USER MANUAL MTB3002HD Tripp Lite

Register your product today and be automatically entered to win an ISOBAR® surge protector in our monthly drawing!

triplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support

Copyright © 2021 Tripp Lite. All rights reserved.

Product Features

• Compatible with macOS® 10.12 and below and Windows® 10 and below
  Supports Ultra High Definition (UHD) 4K x 2K video resolutions up to 4096 x 2160 (60 Hz), as specified in HDMI 2.0, when transmitting to two displays
  Supports up to 36-bit Deep Color (12 bits per channel)
• Compatible with HDCP 2.2 and previous HDCP specifications
  Supports chroma subsamplings of YUV 4:4:4, as well as RGB and YUV 4:2:2
  Plug-and-play adapter-no drivers required

Package Contents

MTB3-002-HD
- Quick Start Guide

System Requirements

• Thunderbolt 3-enabled Mac or Windows PC
• HDMI-enabled monitor

Installation

1. Connect the adapter's Thunderbolt 3 connector to the Thunderbolt 3 port on your Mac or Windows PC.
2. Connect the adapter's HDMI port to a monitor using an HDMI cable (such as Tripp Lite's P568-Series cables).
3. The video image will appear on the add-on monitor. Customize how video is displayed on the add-on monitor using your device's display settings.

Specifications

Connectors
Input Thunderbolt 3 (Male)
Display 2x HDMI (Female)
Video
Maximum Resolutions Dual Monitor: 4096 x 2160 (60 Hz)
Color Depth 36-bit Deep Color Monitor Maxium (12 bits per channel)
Environmental
Operating Temperature 32° to 113°F (0° to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature 14° to 158°F (-10° to 70°C)
Storage Humidity 10% to 90% RH, Non-Condensing
Power Requirements
External Power Supply No

Warranty and Product Registration

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTYES, EXPRESS OR IMPLIED, INCLUDING WARRANTYES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser. EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and Product Registration

PRODUCT REGISTRATION

Visit triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Warranty and Product Registration

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products.

Manufacturing Excellence

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

20-12-306 93-3C2E_RevB

1111 W. 35th Street, Chicago, IL 60609, EE UU tripplite.com/support

Eccelendien Manufacture

1111 W. 35th Street, Chicago, IL 60609, EE UU tripplite.com/support

20-12-306 93-3C2E_RevB

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

20-12-306 93-3C2E_RevB

KpaTKoe pyKOBoDCTBO nOJIb30BaTeIa

Перековский Thunderbolt™ 3 — Dual HDMI

Mодenvb:MTB3-002-HD

English 1 • Espanol 8
Français 14 • Deutsch 26

EAC

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

OxpanaTcA BTOpckn npabom © 2021 Tripp Lite. Iepeneuatka 3anpeaaetc.

20

XapakTepnKn npOnykTa

Cobmectnmoctb c onepaunohbIMn cnCTeMaMn macOS 10.12 (u 6oJee paHnMn BercnA Mn) n Windows 10 (u 6oJee paHnMn BercnA Mn)
- Побларка видаоразшенистандага Ultra High Definition (UHD) 4K x 2K до 4096 x 2160 рп 60 Г (corlaсно тpeбоваям сандага HDMI 2.0) пп посячесгнала на два диспяe
-Подержka 36-6ntoBOrO KoInpobHnI ZaBeta (no 12 6nt Ha KaHaI)
Cobmectnmoctb co ctaHapTom HDCP 2.2 u cootBeTCTBne Tpe6oBaHnM npedbyuX Bepn HDCP
- Пондержkaцьевовсубискретиаши YUV 4:4:4, a takke RGBи YUV 4:2:2
- Поклоченье поTekhoюги Plug-and-Play 6e3 Heo6xOДмоctи ИстпьзOBаня драВеров

CopeKIMoe ynaKOBKN

• UcTpoIcTBoMoI. MTB3-002-HD
  KpaTKoe pyKOBoCTBO noIb30BaTeJIa

CnCTeMHbIe Tpe60BaHnIa

• UcTpoIcTBo Mac nII npcoHaJIbHbI KOMnbIeTp c OC Windows, OChaUeHHbI INTEpfeIcom Thunderbolt 3
• MoHITOp c noIepeKkoI cTaNdapTa HDMI

yctahOBka

1. Поблоче pa3bem Thunderbolt 3 nepexodnka K npoty Thunderbolt 3 cboero yctpoiCTBa Mac nI IN PK c onepaunHno cnCTeMoWindows.
2. Поклочину HDMI-nopт перхониka K HDMI-nopту мониторсnomоцью HDMI-кавеля (нарример, кавеля Tripp Lite cepи P568).
3. HaДононштбнOM MOHTope NOBnEeTcB DuDeoN3O6paKeHne. YCTaHOBtTe INDINBnUdyaJIbHbIe NapaMeTpbl OTO6paKeHnBa BNDecuHaJa HaДононштбнOM MOHTope, NcNoIb3yA COOTBeTCTByIOUne HAcTpoKn CBOero yCTpoNCTBa.

TexHnueckne Tpe6oBaHnIa

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

20-12-306 93-3C2E_RevB

Kurzanleitung

Thunderbolt™ 3 auf

Dual-HDMI-Adapter

Modell: MTB3-002-HD

English 1 • Espanol 8 Français 14 • Pycckn 20

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

31

20-12-306 93-3C2E_RevB
