Product Type	USB-C Gigabit Ethernet Adapter with Charging
Brand	Tripp Lite
Model	U436-06N-G-C (White) / U436-06N-GB-C (Black)
Connectors	1 x USB-C (Male), 1 x RJ45 (Female), 1 x USB-C Female for Charging
Network Compatibility	10/100/1000 Mbps (Gigabit Ethernet)
Network Standards	IEEE 802.3, 802.3u, 802.3ab, 802.3az (Energy Efficient Ethernet)
Features	Wake-on-LAN, Plug-and-Play (no driver required)
OS Compatibility	Windows, macOS, Chrome OS
Power - USB-C Charging Port	Input up to 20 V, 3 A (60 W)
Operating Temperature	0 °C to 70 °C
Storage Temperature	-10 °C to 70 °C
Operating Humidity	10 % to 85 %
Storage Humidity	5 % to 90 %
Warranty	3-Year Limited Warranty
Maintenance and Cleaning	Clean with a dry, non-abrasive cloth. Disconnect before cleaning.
Safety	Complies with applicable standards (EU, etc.). Non-medical use.
General Information	Compact adapter adding a Gigabit Ethernet port and USB-C charging capability to a USB-C host device.

Frequently Asked Questions - U43606NGC Tripp Lite

How do I install the U43606NGC adapter?

Simply plug the USB-C connector into your device (PC, Mac, tablet) and connect an Ethernet cable to the RJ45 port. The adapter is recognized automatically, no drivers are necessary.

Can this adapter charge my device?

Yes, the dedicated USB-C female port allows you to charge your device with an external power supply up to 60 W (20 V / 3 A). Connect a USB-C charger to this port.

Which operating systems are compatible?

The adapter is compatible with Windows, macOS, and Chrome OS. It works without installing additional drivers.

Is Wake-on-LAN supported?

Yes, the adapter supports the Wake-on-LAN (WOL) function to wake up your computer remotely over the network.

What is the maximum network speed?

It supports 10/100/1000 Mbps (Gigabit Ethernet) speeds for fast data transfers.

Can I use this adapter with a USB-C smartphone?

Yes, it is designed for smartphones, tablets, and laptops with a USB-C port. Check that your phone supports USB-C accessories.

Are there network activity LEDs?

The technical specifications do not mention LEDs, but generally Ethernet adapters have link and activity indicators. Check the manual for confirmation.

What is the length of the built-in cable?

The adapter has a male USB-C connector directly on the housing, without a fixed cable. It plugs directly into your device's port.

How do I clean the adapter?

Disconnect the adapter and use a soft, dry cloth to wipe the surface. Do not use liquid or abrasive products.

What does the warranty cover?

Tripp Lite offers a 3-Year Limited Warranty against defects in materials and workmanship. For any claims, contact technical support to obtain an RMA number.

USER MANUAL U43606NGC Tripp Lite

USB 3.1 Gen 1 USB-C™ Gigabit Ethernet Adapter with Charging

Models: U436-06N-G-C, U436-06N-GB-C

Español 8 • Français 14 • Русский 20

PROTECT YOUR INVESTMENT!

Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a \$100 value!

www.tripplite.com/warranty

TRIPP·LITE

1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support

Copyright © 2017 Tripp Lite. All rights reserved. USB Type-C and USB-C are trademarks of USB Implementers Forum

Product Features

• Add Gigabit Ethernet and USB-C charging via the USB-C port on your smartphone, laptop, tablet or other device
• Plug and play with no software or drivers required
• USB 3.1 Gen 1 supports true 10/100/1000 Mbps network speeds
• USB-C charging port for charging your device, supporting up to 20V 3A (60W) of power input
• Compliant with IEEE 802.3, 802.3u, 802.3ab and 802.3az (Energy Efficient Ethernet)
  • Supports Wake-on-LAN
• Compatible with Windows ^® , Mac ^® and Chromium ^™ operating systems

Package Includes

• U436-06N-G-C (White) or U436-06N-GB-C (Black)
- Quick Start Guide

Installation

Note: When the unit is connected to the USB-C port on your computer and to a network via Cat5e/6 cabling, a network connection will be automatically established. If no connection is made, you can manually establish one by going to your computer's network settings page. For example, on a Mac navigate to the Network section found in System Preferences, click the 'Assist Me' button to get to the Network Setup Assistant, then follow the prompts to establish a connection.

1. Connect the adapter's USB Type-C connector to the USB-C port on your smartphone, tablet, Ultrabook™ or computer.
2. Connect the adapter's RJ45 port to a network using a UTP cable (such as Tripp Lite's N201-Series Cat6 cables).
3. Charge your device by connecting a USB-C cable between the USB-C port on the adapter and the charger or external power supply that came with your device.

Specifications

Connectors
USB USB-C Male
Ethernet RJ45 Female
Charging USB-C Female
Environmental
Operating Temperature 32° to 158° F(0° to 70°C)
Operating Humidity 10% to 85% RH,Non-Condensing
Storage Temperature 14° to 158° F(-10° to 70°C)
Storage Humidity 5% to 90% RH,Non-Condensing
Power Requirements
USB-C Charging Port Supports up to 20V 3A(60W) Input

Warranty and Product Registration

3-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

PRODUCT REGISTRATION

Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Warranty and Product Registration

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

Warranty and Product Registration

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended. Do not use this equipment in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
