| Product Type | Dynamic microphone for instruments (studio and live) |
| Brand | SE Electronics |
| Model | V7 X |
| Capsule | Dynamic, aluminum voice coil |
| Magnet | Neodymium |
| Polar Pattern | Supercardioid |
| Frequency Response | 30 Hz - 19 kHz |
| Sensitivity | 2.0 mV/Pa (-54 dBV) |
| Electrical Impedance | 300 ohms |
| Recommended Load Impedance | >1 kΩ |
| Connector | 3-pin male XLR (gold plated) |
| Dimensions | Diameter 47 mm, length 176 mm |
| Weight | 269 g |
| Materials | All-metal body, spring-loaded stainless steel grille |
| Included Accessories | Microphone clip, thread adapter, red internal windscreen, optional black windscreen, storage pouch |
| Recommended Use | Electric guitar cabinets, brass, snare drum, choirs, etc. |
| Cleaning and Maintenance | Clean with a soft, dry cloth after use. Store in a case or pouch. |
| Safety | Only connect to equipment with a grounded plug that complies with safety standards. |
| Warranty | Extended 3-year warranty after registration on the SE Electronics website. |
| Repairability and Spare Parts | Contact the dealer or SE Electronics customer service for any repairs. |
Frequently Asked Questions - V7 X SE Electronics
User questions about V7 X SE Electronics
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Microphone in PDF format for free! Find your manual V7 X - SE Electronics and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. V7 X by SE Electronics.
USER MANUAL V7 X SE Electronics
We would like to thank you cordially for choosing this sE microphone! This manual contains some important instructions for setting up and operating your new equipment. Please take a few minutes to read the instructions below carefully. We hope you will enjoy working with it as much as we enjoyed designing and building it for you.
Most Sincerely,
Your sE Team
Brief Description
The sibling to sE's acclaimed V7 dynamic vocal microphone, the V7 X is a dynamic instrument microphone ideal for a wide range of applications - both in the studio and on the stage. Thanks to its well-balanced, neutral sound, it allows the capture of nearly any source from electric guitar cabinets to brass instruments, snare drums to choir, and more.
With its innovative, specialized aluminum voice coil, the V7 X delivers a crisp, open sound that perfectly captures your instrument in the most natural way you've ever heard on stage - and makes your sound engineer's job easier than ever.
The supercardioid pattern of its sophisticated capsule design also helps isolate your instrument from other sound sources on the stage - efficiently reducing stage bleed and ensuring high gain before feedback. The capsule's unique, patented suspension also helps eliminate handling noise, footfall noise and any rumble.
The red internal windscreen efficiently reduces unwanted wind noise - and in case you prefer a more visually subtle black windscreen, we have also included one as a standard accessory.
The V7 X's robust all-metal construction, stainless spring steel mesh grille and gold-plated XLR contacts ensure durability and reliability with no corrosion for many years. Proven Neodymium magnets, tight production tolerances and high workmanship ensure excellent sensitivity, high-end sound quality and superb consistency.
What's in the box
Your packaging should contain the follow items. If anything is missing, please contact your sE Electronics dealer and let them know.
- V7 X microphone
- microphone stand clip
- thread adapter
- black windscreen
- pouch
Tips for practical use
Point the microphone directly towards the sound source as much as possible to get a dry, direct sound and high gain before feedback.
The closer the distance from the microphone to the source, the more bass you'll get ("proximity effect"). Use this to your advantage when you want it, and be aware of it when you don't.
The fewer microphones you are using on the stage the better. Use just one microphone per source to minimize to risk feedback.
Make sure the microphone is positioned behind the PA speakers to reduce the risk of feedback.
If several microphones are necessary (e.g. choir miking) apply the 3:1 rule: The distance between the microphones should be at least three times the distance of each microphone to its source.
Safety and maintenance
Risk of damage
Please make sure that the piece of equipment to which your microphone will be connected fulfils the safety regulations enforced in your country and is fitted with a ground lead.
Cleaning the microphone
After every use, clean the microphone with a dry, soft cloth tissue and store it in a solid case or a zipper pouch.
Technical Specifications
| Capsule | Dynamic |
| Voice coil | Aluminum |
| Magnet | Neodymium |
| Polar Patterns | Supercardioid |
| Frequency Range | 30 – 19,000 Hz |
| Sensitivity | 2.0 mV/Pa (-54 dBV) |
| Electrical Impedance | 300 ohms |
| Recommended Load Impedance | >1K Ohms |
| Connectivity | 3-pin male XLR connector |
| Dimensions | Diameter: 47 mm (1.85 in.) Length 176 mm (6.93 in.) |
| Weight | 269 g (9.49 oz) |
Frequency Response
line
| Frequency | 5cm(2in.) | 15cm(6in.) | 60cm(2ft.) | | --------- | --------- | ---------- | ---------- | | 20 | -10 | -10 | -10 | | 50 | -5 | -5 | -5 | | 100 | 0 | 0 | 0 | | 200 | 5 | 5 | 5 | | 500 | 10 | 10 | 10 | | 1K | 0 | 0 | 0 | | 2K | -5 | -5 | -5 | | 5K | -10 | -10 | -10 | | 10K | -15 | -15 | -15 | | 20K | -20 | -20 | -20 |Polar Pattern
radar
| Frequency | Angle (°) | Value | |---|---|---| | 125Hz | 0 | 0 | | 250Hz | 315 | 0 | | 500Hz | 45° | 0 | | 1KHz | 90° | 0 | | 2KHz | 180° | -25 | | 4KHz | 270° | -25 | | 8KHz | 315° | -25 | | 16KHz | 135° | -25 |Support
In case you are experiencing any problems or have any questions regarding your sE product, please contact your dealer first for the fastest and more direct service. If an authorized service is required, it will be arranged by that dealer: http://www.seelectronics.com/dealers
If you still have difficulties with support or assistance, please do not hesitate to contact us directly: http://www.seelectronics.com/contact-us
Lastly, remember to register your new gear to extend your warranty to a full three years:
http://www.seelectronics.com/registration
Contact
Feel free to contact us:
sE Electronics International, Inc. www.seelectronics.com
448 Ignacio Blvd, STE 411 contact@seelectronics.com
Novato, CA 94949
USA
Our international distributors and sales representatives: http://www.seelectronics.com/contact-us
This product conforms to the standards listed in the Declaration of Conformity. Please contact us if you want to order a free copy of the Declaration of Conformity
Technical data subject to change without notice.
Danke
Beschädigungsgefahr
radar
| Frequency | Angle (°) | Value | |---|---|---| | 125Hz | 0 | 0 | | 250Hz | 315 | 0 | | 500Hz | 45° | 0 | | 1KHz | 90° | 0 | | 2KHz | 180° | -10 | | 4KHz | 270° | -15 | | 8KHz | 315° | -20 | | 16KHz | 135° | -25 | The chart displays a polar or directional pattern for each frequency. The data is presented in a circular format with angular positions and radial values representing magnitude. No numerical values are labeled on the chart.Kundenservice
损坏风险
line
| X-axis | MOMO(1) | MOMO(2) | |---|---|---| | 20 | -1.5 | -1.8 | | 60 | -1.2 | -1.4 | | 130 | -0.8 | -1.0 | | 200 | -0.5 | -0.7 | | 300 | -0.3 | -0.5 | | 500 | -0.2 | -0.4 | | 14 | -0.1 | -0.3 | | 24 | -0.1 | -0.3 | | 64 | -0.1 | -0.3 | | 104 | -0.1 | -0.3 | | 200000 | -0.1 | -0.3 |指向性
radar
| Direction | Value | |---|---| | 0° | 100 | | 90° | 120 | | 180° | 80 | | 250° | 60 |售后服务
sE Electronics International, Inc.
448 Ignacio Blvd, STE 411
Novato, CA 94949
USA
www.seelectronics.com
contact@seelectronics.com
http://www.seelectronics.com/registration
Grazie
Rischio di danni
sE Electronics International, Inc.
www.seelectronics.com
448 Ignacio Blvd, STE 411 contact@seelectronics.com
Novato, CA 94949
USA
I nostri distributori locali: http://www.seelectronics.com/contact-us
Risque de dommages
Riesgo de daños
http://www.seelectronics.com/registration
Contacto
sE Electronics International, Inc. www.seelectronics.com
448 Ignacio Blvd, STE 411 contact@seelectronics.com
Novato, CA 94949
USA
Nuestros distribuidores y representantes locales: http://www.seelectronics.com/contact-us
http://www.seelectronics.com/registration
Our international distributors & sales representatives: http://www.seelectronics.com/contact-us
This product conforms to the standards listed in the Declaration of Conformity. Please contact us if you want to order a free copy of the Declaration of Conformity. Technical data subject to change without notice.
IMPORTANT
WARRANTY REGISTRATION
Thank you for purchasing an sE product! You are automatically entitled to a two-year warranty, but can extend this to a full three years with registration. To register your new equipment and to read the full warranty details, please go here:
http://www.seelectronics.com/registration
Most Sincerely,
Your sE Team
