CP7397 - Sewing machine SOLAC - Free user manual and instructions

Brand	Solac
Model	CP7397
Product type	Multifunctional groomer
Power supply	Rechargeable battery (mains charger)
Charging time	Approximately 8 hours (first charge 16 hours)
Estimated battery life	45 minutes
Interchangeable heads	Nose/ear head, beard, body, hair clipper (3-12 mm)
Blade material	Stainless steel
Indicator lights	Red light (charging), green light (discharge)
Usage	Cordless, rechargeable
Cleaning	Cleaning brush provided, damp cloth with mild detergent
Lubrication	Light machine oil (provided)
Included accessories	Brush, oil, storage pouch
Warranty	Complies with applicable legislation
After-sales service	http://solac.com
Safety	Unplug before cleaning, do not immerse, keep out of reach of children
Estimated weight	200 g
Estimated dimensions	20 x 5 x 5 cm

Frequently Asked Questions - CP7397 SOLAC

How to charge the device for the first time?

The battery is not charged. Plug the charger into the device (rear socket) then into the mains. The red light indicates charging. The first charge should last 16 hours for optimal performance.

How long does a full charge take?

The charging time is approximately 8 hours. Do not overcharge. Too long a charge can reduce battery life.

Can I use the device while charging?

No, the device should not be used while plugged into the charger. Use it only cordless after a full charge.

How to clean the blades?

Unplug the device and let it cool down. Use the provided brush to remove hair. Do not immerse the device in water.

How to lubricate the device?

After each use, apply a few drops of light machine oil (provided) to the blades to ensure proper operation.

What to do if the device does not turn on?

Check that the battery is charged (green light). If the light does not come on, recharge the device. If the problem persists, contact after-sales service.

Can I use the device on animals?

No, the device is designed only for human use. Do not use it on animals.

How to extract the batteries at end of life?

Fully discharge the battery, unplug the device. Open the housing with a screwdriver, cut first the red wire then the black, insulate the ends with insulating tape, then safely remove the battery.

Where to find spare parts or accessories?

You can purchase accessories (heads, blades, charger) from authorized technical support services. Visit http://solac.com for more information.

Is the device waterproof?

No, the device is not waterproof. Do not immerse it in water or run it under the tap. Clean it with a damp cloth only.

USER MANUAL CP7397 SOLAC

Black SOLAC hairbrush with a circular button and power button, shown against a white background (no text or symbols on the device itself)

A Appliance body
B Nose/ear trimmer head
C Beard trimmer head
D Body trimmer head
E Hair clipper with 4 ajadjustable length (3mm to 12mm)
F Pilot lights
G On/Off button
H Cleaning brush
I Lubricating oil
J Storage pouch

- If the model of your appliance does not have the accessories described above, they can also be bought separately from the Technical Assistance Service.

USE AND CARE:

• Fully extend the Charger's output cable before each use.
• Do not use the appliance if its accessories are not properly fitted.
• Do not use the appliance if its accessories attached to it are defective. Replace them immediately.
• Do not use the appliance if on/off switch doesn't works.

- Modify

- If you use the appliance in a bathroom or similar place, unplug the charger from the mains when it is not in use, even if it is only for a short while, as proximity to water involves a risk, even if the appliance is disconnected.

• Disconnect the charger from the mains when not in use, before undertaking any cleaning task make any adjustment or accessory change.
• Store this appliance out of reach of children and/or persons with physical, sensory or reduced mental or lack of experience and knowledge.
• Never rest the appliance into a surface while in use.

- Keep the appliance in good condition. Check that the moving parts are not misaligned or jammed and make sure there are no broken parts or anomalies that may prevent the appliance from operating correctly.

- Pay special attention when assembling and removing the accessories, as the blades are sharp. Be careful and avoid direct contact with the blades' cutting edges.

- Never leave the appliance connected and unattended if is not in use. This saves energy and prolongs the life of the appliance.

- Do not use the appliance with pets or animals.

- Do not open the battery/ies under any circumstances whatsoever.

- Use the appliance only with the battery/ies for which has been specifically designed. The use of any other battery/ies can cause an explosion or fire hazard.

EN

CHARGING THE BATTERY:

• Caution: a new battery is not fully charged and must therefore be charged before the appliance is used for the first time.
• Charge the battery at an atmospheric temperature of between 4 and 40^
• Connect the charger to the jack using the socket on the appliance. The socket is located at the lower/back part of the appliance.
• Plug the charger into the mains.
• The red light will come on to indicated that the charger is charging the battery
• Approximately 8 hours are needed for a complete charger of the battery. Never attempt to overcharge the battery (although it is recommended that the first charge of the battery be of 16 hours in duration)
• When the battery is full charged, disconnect the charger from the mains supply.
• Do not use the appliance while it is connected to the charger.

INSTRUCTIONS FOR USE BEFORE USE:

- Make sure that all products' packaging has been removed.

- Before using this product for the first time, it is important to make a full charge of batteries.

USE:

• The appliance can be used by using his batteries.
• Extend the cable completely before plugging it in.
• Connect the appliance to the mains.
• Remove the protective cover
• Make sure that the blades are correctly aligned.
• Turn the appliance on, by using the on/off button.
• The green light (?) will come on to indicated that the battery is discharging
• Turn the appliance on, by using the selection knob.
• Select the desired cutting height using the comb height selector Press it and adjust the height according to the desired cutting length.
• The appliance gives to you the choice of trimming or shaving.

ONCE YOU HAVE FINISHED USING THE APPLIANCE:

- Turn the appliance off using the on/off button.

- Modify:

EN

• Unplug the charger from the mains.
• Clean the appliance.
• Put on the protective cover.
• To keep the trimmer working properly. Oil it with light machine oil after each use.

SAFETY THERMAL PROTECTOR:

• The appliance has a safety device, which protects the appliance from overheating.
• If the appliance turns itself off and does not switch itself on again, disconnect it from the mains supply, and wait for approximately 15 minutes before reconnecting. If the machine does not start again seek authorized technical assistance.

CLEANING:

• Disconnect the charger from the mains and allow it to cool before undertaking any cleaning task.
• WARNING: Detach the hand-held part from the charger's output cord before cleaning it in water.
• Clean the equipment with a damp cloth with a few drops of washing-up liquid and then dry.

• Do not use solvents, or products with an acid or base pH such as bleach, or abrasive products, for cleaning the appliance.

• Never submerge the appliance in water or any other liquid or place it under running water.

• During the cleaning process, take special care with the blades, as they are very sharp.
• If the appliance is not in good condition of cleanliness, its surface may degrade and inexorably affect the duration of the appliance's useful life and could become unsafe to us.
• Clean the blades and the comb guide with the cleaning brush. Remove the hairs from the blades and from inside the appliance with the brush. It is important to clean off remaining hairs after each use.
• NEVER disassemble the blades from the appliance for clean it.

HOW TO REMOVE THE BATTERIES FROM THE IN-TERIOR OF THE DEVICE:

• CAUTION: It is important that the batteries are fully discharged prior to its withdrawal from the apparatus.
• CATUION: The appliance must be disconnected from the supply mains whdn removing the batteries.

TO REMOVE THE BATTE- RIES, ONCE THE LIFE OF THE

EN

APPLIANCE, PROCEED AS FOLLOWS:

• Open the top shell of the apparatus, removing previously with the help of a screwdriver fixing screws.
• Identify the battery wires and cut their (Red and Black). To avoid risks of a short circuit with a possible residual battery load, first cut the Red wire and protect it by using insulating tape, then proceed to cut the Black wire proceeding in the same way.
• Safely remove the battery from its housing.

FRANÇAIS FR

DESCRIPTION

This product enjoys the recognition and protection of the legal guarantee in accordance with current legislation. To enforce your rights or interests you must go to any of our official technical assistance services. You can find the closest one by accessing the following web link: http://solac.com

You can also request related information by contacting us by phone. You can download this instruction manual and its updates at http://solac.com
