Glass Cup Warmer - Coffee machine JURA - Free user manual and instructions

Product type	Cup warmer
Brand	JURA
Model	Glass Cup Warmer
Dimensions (L × H × D)	32 × 45 × 32 cm
Weight	15 kg
Power supply	220–240 V ~, 50/60 Hz
Power	75 W
Capacity	60 coffee cups (∅ 80 mm) or 100 espresso cups (∅ 60 mm)
Cable length	Approximately 2 m
Functions	Cup heating, power switch with red control light
Usage	Heating cups before serving
Safety	Do not leave unattended, do not immerse, use on stable surface
Cleaning	With a damp cloth, do not use corrosive detergents
Maintenance	Do not immerse in water, do not put in dishwasher
Repairability	Repair exclusively by an authorized JURA service center
Standards	CE, directives 2006/95/EC, 2004/108/EC, 2009/125/EC
Included accessories	Plug-in power cable, cup support

Frequently Asked Questions - Glass Cup Warmer JURA

How to use the JURA Glass Cup Warmer?

Place the cups on the cup supports. Plug in the appliance and turn it on using the power switch located on top. The red light turns on. Let it heat and then turn off after use.

Can I leave the cup warmer on all day?

It is not recommended to leave the appliance unattended. The manual advises not to leave it unattended and to turn it off if away for an extended period.

How many cups can I heat at the same time?

The cup warmer can hold up to 60 coffee cups (∅ 80 mm) or 100 espresso cups (∅ 60 mm), depending on arrangement. Avoid stacking cups.

How to clean the cup warmer?

Unplug the appliance. Clean it with a damp cloth (not wet). Do not use corrosive or abrasive detergents. Do not immerse the appliance in water.

What to do if the red light does not turn on?

Check that the appliance is properly plugged in and the switch is in the on position. If the problem persists, contact JURA after-sales service.

Can I use the cup warmer with all types of cups?

Yes, it is designed to heat cups of various sizes, but avoid exceeding the maximum capacity. Cups should be heat-resistant.

Does the cup warmer consume a lot of electricity?

Its power is 75 W, which is relatively low. To save energy, turn it off when not in use.

How to install the cup warmer?

Place it on a horizontal and stable surface, away from heat sources. Connect the supplied power cable and plug it into a power outlet.

What to do in case of malfunction?

Never try to repair the appliance yourself. Contact an authorized JURA service center or after-sales service. Use only original parts.

Where to find spare parts?

Spare parts are available from JURA after-sales service or authorized centers. Visit www.jura.com for contact details.

USER MANUAL Glass Cup Warmer JURA

Exterior view of a modern office building (no signage)

Glass Cup Warmer

Bedienungsanleitung

Instructions for Use

Mode d'emploi

Your Glass Cup Warmer

Control elements 6

Important information 7

Proper use....7

For your safety 7

1 Setting up and connecting 8

2 Warming cups 8

3 Cleaning and maintenance 8

4 Transport and environmentally neutral disposal 8

5 Technical data 8

6 JURA contact details / Legal information 9

Symbol description

Warnings

⚠ WARNING⚠ CAUTION

Always take note of any information marked with the words CAUTION or WARNING and a warning sign. The signal word WARNING draws your attention to potential serious injury, and the signal word CAUTION to potential minor injury.

Symbols used

▶	Prompt to take action. This symbol means that you are being prompted to perform some action.
i	Information and tips to make it even easier to use your cup warmer.

Control elements

1 Glass Cup Warmer
2 Plug-in mains cable (back of the machine)

3 Power switch (with red indicator light)
4 Cup tray

Important information

Proper use

The cup warmer is used to warm cups on the heated trays. Use for any other purpose will be deemed improper. JURA cannot accept any responsibility for the consequences of improper use.

Before using the machine read these instructions for use thoroughly and completely and comply with the instructions they contain. A warranty service is not applicable for damage or defects caused by non-compliance with the instructions for use. Keep these instructions for use close to the machine and pass them on to the next user.

The cup warmer may only be operated by instructed persons. Non-professionals must be supervised during use.

For your safety

Please carefully read and observe the important safety information set out below. To avoid danger of potentially fatal electric shock:

■ Never use a machine which is damaged or has a defective mains cable.
■ Never start the machine with wet hands.
■ Before starting the machine, ensure that the mains cable is dry.
■ Only use the mains cable unit supplied as standard to connect the machine to the alternating current network.
In the event of signs of damage, for example if there is a smell of burning, unplug the machine immediately from the mains supply and contact JURA service.
If the mains cable of this machine is damaged, it must be repaired either directly by JURA or by an authorised JURA service centre.
■ Make sure that the cup warmer and the mains cable are not located close to hot surfaces or naked flames.

• Be careful to ensure that the mains cable is not trapped and does not rub against sharp edges.
  ■ Never open and repair the machine yourself. Do not modify the machine in any way that is not described in the instructions for use. The machine contains live parts. Repairs may only be carried out by authorised JURA service centres, using original spare parts and accessories.

A defective machine is not safe and could cause injury or fire. To avoid damage and any associated risk of injury or fire:

■ Never allow the mains cable to loosely hang down. The mains cable could pose a tripping hazard or become damaged.
■ Protect your cup warmer from environmental influences such as rain, frost and direct sunlight.
- Do not immerse the cup warmer, cable or connections in water.
- Do not put the cup warmer or any individual parts in the dishwasher.
■ Switch the cup warmer off before cleaning and disconnect the mains plug. Always wipe the cup warmer with a damp cloth rather than a wet one, and protect it from prolonged exposure to water splash.
■ Only connect the machine to the mains voltage in accordance with the information on the rating plate. The rating plate is located on the underside of your cup warmer. Further technical data is given in these instructions for use (see Chapter 5 "Technical Data").
■ Switch the machine off if you are going to be absent for a longer period of time.
■ Only operate the machine when supervised.

People, including children, who

■ do not have the physical, sensory or mental capabilities to use the machine safely or
■ are inexperienced or lack knowledge in how to use the machine safely

must be supervised by a responsible person when using it, or must be instructed in how to use it correctly.

1 Setting up and connecting

1 Setting up and connecting

When setting up your cup warmer, please note the following:

■ Set the machine down on a stable and horizontal surface.
- Choose a spot for your cup warmer which is protected against overheating. Leave a space between the cup warmer and automatic coffee machine to prevent build-up of heat.
In the interests of hygiene, you should use a damp cloth to clean both the inside and outside of your new machine before starting it.

WARNING

If the machine is operated with a defective mains cable, there is a danger of potentially fatal electric shock.

▶ Never use a machine which is damaged or has a defective mains cable.

• Connect the mains cable to the cup warmer.
• Insert the mains plug into a power socket.

2 Warming cups

CAUTION

Risk of burns. The cup trays can get hot during operation.

▶ Do not touch the cup trays.

i For the best warming results, we recommend not stacking the cups on the top cup tray.
- Place the desired cups on the cup trays.
Switch on the cup warmer using the power switch on the top of the machine. The red indicator light lights up. The machine starts to warm the cups.

i To end the heating process, switch off the machine using the power switch on the top of the machine. The red indicator light is no longer lit up.

3 Cleaning and maintenance

i Do not use harsh or abrasive cleaning agents or hard objects for cleaning. This may damage the cup warmer.
▶ Before cleaning the machine, remove the mains plug from the power socket.
- Clean the machine and cup trays with a damp cloth.

4 Transport and environmentally neutral disposal

Keep the packaging for your cup warmer. It should be used to protect the machine during transport. Clean the cup warmer before transporting it.

Please dispose of old machines in an environmentally neutral way.

[NO TEXT]

Old machines contain valuable, recyclable materials which should be recycled. Please therefore dispose of old machines via suitable collection systems.

5 Technical data

Voltage 220–240 V \~, 50/60 Hz

Conformity mark

CE

Power 75 W

Holding capacity (cups stacked/arranged in staggered rows)

60 coffee cups (80 mm in diameter) or 100 espresso cups (60mm in diameter)

Cable length approx. 2 m

Weight 15 kg

Dimensions (W × H × D)

32 × 45 × 32 cm

6 JURA contact details / Legal information

JURA Elektroapparate AG

@ You will find additional contact details for your country at www.jura.com.

Directives

The machine complies with the following directives:

■ 2006/95/EC – Low Voltage Directive
■ 2004/108/EC – Electromagnetic Compatibility
■ 2009/125/EC – Ecodesign Directive

Technical changes

We reserve the right to make technical changes.

The diagrams used in these instructions for use are for illustration purposes only and do not represent the original colours of the machine. Some details of your machine may vary.

Copyright

The instructions for use contain information which is protected by copyright. It is not permitted to photocopy these instructions for use or translate them into another language without the prior written consent of JURA Elektroapparate AG.
