EXQ5010065 - Dehumidifier Exquisit - Free user manual and instructions
Find the device manual for free EXQ5010065 Exquisit in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Condensation dehumidifier |
| Brand | Exquisit |
| Model | EXQ5010065 (LE 2055 wes) |
| Power supply | 220-240 V ~ 50 Hz |
| Nominal power | 365 W (at 27 °C / 60 % RH) |
| Maximum power | 420 W (at 32 °C / 90 % RH) |
| Nominal current | 2.10 A |
| Dehumidification capacity | 20 L/day (30 °C / 80 % RH); 10 L/day (27 °C / 60 % RH) |
| Water tank capacity | 5.5 L |
| Airflow | 195 m³/h |
| Weight | 14.5 kg |
| Protection class | I |
| Refrigerant | R134a (90 g) |
| Operating temperature | 5 °C to 35 °C |
| Operating modes | Normal (adjustable humidity), Clothes drying, Air circulation |
| Timer | Up to 24 hours |
| LED humidity display | Blue (< 50 %), Green (50-70 %), Red (> 70 %) |
| Adjustable fan flap | 5 positions |
| Defrost function | Automatic |
| Air filter | Washable, clean every 2 weeks |
| Continuous drainage connection | Drain hose supplied (gravity drain) |
| Child safety | Key combination lock |
| Warranty | 24 months (private use), 12 months (commercial use) |
| Noise level | Not specified (silent operation) |
Frequently Asked Questions - EXQ5010065 Exquisit
How to set the desired humidity in normal mode?
In normal mode, press the SETTING HUMIDITY button (22) to make the indicator flash, then use the + and - buttons to choose a humidity level between 30% and 80% in 5% steps, or select CO for continuous dehumidification. The unit automatically stops when the set humidity is reached.
How to use the timer to stop the unit after a certain time?
Press the Timer button (21). The last programmed time flashes. Use + or - to set the operating time up to 24 hours. The On indicator remains lit. To view remaining time, press the button again; to cancel, press again while the time is flashing.
What do the colors of the LED panel mean?
The front LED panel indicates the humidity level: blue for low humidity (< 50%), green for medium humidity (50-70%), red for high humidity (> 70%). A tolerance of about 3% prevents constant changes.
How to clean the air filter?
Remove the filter holder (7/18) by releasing it from the bottom. Take out the grille and foam. Clean them with a soft brush or vacuum cleaner. Replace after drying. The filter should be cleaned approximately every 2 weeks to maintain performance.
How to empty the water tank?
When the tank is full, the unit emits a beep for 20 seconds. Pull out the tank by its handle, empty it, then replace it correctly. You can also connect the supplied drain hose for continuous drainage into a drain or suitable container.
How to activate child safety?
Press the Fan button (19) and Fan speed button (20) simultaneously for 5 seconds. The lock is active. To deactivate, repeat the same operation.
What to do if the unit displays a drain indicator?
The tank empty indicator (14) lights up when the water tank is full or not inserted correctly. Empty the tank and ensure it is properly engaged. If the problem persists, check that the float inside the tank is not blocked.
Can I use the dehumidifier in an unheated room in winter?
Yes, but the ambient temperature must be between 5 °C and 35 °C. Below 5 °C, the compressor may frost. The automatic defrost function activates, but performance decreases. Make sure the room does not freeze.
How to connect a hose for continuous drainage?
Remove the water tank. Push the supplied drain hose onto the connector (8) at the back of the unit. Place the other end in a drain or container. The hose must not rise higher than the connector to prevent backflow. Replace the empty tank.
What to do in case of unusual odor during first use?
A slight odor is normal due to manufacturing residues. Run the unit for about an hour with windows open to ventilate. The odor disappears quickly. If it persists, contact after-sales service.
