IAN 290753 - Doll Playtive - Free user manual and instructions

Product type	Interactive doll
Brand	Playtive
Model	IAN 290753
Dimensions (L x H x D)	approx. 15 x 34 x 21 cm
Weight	Approx. 0.5 kg
Power supply	3 AA / LR6 1.5 V batteries
Recommended age	18 months and up
Main functions	Blushing cheeks, laughter/crying, teeth appearance, 16 sounds when pressing belly, 8 sounds when pressing left hand
TRY ME mode	Limited functions for testing: blushing, laughter/crying, teeth when passing hand in front of face
Package contents	1 doll, 1 pacifier, 1 bottle, 3 AA batteries, 1 instruction manual
Care and cleaning	Clean with a dry cloth. Do not use harsh cleaners. Clothing and hat washable separately (not specified).
Safety	Toy under adult supervision. Keep batteries out of reach of children. Do not ingest. Remove used batteries.
Spare parts and repairability	Essential spare parts available during warranty period (3 years).
Warranty	3 years from date of purchase, covering material and manufacturing defects.
Customer service	France: 0800 919270, [e-mail]
Date of manufacture	Printed on product (month/year)

Frequently Asked Questions - IAN 290753 Playtive

How to change the doll's batteries?

Open the Velcro closure of the clothing then the doll's body. Push the switch to OFF. Unscrew the screw of the battery compartment on the back of the doll, remove the cover and used batteries. Insert 3 new AA batteries respecting polarity (+/-), screw back and close the closures.

Can I use rechargeable batteries?

No, only non-rechargeable alkaline AA / LR6 1.5 V batteries are allowed.

Does the doll make noise?

Yes, pressing the right hand produces laughter or crying, cheeks blush and teeth appear. Pressing the left hand, 8 different sounds. Pressing the belly, 16 different sounds including 'mama' and 'papa'.

From what age is the doll suitable?

From 18 months, under adult supervision.

How to clean the doll?

Clean it only with a dry cloth. Do not use harsh cleaners. The clothing and hat can be washed separately (check the label).

Can the bottle contain liquid?

No, the bottle is a toy and is not designed to contain liquids. The pacifier is also a play accessory.

What to do if the doll stops working?

First check the batteries: replace if necessary. Make sure the switch is ON. If the problem persists, contact customer service at 0800 919270 or by email.

How to activate all functions?

Turn on the doll by pushing the switch to ON. TRY ME mode is preset to test certain functions. In normal mode, all functions are available by pressing the hands or belly.

What is the warranty period?

The warranty is 3 years from the date of purchase. It covers material and manufacturing defects. Keep the receipt.

Can I wash the doll's clothes?

Yes, the clothing and hat are removable. Follow the care instructions on the label (usually hand wash or machine wash at low temperature).

USER MANUAL IAN 290753 Playtive

BABYPUPPE „MEIN ERSTER ZAHN“ BABY DOLL „MY FIRST TOOTH“ POUPON „MA PREMIÈRE DENT“

DE AT CH

BABYPUPPE

„MEIN ERSTER ZAHN“

Gebrauchsanweisung

FR BE

POUPON

„MA PREMIÈRE DENT“

Instructions for use

NL BE

BABYPOP

„MIJN EERSTE TANDJE“

Gebruiksaanwijzing

ES

MUÑECA BEBÉ

«MI PRIMER DIENTE»

With your purchase you have decided on a high-quality product. Get to know the product before you start to use it.

Carefully read the following instructions for use.

Use the product only as described and only for the given areas of application. Keep these instructions safe. When passing the product on to a third party, always make sure that the documentation is included.

Scope of delivery

1 x Doll
1 x Dummy
1 x Bottle
3 x Batteries (1.5V AA)
1 x Instructions for use

Technical data

Size: approx. 15 x 34 x 21 cm

3 x LR6 1.5V=AA batteries

Date of manufacture (Month/Year):

2017

Intended use

This product is a toy for children aged 18 months and over, for private use.

Safety instructions

• Caution! The packaging and mounting materials are not a constituent part of the toy and they must be removed in all cases for safety reasons before the product is given to children to play with.
  • Children may play with this article only under adult supervision.
• The dummy and bottle are toys, not meant for babies or children.
• The bottle is not suitable for filling with liquids.

Warnings on batteries!

- Remove the batteries if they are empty or if the product is not going to be used for an extended period.

• Do not use different battery types or brands, new and used batteries in combination, or batteries with different capacities, as they leak and can thus cause damage.
• Observe the polarity (+/-) when inserting batteries.
• Change all batteries at the same time and dispose of the old batteries properly.
• Warning! Batteries may not be charged or reactivated in any way. They may not be dismantled, thrown into fire, or short-circuited.
  • Always keep batteries out of the reach of children.
• Do not use rechargeable batteries!
• The cleaning and user-maintenance may not be carried out by children without supervision.
• Clean the batteries and the device contacts as necessary and before inserting the batteries.
• Do not expose the batteries to extreme conditions (e.g. radiators or direct sunlight). Otherwise there is an increased risk of leaks.
• Batteries can endanger life if swallowed. Keep batteries out of the reach of small children for this reason. Seek medical help immediately if a battery is swallowed.

Danger!

• Handle a damaged or leaking battery with extreme care and dispose of it properly and immediately. Wear gloves to handle the battery.
• If you come into contact with battery acid then wash the affected area with soap and water. If battery acid gets in your eye rinse it out with water and seek medical help immediately!
• Do not short-circuit the terminals.

Replacing batteries (figure B) and inserting them (figure C)

WARNING! Take note of the following instructions to prevent mechanical and electrical damage.

If the batteries (2) stop working, replace them.

1. Open the hook-and-loop fasteners on the suit and the doll's body.

2. Turn the product off by pushing the switch (1a) into the OFF position.

3. Use a suitable screwdriver to remove the battery compartment cover (1b) from the back of the doll.

4. Remove the batteries (2) from the product.
5. Carefully insert the new batteries (2) into the compartment (1c). The batteries (2) must be fully inside the compartment.

Note: Pay attention to the plus/minus poles of the batteries and insert them correctly.

1. Screw the battery compartment lid (1b) back on to the back of the doll and fasten both hook-and-loop fasteners.

Switching the product on and off (figure B)

To switch the product on or off, push the switch (1a) to ON to turn it on, or to OFF to turn it off.

Note: The TRY ME mode is default. In the TRY ME mode you can try some of the functions of the doll. If you hold the doll's hand in front of its face, its cheeks will turn red, emit a laughing or crying sound, and teeth will come out. Other functions are not active in the TRY ME mode.

Features (figure A)

To use all of the doll's features, switch it on.

Pressing the doll's right hand

• The doll's cheeks will glow red.
• The doll will make a laughing or crying sound.
• The doll's teeth will come out.

Pressing the doll's left hand

• The doll will make a laughing or crying sound.
- The doll will make different sounds if you continue to press the hand.

Note: There are 8 different sounds that the doll can make when you press its left hand.

Pressing the doll's stomach

• The doll laughs, cries, or says "Mama" or "Papa".
• The doll will make different sounds if you continue to press the stomach.

Note: There are 16 different sounds that the doll can make when you press its stomach.

Storage, cleaning

Always store the product in clean and dry condition at room temperature.

Only wipe clean with a dry cleaning cloth. IMPORTANT! Never clean the product with aggressive cleaning agents.

Doll's clothing and hat:

Disposal

Dispose of the article and the packaging materials in accordance with current local regulations. Packaging materials such as foil bags are not suitable to be given to children. Keep the packaging materials out of the reach of children.

Devices that are marked with the symbol shown here may not be disposed of with domestic waste. You are obliged to dispose of these kinds of used electrical and electronic devices separately. Ask your local authority about possible methods for regulated disposal. Remove the batteries from the article before disposing of it.

Dispose of batteries carefully

Please note: Batteries are hazardous waste and may not be disposed of with domestic waste by law. You can hand over used batteries free of charge at local collection points or at retail outlets. Special containers are provided here for this purpose.

Notes on the guarantee and service handling

The product was produced with great care and under constant supervision. You receive a three-year warranty for this product from the date of purchase. Please retain your receipt.

The warranty applies only to material and workmanship and does not apply to misuse or improper handling. Your statutory rights, especially the warranty rights, are not affected by this warranty.

With regard to complaints, please contact the following service hotline or contact us by e-mail.

Our service employees will advise as to the subsequent procedure as quickly as possible.

We will be personally available to discuss the situation with you.

Any repairs under the warranty, statutory guarantees or through goodwill do not extend the warranty period. This also applies to replaced and repaired parts. Repairs after the warranty are subject to a charge.

IAN: 290753

GB Service Great Britain

Tel.: [phone] (£ 0.10/Min.)

E-Mail: [e-mail]

IE Service Ireland

Tel.: [phone]

(0,08 EUR/Min., (peak))

(0,06 EUR/Min., (off peak))

E-Mail: [e-mail]
