FG93 - Deep fryer GIRMI - Free user manual and instructions

USER MANUAL FG93 GIRMI

ENGLISH: SAFETY INSTRUCTIONS

The following are important notes on the installation, use and maintenance; save this instruction manual for future reference; use the equipment only as specified in this guide; any other use is considered improper and dangerous; therefore, the manufacturer cannot be held responsible in the event of damages caused by improper, incorrect or unreasonable use. Before use, ensure the equipment is undamaged; if in doubt, do not attempt to use it and contact the authorized service center; do not leave packing materials (i.e. plastic bags, polystyrene foam, nails, staples, etc.) within the reach of children as they are potential sources of danger; always remember that they must be separately collected. Make sure that the rating information given on the technical label are compatible with those of the electricity grid; the installation must be performed according to the9 manufacturer's instructions considering the maximum power of the appliance as shown on the label; an incorrect installation may cause damage to people, animals or things, for which the manufacturer cannot be considered responsible thereof. If it is necessary to use adapters, multiple sockets or electrical extensions, use only those that comply with current safety standards; in any case do not exceed the power consumption limits indicated on the electrical adapter and / or extensions, as well as the maximum power shown on multiple adaptor. Do not leave the unit plugged; better to remove the plug from the mains when the device is not in use. Always disconnect from power supply if you leave it unattended. Cleaning operations should be carried out after unplugging the unit. If the unit is out of order and you do not want to fix it, it must be made inoperable by cutting power cord. - Do not allow the power cord to get closer to sharp objects or in contact with hot surfaces; do not pull it to disconnect the plug. - Do not use the appliance in the event of damage to the power cord, plug, or in case of short circuits; to repair the product only address an authorized service center. - Do not handle or touch the appliance with wet hands or bare feet. Do not expose the appliance to harmful weather conditions such as rain, moisture, frost, etc.. Always store it in a dry place. - Children must not play with the appliance. - This appliance can be used by children of 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they received supervision or instruction concerning use of the appliance in a safe way and understand hazards involved; children shall not play with the10 appliance; cleaning and user maintenance shall not be made by children without supervision. - Keep the appliance and its cord out of reach of children less than 8 years. - Not for commercial use. Household use only If the power cord is damaged, or in case of failure and / or malfunction do not tamper with the unit. The reparation must be done by manufacturer or by service center authorized by the manufacturer in order to prevent any risk. Failure to comply with the above may compromise the unit safety and invalidate the warranty. the unit safety and invalidate the warranty.

WARNING: This appliance includes heating function.

Surfaces, other than functional surfaces may develop high temperatures. Since temperatures are perceived differently by different people, this device should be used with CAUTION. Hold the appliance exclusively to grip surfaces intended to be touched. - This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments; by clients in hotels, motels and other residential type environments; farm houses, bed and breakfast type environments. - The appliance is not intended to be operated by means of an external timer or separate remote-control system. - Before every use, unroll the power cord - Use original spare parts and accessories only. - Do not subject the product to strong impacts, serious damages may result. - Do not use near or under flammable materials (like curtains), heat, cold spots and steam. Always put the ingredients to be fried in the basket, to prevent it from coming into contact with the heating elements. Do not fill the pan with oil as this may cause a fire hazard.11 Do not cover the air inlet and the air outer openings while the appliance is operating. Never touch the inside of the appliance while it is operating. GENERAL INFORMATION The surfaces of appliance shall not be placed against a wall. Leave at least 10cm free space on the back and sides and 10cm free space above the appliance. Never touch the inside of the appliance while it is operating. The appliance needs approximately 30 minutes to cool down for handle or cleaning safely. Do not place anything on top of the appliance. Handle with care cooked food to avoid risk of burning. Never leave the appliance unattended while it is running. Remove the plug after each use. Do not place the oven in water or other liquids and avoid splashing of liquids on the unit. During hot air frying, hot steam is released through the air outlet openings. Keep your hands and face at a safe distance from air outlet. Also be careful of hot steam when you remove the pan from appliance. Before every use, unroll the power cord. Do not use the appliance as a heating unit. Do not insert anything in the ventilation windows. Before cleaning, always unplug the unit and wait for the complete cooling of each part of the appliance. Remove all packaging materials from the cooking compartment. Put on solid and stable surfaces only. Always leave enough space at every sides of the oven when the unit is working. Do not use the oven as shelf support for objects or as place to store food, pots, containers, etc.. FG93 1 Temperature light 2 Temperature knob 3 Timer Knob 4 Housing 5 Tray 6 Container 7 Silicone mats 8 Handle 9 Air outlet12 COOKING Carefully wash all accessories and the inner housing first. Allow to ventilate the internal compartment keeping the container (6) away for about 30 minutes. Before starting with the first cooking, turn on the appliance for 10 minutes at the maximum temperature. - Connect to a suitable and earthed power socket. - Extract container (6) with care and check that the tray (5) is properly mounted. - Insert food in the container (6) and re-place it in the housing (4). Insert correctly the container, otherwise the appliance can’t work. - Set time (knob 3) and temperature (2) to start cooking. Caution: Never use container (6) without tray (5). Do not touch container or inner parts of appliance during cooking and until complete cooling. Touch only the handle (8). - Some foods should be mixed and shaked at half cooking. Take the handle (8) and extract container (6). Shake it, then replace in its position. - When you ear the timer sound, cooking time is finished. Extract container and check if food is ready. If not ready, replace container in its position and set additional cooking of some more minutes. - To remove food, take out the pot (6) and empty in a container or in a dish Be careful to the hot steam when you remove container after cooking. Don’t turn the container (6) upside down, because oil and cooking residues on the bottom of container could drip on the foods. - Once cooking finished, if you want to start another one, air fryer is immediately ready. SETTINGS This table below will help you to select the basic settings for the ingredients. Note: these settings are indications, as depend on personal taste, origin and type of food, ecc.

Min-max Amount (g) Time (min.) Temp

Frozen bread crumbed cheese snacks 100-400 8-10

Use additional baking tin Quiche

Use additional baking tin/oven dish Sweet snacks

Note: Add 3 minutes to the preparation time when you start frying while the Hot-air fryer is still cold. Tips - Smaller ingredients usually require a slightly shorter preparation time than larger ingredients. - A larger amount of ingredients only requires a slightly longer preparation time. - Shaking smaller ingredients halfway through the preparation time optimizes the end result and can13 help prevent unevenly fried ingredients. - Add some oil to fresh potatoes for a crispy result. Fry your ingredients in the Hot-air fryer within a few minutes after you added the oil. - Do not prepare extremely greasy ingredients such as sausages in the Hot-air fryer . - Place a baking tin or oven dish in the Hot-air fryer contianer if you want to bake a cake or quiche or if you want to fry fragile ingredients or filled ingredients - To reheat ingredients, set the temperature to 150

for up to 10 minutes. CLEANING Clean after every use. Unplug the unit from the electrical outlet and allow each part to cool down before starting any cleaning procedure. Remove container to make the unit cool down faster - Do not place oven in water. In any case prevent splashes of water or other liquids from reaching the unit. - Wipe the outside of the appliance with a moist cloth. - Clean the heating element with a cleaning brush to remove any food residues. - Clean the inside of the appliance with hot water and non-abrasive sponge. Container and tray can be washed as normal non-stick pans, but we suggest to not use dishwasher. Do not use metal kitchen utensils or abrasive sponges or abrasive cleaning materials to clean them, as this may damage the non-stick coating TECHNICAL FEATURES
