Balios S 2in1 - Stroller CYBEX - Free user manual and instructions

Product type	2-in-1 stroller (carrycot + seat)
Brand	Cybex
Model	Balios S 2in1
Recommended age	From birth to approx. 4 years (with carrycot up to 6 months)
Maximum child weight (seat)	22 kg
Stroller weight	Approx. 12.5 kg (frame + seat)
Unfolded dimensions (L x W x H)	Approx. 90 x 60 x 110 cm
Folded dimensions (L x W x H)	Approx. 70 x 60 x 35 cm
Sun canopy	XXL canopy with UV50+ protection
Safety harness	Adjustable 5-point harness
Brake	Rear wheel parking brake
Folding	Compact and automatic folding (One-Hand Fold system)
Upright position	Possible after folding
Adjustable handlebar	Yes, height adjustable
Front wheel swivel	Swiveling front wheels with lock
Removable wheels	Yes, front and rear wheels removable
Car seat adapters	Compatible with Cybex car seats (adapters included)
Carrycot included	Yes, carrycot with canopy and bumper bar
Rain cover	Available for carrycot and seat
Cover cleaning	Removable covers machine washable (30°C)
Spare parts	Available: covers, wheels, adapters, etc.
Repairability	Repairability index: 8.2/10 (manufacturer data)

Frequently Asked Questions - Balios S 2in1 CYBEX

How to fold and unfold the Balios S 2in1 stroller?

Folding is done with one hand: lower the handlebar, pull the folding handle located under the seat, and push the assembly forward. To unfold, unlock the latch and raise the frame until it clicks into place.

How to install the carrycot on the frame?

Place the carrycot on the adapters on the frame, aligning the connectors. Push until you hear a click. Check that the carrycot is secure before placing the child inside.

How to adjust the handlebar to the right height?

Unlock the adjustment mechanism located in the center of the handlebar, adjust to the desired height (multiple positions), then close the latch until it clicks.

How to use the parking brake?

Press the brake pedal on the rear axle to lock the wheels. To release, lift the pedal. Always use the brake when stationary.

How to wash the carrycot and seat covers?

The covers are removable: remove them following the instructions in the manual. Machine wash at 30°C, gentle cycle. Do not use bleach or tumble dry.

What is the maximum weight supported by the seat?

The seat is suitable for a child up to 22 kg (approx. 4 years). For the carrycot, the maximum weight is 9 kg.

How to remove and replace the wheels?

To remove a wheel, press the button in the center of the hub and pull. To replace, push the wheel until it clicks. Make sure the front wheels are properly oriented.

Can I use a car seat adapter?

Yes, the stroller is compatible with Cybex car seats (Aton, Cloud) via specific adapters provided. Follow the installation guide provided.

How to install the rain cover?

The rain cover goes over the canopy or carrycot. Slide the elastics around the frame and fasten the snap buttons. Ensure sufficient ventilation.

Can the stroller stand upright when folded?

Yes, the folding system allows the stroller to remain upright. You can store it easily without it falling.

USER MANUAL Balios S 2in1 CYBEX

Preparing the carry cot 18

Carrying the carry cot 28

Using the sun canopy of the carry cot 30

Using the bumper bar of the carry cot 31

Folding the carry cot 32

Using the raincover on the carry cot 38

Removing the fabric of the carry cot 39

Preparing the seat unit 45

Using the XXL sun canopy of the seat unit 50

Using the bumper bar of the seat unit 51

Adjusting the seat position 52

Using the harness system 53

Using the raincover on the seat unit 56

EN

Using the brake 57

Folding 58

Free-standing position 60

Adjusting the handle bar 62

Using the swivel locks 63

Removing the wheels 64

Attaching the infant car seat 65

Removing the fabric 67

DE
