U338CFSATA5G - Memory reader Tripp Lite - Free user manual and instructions

Product Type	CFast 2.0 Card Reader and SATA III Adapter
Model	U338CFSATA5G (USB-A) / U438CFSATA5G (USB-C)
Brand	Tripp Lite
Host Interface	USB 3.1 Gen 1 (5 Gbps), backward compatible with USB 2.0/1.1
Host Connector	Built-in USB-A (U338) or USB-C (U438)
Supported Card Formats	CFast 2.0 (and 1.0)
Supported Disk Formats	SATA III (6 Gbps), SATA II, SATA I – 2.5-inch drives
Maximum Capacity	2 TB (tested with HDD and SSD)
Simultaneous Use	Yes, CFast card and SATA drive at the same time
Power Supply	USB bus-powered, no external power required
Dimensions (approx.)	10 x 5 x 2 cm
Weight (approx.)	50 g
Housing Material	Rugged plastic
Color	Black
LED Indicators	Blue (CFast card detected), Red (SATA drive detected)
Supported Operating Systems	All major (Windows, macOS, Linux, etc.)
Installation	Plug-and-play, no drivers required
Maintenance	Clean with a dry cloth, avoid moisture
Safety Precautions	Handle drives with care, use an anti-static wrist strap
Spare Parts / Repairability	No detachable parts; integrated cable not replaceable
Warranty	3-year limited
General Information	Compliant with WEEE directive, continuous improvement

Frequently Asked Questions - U338CFSATA5G Tripp Lite

How to install the U338CFSATA5G reader?

Simply plug the built-in USB-A or USB-C connector into an available port on your computer. Insert a CFast card into the designated slot and/or a 2.5-inch SATA drive into the SATA port. No drivers are required: the device is automatically recognized.

What types of memory cards are compatible?

The reader supports CFast 2.0 cards and is backward compatible with CFast 1.0 cards.

Can I use the CFast card and SATA drive at the same time?

Yes, you can use both ports simultaneously. A blue LED indicates detection of the CFast card, a red LED indicates detection of the SATA drive, and both light up if both devices are connected.

What is the maximum transfer speed?

The USB 3.1 Gen 1 interface offers data transfer speeds up to 5 Gbps. To achieve this speed, your computer must have a USB 3.1 Gen 1 (USB 3.0) port.

My SATA drive is not recognized, what should I do?

Check that the drive is inserted correctly (slight angle to avoid stress). If the drive is not formatted, use your system's Disk Management utility to format it. Also ensure the drive is powered via the USB port.

How to safely eject the device?

Before disconnecting the adapter, always eject the device from your operating system (safely remove hardware icon). This prevents data loss.

Does this reader work with a SATA SSD?

Yes, it is compatible with SATA SSDs of 2.5 inches, as well as mechanical hard drives (HDDs) of the same form factor, tested up to 2 TB.

Does the device require external power?

No, the device is USB bus-powered. No additional power source is required.

What should I do if the LED does not light up?

Make sure the USB cable is connected to a working port. Try a different USB port or another computer. If the problem persists, contact Tripp Lite support for possible warranty repair.

What is the warranty period?

Tripp Lite offers a 3-year limited warranty from the date of purchase. For a claim, contact support to obtain an RMA number and return the product with prepaid shipping.

USER MANUAL U338CFSATA5G Tripp Lite

USB 3.1 Gen 1 (5 Gbps) to CFast 2.0 Card Reader with SATA III Adapter and Built-in Cable

Models: U338-CF-SATA-5G (USB-A) and U438-CF-SATA-5G (USB Type-C)

Espanol 9 • Français 15 • Pycckn 22

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a $100 value! www.triplite.com/warranty

TRIPP·LITE

Manufacturing Facilities

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

Copyright © 2018 Tripp Lite. All rights reserved.

Package Contents

• U338-CF-SATA-5G or U438-CF-SATA-5G
- Owner's Manual

Product Features

• Connect a CFast 2.0 Card Reader and/or SATA drive to the USB-A (U338-CF-SATA-5G) or USB Type-C (U438-CF-SATA-5G) port on your computer
• Card Reader and SATA drive can be used individually or simultaneously
• Download and back up high-resolution photos and videos from your camera to a USB-A or Type-C enabled laptop, tablet or computer
  Supports data transfer speeds up to 5 Gbps
• Card reader supports CFast 1.0 memory cards
  Supports USB 3.1 Gen 1 specifications and is backward compatible with previous USB versions
• Quickly access a hard drive's content without time-consuming internal installation

Product Features

• Compliant with SATA III (6 Gbps), SATA II (3 Gbps) and SATA I (1.5 Gbps) drives
• Tested with 2.5 in. SATA HDDs and SSDs up to 2 TB
• Compatible with all major operating systems
• Portable design with built-in cable fits easily into your pocket, backpack, briefcase or laptop bag
  Plug-and-Play-no software, drivers or external power supply required

System Requirements

• Computer, laptop or tablet with an available USB-A or USB-C port (depending on device and model)

Note: A USB 3.1 Gen 1 (USB 3.0) port is required to achieve maximum data transfer rates.

• CFast Memory Card
  2.5 in. SATA drive

Installation

Notes:

• Hard drives are sensitive to static electricity and must be handled properly to prevent data loss. Always handle your hard drive with caution: wear an anti-static strap, such as the Tripp Lite P999-000, when transporting it, or touch a grounded metal surface to discharge yourself of static electricity before picking up the drive.
• If your SATA hard drive has not been formatted, you will first need to format it using your computer's Disk Management utility.

• Before unplugging the adapter, make sure to properly eject the drive from your computer to avoid any potential data loss.

• Connect the built-in USB-A or USB-C plug on the device to the USB-A or USB-C port on your laptop, tablet or computer.

• Insert a CFast Memory Card into the appropriate port on the device.
• Insert a SATA drive into the appropriate port on the device. Take care to keep the drive at a low angle to minimize stress on the connector.

Installation

1. Your device is ready for use. Please note, when individually connected, a blue LED will illuminate when the CFast card is recognized, while a red LED will illuminate when the SATA drive is recognized. Both blue and red LEDs will illuminate when parts are used simultaneously.

Warranty and Product Registration

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

PRODUCT REGISTRATION

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Warranty and Product Registration

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

Warranty and

Product Registration

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

WEEE Compliance Information for Tripp Lite Customers and Recyclers (Union europeenne)

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support
