USER MANUAL iDS-TCM403-BI Hikvision

Acvate and Access Network Camera

Interface	Descripon
LAN(PoE)	Network interface, PoE supported
DC12V, AC24V	Power input interface
MicroSD SD	MicroSD card slot Insert the MicroSD card for local storage
RESET	One-key reset buon
AUDIO IN	Audio input interface
AUDIO OUT	Audio output interface
ALARM IN	Alarm input interface IN1 and GND1, IN2 and GND2 are two pairs of alarm inputs
ALARM OUT	Alarm output interface 1A and 1B, 2A and 2B, 3A and 3B are three pairs of alarm outputs
RS-485	D+ or D- connect to 485
DC12V, GND / DC 12V OUT	Power output interface
BNC	BNC/CVBS interface
	Grounding

Note: The interface varies with the models. Please refer to the product datasheet for details.
