AR4P03 - Heating ARDES - Free user manual and instructions
Find the device manual for free AR4P03 ARDES in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Fan heater |
| Brand | Ardes |
| Model | AR4P03 |
| Power | 2000 W |
| Power supply | 230 V ~ 50 Hz |
| Dimensions (W x H x D) | 25 x 30 x 15 cm |
| Weight | 1.5 kg |
| Main functions | 2 power levels (1000/2000 W), adjustable thermostat, fan without heating |
| Number of speeds | 2 |
| Control type | Rotary knobs |
| Overheat protection | Yes, automatic shutdown |
| Protection rating | IP20 |
| Housing material | Plastic |
| Color | White |
| Power cord length | 1.5 m |
| Heating type | Forced convection (fan heater) |
| Recommended heating area | Up to 25 m² |
| Noise level | Approximately 45 dB |
| Maintenance and cleaning | Unplug and clean with a damp cloth; do not immerse |
| Child safety | No |
| Spare parts and repairability | Parts not available separately; contact customer service |
| Warranty | 2 years |
Frequently Asked Questions - AR4P03 ARDES
How to adjust the temperature of my AR4P03 heater?
Turn the thermostat knob clockwise to increase the temperature. The device automatically stops when the room temperature reaches the set level.
Can I use the heater in a bathroom?
No, this heater has an IP20 protection rating, meaning it is not protected against moisture. Do not use it in a bathroom or near a water source.
How to clean my Ardes AR4P03 heater?
Always unplug the device before cleaning. Use a soft damp cloth to wipe the exterior. Never immerse the device in water and avoid water getting inside.
What to do if the heater does not turn on?
Check that the electrical outlet works and the power cord is not damaged. Make sure the thermostat is not set to the minimum position. If the problem persists, contact customer service.
Does the heater consume a lot of electricity?
With a maximum power of 2000 W, consumption is about 2 kWh in one hour of use at maximum. Use the lowest power (1000 W) to reduce consumption.
Can I leave the heater on all night?
It is not recommended to leave the device unattended. Although it has overheat protection, it is better to turn it off when you sleep or leave the room.
How to use the fan without heating function?
Turn the power selector to the 'fan' position (usually identified by a fan symbol). The heater will blow cold air.
My heater makes an abnormal noise, what to do?
A slight noise is normal during operation. If the noise is loud or unusual, turn off the device and check that no object is blocking the air intakes. If the noise persists, contact customer service.
What safety clearance should be maintained around the heater?
Leave at least 50 cm of free space in front of the device and 30 cm on the sides. Never place flammable materials nearby.
Where can I find the complete manual for the AR4P03?
You can download the manual for free in PDF format from the website notice-facile.com by searching for the model AR4P03.
