WIFILRW10GU10 - Lighting NEDIS - Free user manual and instructions

Product type	Smart Wi-Fi bulb
Brand	Nedis
Model	WIFILRW10GU10
Dimensions	Φ 50 x 52 mm
Weight	47 g
Power supply	220 – 240 V ~ 50/60 Hz
Power	5 W
Current	43 mA
Wireless technology	Wi-Fi
Frequency range	2412 – 2472 MHz
Max radio transmission power	17.87 dBm
Base	GU10
Material	Metal
Brightness	345 lm
Color temperature	2700 – 6500 K
Light color	Adjustable white (warm to cold)
Control app	Nedis SmartLife (iOS and Android)
Voice control	Compatible with Google Home and Amazon Alexa
Automation	Compatible with IFTTT
Required network	Wi-Fi 2.4 GHz
Intended use	Indoor or outdoor lighting
Compliance	RED Directive 2014/53/EU

Frequently Asked Questions - WIFILRW10GU10 NEDIS

How to install the Nedis WIFILRW10GU10 bulb?

Screw the bulb into a standard GU10 base, then turn it on. Open the Nedis SmartLife app, tap the + sign, select the bulb from the list of available devices, confirm it is flashing, enter your Wi-Fi 2.4 GHz network password, and follow the instructions.

Which app should I use to control the bulb?

The Nedis SmartLife app is required. Download it for free from Google Play or the Apple App Store.

Does the bulb work with a 5 GHz Wi-Fi network?

No, the bulb requires a 2.4 GHz Wi-Fi network only. Make sure your phone is connected to a 2.4 GHz network during pairing.

What to do if the bulb does not flash during pairing?

Turn the bulb off and on 3 times in a row (wall switch or power supply). It should then flash, indicating it is in pairing mode.

Can I use the bulb with Amazon Alexa or Google Home?

Yes, the bulb is compatible with Amazon Alexa and Google Home for voice control. Connect it via the Nedis SmartLife app in the integration settings.

Is the Nedis WIFILRW10GU10 bulb dimmable?

This bulb allows you to adjust the color temperature (2700 K to 6500 K) but the manual does not mention a dimming function. Check the app for available options.

How to reset the bulb to factory settings?

Turn the bulb off and on 3 times quickly. Wait for it to flash slowly, indicating it is in AP mode or ready to be re-paired.

Can the bulb be used outdoors?

Yes, the product is intended for indoor or outdoor use. However, for outdoor use, place it in a suitable fixture protected from weather.

What is the equivalent wattage of this LED bulb?

With a consumption of 5 W and a brightness of 345 lumens, it replaces a halogen bulb of about 35 W.

Where can I find the declaration of conformity?

Download the full declaration of conformity on the support site: nedis.fr/wifilrw10gu10#support or contact [e-mail].

USER MANUAL WIFILRW10GU10 NEDIS

full colour and warm

to cool white

WIFILRC10GU10

WIFILRW10GU10

Line drawing of a bulb-shaped lamp with three base legs (no text or symbols)

Quick start guide 4

Kurzanleitung 7

The Nedis WIFILRC10GU10 | WIFILRW10GU10 is a bulb that allows you to wirelessly control the light.

The product is exclusively intended for lighting an indoor or outdoor environment.

The product is intended to be controlled exclusively via the Nedis SmartLife app.

Any modification of the product may have consequences for safety, warranty and proper functioning.

Specifications

Product Wi-Fi Smart Bulb
Dimensions ∅ 50 x 52 mm
Weight 47 g
Power supply 220 - 240 V ~ 50	/ 60 Hz
Wattage 5 W
Current 43 mA
Wireless technology Wi-Fi
Frequency range 2412 - 2472 MHz
Max. radio transmit power 17.87 dBm
Fitting GU10
Material Metal
Article number Brightness Light colour
WIFILRC10GU10 350 lm RGB +	2700 - 6500 K
WIFILRW10GU10 345 lm 2700 - 6500 K

Main parts (image A)

1 Bulb

2 Electric contact

Safety instructions

WARNING

• Ensure you have fully read and understood the instructions in this document before you install or use the product. Keep the packaging and this document for future reference.
• Only use the product as described in this document.
• Do not use a damaged product.
• Do not expose the product to water or moisture.
• Do not drop the product and avoid bumping.

Installation of the Nedis SmartLife app

1. Download the Nedis SmartLife app for Android or iOS on your phone via Google Play or the Apple App Store.
2. Open the Nedis SmartLife app on your phone.
3. Create an account with your mobile phone number or your e-mail address and tap Continue.
4. Enter the received verification code.
5. Create a password and tap Done.
6. Tap Add Home to create a SmartLife Home.
7. Set your location, choose the rooms you want to connect with and tap Done.

Installing the product (image B)

1 Control tile

2 Common functions

3 Add product

4 On / off button

1. Screw the lamp into an GU10 fitting.

2. Turn on the lamp.

3. In the Nedis SmartLife app, tap + B3.

4. Under Search Device, select the lamp from the list of available devices.

5. Check if the lamp is blinking. If so, tap to confirm.

If the lamp does not blink, turn the lamp off and on 3 times and check again.

1. Enter the password of the 2,4 GHz Wi-Fi network to which your phone is connected and tap Confirm. The Nedis SmartLife app will now search for the lamp.

2. Rename the lamp after it has been found and added.

If the regular connection method fails, the lamp can be connected using AP mode:

a. Tap + B 3.

b. Select the lamp from the list of available devices.

c. Select AP Mode in the top right corner.

d. Turn the lamp off and on 3 times and check that the light starts blinking slowly.

e. Follow the steps in the application.

See our support webpage to discover all possibilities of this Nedis® product.

Using the product

The product can be controlled from any distance using the Nedis SmartLife app.

The home menu of the Nedis SmartLife app shows a control tile for each connected lamp and/or group.

The product can be connected to Google Home or Amazon Alexa to enable speech control.

The product can be connected to IFTTT to enable external conditions to trigger the lamp.

Declaration of Conformity

We, Nedis B.V. declare as manufacturer that the product WIFILRC10GU10 | WIFILRW10GU10 from our brand Nedis ^® , produced in China, has been tested according to all relevant CE standards and regulations and that all tests have been passed successfully. This includes, but is not limited to the RED 2014/53/EU regulation.

The complete Declaration of Conformity (and the safety datasheet if applicable) can be found and downloaded via:

nedis.com/wifilrc10gu10#support

nedis.com/wifilrw10gu10#support

For additional information regarding the compliance, contact the customer service:

Web: www.nedis.com

E-mail: [e-mail]

Nedis B.V., de Tweeling 28

5215 MC 's-Hertogenbosch, the Netherlands
