P130000AUD4K6 - Video adapter Tripp Lite - Free user manual and instructions

Product Type	HDMI UHD 4K x 2K Audio De-embedder/Extractor with HDCP 2.2
Dimensions (L x W x H)	76 x 61.5 x 25.5 mm
Weight	0.07 kg
Power Supply	USB Micro-B (bus-powered)
Power Consumption	2.95 W
Maximum Video Resolution	3840 x 2160 @ 60 Hz
Input Ports	1 x HDMI (female), 1 x USB Micro-B (female) for power
Output Ports	1 x HDMI (female), 1 x TOSLINK (female), 1 x RCA Coaxial (female), 1 x 3.5 mm Mini Stereo (female)
Supported Audio Formats	Uncompressed PCM, Dolby Digital, DTS; stereo and 5.1
HDCP Support	HDCP 2.2
3D Support	Yes, up to 60 Hz
HDMI Compatibility	HDMI 2.0
Color Depth	24-bit (8-bit per channel) at 4K, up to 36-bit (12-bit per channel) at 1080p
Operating Temperature	0 to 40 °C
Storage Temperature	-15 to 50 °C
Relative Humidity	0 to 85% non-condensing
Warranty	2-year limited
Package Contents	P130-000-AUD4K6, USB Micro-B cable, user manual
Optional Accessories	RCA Coaxial Audio Cables Series A060, Toslink Cables Series A102, 3.5 mm Mini Audio Cables Series P312, HDMI Cables Series P569, USB Wall Charger U280-W01-QC3

Frequently Asked Questions - P130000AUD4K6 Tripp Lite

How to connect the P130-000-AUD4K6 adapter?

Connect the HDMI source to the HDMI input of the adapter using an HDMI cable. Connect the HDMI output to a monitor with a second HDMI cable. Use the audio outputs (3.5 mm, TOSLINK, or RCA) to connect your speakers. Finally, plug the provided Micro-B USB cable into a USB power source (monitor or wall charger). The green LED lights up to indicate power.

What to do if the LED does not light up?

Check that the Micro-B USB cable is properly connected to a working power source. Try another USB port or a wall charger. If the LED remains off, test with another USB cable. The adapter requires 5V power via the USB port.

Can I use this adapter with a projector?

Yes, as long as the projector has an HDMI input and supports the transmitted resolution and audio formats. The adapter transmits video resolution up to 3840x2160 @ 60 Hz, compatible with most modern projectors.

What type of HDMI cable is recommended?

For optimal performance, use high-speed HDMI cables from Tripp Lite's P569 series. They ensure lossless transmission of 4K and 3D signals.

How to enable stereo sound via the 3.5 mm jack?

Configure the audio source (e.g., TV or player) to output in PCM mode rather than 'Auto' or 'Bitstream'. This ensures the audio signal is output in stereo on the 3.5 mm mini jack.

Does the device require external power?

No, the adapter is bus-powered via USB. Simply plug it into a standard USB port (using the provided Micro-B cable) to operate. No mains power is required.

What to do if the image does not display on the screen?

Check that all HDMI connections are secure. Make sure the display is on and set to the correct input channel. Test with another HDMI cable. If the problem persists, restart the source and display devices. The orange LED indicates that the signal is being transmitted.

Does this product support HDR?

The product supports deep color up to 36-bit at 1080p, but HDR specification is not explicitly mentioned. It is HDMI 2.0 compatible, which allows HDR transmission if the source and display support it.

Can I use it with a gaming console?

Yes, the adapter works with any HDMI source, including gaming consoles. It extracts audio while transmitting video up to 4K @ 60 Hz, ideal for modern gaming.

What is the difference between the available audio outputs?

The TOSLINK (optical) output and Coaxial RCA output transmit a digital signal in 5.1 surround format (Dolby Digital, DTS). The 3.5 mm mini stereo output provides an analog stereo signal. Choose according to your audio system.

USER MANUAL P130000AUD4K6 Tripp Lite

De-Embedder / Extractor with HDCP 2.2

Model: P130-000-AUD4K6

Español 8 • Français 15 • Русский 22

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind.

You could also win an ISOBAR6ULTRA surge protector—a \$100 value!

www.tripplite.com/warranty

Manufacturing

Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Copyright © 2018 Tripp Lite. All rights reserved.

Package Includes

• P130-000-AUD4K6
- USB Micro-B Cable, 3 ft.
- Owner's Manual

Optional Accessories

• A060-Series RCA Digital Coaxial Audio Cables
• A102-Series TOSLINK Digital Audio Cables
• P312-Series 3.5 mm Mini Stereo Audio Cables
• P569-Series High Speed HDMI Cables
• U280-W01-QC3 Single-Port USB Wall Charger

Product Features

• Extracts audio from an HDMI signal for use on a separate audio system
• Transmits Ultra High Definition (UHD) video resolutions up to 3840 x 2160 @ 60 Hz
  • Supports stereo and 7.1 surround sound audio
  • Supports HDMI 2.0 and HDCP 2.2 specifications
• Features 3.5 mm stereo, TOSLINK and RCA coaxial audio outputs
• Supports LPCM uncompressed audio, and DTS and Dolby Digital compressed audio
• Supports up to 24-bit True Color (8 bits per channel) at 4K, and up to 36-bit Deep Color (12-bits per channel) at 1080p
  • Supports optional 3D formats up to 60 Hz
• Bus-powered via Micro USB-B port; no external power supply needed
• Plug-and-play; no drivers or software needed

Installation

Notes:

• Make sure all devices you are connecting are powered off prior to installation.

• If the 3.5 mm port is in use, you will need to enable the stereo audio function by adjusting the source's audio output setting to "PCM" instead of "Auto".

• Connect the HDMI source to the unit's HDMI input using an HDMI audio/video cable.

• Connect an HDMI monitor to the unit's HDMI output port using a second HDMI audio/video cable.

• Connect the unit to a set of speakers, an audio receiver or other audio system equipped with 3.5 mm mini-stereo, TOSLINK, or RCA digital outputs.

• Use the included USB Micro-B cable to connect the unit to a USB port on the display or a USB wall charger. The unit's green power LED will illuminate to indicate it is receiving power.

• Power on the connected devices. The orange LED will indicate the unit is transmitting audio and video from the source to the display and audio system.

Specifications

Specification Value
Input Port HDMI (Female),	USB Micro-B (Female) for power
Output Ports HDMI (Female), TOSLINK (Female), RCA Coaxial (Female), 3.5 mm Mini-Stereo (Female)
Operating Temperature 32 to 104°F (0 to 40°C)
Storage Temperature 5 to 122°F (-15 to 50°C)
Relative Humidity 0 to 85%, Non-Condensing
External Power Supply USB
Power Consumption 2.95W
Max Video Resolutions 3840 x 2160 @ 60 Hz
Unit Dimension (H x W x D, in.)	2.99 x 2.42 x 1
Unit Dimension (H x W x D, mm)	76 x 61.5 x 25.5
Unit Weight (lb.) 0.15
Unit Weight (kg) 0.07

Warranty and Product Registration

2-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of two (2) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

PRODUCT REGISTRATION

Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

Warranty and Product Registration

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
