USER MANUAL U444T6NVUBC Tripp Lite
USB 3.1 Gen 1 USB-C™ to VGA Adapter with PD Charging
Model: U444-T6N-VUBC
USB Type-C and USB-C are trademarks of USB Implementers Forum
Espanol 8 • Français 14 • Pycckn 20
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.triplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.triplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
Package Includes
U444-T6N-VUBC
- Owner's Manual
Optional Accessories
P502-Series High-Resolution VGA Cables
U322-Series USB 3.0 A/B Device Cables
U326-Series USB 3.0 Micro-B Device Cables
- U420-003 USB 3.1 Gen 1 USB-C Male/Male Cable - 3 ft.
Product Features
Supports USB DisplayPort Alternate Mode for connecting a VGA monitor via a USB-C port
Supports VGA video resolutions up to 1920 x 1200, including 1080p (60 Hz)
- USB-A and USB-C hub ports support data transfer rates up to 5 Gbps and are backward compatible with previous USB generations
- USB-C port supports USB Power Delivery (PD) charging with power input up to 20V 5A (100W)
- Plug and play; no software or drivers required
Installation
- Connect the adapter's USB Type-C connector to the USB-C port on your laptop, tablet or other compatible device.
- Connect the adapter's VGA port to the monitor's VGA port using a VGA cable (such as Tripp Lite's P502-Series VGA cables).
- Charge your device by connecting its USB-C charger to the adapter's USB-C port.
- Connect a USB device to the adapter's USB-A hub port.
Specifications
| Input Connectors | |
| USB USB-C (Male) | |
| USB-C Port Charging Support | Yes, with Power Delivery (PD) 3.0 |
| USB-C Port Data Support Yes | |
| Output Connectors | |
| VGA VGA (Female) | |
| USB USB-A (Female), USB-C (Female) | |
| Environmental | |
| Operating Temperature 32°F to 113°F (0°C to 45°C) | |
| Operating Humidity 10% to 85% RH, Non-Condensing | |
| Storage Temperature 14°F to 158°F (-10°C to 70°C) | |
| Storage Humidity 5% to 90% RH, Non-Condensing | |
| Power Requirements | |
| USB-C Charging Port | Supports up to 20V 5A (100W) Input and Power Delivery (PD) 3.0 |
| USB 3.0 Port | Provides up to 5V 1.5A (7.5W) Output |
Warranty and Product Registration
3-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.
PRODUCT REGISTRATION
Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
- No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
Warranty and Product Registration
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.
Warranty and Product Registration
WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:
- Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
- Send the new equipment back for recycling when this ultimately becomes waste
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
