USER MANUAL GCG 18V310 Professional BOSCH

(12) Button for battery charge indicator

(13) Rechargeable battery release button

(14) Rechargeable battery

(15) Handle (insulated gripping surface)

Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range. Technical Data Cordless caulking gun GCG 18V-310 Article number 3 601 JC4 1.. Rated voltage V= 18 Cartridge ml 310 Max. feed rate mm/s 8 Extrusion force kN 3.5 Weight according to EPTA-Procedure 01:2014 – With rechargeable battery kg 2.4−3.4

– Without battery kg 2.0 Dimensions (length× width× height) mm 492× 252× 81 Recommended ambient tem- perature during charging °C 0…+35 Permitted ambient temperature during operation

and during storage °C −15…+50 Recommended rechargeable batteries GBA 18V.… ProCORE18V… Bosch Power Tools 1 609 92A 7G2 | (17.03.2022)12 | English Cordless caulking gun GCG 18V-310 Recommended chargers GAL 18… GAX 18… GAL 36… A) Depends on battery in use B) Limited performance at temperatures <0°C Noise/Vibration Information Noise emission values determined according to EN62841-1. Typically the A-weighted sound pressure level of the product is less than 70 dB(A). The noise level when working can ex- ceed the declared values. Wear hearing protection! Total vibration values a

(triax vector sum) and uncertainty K determined according to EN62841-1: a

www.bosch-pt.com/serviceaddresses

www.bosch-pt.com/serviceaddresses

EU Declaration of Conformity We declare under our sole responsibility that the stated products comply with all applicable provisions of the directives and regulations listed below and are in conformity with the following standards. Technical file at: * Cordless caulking gun Article number

We declare under our sole responsibility that the stated products comply with all applicable provisions of the regulations lis- ted below and are in conformity with the following standards. Technical file at: Robert Bosch Ltd. (PT/SOP-GB), Broadwater Park, North Orbital Road, Uxbridge UB9 5HJ, United Kingdom The Supply of Machinery (Safety) Regulations 2008 The Electromagnetic Compatibility Regulations 2016 The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 EN 62841-1:2015 EN 55014-1:2017+A11:2020 EN 55014-2:2015 EN IEC 63000:2018 Robert Bosch Power Tools GmbH, 70538 Stuttgart, Germany represented (in terms of the above regulations) by Robert Bosch Limited, Broadwater Park, North Orbital Road, Uxbridge UB9 5HJ, United Kingdom Vonjy Rajakoba Managing Director - Bosch UK Martin Sibley Head of Sales Operations and Aftersales Robert Bosch Ltd. Broadwater Park, North Orbital Road, Uxbridge UB9 5HJ, United Kingdom, as authorised representative acting on behalf of Robert Bosch Power Tools GmbH, 70538 Stuttgart, Germany Place of issue: Uxbridge Date of issue: 27/05/2021 Bosch Power Tools 1 609 92A 7G2 | (17.03.2022)
