W4WV75961 - Washing machine LG - Free user manual and instructions

Product type	Front-loading washer dryer
Brand	LG
Model	W4WV75961
Dimensions (W × D × H)	600 × 565 × 850 mm
Net weight	73 kg
Power supply	220-240 V~, 50 Hz
Maximum wash capacity	9 kg
Maximum drying capacity	6 kg
Maximum spin speed	1400 rpm
Required water pressure	50 to 800 kPa
Smart features	LG ThinQ, AI DD, ezDispense, Smart Diagnosis
Wash programs	Cotton, Eco 40-60, TurboWash 59, Mix, Synthetics, Anti-allergy, Baby care, Delicate, Hand/Wool, Rapid 14, Drum Clean, Downloadable program
Drying options	Normal, Timer (30/60/120 min), Ironing, Low temperature, Normal Eco
Compatible detergent types	Liquid (ezDispense), powder or liquid (manual dispenser)
Safety	Child lock, door locked during cycle, leak protection
Maintenance	Drum cleaning (Trommelreinigung), pump filter cleaning, detergent dispenser cleaning
Spare parts	Available from LG service (minimum 10 years according to EU regulations)
Repairability	Repairs by qualified personnel only; parts authorized by the manufacturer

Frequently Asked Questions - W4WV75961 LG

How to use the ezDispense function?

Fill the ezDispense compartments with liquid detergent (right compartment) and fabric softener (left compartment) up to the MAX line. Activate the function via the Dispenser 1 and Dispenser 2 buttons. You can adjust the default quantity (42 ml detergent, 30 ml softener) by holding the button for 3 seconds.

What to do if error code 'IE' appears?

The IE code indicates a water supply problem. Check that the water tap is fully open, the inlet hose is not kinked, and the inlet valve filter is not clogged.

How to clean the drain pump filter?

Unplug the appliance. Open the hatch at the bottom right, remove the drain plug after placing a container. Clean the filter under running water and reinstall it.

Why won't the door open during a cycle?

For safety reasons, the door remains locked as long as the water level or temperature is high. Wait for the lock symbol to turn off. You can use the Add Laundry option if available.

What is the maximum drying capacity?

The maximum drying capacity is 6 kg. For a wash followed by a drying cycle, the wash load must be reduced (about half the washing capacity).

How to activate the child lock?

Press and hold the Delay End and Add Laundry buttons simultaneously for 3 seconds. The CL symbol appears. Repeat to deactivate.

What to do if the appliance does not drain (code 'dE')?

The dE code indicates a drainage problem. Check that the drain hose is not kinked or blocked, and clean the drain pump filter.

Can I use powder detergent with ezDispense?

No, the ezDispense function is designed exclusively for liquid detergent and liquid fabric softener. For powder detergent, use the manual dispenser after deactivating ezDispense.

How to connect the appliance to the LG ThinQ app?

Download the LG ThinQ app on your smartphone. Turn on the appliance, press and hold the Wi-Fi button for 3 seconds until the indicator blinks, then follow the instructions in the app.

What is the standby power consumption?

Standby power consumption is 0.5 W, and 2.0 W in network standby. The appliance automatically enters standby mode after 20 minutes of inactivity.

USER MANUAL W4WV75961 LG

de_main.book.book Page 3 Tuesday, June 28, 2022 1:09 PM

Smart Diagnosis (Diagnostic intelligent) 50

MAINTENANCE

fr_main.book.book Page 3 Tuesday, June 28, 2022 1:15 PM

Ton An/Aus(Son On/Off)

Application LG ThinQ

Smart Diagnosis (Diagnostic intelligent)

Smart Diagnosis (Diagnostic intelligent)

it_main.book.book Page 3 Tuesday, June 28, 2022 1:21 PM

Ton An/Aus(Suono On/Off)

it_main.book.book Page 68 Tuesday, June 28, 2022 1:21 PM

Life's Good
