WK 341 1101 S - Wine cellar AMICA - Free user manual and instructions
Find the device manual for free WK 341 1101 S AMICA in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Wine cellar |
| Brand | Amica |
| Model | WK 341 1101 S |
| Power supply | 220-240 V ~ 50 Hz, 10 A protection |
| Climate class | SN (10-32°C), N (16-32°C), ST (16-38°C), T (16-43°C) (according to rating plate) |
| Storage temperature range | Adjustable from 5°C to 20°C (estimate) |
| Interior lighting | LED, switchable via key |
| Display | Digital (LED), °C/°F unit adjustable |
| Special functions | Silent Mode, Dynamic cooling mode, Weekend mode, Temperature alarm, Push to Open, lighting and screen intensity adjustment |
| Temperature setting | Via + and - keys, default setting 12°C (1 zone) or 8°C/12°C (2 zones) |
| Interior humidity | Humidity maintenance system (water tray on some models) |
| Maintenance and cleaning | Disconnect before cleaning; use warm water and mild detergent; do not use abrasive products; do not wash shelves in dishwasher |
| Safety | Disconnect before maintenance; do not repair yourself; avoid damaging the refrigeration circuit; do not use electrical appliances inside; do not use steam |
| Spare parts | Available 7 to 10 years depending on type (according to EU regulation 2019/2019) |
| Base assembly | Done by at least two people; do not tilt >45°; wait 8 hours before commissioning after tilting |
| Installation instructions | Provide ventilation space (ventilation grille ≥300 cm²); do not obstruct openings; appliance can be built-in under worktop 820-890 mm |
| Warranty | According to warranty card; repairs by authorized service |
| Declaration of conformity | Compliant with EU directives: Low Voltage 2014/35/EU, EMC 2014/30/EU, 2009/125/EU, RoHS 2011/65/EU |
Frequently Asked Questions - WK 341 1101 S AMICA
How to set the temperature of my Amica WK 341 1101 S wine cellar?
Press the + or - key until the desired temperature is displayed. The default temperature is 12°C (single zone model) or 8°C (upper zone) and 12°C (lower zone) for two-zone models.
How to activate Silent Mode?
Press and hold the ⚠ key for 5 seconds, then touch the Ⓞ key 3 times. Use the + and - keys to select F0 (silent mode). Once the temperature is reached, the fans stop.
What to do if the display shows 'E1' or 'E2'?
This indicates a temperature sensor damage. Contact authorized after-sales service for replacement.
How to clean the interior of the wine cellar?
Disconnect the appliance. Use a solution of baking soda and warm water. Rinse and dry thoroughly. Do not use abrasive products. Clean the shelves separately by hand (not in dishwasher).
How to activate Weekend mode?
Press the power and lighting keys simultaneously for 5 seconds. The screen flashes 4 times. This mode disables display, lighting, and audible signals, but cooling continues. It deactivates automatically after 96 hours or by repeating the same operation.
What to do if the door does not close properly?
Check that the appliance is level and stable. Clean the door gasket. Make sure the shelves are correctly inserted. If the door has been disassembled, check the reassembly.
How to change the temperature unit from °F to °C?
Hold the + key for 5 seconds to enter setting mode. Touch the ♦ touch key once, then use + and - to switch between °C and °F. Confirm with ♦ and hold + for 5 seconds to exit.
How to adjust the display screen intensity?
Hold the + key for 5 seconds, then touch the ♦ key once. Use + and - to change intensity (default setting d1). Confirm with ♦ and hold + for 5 seconds to exit.
How does the Push to Open function work?
Gently push the door inward: it opens slightly automatically. Do not block the piston. If the door does not open after closing, wait about 3 seconds. You can adjust sensitivity by turning a screw located at the top center of the door.
What is the ideal temperature for storing wine?
The ideal storage temperature is 13-15°C. For serving: red wine 15-17°C, white wine 12-13°C. The appliance allows temperature adjustment between approximately 5°C and 20°C.
