USER MANUAL B24CB50ESS BOSCH

4.5 Connecting the appliance to the electricity supply ......7

5 Familiarizing yourself with your appliance ..............8

6.3 Fruit and vegetable container with humidity con-

10.2 Switching on the connection to the WLAN home

network (Wi-Fi).......................................................12

10.3 Switching off the connection to the WLAN home

11.1 Tips for storing food in the refrigerator compart-

ment ........................................................................12

11.2 Chill zones in the refrigerator compartment..............12

12 Freezer compartment ..............................................13

12.1 Tips for storing food in the freezer compartment......13

12.2 Tips for freezing fresh food ......................................13

12.3 Defrosting methods for frozen food..........................13

13 Defrosting.................................................................13

13.1 Defrosting in the freezer compartment .....................13

14 Cleaning and maintenance .....................................13

14.1 Preparing the appliance for cleaning........................13

16.1 Taking the appliance out of operation ......................17

18.1 Information regarding Free and Open Source

Software ..................................................................18en-us

Observe the following safety instructions. 1.1 Safety definitions Here you can find explanations of the safety signal words used in this manual. WARNING This indicates that death or serious injuries may occur as a result of non-observance of this warning. CAUTION This indicates that minor or moderate injuries may occur as a result of non-observance of this warning. NOTICE: This indicates that damage to the appliance or property may occur as a result of non-compliance with this advi- sory. Note:This alerts you to important information and/or tips. 1.2 General information ¡ Read this manual carefully. ¡ Keep the manual and the product information in a safe place for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.3 Intended use Only use this appliance: ¡ for chilling and freezing food and for making ice cubes. ¡ In private households and in enclosed spaces in a resi- dential environment. ¡ Up to an altitude of 2000 m above sea level. 1.4 Restrictive Use This appliance is not intended for use by persons (includ- ing children) with reduced physical, sensory or mental ca- pabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concern- ing use of the appliance by a person responsible for their safety. Do not let children play with the appliance. Cleaning and user maintenance must not be performed by children unless they are being supervised. 1.5 Safe transport WARNING The high weight of the appliance may result in injury when lifted. ▶ Do not lift the appliance on your own. 1.6 Safe installation WARNING Incorrect installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternat- ing current only via a correctly installed socket outlet with grounding. ▶ The protective conductor system of the domestic elec- trical installation must be properly installed. ▶ Never equip the appliance with an external switching device, e.g. a timer or remote control. ▶ When the appliance is installed, the mains plug of the power cord must be freely accessible. If free access is not possible, an isolating switch must be integrated into the permanent electrical installation according to the in- stallation regulations. ▶ When installing the appliance, check that the power cord is not trapped or damaged. If the insulation of the power cord is damaged, that can be dangerous. ▶ Never let the power cord come into contact with heat sources. WARNING If the appliance's ventilation openings are sealed, a leak in the refrigeration circuit may result in a flammable mixture of gas and air. ▶ Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING It is dangerous to use an extended power cord and non- approved adapters. ▶ Do not use extension cords or multiple socket strips. ▶ Only use adapters and power cords approved by the manufacturer.

▶ If the power cord is too short and a longer one is not available, please contact an electrician to have the do- mestic installation adapted. Portable multiple socket strips or portable power supply units may overheat and cause a fire. ▶ Do not place portable multiple socket strips or power supply units on the back of the appliance. 1.7 Safe use WARNING Moisture intrusion may cause an electric shock. ▶ Use the appliance in enclosed spaces only. ▶ Never expose the appliance to intense heat or humidity. ▶ Do not use any steam cleaners or high-pressure clean- ers to clean the appliance. WARNING Children may pull packaging material over their heads, or wrap themselves up in it and suffocate. ▶ Keep packaging material away from children. ▶ Do not allow children to play with packaging material. Children may breathe in or swallow small parts, causing them to suffocate. ▶ Keep small parts away from children. ▶ Do not allow children to play with small parts. WARNING If the cooling circuit is damaged, flammable refrigerant may escape and explode. ▶ To accelerate the defrosting process, do not use any other mechanical devices or means other than those recommended by the manufacturer. ▶ If food is stuck to the freezer compartment, loosen it with a blunt implement such as the handle of a wooden spoon. Products which contain flammable propellants and explo- sive substances may explode, e.g. spray cans. ▶ Do not store products which contain flammable propel- lants (e.g. spray cans) or explosive substances in the appliance. WARNING Electrical devices within the appliance may cause a fire, e.g. heaters or electric ice makers. ▶ Do not operate electrical devices within the appliance. WARNING Containers which contain carbonated drinks may burst. ▶ Do not store containers which contain carbonated drinks in the freezer compartment. Injury to the eyes caused by escaping flammable refriger- ant and hazardous gases. ▶ Do not damage the tubes of the refrigerant circuit or the insulation. The appliance may tip. ▶ Do not stand or lean on the base, runners or doors. WARNING Individual parts on the back of the appliance become hot during operation. ▶ Never touch these hot parts. WARNING Contact with frozen food and cold surfaces may cause burns by refrigeration. ▶ Never put frozen food straight from the freezer com- partment into your mouth. ▶ Avoid prolonged skin contact with frozen food, ice and surfaces in the freezer compartment. CAUTION To prevent food from being contaminated, you must ob- serve the following instructions. ▶ Leaving the door open for an extended period of time may lead to a considerable temperature increase in the compartments of the appliance. ▶ Regularly clean the surfaces that may come into con- tact with food and accessible drain systems. ▶ Store raw meat and fish in suitable containers in the re- frigerator so that they do not touch or drip on other food. ▶ If the fridge/freezer is empty for an extended period of time, switch off the appliance, defrost it, clean it and leave the door open to prevent the formation of mold. Metal or metal-style parts in the appliance may contain aluminum. If acidic food comes into contact with aluminum in the appliance, aluminum ions may pass into the food. ▶ Do not consume soiled food.

1.8 Damaged appliance WARNING If the appliance or the power cord is damaged, this is dan- gerous. ▶ Never operate a damaged appliance. ▶ Never pull on the power cord to unplug the appliance. Always unplug the appliance at the power outlet. ▶ If the appliance or the power cord is damaged, immedi- ately unplug the power cord or switch off the breaker in the circuit breaker box. ▶ Call Customer Service. → Page18 Improper repairs are dangerous. ▶ Only original spare parts may be used to repair the ap- pliance. ▶ If the power cord of this appliance becomes damaged, it must be replaced by the manufacturer, the manufac- turer's Customer Service, or an authorized service provider in order to prevent injury. WARNING If the tubes are damaged, flammable refrigerant and harmful gases may escape and ignite. ▶ Keep open flames and ignition sources away from the appliance. ▶ Ventilate the room. ▶ Switch off the appliance. → Page10 ▶ Unplug the appliance from the power source or switch off the circuit breaker in the fuse box. ▶ Call Customer Service. → Page18 1.9 State of California Proposition 65 Warnings This product may contain a chemical known to the State of California, which can cause cancer or reproductive harm. Therefore, the packaging of your product may bear the following label as required by California:

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONSen-us Preventing material damage Preventing material damage 2 Preventing material damage Preventing material damage NOTICE: If not rolling in a straight line, the appliance's castors may damage the floor when the appliance is moved. ▶ Transport the appliance using a hand-cart.▶ Use floor protection when moving the appliance, and do not move it in a zigzag fashion. Using the base, runners or appliance doors as a seat or climbing surface may damage the appliance. ▶ Do not stand or lean on the base, runners or doors. Contamination with oil or fat may cause plastic parts and door seals to become porous. ▶ Keep plastic parts and door seals free of oil and grease. Metal or metal-style parts in the appliance may contain aluminum. Aluminum reacts when it comes into contact with acidic foods. ▶ Do not store unpackaged food in the appliance.Environmental protection and energy-saving 3 Environmental protection and en- ergy-saving Environmental protection and energy-saving 3.1 Disposal of packaging The packaging materials are environmentally compatible and can be recycled. ▶ Sort the individual components by type and dispose of them separately. 3.2 Saving energy If you follow these instructions, your appliance will use less power. Selecting the installation location ¡ Keep the appliance out of direct sunlight. ¡ Install the appliance as far away as possible from heat- ing elements, stoves and other heat sources: – Maintain a 1

” (30mm) clearance to electric or gas stoves. – Maintain an 11

” (300mm) clearance to oil or solid-fuel stoves. ¡ Make sure there is a small gap between the side wall and the appliance. ¡ Never cover or block the external ventilation openings. Saving energy during use Note:The arrangement of the fittings does not affect the energy consumption of the appliance. ¡ Open the appliance only briefly and then close it care- fully. ¡ Never cover or block the interior ventilation openings or the exterior ventilation openings. ¡ Transport purchased food in a cooler and place quickly in the appliance. ¡ Allow warm food and drinks to cool down before storing them. ¡ Thaw frozen food in the refrigerator compartment to uti- lize the low temperature of the food. ¡ Always leave some space between the food and to the back panel. Installation and connection 4 Installation and connection Installation and connection 4.1 Included in delivery After unpacking all the parts, check for any damage in transit and for completeness of delivery. If you have any complaints, contact your dealer or our Customer Service → Page18

The delivery consists of the following: ¡ Free-standing appliance ¡ Equipment and accessories

¡ Energy label ¡ Information on energy consumption and noises ¡ Information about HomeConnect® 4.2 Criteria for the installation location WARNING If the appliance is in a space that is too small, a leak in the refrigeration circuit may result in a flammable mixture of gas and air. ▶ Only install the appliance in a space with a volume of at least 35ft

) per 0.3oz (8g) refrigerant. The amount of refrigerant is indicated on the rating label.

Page8 The weight of the appliance from factory may be up to 265lbs (120kg) depending on the model. The subfloor must be sufficiently stable to bear the weight of the appliance. Over-and-under and side-by-side installation If you want to install 2 refrigerating appliances one over the other or side by side, you must maintain a clearance of at least 150mm between the appliances. Selected appli- ances can be installed without a minimum clearance. Ask your dealer or kitchen planner about this. 4.3 Installing the appliance ▶ Install the appliance in accordance with the enclosed in- stallation instructions. 4.4 Preparing the appliance for first use

1. Remove the information material.2. Remove the protective film and transit bolts, e.g. re-

move the adhesive strips and cardboard.

Clean the appliance for the first time. → Page13

Depending on the appliance specifications

Not in all countriesInstallation and connection en-us

4.5 Connecting the appliance to the electric- ity supply

1. Insert the power plug of the appliance's power cord in a

socket outlet nearby. The connection data of the appliance can be found on the rating plate.

2. Check the power plug is inserted properly.

a The appliance is now ready to use.en-us Familiarizing yourself with your appliance Familiarizing yourself with your appliance 5 Familiarizing yourself with your appliance Familiarizing yourself with your appliance5.1 ApplianceHere you can find an overview of the parts of your appliance.

Refrigerator compartment → Page12

Freezer compartment → Page13

Fruit and vegetable container with humidity con-troller → Page9

Frozen food container → Page14

Door rack for large bottlesNote:Your appliance may differ from the diagrams withregard to features and dimensions. 5.2 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operat-ing status.

switches the warning signal off.

switches the connection to the WLAN home net-work (Wi-Fi) on or off.

lights up if user-defined settings have been setvia the HomeConnect®app. You can find moreinformation in the HomeConnect®app.

switches Super freezing on or off.

Displays the set temperature for the freezer com-partment in °F or °C.

switches Super cooling on or off.

Displays the set temperature for the refrigeratorcompartment in °F or°C.

switches the appliance on or off.Features 6 Features FeaturesThe features of your appliance depend on the model. 6.1 Shelf To vary the shelf as required, you can remove the shelfand re-insert it elsewhere.

"Removing the shelf", Page14 6.2 Storage container The temperatures in the storage container are lower thanin the refrigerator compartment. Temperatures below32°F (0°C) may occur occasionally.In order to reach temperatures close to 32°F (0°C) in thestorage container, set the refrigerator compartment tem-perature to 34°F (2°C). → Page10 Use the lower temperatures in the storage container tostore highly perishable food, e.g. fish, meat and sausages. 6.3 Fruit and vegetable container with hu- midity controller Store fresh fruit and vegetables loose in the fruit and veg-etable container.Cover any chopped fruit and vegetables, or store in air-tight packaging.Condensation may form in the fruit and vegetable con-tainer depending on the food and quantity stored.en-us Basic Operation

Remove the condensation with a dry cloth and adjust the air humidity to a lower setting using the humidity controller. To ensure that the quality and aroma are retained, store fruit and vegetables that are sensitive to cold outside of the appliance at temperatures of approximately 46°F (8°C) to 54°F (12°C), e.g. pineapple, bananas, citrus fruits, cucumbers, zucchinis, bell peppers, tomatoes and potatoes. 6.4 Variable door rack To adjust the variable door rack as required, you can move or remove the variable door rack, and re-insert it elsewhere. You can remove the door rack rail and re-insert it else- where.

"Removing the door rack rail", Page15 6.5 Ice storage container If ice cube production is switched on, the ice cubes are au- tomatically stored in the ice storage container. NOTICE: The ice maker may become blocked or damaged by food or objects stored in the ice storage container. ▶ Never store food or objects in the ice storage container.Basic Operation 7 Basic Operation Basic Operation 7.1 Switching on the appliance

1. Connect the appliance to the electricity supply.

Page7 Note:If the appliance has been previously switched off using the control panel, press and hold for 3seconds. a The appliance begins to cool. a A warning tone sounds and the temperature display (freezer compartment) and flash because the freezer compartment is still too warm.

2. Switch off the warning tone using .

a goes out as soon as the set temperature has been reached.

Set the required temperature. → Page10 7.2 Operating tips ¡ Once you have switched on the appliance, the set tem- perature is only reached after several hours. Do not put any food in the appliance until the set tem- perature has been reached. ¡ The front panels of the housing are temporarily heated slightly. This prevents condensation inthe area ofthedoor seal. ¡ When you close the door, a vacuum may be created. The door is then difficult to open again. Wait a moment until the vacuum is offset. 7.3 Switching off the appliance ▶ Press and hold for 3seconds. 7.4 Setting the temperature Tip:Via the HomeConnect® app, you can set tempera- tures that are not shown on the control panel. Setting the refrigerator compartment temperature ▶ Press the required temperature. The recommended temperature in the refrigerator com- partment is 37°F (3°C). Setting the freezer compartment temperature ▶ Press the required temperature. The recommended temperature in the freezer compart- ment is 0°F (−18°C). Additional functions 8 Additional functions Additional functions Find out which additional functions can be used for your appliance. Additional functions can be set via the HomeConnect® app. 8.1 Super cooling With Super cooling, the refrigerator compartment cools as cold as possible. Switch on Super cooling before placing large quantities of food. Note:When Super cooling is switched on, increased noise may occur. Switching on Super cooling ▶ Press . a lights up. Note:After approximately 6hours, the appliance switches to normal operation. Switching off Super cooling ▶ Press .Alarm en-us

8.2 Super freezing With Super freezing, the freezer compartment cools as cold as possible. Switch on Super freezing 4 to 6hours before placing food weighing 4.4lbs (2kg) or more into the freezer compart- ment. Note:When Super freezing is switched on, increased noise may occur. Switching on Super freezing ▶ Press . a lights up. Note:After approximately 54hours, the appliance switches to normal operation. Switching off Super freezing ▶ Press . 8.3 Sabbath mode To ensure that you can also use the appliance on the Sab- bath, the Sabbath mode switches off all non-essential functions. During Sabbath mode, the following functions are switched off: ¡ Super cooling ¡ Super freezing ¡ Alarm ¡ Interior lighting ¡ Audible signals ¡ Messages on the control panel Note:The control panel lighting is switched off during the Sabbath mode. lights up at a reduced bright- ness level. Switching on Sabbath mode ▶ Press and hold for 15seconds until an audi- ble signal sounds. a lights up. Note:After approximately 80hours, the appliance switches to normal operation. Switching off Sabbath mode ▶ Press and hold for 15seconds until an audi- ble signal sounds. Alarm 9 Alarm Alarm 9.1 Door alarm If the appliance door is open for a while, the door alarm switches on. A warning tone sounds, flashes and the set tem- perature for the affected compartment flashes. Switching off the door alarm ▶ Close the appliance door or press . a The warning tone is switched off. 9.2 Temperature alarm If the freezer compartment becomes too warm, the tem- perature alarm will switch on. A warning tone sounds and the set temperature (freezer compartment) and flash. CAUTION During the thawing process, bacteria may multiply and spoil the frozen food. ▶ Do not refreeze partly or completely thawed food. ▶ Refreeze food only after cooking. ▶ The frozen items should no longer be stored for the maximum storage period. The temperature alarm can be switched on in the following cases: ¡ The appliance is switched on. Do not store any food until the appliance has reached the set temperature. ¡ Large quantities of fresh food are being placed inside. Switch on Super freezing before placing large quantities of food in the appliance. ¡ The freezer compartment door is open for too long. Check whether the frozen food has defrosted or thawed. Switching off the temperature alarm ▶ Press . a The warning tone is switched off. HomeConnect® 10 HomeConnect® HomeConnect® This appliance is network-capable. Connecting your appli- ance to a mobile device lets you control its functions via the HomeConnect® app. The HomeConnect® services are not available in every country. The availability of the HomeConnect® function depends on the availability of HomeConnect® services in your country. You can find information on this at: www.home-connect.com. To be able to use HomeConnect®, you must first set up the connection to the WLAN home network (Wi-Fi

) and to the HomeConnect® app. After switching on the appliance, wait at least 2minutes until internal device initialization is complete. Only then should you set up HomeConnect®. The HomeConnect® app guides you through the entire registration process. Follow the instructions in the HomeConnect® app to implement the settings. Tips ¡ Consult the HomeConnect® documents supplied. ¡ Follow the instructions in the HomeConnect® app as well.

Wi-Fi is a registered trade mark of the Wi-Fi Alliance.en-us Refrigerator compartment

Notes ¡ Also note the safety information in this instruction man- ual and ensure that it is also observed when operating the appliance using the HomeConnect® app.

"Safety", Page3 ¡ Operating the appliance on the appliance itself always takes priority. It is not possible to operate the appliance using the HomeConnect® app during this time. 10.1 Setting upHomeConnect® Requirements ¡ The mobile device supports the Bluetooth standard 4.2 or higher. ¡ The HomeConnect®app has been installed on your mobile device.

1. Scan the QR code using the HomeConnect®app.

2. Follow the instructions in the HomeConnect®app.

10.2 Switching on the connection to the WLAN home network (Wi-Fi) ▶ Press . 10.3 Switching off the connection to the WLAN home network (Wi-Fi) ▶ Press . 10.4 Installing updates for the HomeCon- nect®software Note:If an update of the HomeConnect® software is available, a message appears in the HomeConnect® app. ▶ To install the update for the HomeConnect® software, follow the instructions in the HomeConnect® app. a The control panel is partially locked during the installa- tion. 10.5 Resetting the HomeConnect® settings If your appliance experiences connection problems with the WLAN home network (Wi-Fi) or your appliance wants to log into a different WLAN home network (Wi-Fi), you can reset the HomeConnect®settings. ▶ Press and hold for 6 seconds until goes out. a The HomeConnect®settings have been reset. 10.6 Data Protection Please see the information on data protection. The first time your appliance is registered on a home network connected to the Internet, your appliance will transmit the following types of data to the HomeConnect® server (initial registration): ¡ Unique appliance identification (consisting of appliance codes as well as the MAC address of the installed Wi-Fi communication module). ¡ Security certificate of the Wi-Fi communication module (to ensure a secure data connection). ¡ The current software and hardware version of your ap- pliance. ¡ Status of any previous reset to factory settings. This initial registration prepares the HomeConnect® func- tions for use and is only required when you want to use the HomeConnect® functions for the first time. Note:Please note that the HomeConnect® functions can be utilized only with the HomeConnect® app. Information on data protection can be called up in the HomeConnect® app. Refrigerator compartment 11 Refrigerator compartment Refrigerator compartment You can keep dairy products, eggs, prepared meals, pas- tries, open preserves and hard cheese in the refrigerator compartment. The temperature can be set from 42°F (1°C) to 34°F (6°C). The refrigerator compartment can also be used to store highly perishable foods in the short to medium term. The lower the selected temperature, the longer the food re- mains fresh. 11.1 Tips for storing food in the refrigerator compartment ¡ Only store food when fresh and undamaged. ¡ Store food covered or in air-tight packaging. ¡ To avoid impeding the circulation of air and to prevent food from freezing, do not place food so that it has di- rect contact with the back wall. ¡ Allow hot food and drinks to cool down first before plac- ing in the appliance. ¡ Observe the best-before date or expiration date speci- fied by the manufacturer. 11.2 Chill zones in the refrigerator compart- ment The air circulation in the refrigerator compartment creates different chill zones. Coldest zone The coldest zone is in the storage container. Tip:Store highly perishable food such as fish, sausages and meat in the coldest zone. Warmest zone The warmest zone is at the very top of the door.Freezer compartment en-us

Tip:Store groceries that do not spoil easily in the warmest zone, e.g. hard cheese and butter. Cheese can then con- tinue to release its flavor and the butter will still be easy to spread. Freezer compartment 12 Freezer compartment Freezer compartment You can store frozen food, freeze food and make ice cubes in the freezer compartment. The temperature can be set from 6°F (−14°C) to −7°F (−22°C). Long-term storage of food should be at 0°F (−18°C) or lower. The freezer compartment can be used to store perishable food long-term. The low temperatures slow down or stop the spoilage. 12.1 Tips for storing food in the freezer com- partment ¡ Store food in air-tight packaging. ¡ Do not bring food which is to be frozen into contact with frozen food. ¡ Place thefood over thewhole area ofthefrozen food containers. ¡ To quickly and gently freeze larger quantities of fresh food, place this in the bottom frozen food container. ¡ To ensure that the air can circulate freely in the appli- ance, push the frozen food containers in as far as they will go. 12.2 Tips for freezing fresh food ¡ Freeze fresh and undamaged food only. ¡ Freeze food in portions. ¡ Cooked food is more suitable for freezing than food that can be eaten raw. ¡ Vegetables: Wash, chop up and blanch before freezing. ¡ Fruit: Wash, pit and perhaps peel, possibly add sugar or ascorbic acid solution. ¡ Food that is suitable for freezing includes baked items, fish and seafood, meat, game, poultry, eggs without shells, cheese, butter and curd cheese, prepared meals and leftovers. ¡ Food that is unsuitable for freezing includes lettuce, radishes, eggs in shells, grapes, raw apples and pears, yogurt, sour cream, crème fraîche and mayonnaise. Packing frozen food If you select suitable packaging material and the correct type of packaging, you can determine the product quality and prevent freezer burn.

1. Place the food in the packaging.2. Squeeze out the air.3. Pack food airtight to prevent it from losing flavor or dry-

4. Label the packaging with the contents and the date of

freezing. 12.3 Defrosting methods for frozen food CAUTION During the thawing process, bacteria may multiply and spoil the frozen food. ▶ Do not refreeze partly or completely thawed food.▶ Refreeze food only after cooking.▶ The frozen items should no longer be stored for the maximum storage period. ¡ Defrost animal-based food, such as fish, meat, cheese, curd cheese, in the refrigerator compartment. ¡ Defrost bread at room temperature. ¡ Prepare food for immediate consumption in the mi- crowave, in the oven, or on the cooktop. Defrosting 13 Defrosting Defrosting 13.1 Defrosting in the freezer compartment The fully automatic NoFrost system ensures that the freezer compartment remains frost-free. Defrosting is not required. Cleaning and maintenance 14 Cleaning and maintenance Cleaning and maintenance To keep your appliance working efficiently for a long time, it is important to clean and maintain it carefully. Customer Service must clean inaccessible points. Clean- ing by Customer Service can give rise to costs. 14.1 Preparing the appliance for cleaning

Switch off the appliance. → Page10

2. Disconnect the appliance from the power supply.

Unplug the appliance from the power source or switch off the circuit breaker in the fuse box.

3. Take out all of the food and store it in a cool place.

Place ice packs (if available) onto the food.

4. Remove all fittings and accessories from the appliance.

Remove the door rack rail. → Page15 14.2 Cleaning the appliance WARNING Moisture intrusion may cause an electric shock. ▶ Do not use any steam cleaners or high-pressure clean- ers to clean the appliance. NOTICE: Unsuitable cleaning agents may damage the surfaces of the appliance. ▶ Do not use hard scouring pads or cleaning sponges.▶ Do not use strong or abrasive cleaning agents.▶ Do not use cleaning agents with a high alcohol content.▶ Do not use stainless-steel cleaning agents on the out- side of the appliance. If you clean fittings and accessories in the dishwasher, this may cause them to become deformed or discolor. ▶ Never clean fittings and accessories in the dishwasher.

Prepare the appliance for cleaning. → Page13 Clean the following with a dish cloth, lukewarm water and a little pH-neutral liquid detergent: – The outside of the appliance – The inside of the appliance – The fittings – The accessoriesen-us Cleaning and maintenance

– The door seals 3. Dry thoroughly with a soft, dry cloth.4. Insert the fittings and install the appliance components.5. Connect the appliance to the electricity supply.

6. Put the food into the appliance.

14.3 Removing the fittings If you want to clean the fittings thoroughly, remove these from your appliance. Removing the shelf ▶ Lift the shelf at the front , pull it out and remove it . Removing the storage container

1. Pull the storage container out all the way.2. Lift the storage container at the front and remove it

Removing the fruit and vegetable container

1. Pull out the fruit and vegetable container as far as it will

2. Lift the fruit and vegetable container at the front and

remove it . Removing the frozen food container

1. Pull out the frozen food container as far as it will go.2. Lift the frozen food container at the front and remove

it . Removing the front of the container You can remove the front of the fruit and vegetable con- tainer and frozen food container to facilitate cleaning.Cleaning and maintenance en-us

▶ Press in the snap-in hooks on the side of the container and remove the front from the container in a turning motion . Removing the ice cube container

1. Pull out the flat frozen food container as far as it will go.

2. Lift the ice cube container at the front and remove it.

14.4 Removing the appliance components If you want to clean your appliance thoroughly, you can re- move certain components from your appliance. Removing the door rack rail ▶ Lift the door rack rail upwards and remove it.en-us Troubleshooting

Troubleshooting 15 Troubleshooting Troubleshooting You can eliminate minor issues on your appliance your- self. Please read the information on eliminating issues be- fore contacting Customer Service. This may avoid unnec- essary repair costs. WARNING Improper repairs are dangerous. ▶ Only original spare parts may be used to repair the ap- pliance. ▶ If the power cord of this appliance becomes damaged, it must be replaced by the manufacturer, the manufac- turer's Customer Service, or an authorized service provider in order to prevent injury. Issue Cause and troubleshooting The appliance is not cooling, the displays and lighting are lit. Showroom mode is switched on.

Switch off the appliance. → Page10

Switch the appliance back on. → Page10

4. Wait 1minute and then hold down until 4 audible signals sound.

5. After a short time, check whether your appliance is cooling.

The LED lighting does not work. Various causes are possible. ▶ Call customer service.

"Customer Service", Page18 Side panels of the appliance are warm. Not a fault. The side panels contain pipes which heat up during the cooling process. Units touching the appliance will not be damaged by the heat. No action required. HomeConnect® is not working properly. Various causes are possible. ▶ Go to www.home-connect.com. The temperature displays and light up. A sensor is defective. ▶ Call customer service.

"Customer Service", Page18 A warning tone sounds and the set temperature (refrigerator compart- ment) and flash. The refrigerator compartment door is open. ▶ Close the refrigerator compartment door. A warning tone sounds and the set temperature (freezer compartment) and flash. Various causes are possible. ▶ Press . a The alarm is switched off. The freezer compartment door is open. ▶ Close the freezer compartment door. External ventilation openings are covered up. ▶ Remove any obstructions from in front of the external ventilation openings. Large quantities of fresh food have been placed inside. ▶ Do not exceed the freezing capacity. The set temperature is not reached. Fully automatic defrosting no longer works. The freezer compartment door was open for a long time. The evaporator (refrigera- tion unit) in the NoFrost system is heavily iced up. Requirement:Store the frozen food well insulated in a cool place.

Switch off the appliance. → Page10

2. Disconnect the appliance from the power supply.

Unplug the power plug or switch off the circuit breaker in the fuse box.

3. Call customer service.

"Customer Service", Page18 The temperature differs greatly from the setting. Various causes are possible.

Switch off the appliance. → Page10

Switch the appliance back on after approximately 5minutes. → Page10 ‒ If the temperature is too warm, check the temperature again after a couple of hours. ‒ If the temperature is too cold, check the temperature again on the following day.Storage and disposal en-us

Issue Cause and troubleshooting Condensation accumulates on the surface of the appliance and on the shelves inside. The water contained in warm and humid air condenses on the colder surfaces of the appliance. 1. Wipe away the water with a soft, dry cloth.2. Open the appliance as briefly as possible.3. Ensure that the appliance is always closed properly. A large volume of condensation collects regularly in the fruit and vegetable container. Depending on the food and quantity stored, condensation may form in the fruit and vegetable container.

Remove the fruit and vegetable container. → Page14

2. Remove the ventilation clips and rotate them before inserting again .

The appliance hums, bubbles, buzzes, gargles, clicks or crackles. Not an issue. A motor is running, e.g. refrigerating unit, fan. Refrigerant is flowing through the pipes. The motor, switches or solenoid valves are switching on or off. Automatic defrosting is running. No action required. The appliance makes noises. The appliance is not level. ▶ Align the appliance using a bubble level and the screw feet. The appliance is not free-standing. ▶ Observe the minimum clearances for the appliance. Fittings wobble or stick. ▶ Check the removable fittings and, if required, replace these. Bottles or containers are touching. ▶ Move the bottles or containers away from each other. Super freezing is switched on. No action required. 15.1 Power failure During a power failure, the temperature in the appliance rises; this reduces the storage time and the quality of the frozen food. Notes ¡ Open the appliance as little as possible during a power failure and do not place any other food in the appliance. ¡ Check the quality of the food immediately after a power failure. – Dispose of any frozen food that has defrosted and is warmer than 41°F (5°C). – Cook or fry slightly thawed frozen food, and then ei- ther consume it or freeze it again. 15.2 Conducting an appliance self-test Your appliance has an appliance self-test which displays faults that can be eliminated by your customer service.

Switch off the appliance. → Page10

2. Disconnect the appliance from the power supply.

Unplug the appliance from the power source or switch off the circuit breaker in the fuse box.

3. Connect the appliance to the electricity supply after 5

4. One minute after connecting to the power supply, press

and hold for 3 to 5seconds until a second au- dible signal sounds. a The appliance self-test starts when the temperature dis- plays light up in succession. a If, at the end of the appliance self-test, two audible sig- nals sound and the temperature display indicates the set temperature, your appliance is OK. The appliance switches to normal operation. a If, at the end of the appliance self-test, 5audible signals sound and the temperature display LEDs light up with a different brightness, inform customer service. The LEDs provide customer service with information about this fault. Storage and disposal 16 Storage and disposal Storage and disposal 16.1 Taking the appliance out of operation

2. Disconnect the appliance from the power supply.

Unplug the appliance from the power source or switch off the circuit breaker in the fuse box.

3. Remove all of the food.

Clean the appliance. → Page13

NOTICE: Objects jammed between the door and the housing may damage the door hinge. ▶ Open the door until it remains open by itself.▶ Do not insert any objects between the door and the housing. To ensure the ventilation inside the appliance, leave the appliance open. 16.2 Disposal of your old appliance Environmentally compatible disposal allows valuable raw materials to be recycled. WARNING Children can lock themselves in the appliance, thereby putting their lives at risk. ▶ Remove the appliance doors.▶ To prevent children from climbing in, leave shelves and containers in the appliance. ▶ Keep children away from the discarded appliance. WARNING If the tubes are damaged, flammable refrigerant and harm- ful gases may escape and ignite. ▶ Do not damage the tubes of the refrigerant circuit or the insulation. 1. Unplug the appliance from the power supply.2. Cut through the power cord.3. Dispose of the appliance in an environmentally respon- sible manner. Information about current disposal methods can be ob- tained from your specialist dealer or local authority. Customer Service 17 Customer Service Customer Service With any warranty repair, we will make sure your appli- ance is repaired by an authorized service provider using genuine replacement parts. We use only genuine replace- ment parts for all repairs. Detailed information on the warranty period and terms of warranty can be found in the Statement of Limited Product Warranty, from your retailer, or on our website. If you contact the Customer Service, you will need the model number (E-Nr.), the production number (FD) and the consecutive numbering (Z-Nr.) of your appliance. USA: 1-800-944-2904 www.bosch-home.com/us/owner-support/get-support www.bosch-home.com/us/shop CA: 1-800-944-2904 www.bosch-home.ca/en/service/get-support www.bosch-home.ca/en/service/cleaners-and-accessories For assistance with connecting to HomeConnect®, you can also view instructions here: www.home-connect.com/us/en/help-support/set-up 17.1 Model number (E-Nr.), production num- ber (FD) and consecutive numbering (Z- Nr.) You can find the model number (E-Nr.), the production number (FD) and the consecutive numbering (Z-Nr.) on the appliance's rating plate.

Page8 Making a note of your appliance's details and the Cus- tomer Service telephone number will enable you to find them again quickly. Technical specifications 18 Technical specifications Technical specifications Refrigerant, cubic capacity and further technical specifica- tions can be found on the rating plate.

Page8 18.1 Information regarding Free and Open Source Software This product includes software components that are li- censed by the copyright holders as free or open source software. The applicable license information is stored on your home appliance. You can also access the applicable license in- formation via your HomeConnect® app: "Profile -> Legal information -> License Information".

You can download the license information on the brand product website. (Please search on the product website for your appliance model and additional documents). Alternatively, you can request the relevant information from ossre- [e-mail] or BSH Hausgeräte GmbH, Carl-Wery- Str. 34, 81739 Munich, Germany. The source code will be made available to you on request. Please send your request to [e-mail] or BSH Hausgeräte GmbH, Carl-Wery-Str.34, 81739 Munich, Germany. Subject: „OSSREQUEST“ The cost of performing your request will be charged to you. This offer is valid for three years from the date of pur- chase or at least as long as we offer support and spare parts for the relevant appliance.
