightly lift up the rear side of the shelf to pull out. Door bins Slightly lift up and pull out the door bin. CAUTION To prevent accidents, empty the door bins before removing. Untitled-6 44 2022-11-01 3:56:58English 45 Maintenance Cleaning Interior and exterior WARNING

• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning purposes. They may damage the surface of the refrigerator and cause a re.

• Do not spray water onto the refrigerator. This may cause an electric shock. Regularly use a dry cloth to remove all foreign substances such as dust or water from the power plug terminals and contact points.

1. Unplug the power cord.

2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior

3. When done, use a dry cloth or paper towel to dry well.

4. Plug in the power cord.

Replacement LED Lamps To replace the lamps of the refrigerator, contact a local Samsung service center. WARNING

• The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause an electric shock. Lamp (Light Source) This product contains a light source of energy efciency class <G>. The lamp(s) and/or control gear(s) are not user-serviceable. To replace the lamp(s) and/or control gear(s) in the product, contact a local Samsung service centre. For detailed instructions on replacing lamp(s) or control gear(s) in your product, visit the Samsung website (http://www.samsung.com), go to Support > Support home, and then enter the model name. For detailed instructions on dismantling lamp(s) and/or control gear(s), simply follow the replacement instruction reached as described above. Door panel (applicable models only) You can select the door panel you prefer for your BESPOKE refrigerator. Purchase the door panel at a Samsung retail store and an authorized installer will install the panel for you. CAUTION

• Disassembling or assembling the door panel on your own may result in product damage or personal injury. If you nd any problems with the door panel, contact a Samsung service center

• A service fee may be charged for panel replacement even within the warranty period. Untitled-6 45 2022-11-01 3:56:58Maintenance English46 Maintenance Pair installation You can install this refrigerator side by side with another Samsung refrigerator if you want. However, the refrigerators must be the BESPOKE models. If you want the pair installation, check if the desired models allow pair installation before purchasing them. You can check it at the retail store or Samsung.com website. NOTE Purchase the pair installation kit at a Samsung retail store and you can request an authorized installer for pair installation.

01 more than 50 mm recommended 02 105° 03 1181 mm 04 1047 mm 05 Locker xer 06 Fixer 07 Install direction Tools required (not provided) Phillips screwdriver Flat-head screwdriver 8 mm socket wrench (for bolts) Untitled-6 46 2022-11-01 3:56:58English 47 Maintenance Pair installation kit accessories 01 Upper bracket (1) 02 Lower bracket (1) 03 Trim (1) 04 A/S Jig-sheet ref (4) 05 Level adjustment pad (4) 06 T7 LEX foam (8) 07 T5 PE foam (1) 08 Rear bracket (1) 09 M5 x 16 hex screws (4) 10 M4 x 18 screws (2) NOTE The number in parenthesis refers to the quantity of each accessory. Untitled-6 47 2022-11-01 3:56:59Maintenance English48 Maintenance Step-by-step instruction NOTE The numbers on the gure and in the parenthesis are the same as those in the accessories list.

1. Check the level of the oor.

- Use a level to check the level of the oor where the refrigerator’s two rear casters will be placed.

check the level. - Place the two provided A/S jig-sheet refs (04) on the oor where the refrigerator’s two rear casters will be placed, and then check the level. - If the oor is not level, put the provided level adjustment pads (05) under the A/S jig-sheet refs (04) so the refrigerator will stand on a level surface. - Once you sort out all the necessary parts to level, peel off the double- sided tape on the bottom of each part and attach the part in its nal position. Untitled-6 48 2022-11-01 3:57:00English 49 Maintenance

3. Attach the foam(s) to maintain a gap

between the two refrigerators. A. Pair install with the one door model: - If the gap between refrigerators is 7 mm, use four T7 LEX foams (06) and attach them to one of the refrigerators. - If the gap between refrigerators is 15 mm, use eight T7 LEX foams (06) and attach them to one of the refrigerators. (Stack two foams for each position.) - See the gure for the position of the foams.

B. Pair install with the BMF (Bottom- mounted freezer) model: - Attach the T5 PE foam (07) on the BMF (Bottom-mounted freezer) model, and then attach four T7 LEX foams (06) on top of the T5 PE foam (07). - See the gure for the position of the foams. NOTE You must attach the T5 PE foam (07) to the BMF (Bottom-mounted freezer) model only. (In case you install two different types of refrigerators in pair.)

4. Align the two refrigerators.

- Check the alignment at the top and front of the refrigerators and realign them if necessary. Untitled-6 49 2022-11-01 3:57:00Maintenance English50 Maintenance

5. Remove the screws from the two holes

where the lower bracket will be fastened to. - Open the door of the refrigerators to be paired, and then remove the screws located where the lower bracket will be fastened.

- Fasten the lower bracket (02) with the two M4 x 18 screws (10) (one fastened to each refrigerator) to secure the lower parts of the refrigerators.

- Fasten the upper bracket (1) with the four M5 x 16 hex screws (09) to secure the top part of the refrigerators. NOTE Align the tops of the refrigerators before fastening the upper bracket.

8. Remove the screws at the back of the

9. Use the screws removed from step 8 to

10. Check the spacing between the

refrigerators. - After fastening the upper and lower brackets, make sure the spacing between the refrigerators is 7 or 15 mm at the top and bottom. NOTE If the spacing between the refrigerators is greater than 7 or 15 mm, there may be less room between the refrigerator and the walls (or cabinets), and this may interfere when opening the doors.

11. Push the refrigerators into the walls (or

cabinets). - Have two people simultaneously push the refrigerators, xed with brackets, into the walls (or cabinets). NOTE If the two people do not push the refrigerators evenly, the rear parts of the refrigerators may spread out or may deviate from their intended spot.

12. Adjust the height of the refrigerators.

- Turn the leveling leg right or left to adjust the height of the refrigerators to be ush with the walls (or cabinets). Untitled-6 51 2022-11-01 3:57:01Maintenance English52 Maintenance

13. Insert the trim (03) between the

refrigerators. - Open the doors and insert the trim (03) between the refrigerators. NOTE See the enlarged part of the trim in the gure to identify the trim’s top side.

- If there are no problems, peel all the protective lm off the product. Untitled-6 52 2022-11-01 3:57:01English 53 Troubleshooting Before calling for service, review the checkpoints below. Any service calls regarding normal situations (No Defect Cases) will be charged to users. General Temperature Symptom Possible causes Solution The refrigerator does not operate. The refrigerator temperature is warm.

• The power cord is not plugged in properly.

• Properly plug in the power cord.

• Temperature control is not set correctly.

• Set the temperature lower.

• The refrigerator is located near a heat source or direct sunlight.

• Keep the refrigerator away from direct sunlight or a heat source.

• Not enough clearance between refrigerator and sides/rear.

• We recommend that the gap between the refrigerator and nearby walls (or cabinets) is more than 50 mm.

• The refrigerator is overloaded. Food is blocking the refrigerator vents.

• Do not overload the refrigerator. Do not allow food to block ventilation. The refrigerator is over-cooling.

• Temperature control is not set correctly.

• Set the temperature higher. The interior wall is hot.

• The refrigerator has heat- proof piping in the interior wall.

• To prevent condensation from forming, the refrigerator has heat-proof piping in the front corners. If the ambient temperature rises, this equipment may not work effectively. This is not a system failure. Troubleshooting Untitled-6 53 2022-11-01 3:57:01Troubleshooting English54 Troubleshooting Odors Symptom Possible causes Solution The refrgierator has odors.

• Clean the refrigerator and remove any spoiled food.

• Food with strong odors.

• Make sure strong smelling food is wrapped airtight. Frost Symptom Possible causes Solution Frost around the vents.

• Food is blocking the vents.

• Make sure no food blocks the refrigerator vents. Frost on interior walls.

• Door is not closed properly.

• Make sure food does not block the door. Clean the door gasket. Condensation Symptom Possible causes Solution Condensation forms on the interior walls.

• If the door is left open, moisture enters the refrigerator.

• Remove the moisture and do not open the door for a long time.

• Food with high moisture content.

• Make sure food is wrapped airtight. Untitled-6 54 2022-11-01 3:57:02English 55 Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal.

• When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting. As the operation stabilizes, the sounds will decrease. Clicking! or Chirping! Buzzing!

• While the fan is operating, these sounds may occur. When the refrigerator reaches the set temperature, no fan sound will occur. SSSRRR!Whir!

• During a defrost cycle, water may drip on the defrost heater, causing sizzling sounds. HiSS! Untitled-6 55 2022-11-01 3:57:02Troubleshooting English56 Troubleshooting

• As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling!

• As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working. Cracking!

• For ice maker models: When the water valve opens to ll the ice maker, buzzing sounds may occur.

• Due to pressure equalizing when opening and closing the refrigerator door, whooshing sounds may occur. Untitled-6 56 2022-11-01 3:57:02English 57 Appendix Safety Instruction

• For the most efcient use of energy, please keep the all inner ttings such as baskets, drawers, shelves and ice cube tray on the position supplied by manufacturer.

• This refrigerating appliance is not intended to be used as a built-in appliance. Install Instruction For refrigerating appliances with climate class Depending on the climate class, This refrigerating appliance is intended to be used at ambient temperatures range as specied following table. The climate class can be found on the rating plate. The product may not operate properly at temperatures outside of the specic range. You can nd climate class on label inside of your refrigerator Effective temperature range The refrigerator is designed to operate normally in the temperature range specied by its class rating. Class Symbol Ambient Temperature range (°C)

IEC 62552 (ISO 15502) ISO 8561

Extended Temperate SN +10 to +32 +10 to +32 Temperate N +16 to +32 +16 to +32 Subtropical ST +16 to +38 +18 to +38 Tropical T +16 to +43 +18 to +43 NOTE The cooling performance and power consumption of the refrigerator may be affected by the ambient temperature, the door-opening frequency, and the location of the refrigerator. We recommend adjusting the temperature settings as appropriate. Untitled-6 57 2022-11-01 3:57:02Appendix English58 Temperature Instruction Recommended Temperature The optimal temperature setting for food storage:

• Soft Freeze: -3 °C NOTE The optimal temperature setting of each compartment depends on the ambient temperature. Above optimal temperature is based on the ambient temperature of 25 °C. How to store for best preservation (applicable models only) Cover foods to retain moisture and prevent them from picking up odors from other foods. A large pot of food like soup or stew should be divided into small portions and put in shallow containers before being refrigerated. A large cut of meat or whole poultry should be divided into smaller pieces or placed in shallow containers before refrigerating. Placement of Foods Shelves Shelves should be adjustable to accommodate a variety of packages. Specialized compartment (applicable models only) Sealed crisper drawers provide an optimal storage environment for fruits and vegetables. Vegetables require higher humidity conditions while fruits require lower humidity conditions. Crispers are equipped with controls devices to control the humidity level. (*Depending on model and options) An adjustable temperature meat drawer maximizes the storage time of meats and cheeses. Stored on the door Don’t store perishable foods in the door. Eggs should be stored in the carton on a shelf. The temperature of the storage bins in the door uctuate more than the temperature in the cabinet. Keep the door closed as much as possible. Freezer Compartment You can store frozen food, make ice cubes and freeze fresh food in the freezer compartment. NOTE Freeze fresh, undamaged food only. Keep food which is to be frozen away from food which is already frozen. To prevent food from losing its avour or drying out, place in airtight containers. Untitled-6 58 2022-11-01 3:57:02English 59 Refrigerator & Freezer Storage Chart The freshness longevity depends on temperature and exposure to moisture. Since product dates aren't a guide for safe use of a product, consult this chart and follow these tips. Milk products Product Refrigerator Freezer Milk 1 week 1 month Butter 2 weeks 12 months Ice cream - 2-3 weeks Natural cheese 1 month 4-6 months Cream cheese 2 weeks Not recommended Yogurt 1 month - Meat Product Refrigerator Freezer Fresh roasts, steaks, chops 3-4 days 2-3 months Fresh ground meat, stew meat 1-2 days 3-4 months Bacon 7 days 1 month Sausage, Raw from pork, beef, turkey 1-2 days 1-2 months Poultry / Eggs Product Refrigerator Freezer Fresh poultry 2 days 6-8 months Poultry salad 1 day - Eggs, Fresh in shell 2-4 weeks Not recommended Untitled-6 59 2022-11-01 3:57:02Appendix English60 Fish / Seafood Product Refrigerator Freezer Fresh sh 1-2 days 3-6 months Cooked sh 3-4 days 1 month Fish salad 1 day Not recommended Dried or pickled sh 3-4 weeks - Fruits Product Refrigerator Freezer Apples 1 month - Peaches 2-3 weeks - Pineapple 1 week - Other fresh fruit 3-5 days 9-12 months Vegetables Product Refrigerator Freezer Asparagus 2-3 days - Broccoli, Brussels sprouts, green peas, mushrooms 3-5 days - Cabbage, cauliower, celery, cucumbers, lettuce 1 week - Carrots, beets, radishes 2 weeks - Untitled-6 60 2022-11-01 3:57:02English 61 Information for model and ordering spare parts Model information To access energy labelling information about this product on the European Product Registry for Energy Labelling (EPREL), scan QR-Code on the energy label. You can nd QR-Code on the energy label in your product box. Part information

• The minimum period during which spare parts, necessary for the repair of the appliance, are available - 7 Years thermostats, temperature sensors, printed circuit boards and light sources, door handles, door hinges, trays, baskets (boxes or drawers) - 10 Years door gaskets

• The minimum duration of the guarantee of the refrigerating appliance offered by the manufacturer 24 Months.

• Relevant information for ordering spare parts, directly or through other channels provided by the manufacturer, importer or authorized representative
