Mini DMW100WT - Waffle Maker Dash - Free user manual and instructions

Product Type	Waffle Maker
Brand	Dash
Model	Mini DMW100WT
Dimensions (approx.)	15 x 15 x 8 cm
Weight (approx.)	0.5 kg
Power Supply	120 V, 60 Hz, 600 W (estimation)
Coating	Non-stick
Capacity	1 small waffle
Main Functions	Baking waffles, heating indicator light
Safety	Cool-touch handle, locking lid, short cord
Maintenance and Cleaning	Clean with a damp cloth after cooling; do not immerse; do not use abrasive or metal utensils
Spare Parts and Repairability	Contact StoreBound at 1-800-898-6970 or [e-mail]
General Information	Household use only, do not use outdoors

Frequently Asked Questions - Mini DMW100WT Dash

How to use the Dash Mini Waffle Maker?

Plug in the appliance, wait for the light to turn on (indicating the appliance is hot), pour batter onto the lower plate, close the lid, and let it cook until the light goes off or to your preference. Always use the handle to open the lid.

Can the waffle maker plates be washed?

No, the waffle maker is not dishwasher safe. Let it cool completely, then wipe the plates with a damp cloth. Never use abrasive cleaners or metal utensils to avoid damaging the non-stick coating.

How much batter should I use?

Pour about 1/4 to 1/3 cup of batter in the center of the lower plate. Do not overfill to avoid overflow. The batter should cover the patterns without spilling over.

Why is the indicator light not turning on?

Check that the appliance is properly plugged in and the outlet works. If the light still does not turn on, the appliance may be defective. Contact StoreBound customer service.

Does the waffle maker have automatic shut-off?

This model does not have automatic shut-off. Monitor cooking and unplug after use. Never leave the appliance unattended.

Can metal utensils be used on the plates?

No, metal utensils scratch the non-stick coating. Use wood, silicone, or heat-resistant plastic.

What if the waffle sticks?

Ensure the plate is hot before adding batter. You can also spray a little cooking oil on the plate before each use. If it still sticks, reduce the amount of sugar in the batter.

How to clean the outside of the waffle maker?

Unplug the appliance and let it cool. Wipe the outside with a damp cloth. Never immerse the appliance in water or pour water on electrical parts.

What is the wattage of this waffle maker?

The wattage is not stated in the manual, but for a mini waffle maker it is typically around 600 watts.

Where to find spare parts?

Contact StoreBound directly by phone at 1-800-898-6970 or by email at [e-mail]. They can provide available parts.

USER MANUAL Mini DMW100WT Dash

Instruction Manual | Recipe Guide

HEART MINI

MAKER WAFFLE

Important Safeguards. 47

Parts & Features. 8

Using Your Mini Waffle Maker. 10-13

Cleaning & Maintenance. 14

Troubleshooting. 16-17

Recipes. 19-28

Customer Support. 30

Warranty. 31

IMPORTANT SAFEGUARDS IMPORTANT SAFEGUARDS

IMPORTANT SAFEGUARDS: PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL.

When using electrical appliances, basic safety precautions should be followed, including:

• Read all instructions.
• Remove all bags and packaging from appliance before use.
• Never leave appliance unattended when in use.
• Make sure the appliance is cleaned thoroughly before using.
• Do not use appliance for other than intended use. For household use only. Do not use outdoors.
• Warning: Hot surfaces! Never touch the Cooking Surface or Cover while appliance is in use. Always lift and lower the Cover by the Cover Handle.

• DO NOT lift the Cover so that your arm is over the Cooking Surface as it is hot and may cause injury. Lift from the side.
  To prevent the risk of fire, electric shock, or personal injury, do not put cord, plug, or appliance in or near water or other liquids. The Mini Maker Waffle is NOT dishwasher safe. Never use abrasive cleaning agents to clean your appliance as this may damage the Mini Maker Waffle and its non-stick Cooking Surface.

• Do not operate this appliance with a damaged cord, damaged plug, after the appliance malfunctions, is dropped, or damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or adjustment.
  DO NOT use the Mini Maker Waffle near water or other liquids, with wet hands, or while standing on a wet surface.
  For maintenance other than cleaning, please contact StoreBound directly at 1-800-898-6970 from 7 AM -7PM PST Monday - Friday or by email at [e-mail].

• Do not use metal utensils on the Cooking Surface as this will damage the non-stick surface.
  This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge unless they are provided with supervision and instruction concerning use of the appliance by a person responsible for their safety.

• Do not place appliance on or near a hot gas burner, hot electric burner, or in a heated oven.

• Be cautious when moving an appliance containing hot oils or other hot liquids.
• Refrain from using attachments that are not recommended by the appliance manufacturer, as this may result in fire, electric shock, or personal injury.
• Allow Mini Maker Waffle to cool completely before moving, cleaning, or storing.
• Close supervision is necessary when any appliance is used by or near children.
• Do not let the cord touch hot surfaces or hang over the edge of tables or counters.
  Always be sure to unplug the appliance from outlet prior to moving, cleaning, storage, and when not in use.
• StoreBound shall not accept liability for damages caused by improper use of the appliance.

• Improper use of the Mini Maker Waffle can result in property damage or even in personal injury.

• This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not completely fit in the outlet, reverse the plug, if it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
  A short power supply cord is to be provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord may be used if care is exercised in its use. If an extension cord is used, the marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance. If the appliance is of the grounded type, the extension cord should be a grounding 3-wire cord. The extension cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.

IMPORTANT SAFEGUARDS: PLEASE READ AND SAVE THIS INSTRUCTION AND CARE MANUAL.

GARANTIES IMPORTANTES

GARANTIES IMPORTANTES: VEUILLEZ LIRE ET CONSERVER CE MODE D'EMPLOI ET D'ENTRETION

USING YOUR MINI MAKER WAFFLE USING YOUR MINI MAKER WAFFLE

BEFORE FIRST USE

Remove all packaging material and thoroughly clean your Mini Maker Waffle.

Never touch the Cooking Surface or Cover while appliance is in use.

DO NOT lift the Cover so that your arm is over the Cooking Surface as it is hot and may cause injury.

Always lift and lower the Cover by the Cover Handle. Lift from the side.

1 Place the appliance on a stable and dry surface. Plug the cord into a power outlet. The Indicator Light (photo A) will illuminate, signaling that the Mini Maker Waffle is heating up.

2 Once the Cooking Surface reaches the optimal cooking temperature, the Indicator Light will automatically shut off. Now, you're ready to get cooking (photo B)!

USING YOUR MINI MAKER WAFFLE USING YOUR MINI MAKER WAFFLE

3 Carefully lift the Cover by the Cover Handle and spray both Cooking Surfaces with a small amount of cooking spray (photo C).

4 Place or pour batter onto the Cooking Surface (photo D) and close the Cover.

5 Once waffle is cooked to your preference, carefully remove it from the Cooking Surface with a heat-resistant nylon or silicone cooking utensil (photo E).

6 When you have finished cooking, unplug your Mini Maker Waffle and allow it to cool before moving or cleaning (photo F).

NOTE: Do not use metal utensils to remove or place food on the Cooking Surface as this will damage the non-stick surface.

CLEANING & MAINTENANCE

Always allow the appliance to cool completely before moving, cleaning, or storing. Do not submerge appliance in water or any other liquids. Never use abrasive cleaning agents to clean your appliance as this may damage the Mini Waffle Maker.

In order to keep your Mini Waffle Maker in pristine working order, thoroughly clean the appliance after each use. This will prevent the build-up of food or oil.

• Unplug Mini Waffle Maker and allow it to cool completely.
• Using a damp, soapy cloth, wipe down the Cooking Surface and Cover. Thoroughly rinse the cloth and wipe again.
  Thoroughly dry Mini Waffle Maker before storing.
• If there is food burned onto the Cooking Surface, pour on a little cooking oil and let sit for 5 to 10 minutes. Scrub the Cooking Surface with a sponge or soft bristled brush to dislodge food. Use a damp, soapy cloth to wipe down the Cooking Surface. Thoroughly rinse the cloth and wipe again. If any food remains, pour on cooking oil and let sit for a few hours, then scrub and wipe clean.
• Never use abrasive cleaning agents to clean your appliance as this may damage the Mini Waffle Maker and its nonstick Cooking Surface.

TROUBLESHOOTING TROUBLESHOOTING

While Dash products are durable, you may encounter one or more of the problems listed below. If the issue is either not solved by the solutions recommended below or not included on this page, please contact our Customer Support Team at 1-800-898-6970 or [e-mail].

ISSUE SOLUTION
The light on the Mini Maker Waffle keeps shutting off.	This is normal. During the cooking process, the heating element will automatically turn on and off to regulate the temperature and ensure that the Cooking Surface does not get too hot or cold. When this occurs, the Indicator Light turns on and off.
How do I know when the Mini Maker Waffle is heated and ready to use?	When the Waffle Maker reaches the optimal temperature, the Indicator Light shuts off and that means you're ready to get cooking!
There is no On/Off Button. How do I turn the Mini Maker Waffle off and on?	To turn on, simply plug in the power card. When you're done cooking, turn off the Mini Maker Waffle by unplugging it.

ISSUE SOLUTION
When using my Mini Maker Waffle, the Cover gets very hot. Is this normal?	Yes, this is completely normal. When using your Waffle Maker, always lift and lower the Cover by the Cover Handle. To prevent personal injury, DO NOT lift the Cover so that your arm is over the Cooking Surface as it is hot and may cause injury. Lift from the side.
After using my Mini Maker Waffle a few times, food is starting to stick to the surface. What is happening?	There is probably a build-up of burnt food residue on the Cooking Surface. This is normal, especially when cooking with sugar. Allow the appliance to cool fully, pour on a little cooking oil and let sit for 5-10 minutes. Scrub Surface with a sponge or soft bristled brush to dislodge food. Use a damp, soapy cloth to wipe down the Cooking Surface. Rinse the cloth and wipe again. If food remains, pour on cooking oil and let sit for a few hours, then scrub and wipe clean.
The Indicator Light will not turn on and the Cooking Surface is failing to heat.	1. Ensure that the power cord is plugged into the power outlet. 2. Check to make sure the power outlet is operating correctly. 3. Determine if a power failure has occurred in your home, apartment or building.

MINIMAKER WAFFLE

RECIPEGUIDE

Follow us @unprocessyourfood

for recipes, videos, & daily inspiration

CLASSIC WAFFLES

Ingredients:

1 cup flour
1 tbsp sugar
2 tsp baking powder
1% tsp salt
1 egg
1 cup milk
2 tbsp melted butter or vegetable oil

Directions:

1. In a medium bowl, sift the flour, sugar, baking powder, and salt. Whisk the egg, milk, and melted butter in a separate bowl. Add the wet ingredients to the dry and mix until just incorporated.
2. Grease the Mini Waffle Maker with butter or coat with a light coat of cooking spray. Pour 14 cup of the batter into the Mini Waffle Maker and cook until golden brown. Repeat with the remaining batter.
3. Serve with a drizzle of maple syrup and fresh berries.

PIZZA CHAFFLE

Ingredients:

1 large egg

12 cupricad cauliflower

12 cup shredded mozzarella cheese

12 tsp dried oregano

_g tsp garlic powder

12 cup shredded Parmesan cheese

4 tbsp pizza sauce

4 tbsp shredded mozzarella (for pizza topping)

Directions:

1. In a mini food processor, pulse the egg, cauliflower, mozzarella, oregano, and garlic powder until the mixture is very finely chopped.
2. Spread 1 tbsp of the Parmesan cheese on the bottom of the Dash Mini Waffle Maker. Add half the cauliflower mixture, spreading it evenly. Sprinkle 1 tbsp more of the Parmesan cheese on top of the cauliflower mixture.
3. Cook the chaffle until well-browned and crisp, 6 mins. Set chaffle aside to cool. Repeat 3 more times making 4 chaffes.
4. Top each chaffle with 2 tbsp of the pizza sauce. Sprinkle on 1 tbsp mozzarella, Place the chaffles under the broiler until the cheese melts, 1-2 mins. Watch carefully so they don't burn and serve immediately.

PALEO WAFFLES

Ingredients:

2 large eggs
12 banana, mashed
% tsp maple syrup
1/2 tsp vanilla extract
1 / 2 tsp baking powder
1/4 cup almond flour
1 ½ tbsp coconut flour
Pinch of salt

Directions:

1. Mix together eggs, banana, vanilla extract and maple syrup in a small bowl.
2. Whisk together dry ingredients in a separate bowl. Add the wet ingredients to the dry and mix until just incorporated.
3. Add 3.5 tbsp of batter to your Mini Waffle Maker and cook until golden brown on both sides.

RED VELVET WAFFLES

Ingredients:

2 cups all-purpose flour
14 cup white granulated sugar
1 / 4 cup cocoa powder
1 tsp baking powder
1/2 tsp baking soda
12 tsp cinnamon
1 tsp salt

1 3/4 cups buttermilk
2 large eggs
14 cup unsalted butter
2 tsp vanilla extract
1 tbsp red food coloring
12 tsp vanilla extract

Cream Cheese Icing
2 tbsp butter, melted
2 tbsp cream cheese, softened
12 cup powdered sugar
14 tsp vanilla extract
2-3 tbsp milk

WAFFLE POPS

Ingredients:

1 cup all-purpose flour
1 tbsp sugar
2 tsp baking powder
14 tsp salt
1 large egg
1 cup milk
2 tbsp softened unsalted butter

For Waffle Pop Coating
1 cup vanilla frosting
14 cup cereal of your choice
½ cup rainbow sprinkles
1/4 cup water
Toppings
Chocolate sauce
Mini marshmallows

Directions:

1. Mix together flour, sugar, baking powder and salt in a medium bowl.
2. Whisk together milk, egg and melted butter in a separate bowl. Add the wet ingredients to the dry and mix until just incorporated.
3. Add 2 tbsp of batter to your Mini Waffle Maker and cook until golden brown on both sides.
4. Vertically insert popsicle stick through each waffle while warm.

For Waffle Pop Coating

1. Mix together frosting, cereal, water and sprinkles in a medium bowl.
2. Once each waffle is attached to a popcorn stick, hold the edge of each stick furthest from the waffle and dip waffle into coating bowl.
3. Use the popsicle stick to twirl each waffle while pulling away from the coating mixture bowl.
4. Top with chocolate sauce drizzle and mini marshmallows, if desired.

MORE RECIPE IDEAS

RECIPE IDEA	INGREDIENTS	COOKING TIME
Protein Waffle	Classic Waffle Recipe (pg 20) 1 scoop protein powder	4-6 min
Cornbread Waffle	¼ cup cornbread batter	6-8 min
Mashed Potato Bite	3 tbsp mashed potatoes	5 min
Smore Biscuit	1 refrigerated biscuit dough, sliced lengthwise 2 squares milk chocolate 5 mini marshmallows	5-7 min
Grilled Cheese	2 slices white or wheat bread, buttered 2 slices American Cheese	5 min
Chocolate Chip Cookie	2 tbsp cookie dough	5-7 min
Waffle Omelette	1 egg beaten 2 tbsp chopped veggies 1 tbsp grated Swiss cheese	5 min

CUSTOMER SUPPORT

WARRANTY

FEEL GOOD

GUARANTEI

Dash values quality and workmanship and stands behind this product with our Feel Good Guarantee". To learn more about our commitment to quality, visit bydash.com/feelgood.

US-based customer support team is at your service

Monday - Friday during the times below.

Reach us at 1 [phone] or [e-mail]

Hey Hawaii! You can reach our customer service team from 5AM to 5PM.
And also, Alaska, feel free to reach out from 6AM - 6PM.

STOREBOUND, LLC - 1 YEAR LIMITED WARRANTY

Your StoreBound product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase when utilized for normal and intended household use. Should any defect covered by the terms of the limited warranty be discovered within one (1) year, StoreBound

LLC will repair or replace the defective part. To process a warranty claim, contact Customer Support at 1-800-898-6970 for further assistance and instruction. A Customer Support agent will assist you by troubleshooting minor problems. If troubleshooting fails to fix the problem, a return authorization will be issued. Proof of purchase indicating the date and place of purchase is required and should accompany the return. You must also include your full name, shipping address, and telephone number. We are unable to ship returns to a PO box. StoreBound will not be responsible for delays or unprocessed claims resulting from a purchaser's failure to provide any or all of the necessary information. Freight costs must be prepaid by the purchaser.

Send all inquiries to [e-mail].

There are no express warranties except as listed above.

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CUSTOMER. STOREBOUND SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR BREFACH OF ANY EXPRESS OR IMplied WARRANTY ON THIS PRODUCT EXCEPT TO THE EXTENT REQUIRED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts. Therefore, the above exclusions or limitations may not apply to you. This warranty gives you specific legal rights and you may also have other rights, which vary from state to state.

REPAIRS

DANGER! Risk of electric shock! The Dash Mini Waffle Maker is an electrical appliance.

Do not repair the appliance yourself under any circumstances.

Contact Customer Support regarding repairs to the appliance.

TECHNICAL SPECIFICATIONS

Voltage 120V-60Hz

Power Rating 350W

Stock#:DMWH100_20200309_V1
