Product type	Hand mixer
Brand	G3 Ferrari
Model	DOLCECUORE G20151
Power supply	220-240 V ~ 50/60 Hz
Number of speeds	5 + Turbo
Whisk material	Stainless steel
Turbo button	Yes, for temporary maximum speed
Whisk eject button	Yes, for easy whisk removal
Ergonomic handle	Yes, with air intakes for the motor
Waterproof motor body	No, do not immerse
Maximum continuous operation time	5 minutes, with 10-minute rest
Cleaning the motor body	Damp cloth, no abrasive detergents
Cleaning the whisks	Dishwasher safe up to 65 °C
Included accessories	2 whisks
Common uses	Beating, mixing, whipping eggs and cream, light batters
Safety precautions	Do not use if the cord is damaged; keep out of reach of children
Repairability	Repair by an authorized service center only

Frequently Asked Questions - DOLCECUORE G20151 G3 Ferrari

How to attach the whisks to the mixer?

Insert the ends of both whisks into the sockets on the motor body, applying slight pressure until they click into place. To remove them, turn off the appliance, unplug it, then press the eject button (1).

Which speed to use for whipping egg whites?

Use speed 5 or TURBO mode to whip eggs and cream. Start at minimum speed to avoid splashes, then increase gradually.

Can I use the mixer to knead bread dough?

Yes, speed 5 or TURBO is suitable for thick doughs like bread or pizza dough. Be careful not to exceed 5 minutes of continuous operation and take 10-minute breaks.

What is the maximum continuous operation time?

Do not exceed 5 minutes of continuous operation. For large quantities, take at least 10-minute breaks between cycles to avoid overheating.

How to clean the motor body?

Unplug the appliance and wipe the motor body (6) with a damp cloth. Do not use abrasive detergents and never immerse it in water or any other liquid.

Are the whisks dishwasher safe?

Yes, the whisks (7-9) can be washed in the dishwasher at a temperature not exceeding 65 °C. You can also wash them by hand with warm water and mild detergent.

What to do if the mixer does not start?

Check that the switch (3) is in the on position (1-5 or TURBO) and that the plug is properly connected. Make sure the cord is not damaged. If the problem persists, contact authorized customer service.

Is the Turbo button dangerous?

No, it is designed for temporary high-speed use. Press it briefly for quick mixing. Avoid holding it down too long and respect the maximum duration of 5 minutes.

Can I mix hot foods?

It is not recommended to mix very hot foods, as this could damage the appliance or cause splashing. Let the food cool to a lukewarm temperature before mixing.

How to safely remove the whisks?

Turn off the appliance by setting the switch (3) to OFF and unplug it. Then press the eject button (1) to release the whisks. Never do this while it is operating.

USER MANUAL DOLCECUORE G20151 G3 Ferrari

Technical model: YDHM-002-1

White and red French-branded hand mixer with handle, no visible text or symbols on the device itself

Safety instructions.... p. 7

General information.... p. 9

G20151.... p. 9

Operating.... p. 9

Select the accessories.... p. 10

Cleaning.... p. 10

Technical features.... p. 10

Waste of electric and electronic equipment (WEEE

Directive) p. 30

PORTUGUES:....p. 10

ESPAÑOL......p. 14

DEUTSCH p. 18

FRANCAIS p. 23

CLASSI DI PROTEZIONE / PROTECTION CLASSES

ATTENZIONE RISCHIO DI SCOSSE ELETTRICHE NON ESPORRE A PIOGGIA E UMIDITA'

WARNING ELECTRIC SHOCK RISK DO NOT EXPOSE TO RAIN OR MOISTURE

ATTENZIONE: NON APRITE L'APPARECCHIO. ALL'INTERNO NON VI SONO COMANDI MANIPOLABILI DALL'UTENTE NE' PARTI DI RICAMBIO. PER TUTTE LE OPERAZIONI DI SERVIZIO RIVOLGERSI AD UN CENTRO DI ASSISTENZA AUTORIZZATO.

This symbol warns the user that un-insulated dangerous voltage inside the system may cause an electrical shock. Do not open the case.

Class II Appliance symbol. The double insulated electrical appliance is one which has been designed in such a way that it does not require a safety connection to electrical earth/ground.

Caution: this symbol reminds the user to read carefully the important operations and maintenance instructions in this owner's guide.

AVVERTENZE DI SICUREZZA

ENGLISH: SAFETY INSTRUCTIONS

The following are important notes on the installation, use and maintenance; save this instruction manual for future reference; use the equipment only as specified in this guide; any other use is considered improper and dangerous; therefore, the manufacturer cannot be held responsible in the event of damages caused by improper, incorrect or unreasonable use.

Before use, ensure the equipment is undamaged; if in doubt, do not attempt to use it and contact the authorized service center; do not leave packing materials (i.e. plastic bags, polystyrene foam, nails, staples, etc.) within the reach of children as they are potential sources of danger; always remember that they must be separately collected. Make sure that the rating information given on the technical label are compatible with those of the electricity grid; the installation must be performed according to the manufacturer's instructions considering the maximum power of the appliance as shown on the label; an incorrect installation may cause damage to people, animals or things, for which the manufacturer cannot be considered responsible thereof.

If it is necessary to use adapters, multiple sockets or electrical extensions, use only those that comply with current safety standards; in any case do not exceed the power consumption limits indicated on the electrical adapter and / or extensions, as well as the maximum power shown on multiple adaptor.

Do not leave the unit plugged; better to remove the plug from the mains when the device is not in use. Always disconnect from power supply if you leave it unattended.

Cleaning operations should be carried out after unplugging the unit.

If the unit is out of order and you do not want to fix it, it

must be made inoperable by cutting power cord.

- Do not allow the power cord to get closer to sharp objects or in contact with hot surfaces; do not pull it to disconnect the plug.

- Do not use the appliance in the event of damage to the power cord, plug, or in case of short circuits; to repair the product only address an authorized service center.

- Do not handle or touch the appliance with wet hands or bare feet. Do not expose the appliance to harmful weather conditions such as rain, moisture, frost, etc.. Always store it in a dry place.

- Children must not play with the appliance.

- Keep the appliance and its cord out of reach of children less than 8 years. This appliance cannot be used by children, even if they're more than 8 years old.

- This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they received supervision or instruction concerning use of appliance in a safe way and understand the hazards involved.

If the power cord is damaged, or in case of failure and / or malfunction do not tamper with the unit. The reparation must be done by manufacturer or by service center authorized by the manufacturer in order to prevent any risk. Failure to comply with the above may compromise the unit safety and invalidate the warranty.

- This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments; by clients in hotels, motels and other residential type environments; farm houses, bed and breakfast type environments.

- The appliance is not intended to be operated by means of an external timer or separate remote-control system.

- Before every use, unroll the power cord.

• Use original spare parts and accessories only.
• Do not subject the product to strong impacts, serious damages may result.
• Do not use near or under flammable materials (like curtains), heat, cold spots and steam.

GENERAL INSTRUCTIONS

At the first use, wash carefully all the parts that come in touch with food such as whips and attachments.

Bring knob on "0" (OFF) position before inserting the plug in the socket.

To avoid overheating of the engine, do not use the appliance for more than 5 minutes continuously at the minimum speed or 1 minute at max speed, then rest for at least 5 minutes. Do not use the unit without food. Do not use TURBO button for more than 1 minute continuously.

Do not insert fingers inside the food container while the appliance is running. Keep your hair and clothes far from the unit while it is working.

Before operating, check that all parts are well assembled. Before releasing the whips or other attachments, move the speed selector to "0". Clean the beaters after each use.

Never leave the appliance unattended while it is running. Disconnect the electric plug from the power outlet after each use and / or before you install or remove any attachments.

Do not immerse the motor unit in water or other liquids

DESCRIPTION G20151

1. Release button

2. Handle

3. Hooks

4. TURBO button

5. Base

6. Air-outlet grids

3.5 speeds selector

1. Motor unit

2. Whips / beaters

OPERATING

The hand mixer model G20151 is suitable for mixing, beating and mounting eggs. Thanks to 5 operation speed, it allows to obtain more or less homogeneous preparations according to the requirements.

- Fit the whips/beaters on the motor housing (6). Choose whips (9) to whip, beat and stir. Choose hooks (7) to knead. Set the speed selector (3) to speed "0" and then connect the plug to the power outlet.

- Insert the appliance in the container with the food to work (make sure to completely submerge the whips as to avoid any splashing). Select the speed from "1" up to "5" to start the operations. For a best result, work first at the lower speed and then finish with the highest one.

WARNING: not insert fingers, hair or clothes in food container while the appliance is running.

- Press TURBO button (2) if you wish to use the appliance at the maximum speed. At the end of the operations, unplug the unit first, then eject the attachments by pressing the release button (1).

Caution: to prevent the overheating of the engine, do not use the appliance for more than 5 minutes continuously at a minimum speed or for more than 1 minute at maximum speed; then make a rest for at least 5 minutes. Do not use the unit without food. Do not use TURBO button for more than 1 minute continuously.

SELECT THE ATTACHMENTS

There are 2 couple of attachments included, since they have different use.

Whips for beating

The whips (9) are indicated for whipping, beating, emulsifying and must be used at higher speeds. Typical application are: mix and beat the eggs for preparing cakes and omelettes, beat the whites of eggs, prepare creams, emulsifying while preparing mayonnaise.

Hooks for kneading

The hooks for kneading (7) are suitable for cakes, pizzas or for kneading food in general. It is not recommended the use of the hooks if the dough has a heavy consistency.

CLEANING

Unplug the unit from the power outlet before starting cleaning operations.

Do not immerse the motor unit in water, but wash it with a damp cloth and non-abrasive detergent. Also avoid any infiltration of water inside the motor housing. The attachments can be washed like every day crockery with non-abrasive sponge and dishwashing liquid or in the dishwasher. Completely dry all the accessories before assembling them again.

TECHNICAL FEATURES

• Power supply: AC 230V\~50-60Hz. Power 150W
• 5 working speeds and TURBO option, release button
• Accessories: whips for beating and hooks for kneading

PORTUGUES: ADVERTÊNCIAS

The product is made of non-biodegradable and potentially polluting substances if not properly disposed of; other parts can be recycled. It’s our duty to contribute to the ecological health of the environment following the correct procedures for disposal. The crossed out wheelie bin symbol indicates the product complies with the requirements of the new directives introduced to protect the environment (2002/96/EC, 2003/108/EC, 2002/95/EC, 2012/19/EC) and must be properly disposed at the end of its lifetime. If you need further information, ask for the dedicated waste disposal areas at your place of residence. Who does not dispose of the product as specified in this section shall be liable according to the law.

To find the nearest service center, please call the telephone number 0541 694246, fax number 0541 756430 or contact us at [e-mail] asking for the service centers supervisor.

Appliance is conform to the pertinent European regulation and is therefore marked with the CE mark.
